FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Bolts and Nuts | ||
| M6 | 10 | |
| M7 | 15 | |
| M8 | 25 | |
| M10 | 40 | |
| M12 | 60 | |
Scheme 393
A = 20 Nm + an additional 90° (1/4) turn 1
B = 40 Nm + an additional 90° (1/4) turn 1
C = 60 Nm + an additional 90° (1/4) turn 1
Scheme 394
1 = 40 Nm + an additional 90° (1/4) turn 1
2 = 60 Nm + an additional 90° (1/4) turn 1
Scheme 395
Note. First, secure the pendulum support to the transmission and then to the subframe.
A - Strength category 8.8 = 40 Nm + an additional 90° (1/4) turn 1
A - Strength category 10.9 = 50 Nm + an additional 90° (1/4) turn 1
B - = 100 Nm + an additional 90° (1/4) turn 1
- 1 Always replace
