Engine Control System (2GR-FE) (Diagnostic Codes (P0365-P1605)): Other Toyota Venza I facelift

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

P0365 AND P0390: EXHAUST VVT SENSOR VERIFY PULSE INPUT

P0367, P0368, P0392 AND P0393: EXHAUST VVT SENSOR RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)

TYPICAL MALFUNCTION THRESHOLDS

P0365 AND P0390: VVT SENSOR VERIFY PULSE INPUT

P0367 AND P0392: VVT SENSOR RANGE CHECK (LOW VOLTAGE)

P0368 AND P0393: VVT SENSOR RANGE CHECK (HIGH VOLTAGE)

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine.
7. Idle the engine for 10 seconds or more [A].
8. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0365, P0367, P0368, P0390, P0392 or P0393.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

PROCEDURE

1. CHECK VVT SENSOR FOR EXHAUST SIDE (SENSOR POWER SOURCE) Disconnect the VVT sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B31-3 (VC2) - Body ground Ignition switch ON 4.5 to 5.5 V B33-3 (VC2) - Body ground Ignition switch ON 4.5 to 5.5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to VVT Sensor for Exhaust Side) *2 Bank 1 *3 Bank 2 NG --> See step 8 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR EXHAUST SIDE - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B31-1 (EX+) - B39-69 (EV1+) Always Below 1 ohms B31-2 (EX-) - B39-89 (VV1-) Always Below 1 ohms B33-1 (EX+) - B39-64 (EV2+) Always Below 1 ohms B33-2 (EX-) - B39-89 (VV1-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B31-1 (EX+) or B39-69 (EV1+) - Body ground Always 10 kohms or higher B31-2 (EX-) or B39-89 (VV1-) - Body ground Always 10 kohms or higher B33-1 (EX+) or B39-64 (EV2+) - Body ground Always 10 kohms or higher B33-2 (EX-) or B39-89 (VV1-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (VVT SENSOR FOR EXHAUST SIDE - ECM) OK: Go to next step
3. CHECK SENSOR INSTALLATION (VVT SENSOR FOR EXHAUST SIDE) Check the VVT sensor installation. OK Sensor is installed correctly. NG --> See step 9 OK: Go to next step
4. CHECK EXHAUST CAMSHAFT (TIMING ROTOR) Check the timing rotor of the exhaust camshaft. OK Timing rotor does not have any cracks or deformation. NG --> See step 10 OK: Go to next step
5. CHECK VALVE TIMING (CHECK FOR LOOSE OR JUMPED TEETH ON TIMING CHAIN). Refer to «PROCEDURE - Step 4»(ref-649441-S08729083712014081400000) NG --> See step 13 OK: Go to next step
6. REPLACE VVT SENSOR FOR EXHAUST SIDE Replace the VVT sensor for exhaust side. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S10117132532014081400000) . NEXT: Go to next step
7. CHECK WHETHER DTC OUTPUT RECURS (DTC P0365, P0367, P0368, P0390, P0392 AND/OR P0393) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0365, P0367, P0368, P0390, P0392 or P0393 is output A DTC is not output B HINT: If the engine does not start, replace the ECM. B --> END A --> See step 12
8. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR EXHAUST SIDE - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B31-3 (VC2) - B39-67 (VCV1) Always Below 1 ohms B33-3 (VC2) - B39-67 (VCV1) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B31-3 (VC2) or B39-67 (VCV1) - Body ground Always 10 kohms or higher B33-3 (VC2) or B39-67 (VCV1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (VVT SENSOR FOR EXHAUST SIDE - ECM) OK --> See step 11
9. SECURELY REINSTALL VVT SENSOR FOR EXHAUST SIDE. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S10117132532014081400000)
10. REPLACE EXHAUST CAMSHAFT. Refer to «REMOVAL [08/2013 - ]»(ref-649401-S27718859392014081400000)
11. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
12. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
13. ADJUST VALVE TIMING. Refer to «DISASSEMBLY [08/2013 - ]»(ref-649401-S00741767472014081400000)

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

HINT

Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.

Scheme 353

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
8. Check that Catalyst Efficiency / Current is Incomplete.
9. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
10. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
11. Turn the ignition switch off and wait for at least 30 seconds [C].
12. Turn the ignition switch ON and turn the Techstream on.
13. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [D].
14. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item change to Complete as the Catalyst Efficiency monitor operates.
15. Enter the following menus: Powertrain / Engine / Trouble Codes [F].
16. Check if any DTCs (pending DTCs) are stored. HINT: If the monitor item does not change to Complete, and no pending DTCs are stored, perform the following procedure.
17. Drive the vehicle at a speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes or more [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates.
18. Enter the following menus: Powertrain / Engine / Trouble Codes [H].
19. Check if any DTCs (pending DTCs) are stored. HINT: If the monitor item does not change to Complete, and no pending DTCs are stored, extend the driving time.
20. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 and/or P0430 are output A DTC P0420 and/or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of - 12% to +12%. The injection volume can be changed in fine gradations. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 AFS Voltage B2S1 (Air fuel ratio) +12% Rich Below 3.1 V -12% Lean Higher than 3.4 V O2S B1S2 O2S B2S2 (Heated oxygen) +12% Rich Higher than 0.55 V -12% Lean Below 0.4 V RESULT Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 Actual air fuel ratio, air fuel ratio sensor and heated oxygen sensor condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leak from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system Lean Lean Actual air fuel ratio lean May occur Extremely lean actual air fuel ratio Gas leak from exhaust system D Rich Rich Actual air fuel ratio rich - Extremely rich actual air fuel ratio Gas leak from exhaust system Lean: During Control the Injection Volume, the air fuel ratio sensor output voltage (AFS Voltage B1S1 or AFS Voltage B2S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2 or O2S B2S2) is consistently below 0.4 V. Rich: During Control the Injection Volume, the AFS Voltage B1S1 or AFS Voltage B2S1 is consistently below 3.1 V, and the O2S B1S2 or O2S B2S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume of the Active Test, the output voltage of the air fuel ratio sensor and heated oxygen sensor alternate correctly. B --> See step 7 C --> See step 5 D --> See step 6 A: Go to next step
3. CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> See step 8 OK: Go to next step
4. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: When outputting DTC P0420 replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalysts replacement is necessary. When outputting DTC P0430 replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalysts replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 is output A, C DTC P0430 is output B, C DTC P0420 and P0430 are output A, B, C A --> See step 14 B --> See step 15 C --> See step 16
5. CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. OK --> See step 9 NG --> See step 8
6. CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. OK --> See step 10 NG --> See step 8
7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S19236236962014081400000) . NEXT --> See step 11
8. REPAIR OR REPLACE EXHAUST GAS LEAK POINT Repair or replace exhaust gas leak point. NEXT --> See step 11
9. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S13523712612014081400000) . NEXT --> See step 11
10. CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO Check the cause of extremely rich or lean actual air fuel ratio, referring to the DTC P0171 and P0174 Inspection Procedure. Refer to «INSPECTION PROCEDURE»(ref-649441-S07193785092014081400000) . NEXT: Go to next step
11. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC P0420 and/or P0430 is output A DTC is not output B B --> END A: Go to next step
12. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: When outputting DTC P0420 replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalysts replacement is necessary. When outputting DTC P0430 replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalysts replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 is output A, C DTC P0430 is output B, C DTC P0420 and P0430 are output A, B, C A --> See step 14 B --> See step 15 C --> See step 16
13. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649258-S29699066962014081400000)
14. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST). Refer to «COMPONENTS [08/2013 - ]»(ref-649448-S21197203962014081400000)
15. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST). Refer to «COMPONENTS [08/2013 - ]»(ref-649448-S21197203962014081400000)
16. REPLACE CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS [08/2013 - ]»(ref-649448-S25497116002014081400000)

"Saturated" indicates that the EVAP pressure change is less than 0.286 kPa(gauge) [2.145 mmHg(gauge)] in 60 seconds.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
8. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

KEY-OFF MONITOR

PURGE FLOW MONITOR

PURGE VSV STUCK OPEN

PURGE VSV STUCK CLOSED

PURGE FLOW

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and wait 15 minutes or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0441.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
12. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
13. Turn the ignition switch off and wait for at least 30 seconds.
14. Turn the ignition switch to ON and turn the Techstream on.
15. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
16. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
17. Input the DTC: P0441.
18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
19. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

P0451 (NOISE MONITORING)

P0451 (STUCK MONITORING)

P0452 AND P0453

P0451: CANISTER PRESSURE SENSOR NOISE MONITORING

P0451: CANISTER PRESSURE SENSOR STUCK MONITORING

P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE

P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Enter the following menus: Powertrain / Engine / Data List / Intake Air.
4. Check that the intake air temperature is between 4.4 and 35°C (40 and 95°F).
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Turn the ignition switch off and wait for at least 30 seconds.
7. Turn the ignition switch to ON and turn the Techstream on.
8. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
9. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0451, P0452 or P0453.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 354

1. CONFIRM DTC AND EVAP PRESSURE Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not start the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Enter the following menus: Powertrain / Engine / Data List / Gas Evaporative / Vapor Pressure Pump. Read the EVAP (Evaporative Emission) pressure displayed on the Techstream. RESULT Display (DTC Output) Test Result Suspected Trouble Area Proceed to P0451 - Canister pressure sensor C P0452 Less than 42.11 kPa(abs) [315.867 mmHg(abs)] Wire harness/connector (ECM - canister pressure sensor) Canister pressure sensor Short in ECM circuit A P0453 Higher than 123.761 kPa(abs) [928.331 mmHg(abs)] Wire harness/connector (ECM - canister pressure sensor) Canister pressure sensor Open in ECM circuit B B --> See step 4 C --> See step 9 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Result Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to B39-121 (PPMP) - Body ground Always Below 10 ohms Wire harness/connector (ECM - canister pressure sensor) Short in canister pressure sensor circuit A 10 kohms or higher Wire harness/connector (ECM - canister pressure sensor) Short in ECM circuit B B --> See step 7 A: Go to next step
3. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Result Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to B39-121 (PPMP) - Body ground Always 10 kohms or higher Short in canister pressure sensor circuit A Below 10 ohms Short in wire harness/connector (ECM - Canister pressure sensor) B A --> See step 5 B --> See step 6
4. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Canister Pump Module) - - Turn the ignition switch to ON. Measure the voltage and resistance according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition L32-6 (VCC) - Body ground Ignition switch ON 4.5 to 5.5 V L32-7 (VOUT) - Body ground Ignition switch ON 4.5 to 5.5 V Standard Resistance Tester Connection Condition Specified Condition L32-8 (SGND) - Body ground Always Below 100 ohms Result Test Result Suspected Trouble Area Proceed to Voltage and resistance within standard ranges Open in canister pressure sensor circuit A Voltage and resistance outside standard ranges Open in wire harness/connector (ECM - canister pressure sensor) B B --> See step 6 A: Go to next step
5. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL [08/2013 - ]»(ref-649411-S32758858972014081400000) . NOTE: When replacing the canister pump module, check the canister pump module interior, canister interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. If liquids are present in the canister interior, replace canister and canister pump module together. Check for filter blockage in the canister. If the charcoal filter inside the canister is clogged, replace canister and the canister pump module together. Check for filter blockage in the canister filter. If the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 Canister Filter - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT --> See step 8
6. REPAIR OR REPLACE HARNESS OR CONNECTOR (CANISTER PUMP MODULE - ECM) HINT: If the exhaust tail pipe assembly has been removed, go to the next step before reinstalling it. NEXT --> See step 8
7. REPLACE ECM Replace the ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (AFTER REPAIR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Perform the Evaporative System Check using the Techstream, referring to the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0451, P0452 or P0453. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
9. GO TO EVAP SYSTEM. Refer to «EVAP System [08/2013 - ]»(ref-649439-S03295381962014081400000)

P0455: EVAP GROSS LEAK

P0456: EVAP SMALL LEAK

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
8. Input the DTC: P0455 or P0456.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 355

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Drive the vehicle at 24 km/h (15 mph) or more for a total of 30 seconds or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Stop the vehicle.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0500.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 356

1. READ VALUE USING TECHSTREAM (VEHICLE SPEED) Drive the vehicle and check whether the operation of the speedometer in the combination meter assembly is normal. HINT: The vehicle speed sensor is operating normally if the speedometer reading is normal. If the speedometer does not operate, check it by following the procedure described for a speedometer malfunction. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. OK Vehicle speeds displayed on the Techstream and speedometer display are equal. NG --> See step 2 OK --> See step 6
2. CHECK COMBINATION METER ASSEMBLY (SPD SIGNAL WAVEFORM) Inspect the combination meter assembly using an oscilloscope. Jack up the vehicle. Move the shift lever to N. Turn the ignition switch to ON. Measure the voltage between the terminal of the combination meter assembly and the body ground while the wheel is turned slowly. Standard Voltage Tester Connection Switch Condition Specified Condition E1-16 (+S) - Body ground Ignition switch ON Voltage generated intermittently TEXT IN ILLUSTRATION *1 Rear view of wire harness connector (to Combination Meter Assembly) *2 Turn Wheel HINT: The output voltage should fluctuate up and down, similarly to the diagram, when the wheel is turned slowly. NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (COMBINATION METER ASSEMBLY - ECM) Disconnect the combination meter assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E1-16 (+S) - A41-13 (SPD) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (COMBINATION METER ASSEMBLY - ECM) OK --> See step 4
4. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
5. GO TO METER / GAUGE SYSTEM (SPEED SIGNAL CIRCUIT). Refer to «Speed Signal Circuit [08/2013 - ]»(ref-649428-S37098547632014081400000)
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)

1. CHECK STOP LIGHT SWITCH ASSEMBLY (TERMINAL VOLTAGE) Disconnect the stop light switch assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A35-2 - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Stop Light Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - BATTERY) OK: Go to next step
2. CHECK STOP LIGHT SWITCH ASSEMBLY (TERMINAL VOLTAGE) Disconnect the stop light switch assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition A35-4 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Stop Light Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - IG2 RELAY) OK: Go to next step
3. INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649429-S01053010702014081400000) . NG --> See step 5 OK: Go to next step
4. CHECK ECM (STP AND ST1- VOLTAGE) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Brake Pedal Operation Specified Condition A41-35 (ST1-) - Body ground Released 7.5 to 14 V Depressed 0 to 1.5 V A41-36 (STP) - Body ground Released 0 to 1.5 V Depressed 7.5 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to ECM) *2 Brake Pedal Depressed *3 Brake Pedal Released - - NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - ECM) OK --> See step 6
5. REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649429-S18901238832014081400000)
6. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

Scheme 357

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
7. Idle the engine for 5 minutes or more [C]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0505.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
13. Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine for 20 seconds or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Repeat step [E] 5 times.
15. Enter the following menus: Powertrain / Engine / Trouble Codes [F].
16. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P0505.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
20. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
2. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649446-S34300210942014081400000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649445-S07921361642014081400000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
4. CHECK THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. And check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 6 OK --> See step 7
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649258-S29699066962014081400000)
6. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S37273897032014081400000)
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp.
7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
8. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
9. Idle the engine for 1 minute or more [B].
10. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
11. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P050A.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / Short FT #1, Long FT #1, Short FT #2 and Long FT #2. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values, and the Short FT #2 and Long FT #2 values to obtain the total fuel trim. Standard The total of the Short FT #1 and Long FT #1 values, and the total of the Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. Result Result Proceed to NG A OK B B --> See step 14 A: Go to next step
4. REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S37273897032014081400000) . NEXT --> See step 14
5. CHECK PCV HOSE Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649445-S07921361642014081400000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. OK No leakage from intake system. NG --> See step 11 OK: Go to next step
7. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
8. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Operate the VVT system through the Active test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «PROCEDURE - Step 2»(ref-649441-S08729083712014081400000) . Perform the Active Test, referring to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «PROCEDURE - Step 2»(ref-649441-S38451067032014081400000) . NG --> See step 13 OK: Go to next step
9. READ VALUE USING TECHSTREAM (MAF). Refer to «PROCEDURE - Step 6»(ref-649441-S40154863852014081400000) OK --> See step 14 NG --> See step 15
10. REPAIR OR REPLACE PCV HOSE Repair or replace PCV hose. NEXT --> See step 14
11. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 14
12. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
13. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. HINT: Refer to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1); DTC P0021: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 2); DTC P0022: Camshaft Position "A" - Timing Over-Retarded (Bank 2) [08/2013 - ]»(ref-649441-S41168121302014081400000) . Refer to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «DTC P0014: Camshaft Position "B" - Timing Over-Advanced or System Performance (Bank 1); DTC P0015: Camshaft Position "B" - Timing Over-Retarded (Bank 1); DTC P0024: Camshaft Position "B" - Timing Over-Advanced or System Performance (Bank 2); DTC P0025: Camshaft Position "B" - Timing Over-Retarded (Bank 2) [08/2013 - ]»(ref-649441-S16818852852014081400000) . NEXT: Go to next step
14. CHECK WHETHER DTC OUTPUT RECURS (P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 15 A --> END
15. CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [08/2013 - ]»(ref-649249-S41225597262014081400000) . HINT: Repair any problems. NEXT: Go to next step
16. CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
17. CHECK HARNESS AND CONNECTOR (MAS AIR FLOW METER SUB-ASSEMBLY - ECM). Refer to «PROCEDURE - Step 3»(ref-649441-S24821348342014081400000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
18. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
19. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 20 A --> END
20. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
21. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649258-S29699066962014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp.
7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
8. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
9. Idle the engine for 1 minute or more [B].
10. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
11. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P050B.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / Short FT #1, Long FT #1, Short FT #2 and Long FT #2. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values, and the Short FT #2 and Long FT #2 values to obtain the total fuel trim. Standard The total of the Short FT #1 and Long FT #1 values, and the total of the Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. Result Result Proceed to NG A OK B B --> See step 14 A: Go to next step
4. REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace throttle with motor body assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S37273897032014081400000) . NEXT --> See step 14
5. CHECK PCV HOSE Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649445-S07921361642014081400000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leakage. OK No leakage from intake system. NG --> See step 11 OK: Go to next step
7. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
8. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Operate the VVT system through the Active test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «PROCEDURE - Step 2»(ref-649441-S08729083712014081400000) . Perform the Active Test, referring to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «PROCEDURE - Step 2»(ref-649441-S38451067032014081400000) . NG --> See step 13 OK: Go to next step
9. READ VALUE USING TECHSTREAM (MAF). Refer to «PROCEDURE - Step 6»(ref-649441-S40154863852014081400000) OK --> See step 14 NG --> See step 15
10. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
11. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 14
12. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
13. CHECK AND REPAIR VVT SENSOR Check and repair the VVT system. HINT: Refer to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1); DTC P0021: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 2); DTC P0022: Camshaft Position "A" - Timing Over-Retarded (Bank 2) [08/2013 - ]»(ref-649441-S41168121302014081400000) . Refer to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «DTC P0014: Camshaft Position "B" - Timing Over-Advanced or System Performance (Bank 1); DTC P0015: Camshaft Position "B" - Timing Over-Retarded (Bank 1); DTC P0024: Camshaft Position "B" - Timing Over-Advanced or System Performance (Bank 2); DTC P0025: Camshaft Position "B" - Timing Over-Retarded (Bank 2) [08/2013 - ]»(ref-649441-S16818852852014081400000) . NEXT: Go to next step
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 15 A --> END
15. CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [08/2013 - ]»(ref-649249-S41225597262014081400000) . HINT: Repair any problems. NEXT: Go to next step
16. CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
17. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM). Refer to «PROCEDURE - Step 3»(ref-649441-S24821348342014081400000) NG --> REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
18. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
19. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 20 A --> END
20. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
21. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649258-S29699066962014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0560.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 358

1. CHECK HARNESS AND CONNECTOR (EFI NO. 1 FUSE - ECM) Disconnect the ECM connector. Remove the EFI NO. 1 fuse from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 2 (EFI NO. 1 fuse) - A41-1 (BATT) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 2 (EFI NO. 1 fuse) or A41-1 (BATT) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI NO. 1 FUSE - ECM) OK: Go to next step
2. INSPECT BATTERY Check the battery voltage. Battery voltage 11 to 14 V NG --> REPLACE BATTERY OK: Go to next step
3. CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR OR REPLACE BATTERY TERMINAL OK --> See step 4
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P0604.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 1 second or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P0606.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 1 second or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

Scheme 359

1. Stop the engine for 30 minutes or more [A].
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on [B].
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on [C].
7. Start the engine and wait 2 minutes [D].
8. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
9. Idle the engine for 1 minute [F].
10. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Enter the following menus: Powertrain / Engine / Trouble Codes [I].
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P0607, P0136, P0137, P0138, P0156, P0157 or P0158.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [I] again.
17. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A P0607 is output B B --> See step 3 A: Go to next step
2. INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Inspect the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-649441-S05173587032014081400000) . Then proceed to "INSPECT ECM". If P0137 or P0157 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-649441-S05173587032014081400000) . Then proceed to "INSPECT ECM". If P0138 or P0158 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-649441-S05173587032014081400000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT --> See step 6
3. CHECK FOR EXHAUST GAS LEAK Allow the engine to idle and rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair it and proceed to "PERFORM CONFIRMATION DRIVING PATTERN". If no exhaust gas leaks are present, proceed to "PERFORM CONFIRMATION DRIVING PATTERN". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit is suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
4. PERFORM CONFIRMATION DRIVING PATTERN Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or higher. Perform the driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Accelerate the vehicle until 80 km/h (50 mph) and stop the vehicle. Drive the vehicle between 60 to 80 km/h (37 to 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A DTC P0607 is output B DTC is not output C B --> See step 7 C --> See step 6 A: Go to next step
5. INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Inspect the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-649441-S05173587032014081400000) . Then proceed to "INSPECT ECM". If P0137 or P0157 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-649441-S05173587032014081400000) . Then proceed to "INSPECT ECM". If P0138 or P0158 is output, troubleshoot for that DTC first. Refer to «INSPECTION PROCEDURE»(ref-649441-S05173587032014081400000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT: Go to next step
6. INSPECT ECM Clear the DTC. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P060A.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

CASE 1 AND CASE 4

CASE 2 AND CASE 3

CASE 1

CASE 2

CASE 3

CASE 4

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P060B.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328, P0332 or P0333 are output C B --> See step 3 C --> See step 4 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
4. GO TO DTC (P0327, P0328, P0332 AND P0333). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor); DTC P0332: Knock Sensor 2 Circuit Low Input (Bank 2); DTC P0333: Knock Sensor 2 Circuit High Input (Bank 2) [08/2013 - ]»(ref-649441-S22733628252014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P060D.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P060D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060D is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

CASE 1

CASE 2

CASE 1

CASE 2

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P060E.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

Scheme 360

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 5 seconds or more [B].
8. Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0617.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 361

Scheme 362

1. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Starter Signal. Check the value displayed on the Techstream when the vehicle is driven at 12 mph (20 km/h) or more. Result Condition Starter Signal Proceed to Driving at 12 mph (20 km/h) or more OFF A ON B B --> See step 2 A --> See step 3
2. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly (for 2WD). Refer to «INSPECTION [08/2013 - ]»(ref-649449-S26637096042014081400000) or AWD. Refer to «INSPECTION [08/2013 - ]»(ref-649450-S24506699052014081400000) . RESULT Result Proceed to OK A NG (for 2WD) B NG (for AWD) C B --> See step 4 C --> See step 5 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR (SHORT IN STARTER SIGNAL CIRCUIT)
3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
4. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649449-S42549399942014081400000)
5. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649450-S01003190172014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Start the engine and wait 30 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P062F.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and wait 30 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P062F is output B B --> See step 2 A --> See step 3
2. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)

COMPONENT OPERATING RANGE

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0630.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0630 is output A DTC P0630 and other DTCs are output B NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. HINT: If any DTCs other than P0630 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
2. INPUT VIN Input the VIN. Refer to «REGISTRATION [08/2013 - ]»(ref-649258-S37890623612014081400000) . NEXT --> END
3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649258-S29699066962014081400000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Turn the ignition switch to ON.
10. Wait 10 seconds or more.
11. Turn the ignition switch off.
12. Wait 15 seconds or more.
13. Connect the Techstream to the DLC3.
14. Turn the ignition switch to ON and turn the Techstream on.
15. Wait 5 seconds or more.
16. Enter the following menus: Powertrain / Engine / Trouble Codes.
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
19. Input the DTC: P0657.
20. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
21. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Wait 10 seconds or more. Turn the ignition switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)

ALL

CASE 3

CASE 1

CASE 2

CASE 3

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Move the shift lever to R and wait 2 seconds or more.
7. Move the shift lever to N and wait 2 seconds or more.
8. Move the shift lever to D and wait 2 seconds or more.
9. Move the shift lever to S and wait 2 seconds or more.
10. Move the shift lever to P and wait 2 seconds or more.
11. Wait 1 minute or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P0705.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 363

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data. Read the values displayed on the Techstream. OK Techstream Display Shift Lever Specified Condition Neutral Position SW Signal P or N ON Except P or N OFF Shift SW Status (R Range) R ON Except R OFF Shift SW Status (P Range) P ON Except P OFF Shift SW Status (N Range) N ON Except N OFF Shift SW Status (D Range) D or S ON Except D or S OFF NG --> See step 4 OK: Go to next step
2. READ VALUE USING TECHSTREAM (SPORTS MODE SELECTION SW) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Sports Mode Selection SW. Read the values displayed on the Techstream. OK Techstream Display Shift Lever Specified Condition Sports Mode Selection SW S ON Except S OFF NG --> See step 3 OK --> See step 10
3. INSPECT TRANSMISSION CONTROL SWITCH Inspect the transmission control switch for 2WD. Refer to «INSPECTION [08/2013 - ] - Step 3»(ref-649449-S14795499222014081400000) or AWD. Refer to «INSPECTION [08/2013 - ] - Step 3»(ref-649450-S19167006612014081400000) . RESULT Result Proceed to OK A NG (for 2WD) B NG (for AWD) C B --> See step 8 C --> See step 13 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - TRANSMISSION CONTROL SWITCH)
4. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY VOLTAGE) Disconnect the park/neutral position switch assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B2-1 (RB) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Park/Neutral Position Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - BATTERY) OK: Go to next step
5. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly for 2WD. Refer to «INSPECTION [08/2013 - ]»(ref-649449-S26637096042014081400000) or AWD. Refer to «INSPECTION [08/2013 - ]»(ref-649450-S24506699052014081400000) . RESULT Result Proceed to OK A NG (for 2WD) B NG (for AWD) C B --> See step 9 C --> See step 12 A: Go to next step
6. CHECK HARNESS AND CONNECTOR (ECM - PARK/NEUTRAL POSITION SWITCH ASSEMBLY) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B39-2 (P) - Body ground Ignition switch ON Shift lever in P 11 to 14 V Ignition switch ON Shift lever in any position other than P 0 to 1.5 V B39-26 (R) - Body ground Ignition switch ON Shift lever in R 11 to 14 V Ignition switch ON Shift lever in any position other than R 0 to 1.5 V B39-25 (N) - Body ground Ignition switch ON Shift lever in N 11 to 14 V Ignition switch ON Shift lever in any position other than N 0 to 1.5 V B39-27 (D) - Body ground Ignition switch ON Shift lever in D or S 11 to 14 V Ignition switch ON Shift lever in any position other than D or S 0 to 1.5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - PARK/NEUTRAL POSITION SWITCH ASSEMBLY) OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) Disconnect the park/neutral position switch assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B2-4 (B) - B39-120 (NSW) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B2-4 (B) or B39-120 (NSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) OK --> See step 11
8. REPLACE SHIFT LOCK CONTROL UNIT ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649449-S37589480742014081400000)
9. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649449-S42549399942014081400000)
10. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
11. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
12. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649450-S01003190172014081400000)
13. REPLACE SHIFT LOCK CONTROL UNIT ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649450-S22089815302014081400000)

Scheme 364

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0724.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] through [E].
12. Start the engine [C].
13. Accelerate the vehicle to 30 km/h (18.65 mph) or more, depress the brake pedal and decelerate the vehicle to 3 km/h (1.86 mph) or less [D]. Repeat step [D] 5 times. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Check the DTC judgment result [E].
15. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Stop Light Switch. Read the value displayed on the Techstream when the brake pedal is depressed and released. OK Techstream Display Measurement Item: Range Normal Condition Stop Light Switch Stop light switch assembly status: ON or OFF ON: Brake pedal depressed OFF: Brake pedal released NG --> See step 2 OK --> See step 6
2. INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649429-S01053010702014081400000) . NG --> See step 5 OK: Go to next step
3. CHECK TERMINAL VOLTAGE (STP VOLTAGE) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A41-36 (STP) - Body ground Brake pedal depressed 7.5 to 14 V A41-36 (STP) - Body ground Brake pedal released 0 to 1.5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - STOP LIGHT SWITCH ASSEMBLY) OK --> See step 4
4. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
5. REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649429-S18901238832014081400000)
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)

1. CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . RESULT Result Proceed to Only DTC P1603 and/or P1605 is output A DTC and other DTCs P1603 and/or P1605 are output B HINT: If any DTCs other than P1603 or P1605 are output, troubleshoot those DTCs first. B --> See step 104 A: Go to next step
2. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . OK Immobiliser Fuel Cut is OFF. RESULT Result Proceed to Abnormal A Normal B B --> See step 4 A: Go to next step
3. CHECK ENGINE IMMOBILISER SYSTEM Connect the Techstream to the DLC3. Start the engine. Idle the engine Enter the following menus: Powertrain / Engine / Data List / Immobiliser Communication and Immobiliser Fuel Cut. Check the Data List indication. STANDARD Data List Item Specified Condition Immobiliser Communication ON Immobiliser Fuel Cut OFF RESULT Result Proceed to OK A NG (w/ smart key system) B NG (w/o smart key system) C B --> See step 110 C --> See step 124 A: Go to next step
4. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Problem Symptom Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to Closed Throttle Position SW Engine Speed Total of Short FT and Long FT When idling or decelerating, engine speed slowly decreases (and engine stalls) All 5 sets of freeze frame data are ON Decreases slowly*1 All 5 sets of freeze frame data are +15% or more*2 Air suction Sensor malfunction (value from sensor too lean) Fuel supply problem A At least 1 of the 5 sets of freeze frame data is -15% or less*3 Sensor malfunction (value from sensor too rich) B All 5 sets of freeze frame data are from -15% to +15% Intake air volume insufficient Ignition timing incorrect C When idling or decelerating, engine speed rapidly decreases (and engine stalls) Decreases rapidly*1 - Injection stoppage, ignition stoppage Load from external parts D When accelerating or driving at constant speed, engine stalls*4 At least one is OFF - - Sensor malfunction Injection stoppage, ignition stoppage Fuel supply problem E HINT: *1: A rapid decrease in engine speed may be caused by an electrical fault in the shared wiring of all or a number of cylinders, an increase in load from external parts, etc. The engine speed is considered to have decreased rapidly if either of the following conditions applies. Otherwise, the engine speed is considered to have decreased slowly. In the freeze frame data, the decrease in engine speed from #3 to #5 is 400 rpm or more. In the freeze frame data, the engine speed at #5 is 120 rpm or less. If the vehicle speed is 15 km/h (9 mph) or less and the difference between Engine Speed and SPD (NT) is 100 rpm or less, inspect the automatic transmission. (Depending on the rate of vehicle deceleration, the engine speed may have decreased due to the A/T lock-up release being late.) *2: When a DTC is stored, feedback compensation increases because the air fuel ratio is determined to be lean. *3: When a DTC is stored, feedback compensation decreases because the air fuel ratio is determined to be rich. *4: This item should be checked when DTC P1603 is output and is not necessary to check when only P1605 is output. B --> See step 38 C --> See step 52 D --> See step 65 E --> See step 70 A: Go to next step
5. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649445-S07921361642014081400000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
6. CHECK PURGE VSV Disconnect the purge hose (on the canister side) of the purge VSV. TEXT IN ILLUSTRATION *1 Purge Hose (to Canister) *2 Purge VSV Connector *3 Purge VSV Start the engine. Idle the engine. Disconnect the connector of the purge VSV. Check if air flows through the purge VSV. OK Air does not flow. HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . NG --> See step 82 OK: Go to next step
7. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Stop Light Switch At least 1 of the 5 sets of freeze frame data is ON Air suction from brake booster A All 5 sets of freeze frame data are OFF - B B --> See step 10 A: Go to next step
8. READ VALUE USING TECHSTREAM (SHORT FT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Short FT #1 and Short FT #2 in the Data List while depressing the brake pedal. Standard Short FT #1 and Short FT #2 changes by +10% or less. HINT: When air leakage from the brake booster is present, the feedback compensation increases because the air fuel ratio becomes lean. NG --> See step 109 OK: Go to next step
9. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Short FT #1, Long FT #1, Short FT #2 and Long FT #2 in the Data List. Standard Data List Condition Specified Condition Short FT #1 + Long FT #1 The conditions of the vehicle are matched to those present when the problem occurs -15 to +15% Short FT #2 + Long FT #2 The conditions of the vehicle are matched to those present when the problem occurs -15 to +15% NG --> See step 111 OK: Go to next step
10. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649407-S22061483862014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
11. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Calculate Load Below 90% of the current value of the vehicle*1 Mass air flow meter sub-assembly A AFS Voltage B1S1 AFS Voltage B2S1 3.3 V or higher*2 Air fuel ratio sensor Wire harness or connector B HINT: *1: If the mass air flow meter sub-assembly is malfunctioning and incorrectly measures the intake air volume to be less than the actual volume, the freeze frame data will show a low engine load value. *2: If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air fuel ratio is lean, the actual air fuel ratio will become rich and the engine may stall. B --> See step 15 A: Go to next step
12. CHECK MASS AIR FLOW METER SUB-ASSEMBLY Remove the mass air flow meter sub-assembly. Check for foreign matter in the air flow passage of the mass air flow meter sub-assembly. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 96 A: Go to next step
13. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0102 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649441-S24821348342014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
14. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle RESULT Result Proceed to Abnormal A Normal B B --> See step 18 A --> See step 120
15. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor / AFS Voltage B1S1 and AFS Voltage B2S1. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Specified Condition Control the Injection Volume for A/F Sensor (+12.5%) Air fuel ratio sensor output voltage is below 3.1 V Control the Injection Volume for A/F Sensor (-12.5%) Air fuel ratio sensor output voltage is higher than 3.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. B --> See step 18 A: Go to next step
16. CHECK TERMINAL VOLTAGE (+B OF AIR FUEL RATIO SENSOR) Check the harnesses and connectors, referring to DTC P0031 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649441-S02862381262014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR AIR FUEL RATIO SENSOR POWER SOURCE CIRCUIT OK: Go to next step
17. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Check the harnesses and connectors, referring to DTC P2237 inspection procedure. Refer to «PROCEDURE - Step 1»(ref-649439-S11490970622014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
18. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Proceed to Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C (18°F) *1 A Difference in temperature between each item is 10°C (18°F) or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 21 A: Go to next step
19. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature sensor B Range C - C HINT: This step is not directly related to engine stall. B --> See step 22 C --> See step 24 A: Go to next step
20. INSPECT THERMOSTAT Inspect the thermostat. Refer to «INSPECTION [08/2013 - ]»(ref-649405-S17331870552014081400000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 22 A --> See step 84
21. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Coolant Temp 120°C (248°F) or higher Engine coolant temperature sensor A Engine coolant temperature is lower than outside temperature* by 15°C (27°F) or more Engine coolant temperature sensor Values are other than above - B HINT: *: Use an actual outside temperature estimated from the Initial Intake Air, Ambient Temp for A/C, and (if possible) the weather when the DTC was detected. B --> See step 24 A: Go to next step
22. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [08/2013 - ]»(ref-649443-S14602064202014081400000) . NG --> See step 94 OK: Go to next step
23. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B39-76 (THW) - B6-2 Always Below 1 ohms B39-97 (ETHW) - B6-1 Always Below 1 ohms B39-76 (THW) or B6-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
24. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to EVAP (Purge) VSV At least 1 of the 5 sets of freeze frame data is not 0% Purge VSV A All 5 sets of freeze frame data are 0% - B HINT: If the purge VSV is stuck closed, air fuel ratio compensation by the purge VSV is incorrectly adjusted, and then the air fuel ratio becomes lean and the engine may stall. B --> See step 33 A: Go to next step
25. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VSV FOR EVAP CONTROL) Disconnect the purge hose (on the canister side) of the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Purge Hose (to Canister) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for Evap Control. Operate the purge VSV and check the air flow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 33 A: Go to next step
26. INSPECT PURGE VSV Inspect the purge VSV. Refer to «INSPECTION [08/2013 - ]»(ref-649411-S17348289282014081400000) . NG --> See step 86 OK: Go to next step
27. CHECK TERMINAL VOLTAGE (PURGE VSV POWER SOURCE) Disconnect the purge VSV connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B34-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge VSV) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PURGE VSV - EFI MAIN RELAY) OK: Go to next step
28. CHECK HARNESS AND CONNECTOR (PURGE VSV - ECM) Check harness and connector. HINT: Refer to EVAP System inspection procedure. Refer to «PROCEDURE - Step 26»(ref-649439-S20720883322014081400000) . Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
29. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . NEXT: Go to next step
30. READ VALUE USING TECHSTREAM (EVAP (PURGE) VSV) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine for 15 minutes or more. Using the Techstream, read the value of EVAP (Purge) VSV in the Data List. Standard Data List Specified Condition EVAP (Purge) VSV Value other than 0% is displayed RESULT Result Proceed to Abnormal A Normal B B --> See step 112 A: Go to next step
31. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VSV FOR EVAP CONTROL) Disconnect the purge hose (on the canister side) of the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Purge Hose (to Canister) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for Evap Control. Operate the purge VSV and check the air flow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 113 A: Go to next step
32. CHECK CONNECTOR CONNECTION CONDITION (ECM) Check the ECM connector connection condition. HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> RECONNECT CONNECTOR CORRECTLY OK --> See step 87
33. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operating sound occurs when performing the Active Test on the Techstream. Standard Techstream Operation Specified Condition ON Operating sound heard OFF Operating sound not heard Result Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 34. B --> See step 35 A: Go to next step
34. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [08/2013 - ]»(ref-649444-S09268970732014081400000) . NG --> See step 107 OK --> See step 88
35. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Perform the Active Test [Control the All Cylinders Fuel Cut]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649447-S08012156822014081400000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 114 A: Go to next step
36. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is no foreign matter and no signs that fuel pump was stuck A There is foreign matter or signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> REPAIR OR REPLACE FUEL SYSTEM A: Go to next step
37. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Perform the Active Test [Control the All Cylinders Fuel Cut]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649447-S08012156822014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK --> END
38. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649407-S22061483862014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
39. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Calculate Load 110% or more of the current value of the vehicle*1 Mass air flow meter sub-assembly A AFS Voltage B1S1 AFS Voltage B2S1 Below 3.3 V*2 Air fuel ratio sensor Harness and connector B Both freeze frame data items listed above Values are other than above - C HINT: *1: If the mass air flow meter sub-assembly is malfunctioning and incorrectly measures the intake air volume to be higher than the actual volume of air flowing through the intake air surge tank assembly, the freeze frame data will show a high engine load value. *2: As the air fuel ratio sensor output is low before the sensor warms up, the value at that time cannot be used for diagnosis. If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air fuel ratio is rich, the actual air fuel ratio will become lean and the engine may stall. B --> See step 43 C --> See step 46 A: Go to next step
40. CHECK MASS AIR FLOW METER SUB-ASSEMBLY Remove the mass air flow meter sub-assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000) . Check for foreign matter in the air flow passage of the mass air flow meter sub-assembly. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 83 A: Go to next step
41. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0102 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649441-S24821348342014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
42. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle NG --> See step 115 OK: Go to next step
43. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor / AFS Voltage B1S1 and AFS Voltage B2S1. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Specified Condition Control the Injection Volume for A/F Sensor (+12.5%) Air fuel ratio sensor output voltage is below 3.1 V Control the Injection Volume for A/F Sensor (-12.5%) Air fuel ratio sensor output voltage is higher than 3.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. B --> See step 46 A: Go to next step
44. CHECK TERMINAL VOLTAGE (+B OF AIR FUEL RATIO SENSOR) Check the harnesses and connectors, referring to DTC P0031 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649441-S02862381262014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR AIR FUEL RATIO SENSOR POWER SOURCE CIRCUIT OK: Go to next step
45. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Check the harnesses and connectors, referring to DTC P2237 inspection procedure. Refer to «PROCEDURE - Step 1»(ref-649439-S11490970622014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
46. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Proceed to Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C (18°F)*1 A Difference in temperature between each item is 10°C (18°F) or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 49 A: Go to next step
47. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature B Range C - C HINT: This step is not directly related to engine stall. B --> See step 50 C --> See step 78 A: Go to next step
48. INSPECT THERMOSTAT Inspect the thermostat. Refer to «INSPECTION [08/2013 - ]»(ref-649405-S17331870552014081400000) . RESULT Result Proceed to Abnormal A Normal B HINT: This step is not directly related to engine stall. B --> See step 50 A --> See step 91
49. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Coolant Temp 120°C (248°F) or higher Engine coolant temperature sensor A Engine coolant temperature is lower than outside temperature* by 15°C (27°F) or more Engine coolant temperature sensor Values are other than above - B HINT: *: Use an actual outside temperature estimated from the Initial Intake Air, Ambient Temp for A/C, and (if possible) the weather when the DTC was detected. B --> See step 81 A: Go to next step
50. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [08/2013 - ]»(ref-649443-S14602064202014081400000) . NG --> See step 92 OK: Go to next step
51. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B39-76 (THW) - B6-2 Always Below 1 ohms B39-97 (ETHW) - B6-1 Always Below 1 ohms B39-76 (THW) or B6-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 121
52. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649407-S22061483862014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
53. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Result Suspected Area Proceed to Total of ISC Learning Value and ISC Feedback Value Below 80% of the current value of the vehicle Intake air volume insufficient A 80% or more of the current value of the vehicle B B --> See step 56 A: Go to next step
54. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649445-S07921361642014081400000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
55. CHECK INTAKE SYSTEM Check the intake system. Inspect the brake booster assembly. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649399-S38578661012014081400000) . Inspect the mass air flow meter sub-assembly. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649443-S17078079352014081400000) . Check the PCV hose. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649446-S34300210942014081400000) . Inspect the PCV valve. Refer to «INSPECTION [08/2013 - ]»(ref-649411-S21251382272014081400000) . Inspect the purge VSV. Refer to «INSPECTION [08/2013 - ]»(ref-649411-S17348289282014081400000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 60 A --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA
56. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Perform the Active Test, referring to DTC P0011 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649441-S08729083712014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 93 OK: Go to next step
57. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0010 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649441-S17167668642014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
58. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Perform the Active Test, referring to DTC P0014 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649441-S38451067032014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 108 OK: Go to next step
59. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0013 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649441-S22665967142014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
60. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10 deg or more Less than 3 deg(CA) Engine coolant temperature sensor Mass air flow meter sub-assembly Knock control sensor A 3 deg(CA) or more - B Differs from the current value of the vehicle by less than 10 deg - - B --> See step 116 A: Go to next step
61. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [08/2013 - ]»(ref-649443-S14602064202014081400000) . NG --> See step 85 OK: Go to next step
62. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B39-76 (THW) - B6-2 Always Below 1 ohms B39-97 (ETHW) - B6-1 Always Below 1 ohms B39-76 (THW) or B6-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
63. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY (INTAKE AIR TEMPERATURE SENSOR) Inspect the mass air flow meter sub-assembly (intake air temperature sensor). Refer to «INSPECTION [08/2013 - ]»(ref-649443-S36903419362014081400000) . HINT: If the intake air temperature sent to the ECM is higher than the standard due to the mass air flow meter sub-assembly (intake air temperature sensor) malfunctioning, the ignition timing may become delayed. NG --> See step 90 OK: Go to next step
64. READ VALUE USING TECHSTREAM (IGN ADVANCE AND KNOCK CORRECT LEARN VALUE) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of IGN Advance and Knock Correct Learn Value in the Data List. RESULT Freeze Frame Data Item for DTC P1605 Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10 deg or more Less than 3 deg(CA) A 3 deg(CA) or more B Differs from the current value of the vehicle by less than 10 deg - HINT: If the results of the checks performed in steps 56 to 64 were all normal and the sum of ISC Feedback Value and ISC Learning Value in the Data List is 120% of the normal value or more, check for carbon deposits in the throttle body assembly. If there are carbon deposits, clean them off to finish the troubleshooting procedure. B --> END A --> See step 95
65. CHECK TERMINAL VOLTAGE (POWER SOURCE OF FUEL INJECTOR ASSEMBLY) Check the harness and connectors, referring to Fuel Injector Circuit inspection procedure. Refer to «PROCEDURE - Step 1»(ref-649439-S16330042762014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> See step 97 OK: Go to next step
66. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649407-S22061483862014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
67. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to A/C Signal Air Conditioner FB Val Power Steering Signal A/C Signal display does not change from OFF Value displayed for Air Conditioner FB Val does not increase Changes from OFF to ON Power steering system A Does not change from OFF - A/C Signal display changes from OFF to ON*1 Value displayed for Air Conditioner FB Val increases Changes from OFF to ON Power steering system Does not change from OFF A/C system B HINT: *1: Check not only the ON/OFF state of the air conditioner but also the change in air conditioner load. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the power steering system or A/C system may have been malfunctioning. If there are no problems with other parts, inspect the power steering system or A/C system. B --> See step 98 A: Go to next step
68. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to Electrical Load Signal 1 (2) or Electric Load Feedback Val Electric Load Feedback Val Difference between Engine Speed and SPD (NT) Vehicle Speed Electrical Load Signal 1 (2) display changes from OFF to ON*3, or value displayed for Electric Load Feedback Val increases*3 Value displayed for Electric Load Val changes - - Electrical load signal circuit D Value displayed for Electric Load Val does not change At least 1 of the 5 sets of freeze frame data is less than 100 rpm Less than 15 km/h (9 mph) A/T system B*1 C*2 15 km/h (9 mph) or more - A All 5 sets of freeze frame data are 100 rpm or more - - A Electrical Load Signal 1 (2) display does not change from OFF, or value displayed for Electric Load Feedback Val does not increase - At least 1 of the 5 sets of freeze frame data is less than 100 rpm Less than 15 km/h (9 mph) A/T system B*1 C*2 15 km/h (9 mph) or more - A All 5 sets of freeze frame data are 100 rpm or more - - A *1: for 2WD *2: for AWD HINT: *3: If the Electrical Load Signal 1 (2) display changes from OFF to ON, or the "Electric Load Feedback Val" increases, it probably is a malfunction due to a change in electrical load. Check the generator and the continuity and connections between the generator and ECM. If the vehicle speed is 15 km/h (9 mph) or less and the difference between Engine Speed and SPD (NT) is 100 rpm or less, inspect the automatic transmission. (Depending on the rate of vehicle deceleration, the engine speed may have decreased due to the A/T lock-up release being late.) The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the electrical load signal system and/or A/T system may have been malfunctioning. If there are no problems with other parts, inspect the electrical load system and/or A/T system. B --> See step 105 C --> See step 122 D --> See step 106 A: Go to next step
69. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item for DTC P1605 Suspected Area Proceed to Shift SW Status (P Range) Shift SW Status (N Range) Neutral Position SW Signal P and N position are both OFF in at least one data set ON when shift lever in D or R Park/Neutral position switch assembly A*1 B*2 OFF when shift lever in D or R A/T system C*1 D*2 All 5 sets of freeze frame data are ON - - E *1: for 2WD *2: for AWD HINT: Even if the results are normal, the park/neutral position switch assembly and/or A/T system may have been malfunctioning. If there are no problems with other parts, inspect the park/neutral position switch assembly and/or A/T system. B --> See step 123 C --> See step 99 D --> See step 122 E --> See step 117 A --> See step 100
70. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649258-S33717077462014081400000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Throttle Sensor Position, Calculate Load Calculate Load decreases while Throttle Sensor Position increases Mass air flow meter sub-assembly A Calculate Load does not decrease while Throttle Sensor Position increases - B B --> See step 74 A: Go to next step
71. CHECK MASS AIR FLOW METER SUB-ASSEMBLY Remove the mass air flow meter sub-assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000) . Check for foreign matter in the air flow passage of the mass air flow meter sub-assembly. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 101 A: Go to next step
72. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0102 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649441-S24821348342014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
73. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle NG --> See step 118 OK: Go to next step
74. CHECK TERMINAL VOLTAGE (POWER SOURCE OF FUEL INJECTOR ASSEMBLY) Check the harness and connectors, referring to Fuel Injector Circuit inspection procedure. Refer to «PROCEDURE - Step 1»(ref-649439-S16330042762014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> See step 102 OK: Go to next step
75. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649407-S22061483862014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
76. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operating sound occurs when performing the Active Test on the Techstream. Standard Techstream Operation Specified Condition ON Operating sound heard OFF Operating sound not heard Result Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 77. B --> See step 78 A: Go to next step
77. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [08/2013 - ]»(ref-649444-S09268970732014081400000) . NG --> See step 89 OK --> See step 103
78. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Perform the Active Test [Control the All Cylinder Fuel Cut]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649447-S08012156822014081400000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 119 A: Go to next step
79. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is no foreign matter and no signs that fuel pump was stuck A There is foreign matter or signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> REPAIR OR REPLACE FUEL SYSTEM A: Go to next step
80. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Perform the Active Test [Control the All Cylinder Fuel Cut]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649447-S08012156822014081400000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK --> END
81. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649258-S07470507852014081400000) . NEXT --> END
82. REPLACE PURGE VSV. Refer to «REMOVAL [08/2013 - ]»(ref-649411-S42242710552014081400000)
83. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
84. REPLACE THERMOSTAT. Refer to «REMOVAL [08/2013 - ]»(ref-649405-S21649112552014081400000)
85. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S31156489652014081400000)
86. REPLACE PURGE VSV. Refer to «REMOVAL [08/2013 - ]»(ref-649411-S42242710552014081400000)
87. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S09949946382014081400000)
88. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit [08/2013 - ]»(ref-649439-S40986797742014081400000)
89. REPLACE FUEL PUMP. Refer to «REMOVAL [08/2013 - ]»(ref-649444-S38448068002014081400000)
90. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
91. REPLACE THERMOSTAT. Refer to «REMOVAL [08/2013 - ]»(ref-649405-S21649112552014081400000)
92. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S31156489652014081400000)
93. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-649443-S41909308552014081400000)
94. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S31156489652014081400000)
95. CHECK KNOCK SENSOR CIRCUIT. Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor); DTC P0332: Knock Sensor 2 Circuit Low Input (Bank 2); DTC P0333: Knock Sensor 2 Circuit High Input (Bank 2) [08/2013 - ]»(ref-649441-S22733628252014081400000)
96. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
97. REPAIR FUEL INJECTOR ASSEMBLY POWER SOURCE CIRCUIT. Refer to «Fuel Injector Circuit [08/2013 - ]»(ref-649439-S23576378112014081400000)
98. CHECK AIR CONDITIONING SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649424-S00112749802014081400000)
99. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649263-S36272283932014081400000)
100. INSPECT PARK/NEUTRAL POSITION SWITCH. Refer to «INSPECTION [08/2013 - ]»(ref-649449-S26637096042014081400000)
101. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
102. REPAIR FUEL INJECTOR ASSEMBLY POWER SOURCE CIRCUIT. Refer to «Fuel Injector Circuit [08/2013 - ]»(ref-649439-S23576378112014081400000)
103. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit [08/2013 - ]»(ref-649439-S40986797742014081400000)
104. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649258-S29699066962014081400000)
105. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649263-S36272283932014081400000)
106. CHECK GENERATOR CIRCUIT. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649409-S17020098422014081400000)
107. REPLACE FUEL PUMP. Refer to «REMOVAL [08/2013 - ]»(ref-649444-S38448068002014081400000)
108. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-649443-S41909308552014081400000)
109. INSPECT BRAKE BOOSTER ASSEMBLY. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649399-S38578661012014081400000)
110. CHECK ENGINE IMMOBILISER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649259-S38035525852014081400000)
111. INSPECT BRAKE BOOSTER ASSEMBLY. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649399-S38578661012014081400000)
112. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
113. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
114. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
115. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
116. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
117. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
118. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
119. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
120. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649443-S12351514592014081400000)
121. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649258-S10601315592014081400000)
122. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649261-S15712546192014081400000)
123. INSPECT PARK/NEUTRAL POSITION SWITCH. Refer to «INSPECTION [08/2013 - ]»(ref-649450-S24506699052014081400000)
124. CHECK ENGINE IMMOBILISER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649260-S05394856112014081400000)
