Engine Control System (1AR-FE) (Diagnostic Codes (P1604-U0101) & Circuit Tests): Other Toyota Venza I facelift

PROCEDURE

1. CHECK ANY OTHER DTCS OUTPUT AND RECORD FREEZE FRAME DATA (IN ADDITION TO DTC P1604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs and record the Freeze Frame Data. HINT: This freeze frame data shows the actual engine conditions when engine starting trouble occurred. When confirming the freeze frame data, be sure to check all 5 data sets of freeze frame data. The fourth set of freeze frame data is the data recorded when then the DTC is stored. RESULT Result Proceed to DTC P1604 is output A DTC P1604 and other DTCs are output B B --> See step 118 A: Go to next step
2. CHECK ENGINE IMMOBILISER SYSTEM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Immobiliser Fuel Cut. Read the value displayed on the Techstream. OK Immobiliser Fuel Cut is OFF HINT: If the engine is cranked immediately after reconnecting the battery cable (key verification for engine immobiliser system not completed), the engine cannot be started. Key verification needs to wait for several seconds after turning the ignition switch to ON. RESULT Result Proceed to OK A NG (w/ smart key system) B NG (w/o smart key system) C B --> See step 119 C --> See step 143 A: Go to next step
3. CHECK MALFUNCTION CONDITION Confirm the problem symptoms. RESULT Result Proceed to Freeze frame data exists, but the starting difficulty cannot be reproduced and it is unknown what kind of starting difficulty occurred A The problem symptoms can be reproduced, or the malfunction conditions are known B B --> See step 25 A: Go to next step
4. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Engine Speed Battery Voltage All 5 sets of freeze frame data are 0 RPM (no engine cranking at all) Minimum voltage is less than 5 V Battery fully depleted A Minimum voltage is 5 V or higher Starter assembly malfunction Crankshaft position sensor system Excess engine friction ECM B 60 to 250 RPM (engine cranks but no initial combustion) - Fuel pump control system Ignition system Engine coolant temperature sensor Fuel injection system C 250 RPM or higher (combustion occurs but initial combustion and starter turnoff occur late) - Engine assembly Engine coolant temperature sensor Fuel injection system Fuel pump control system D Freeze Frame Data Item Suspected Area Proceed to Low Rev for Eng Start ON exists Intake system connections Throttle body Camshaft timing oil control valve assembly Mass air flow meter sub-assembly E HINT: When DTC P1604 is stored, either "Engine Start Hesitation"*1 or "Low Rev for Eng Start"*2 in the Freeze Frame Data will be ON. If "Low Rev for Eng Start" is ON, proceed to E. *1: This value turns ON when the engine speed does not reach a certain value for a certain period of time when starting the engine. *2: This value turns ON when the engine stalls immediately after starting the engine. If "Low Rev for Eng Start" is ON, as there is a possibility that the low engine speed or engine stall was caused by the user, confirm the following freeze frame data items. Immobiliser Fuel Cut Engine Speed (Starter Off) Shift SW Status (R, D Range) B --> See step 5 C --> See step 10 D --> See step 15 E --> See step 49 A --> CHARGE OR REPLACE BATTERY
5. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Battery Voltage Minimum voltage is 6 V or higher and voltage does not fluctuate*1 Starter system A Minimum voltage is 6 V or higher and voltage fluctuates*2, *3 Crankshaft position sensor system ECM B Minimum voltage is 5 to 6 V*4 Excess engine friction Battery fully depleted C HINT: *1: The 5 sets of freeze frame data show approximately the same battery voltage. *2: The 5 sets of freeze frame data show different battery voltages. *3: If the voltage fluctuates, it can be determined that cranking is being performed. When the engine speed is 0 RPM, the crankshaft position sensor system and/or the ECM may be malfunctioning. *4: There may be excess engine friction. Make sure that the crankshaft rotates smoothly when turning it by hand. Excess engine friction may have occurred temporarily. Remove the cylinder head cover and oil pan, and check for foreign matter such as iron fragments. If there is a malfunction or signs of a malfunction present, perform a detailed inspection by disassembling all the parts. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 6 C --> CHECK AND REPAIR ENGINE ASSEMBLY OR BATTERY A --> See step 120
6. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR OK: Go to next step
7. INSPECT CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position sensor connector. Check for oil on the connector terminals. OK No oil on the terminals. NG --> See step 121 OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Check the harnesses and connectors, referring to DTC P0335 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S35430785422014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 141 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
10. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Coolant Temp, Intake Air Coolant Temp Fuel Pump/Speed Status Difference between Coolant Temp and Intake Air is 10°C (18°F) or higher*1 Coolant Temp is 125°C (257°F) or higher, or lower than outside temperature*3 by 15°C (27°F) or higher - Engine coolant temperature sensor A Other than above All 5 sets of freeze frame data are ON - B At least 1 of the 5 sets of freeze frame data is OFF Fuel pump control system C Difference between Coolant Temp and Intake Air is less than 10°C (18°F) *2 - At least 1 of the 5 sets of freeze frame data is OFF Fuel pump control system C All 5 sets of freeze frame data are ON - B HINT: *1: A long time had not elapsed after stopping the engine. *2: A long time had elapsed after stopping the engine. *3: Use an actual outside temperature estimated from the Initial Intake Air, Ambient Temp for A/C, and (if possible) the weather when the DTC was detected. Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 11 C --> See step 122 A --> See step 132
11. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Disconnect the fuel pump connector. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition L12-4 - Body ground Active Test is being performed 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Pump) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 122 OK: Go to next step
12. CHECK TERMINAL VOLTAGE (FUEL INJECTOR CIRCUIT) Check the harnesses and connectors, referring to DTC P0300 inspection procedure. Refer to «PROCEDURE - Step 10»(ref-649418-S32442696892014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 142 OK: Go to next step
13. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When performing the Active Test, if there is no operating noise from the fuel pump, the fuel pump system may be malfunctioning. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. B --> See step 14 A --> REPAIR OR REPLACE FUEL LINE
14. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> See step 24 A --> REPAIR OR REPLACE FUEL SYSTEM
15. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Coolant Temp, Intake Air Coolant Temp Long FT #1 Engine Speed Difference between Coolant Temp and Intake Air is 10°C (18°F) or higher Coolant Temp is 125°C (257°F) or higher, or lower than outside temperature*2 by 15°C (27°F) or higher - - Engine coolant temperature sensor A Other than above -15% or less, or +15% or higher - Fuel pump control system Fuel injector assembly B -15 to +15% Minimum speed is 300 RPM or higher*1 Engine assembly C Minimum speed is below 300 RPM Fuel system Intake air system D Difference between Coolant Temp and Intake Air is less than 10°C (18°F) - -15% or less, or +15% or higher - Fuel pump control system Fuel injector assembly B -15 to +15% Minimum speed is 300 RPM or higher*1 Engine assembly C Minimum speed is below 300 RPM Fuel system Intake air system D HINT: *1: Compression loss may have occurred in the engine assembly. *2: Use an actual outside temperature estimated from the Initial Intake Air, Ambient Temp for A/C, and (if possible) the weather when the DTC was detected. Perform "Inspection After Repair" after replacing the engine assembly or engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 16 C --> CHECK AND REPAIR ENGINE ASSEMBLY D --> See step 18 A --> See step 132
16. INSPECT FUEL INJECTOR ASSEMBLY Check that no carbon is stuck to the fuel injector assembly. OK No carbon present. HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 123 OK: Go to next step
17. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> See step 24 A --> REPAIR OR REPLACE FUEL SYSTEM
18. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Coolant Temp Engine coolant temperature is 40°C (104°F) or less*1 Pressure regulator A Engine coolant temperature is 40 to 90°C (104 to 194°F)*2 Fuel injector assembly B Engine coolant temperature is 90°C (194°F) or higher*3 Pressure regulator A HINT: *1: If the engine coolant temperature is 40°C [104°F] or less (after stopping the engine and the vehicle is not driven for a long period of time), the pressure regulator may be stuck open. Attach a fuel pressure gauge and check the ability to maintain fuel pressure after stopping the engine. *2: If the engine coolant temperature is 40 to 90°C [104 to 194°F] (15 to 120 minutes have passed after stopping the engine), there may be fuel leaking from a fuel injector. *3: If the engine coolant temperature is 90°C [194°F] or higher (2 to 5 minutes have passed after stopping the engine), there may be a problem with the pressure regulator failing to maintain the fuel pressure. Attach a fuel pressure gauge and check the ability to maintain fuel pressure after stopping the engine. B --> See step 20 A: Go to next step
19. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. Standard 147 kPa (1.5 kgf/cm 2 , 21 psi) or higher (5 minutes after stopping the engine) HINT: If the engine cannot be started, read the values after cranking the engine. RESULT Result Proceed to Abnormal A Normal B B --> See step 24 A --> See step 140
20. INSPECT FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or higher A Less than 4000 ppm B HINT: If the concentration is 4000 ppm or higher, a fuel injector assembly may have a sealing problem. B --> See step 22 A: Go to next step
21. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assemblies. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S10292322332014081400000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 123 OK: Go to next step
22. INSPECT THROTTLE BODY ASSEMBLY Check if carbon is in the air flow passage. RESULT Result Proceed to No carbon present A Carbon in passage B HINT: Perform "Inspection After Repair" after cleaning or replacing the throttle body assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 124 A: Go to next step
23. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649423-S41759180272014081400000) . OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
24. PERFORM SIMULATION TEST Check if the engine can be started. RESULT Result Proceed to Engine cannot be started A Engine can be started B B --> END A: Go to next step
25. CONFIRM PROBLEM SYMPTOM Confirm the problem symptoms. HINT: The problem symptoms below can be determined by reading the freeze frame data. RESULT Problem Symptom Suspected Area Proceed to The engine does not crank Battery fully depleted Starter assembly (includes pinion gear wear or teeth damage) Starter system Engine assembly (excess friction) Drive plate and ring gear sub-assembly wear or teeth damage A Abnormal cranking speed Battery fully depleted Starter assembly Engine assembly (excess friction, compression loss) B There is no initial combustion (combustion does not occur even once)*1 Pressure regulator fuel pressure maintenance Fuel injector assembly leak Fuel leak from fuel line Fuel pump control system Fuel pump Spark plug Crankshaft position sensor system Ignition coil assembly system C The engine stalls after starter turn off (engine stalls immediately after the first time the engine speed increases)*2 Intake system connections Throttle body assembly Camshaft timing oil control valve assembly Mass air flow meter sub-assembly system D The initial combustion and starter turnoff occur late*3 Engine coolant temperature sensor Mass air flow meter sub-assembly Air fuel ratio sensor Heated oxygen sensor Fuel injector assembly Spark plug Pressure regulator Fuel pump Fuel pump control system E HINT: If there is hesitation (cranking speed is slow and combustion occurs before passing TDC) during the initial cranking period, the battery charge may be insufficient or the starter may be malfunctioning. *1: If there is no initial combustion, a wire harness may be malfunctioning, or the ignition or fuel system may be malfunctioning. *2: If the engine stalls after starter turnoff, the air fuel ratio may be incorrect or the camshaft timing oil control valve may have a problem returning. *3: If the initial combustion and starter turnoff occur late, the fuel injection volume may be incorrect (too low or too high). B --> See step 32 C --> See step 35 D --> See step 49 E --> See step 55 A: Go to next step
26. PERFORM SIMULATION TEST When cranking the engine, check for a noise indicating that the starter pinion gear is extending, and check that the starter pinion gear is not spinning freely. RESULT Problem Symptom Suspected Area Proceed to A noise indicating that the starter pinion gear is extending is heard and the starter pinion gear is not spinning freely.*1 Battery Excess engine friction Starter assembly A A noise indicating that the starter pinion gear is extending is heard but the starter pinion gear is spinning freely. Drive plate and ring gear sub-assembly Starter assembly B A noise indicating that the starter pinion gear is extending is not heard Battery Starter assembly Starter system C HINT: *1: The battery may be fully depleted or there may be excess engine friction. B --> See step 29 C --> See step 30 A: Go to next step
27. INSPECT BATTERY Inspect the battery. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649410-S20734405492014081400000) . NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
28. CHECK ENGINE ASSEMBLY Check that the crankshaft rotates smoothly when rotating it by hand. OK Crankshaft rotates smoothly. HINT: Excess engine friction may have occurred temporarily. Remove the cylinder head cover and oil pan, and check for foreign matter such as iron fragments. If there is a malfunction or signs of a malfunction present, perform a detailed inspection by disassembling all the parts. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE ENGINE ASSEMBLY OK --> See step 125
29. INSPECT STARTER ASSEMBLY (STARTER PINION GEAR) Remove the starter assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649420-S38038266392014081400000) . Check for starter pinion gear wear and damage. OK There is no wear or damage. NG --> See step 126 OK --> REPLACE DRIVE PLATE AND RING GEAR SUB-ASSEMBLY
30. INSPECT BATTERY Inspect the battery. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649410-S20734405492014081400000) . NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
31. INSPECT STARTER ASSEMBLY Inspect the starter assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649420-S23551673972014081400000) . NG --> See step 126 OK --> See step 120
32. PERFORM SIMULATION TEST Check the cranking speed. RESULT Problem Symptom Suspected Area Proceed to Cranking speed is slow (100 RPM or less) Battery Starter assembly Excess engine friction A Cranking speed is fast (300 RPM or higher)*1 Engine compression loss B HINT: *1: If the cranking speed is fast, there may be compression loss. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> CHECK AND REPAIR ENGINE ASSEMBLY A: Go to next step
33. INSPECT BATTERY Inspect the battery. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649410-S20734405492014081400000) . NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
34. CHECK ENGINE ASSEMBLY Check that the crankshaft rotates smoothly when rotating it by hand. OK Crankshaft rotates smoothly. HINT: Excess engine friction may have occurred temporarily. Remove the cylinder head cover and oil pan, and check for foreign matter such as iron fragments. If there is a malfunction or signs of a malfunction present, perform a detailed inspection by disassembling all the parts. Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> CHECK AND REPAIR ENGINE ASSEMBLY OK --> See step 125
35. INSPECT FUEL INJECTOR ASSEMBLY Using a sound scope or screwdriver, check for an injector operating sound while cranking the engine. OK Fuel injector assembly operating sound is heard. NG --> See step 47 OK: Go to next step
36. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . NG --> See step 45 OK: Go to next step
37. CHECK SPARK PLUG AND SPARK Check for sparks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 1»(ref-649408-S33370565342014081400000) . NG --> See step 41 OK: Go to next step
38. CONFIRM VEHICLE CONDITION Confirm the conditions present when the malfunction occurred based on the customer problem analysis. RESULT Problem Symptom Suspected Area Proceed to When the engine is stopped and a long time has passed, engine starting trouble occurs*1 Pressure regulator is stuck open A When the engine is stopped and approximately 15 to 120 minutes have passed, engine starting trouble occurs*2 Fuel injector assembly leak B When the engine is stopped and approximately 2 to 3 minutes have passed, engine starting trouble occurs*3 Failure to maintain fuel pressure by pressure regulator A Condition other than above, or there is an inconsistency in the conditions present when engine starting trouble occurs - C*4 HINT: *1: The pressure regulator may be stuck open. Attach a fuel pressure gauge and check the ability to maintain fuel pressure after stopping the engine. *2: Fuel may be leaking from a fuel injector assembly. *3: The pressure regulator may not be able to maintain the fuel pressure. Attach a fuel pressure gauge and check the ability to maintain fuel pressure after stopping the engine. *4: From step 69, perform fuel system troubleshooting C (steps 70 to 74). B --> See step 40 C --> See step 69 A: Go to next step
39. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. Standard 147 kPa (1.5 kgf/cm 2 , 21 psi) or higher (5 minutes after stopping the engine) RESULT Result Proceed to Abnormal A Normal B*1 HINT: If the engine cannot be started, read the values after cranking the engine. *1: from step 69, perform fuel system troubleshooting C (steps 70 to 74). B --> See step 69 A --> See step 140
40. INSPECT FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or higher A Less than 4000 ppm B*1 HINT: If the concentration is 4000 ppm or higher, a fuel injector may have a sealing problem. *1: From step 69, perform fuel system troubleshooting C (steps 70 to 74). Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 69 A --> See step 123
41. INSPECT SPARK PLUG Inspect the spark plugs. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 3»(ref-649408-S33370565342014081400000) . HINT: Even if the spark plug of only one cylinder is malfunctioning, replace the spark plugs of all cylinders. Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 127 OK: Go to next step
42. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Engine Speed. Start the engine. While running the engine, read the [Engine Speed] value. OK A value that matches the actual engine speed is constantly output. HINT: Check the engine speed using a line graph. If the engine cannot be started, check the engine speed while cranking the engine. If the engine speed is 0 RPM, the crankshaft position sensor may have an open or short circuit. NG --> See step 128 OK: Go to next step
43. CHECK TERMINAL VOLTAGE (POWER SOURCE OF IGNITION COIL ASSEMBLY) Check the harnesses and connectors, referring to DTC P0351 inspection procedure. Refer to «PROCEDURE - Step 1»(ref-649418-S10509866402014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 129 OK: Go to next step
44. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0351 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649418-S10509866402014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness is normal, after replacing the ignition coil assembly, check if engine starting trouble occurs again. If engine starting trouble occurs again, proceed to step 69 and perform troubleshooting for the ignition system (steps 75 to 83). Perform "Inspection After Repair" after replacing the ignition coil assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 130
45. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for an operating sound from the fuel pump. OK Control the Fuel Pump / Speed Specified Condition ON Operating sound heard OFF Operating sound not heard HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. NG --> See step 122 OK: Go to next step
46. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. If there are no fuel leaks, after inspecting the fuel pump control system, check if engine starting trouble occurs again. If engine starting trouble occurs again, proceed to step 69 and perform fuel system troubleshooting C (steps 70 to 74). B --> See step 122 A --> REPAIR OR REPLACE FUEL LINE
47. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Engine Speed. Start the engine. While running the engine, read the [Engine Speed] value. OK A value that matches the actual engine speed is constantly output. HINT: Check the engine speed using a line graph. If the engine cannot be started, check the engine speed while cranking the engine. If the engine speed is 0 RPM, the crankshaft position sensor may have an open or short circuit. NG --> See step 121 OK: Go to next step
48. CHECK TERMINAL VOLTAGE (FUEL INJECTOR CIRCUIT) Check the harnesses and connectors, referring to DTC P0300 inspection procedure. Refer to «PROCEDURE - Step 10»(ref-649418-S32442696892014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 142 OK --> See step 141
49. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S02331794862014081400000) . HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 54 OK: Go to next step
50. CHECK INTAKE SYSTEM Check for air leaks in the intake system (vacuum hose disconnection, cracks, damaged gaskets, etc.). Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649423-S41759180272014081400000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake manifold increases and the air suction noise becomes louder. If Short FT #1 and Long FT #1 are largely different from the normal values (differ by higher than 15%) when idling (intake air volume is small) and almost the same as the normal values when racing the engine (for example, when maintaining a speed of 3000 RPM) (intake air volume is high), air leakage may be present. OK There is no air leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
51. INSPECT THROTTLE BODY ASSEMBLY Disconnect the throttle body assembly connector. HINT: When the connector is disconnected, the vehicle enters fail-safe mode and the throttle valve opening angle is 4 to 7°. Crank the engine and check that it starts. RESULT Result Proceed to Engine starts A Engine does not start B HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . B --> See step 53 A: Go to next step
52. INSPECT THROTTLE BODY ASSEMBLY Check if carbon is in the air flow passage. OK No carbon present. HINT: Perform "Inspection After Repair" after cleaning the throttle body assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REMOVE FOREIGN OBJECT AND CLEAN THROTTLE BODY ASSEMBLY OK: Go to next step
53. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Operate the VVT system through the Active Test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 inspection procedure (VVT system for intake camshaft). Refer to «PROCEDURE - Step 2»(ref-649418-S22558348402014081400000) . Perform the Active Test, referring to DTC P0014 inspection procedure (VVT system for exhaust camshaft). Refer to «PROCEDURE - Step 2»(ref-649418-S10921503472014081400000) . RESULT Result Proceed to NG A OK B*1 HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. *1: From step 69, perform intake system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). B --> See step 69 A --> See step 131
54. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0102 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S09444250472014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness is normal, after replacing the mass air flow meter sub-assembly, check if engine starting trouble occurs again. If engine starting trouble occurs again, proceed to step 69 and perform intake system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 133
55. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S38259951232014081400000) . HINT: If the engine coolant temperature sensor is malfunctioning, after replacing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 132 OK: Go to next step
56. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Check the harnesses and connectors, referring to DTC P0115 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S29798089662014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness or connector is malfunctioning, after replacing or repairing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
57. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649421-S32902613222014081400000) . HINT: If the mass air flow meter sub-assembly is malfunctioning, after replacing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 133 OK: Go to next step
58. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Check the harnesses and connectors, referring to DTC P0102 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S09444250472014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. If the wire harness or connector is malfunctioning, after replacing or repairing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
59. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / Long FT #1 and Atmosphere Pressure. RESULT Data List Item Result Suspected Area Proceed to Long FT #1 +25% or higher, or less than -25% Air fuel ratio sensor (sensor 1) Heated oxygen sensor (sensor 2) Mass air flow meter sub-assembly Fuel injector assembly ECM A Atmosphere Pressure 80 kPa(abs) [600 mmHg(abs)] or less (when altitude is 0 m [0 ft.]) Both Data List items listed above Values are other than above - B B --> See step 63 A: Go to next step
60. PERFORM SIMULATION TEST Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / Learning Value Reset. Confirm the following conditions as instructed on the screen. - Ignition switch ON - Engine stopped - Battery voltage 9 V or higher After confirming, select "Next" and initialize the learn value. HINT: If a message indicating learned value initialization failure is displayed on the screen, confirm the execution conditions, and perform learned value initialization again. Check if the engine can be started. RESULT Result Proceed to Engine can be started A Engine cannot be started B B --> See step 63 A: Go to next step
61. INSPECT AIR FUEL RATIO SENSOR Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / Fuel System Status #1. Confirm that Fuel System Status #1 is CL. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / AF Lambda B1S1. Confirm that AF Lambda B1S1 is within the range of 0.95 to 1.05 when idling. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Injection Volume Specified Condition AFS Voltage B1S1 +12% Air fuel ratio sensor output voltage is below 3.1 V -12% Air fuel ratio sensor output voltage is higher than 3.4 V HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the air fuel ratio sensor is malfunctioning, after replacing it, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 134 OK: Go to next step
62. PERFORM SIMULATION TEST Check if the idle speed is stable after starting the engine. OK Engine speed is stable. HINT: After replacing the fuel injector assembly or mass air flow meter sub-assembly, check if engine starting trouble occurs again. If engine starting trouble occurs, replace the ECM. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. Perform "Inspection After Repair" after replacing the fuel injector assembly or mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 123 OK --> See step 133
63. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . NG --> See step 68 OK: Go to next step
64. INSPECT SPARK PLUG Inspect the spark plugs. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 3»(ref-649408-S33370565342014081400000) . RESULT Result Proceed to All cylinders are normal A One cylinder is abnormal*1 B All cylinders are abnormal*2, *3 C HINT: *1: If one cylinder is abnormal, replace the spark plug of that cylinder and inspect the ignition and fuel system for that cylinder. After performing repairs, check if engine starting trouble occurs again. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. *2: If all cylinders are abnormal, replace the spark plugs of all cylinders and check if engine starting trouble occurs again. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. *3: Engine starting trouble may occur if the vehicle is driven extremely short distances repeatedly. Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 135 C --> See step 136 A: Go to next step
65. CONFIRM VEHICLE CONDITION Confirm the conditions present when the malfunction occurred based on the customer problem analysis. RESULT Problem Symptom Suspected Area Proceed to When the engine is stopped and a long time has passed, engine starting trouble occurs*1 Pressure regulator is stuck open A When the engine is stopped and approximately 15 to 120 minutes have passed, engine starting trouble occurs*2 Fuel injector assembly leak B When the engine is stopped and approximately 2 to 3 minutes have passed, engine starting trouble occurs*3 Failure to maintain fuel pressure by pressure regulator A Condition other than above, or there is an inconsistency in the conditions present when engine starting trouble occurs - C*4 HINT: *1: The pressure regulator may be stuck open. Attach a fuel pressure gauge and check the ability to maintain fuel pressure after stopping the engine. *2: Fuel may be leaking from a fuel injector assembly. *3: The pressure regulator may not be able to maintain the fuel pressure. Attach a fuel pressure gauge and check the ability to maintain fuel pressure after stopping the engine. *4: From step 69, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. B --> See step 67 C --> See step 69 A: Go to next step
66. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. Standard 147 kPa (1.5 kgf/cm 2 , 21 psi) or higher (5 minutes after stopping the engine) RESULT Result Proceed to Abnormal A Normal B*1 HINT: If the engine cannot be started, read the values after cranking the engine. *1: From step 69, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. B --> See step 69 A --> See step 140
67. INSPECT FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or higher A Less than 4000 ppm B*1 HINT: If the concentration is 4000 ppm or higher, a fuel injector assembly may have a sealing problem. *1: From step 69, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 69 A --> See step 123
68. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. If there are no fuel leaks, after inspecting the fuel pump control system, check if engine starting trouble occurs again. If engine starting trouble still occurs, proceed to step 69 and perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. B --> See step 122 A --> REPAIR OR REPLACE FUEL LINE
69. CHECK MALFUNCTION CONDITION If the malfunction could not be identified during the inspection in steps 38, 39, 40 and 46, perform fuel system troubleshooting C (steps 70 to 74). RESULT Performed Step Troubleshooting by System Procedure Proceed to Steps 38, 39, 40 and 46 Fuel system troubleshooting C 70 to 74 A If the malfunction could not be identified during the inspection in step 44, perform ignition system troubleshooting (steps 75 to 83). RESULT Performed Step Troubleshooting by System Procedure Proceed to Step 44 Ignition system troubleshooting 75 to 83 B If the malfunction could not be identified during the inspection in steps 53 and 54, perform intake air system troubleshooting (steps 84 to 86). If engine starting trouble still occurs, perform fuel system troubleshooting A (steps 87 to 94). RESULT Performed Step Troubleshooting by System Procedure Proceed to Step 53 and 54 Intake air system troubleshooting 84 to 86 C Fuel system troubleshooting A 87 to 94 If the malfunction could not be identified during the inspection in steps 55, 56, 57, 58, 61, 62, 64, 65, 66, 67 and 68, perform fuel system troubleshooting A (steps 95 to 102), fuel system troubleshooting B (steps 103 to 105), intake air system troubleshooting (steps 106 to 108), and ignition system troubleshooting (steps 109 to 117), in that order. RESULT Performed Step Troubleshooting by System Procedure Proceed to Steps 55, 56, 57, 58, 61, 62, 64, 65, 66, 67 and 68 Fuel system troubleshooting A 95 to 102 D Fuel system troubleshooting B 103 to 105 Intake air system troubleshooting 106 to 108 Ignition system troubleshooting 109 to 117 B --> See step 75 C --> See step 84 D --> See step 95 A: Go to next step
70. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assemblies. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S10292322332014081400000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 123 OK: Go to next step
71. CHECK TERMINAL VOLTAGE (FUEL INJECTOR CIRCUIT) Check the harnesses and connectors, referring to DTC P0300 inspection procedure. Refer to «PROCEDURE - Step 10»(ref-649418-S32442696892014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> See step 142 OK: Go to next step
72. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 73 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
73. REPLACE CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) Replace the camshaft position sensor (for intake camshaft). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 74 OK --> END (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) IS DEFECTIVE)
74. REPLACE CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) Replace the camshaft position sensor (for exhaust camshaft). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 141 OK --> END (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) IS DEFECTIVE)
75. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR OK: Go to next step
76. CHECK SENSOR INSTALLATION (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT)) Check the tightening and installation condition of the camshaft position sensor (for intake camshaft) bolt. Check the connection of the camshaft position sensor (for intake camshaft) connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR (FOR INTAKE CAMSHAFT) OK: Go to next step
77. CHECK SENSOR INSTALLATION (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT)) Check the tightening and installation condition of the camshaft position sensor (for exhaust camshaft) bolt. Check the connection of the camshaft position sensor (for exhaust camshaft) connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR (FOR EXHAUST CAMSHAFT) OK: Go to next step
78. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Check the harnesses and connectors, referring to DTC P0335 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S35430785422014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
79. CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) - ECM) Check the harnesses and connectors, referring to DTC P0340 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649418-S13005462942014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
80. CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) - ECM) Check the harnesses and connectors, referring to DTC P0365 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649418-S11186661852014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
81. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 82 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
82. REPLACE CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) Replace the camshaft position sensor (for intake camshaft). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 83 OK --> END (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) IS DEFECTIVE)
83. REPLACE CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) Replace the camshaft position sensor (for exhaust camshaft). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 141 OK --> END (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) IS DEFECTIVE)
84. READ VALUE USING TECHSTREAM (ISC LEARNING VALUE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / ISC Learning Valve. Start the engine and warm it up until the engine coolant temperature stabilizes with the A/C switch and all the accessory switches off. RESULT Data List Item Result Suspected Area Proceed to ISC Learning Value (engine displacement (liters) x 0.9) or higher Valve timing Compression A Less than (engine displacement (liters) x 0.9) - B B --> See step 86 A: Go to next step
85. CHECK CYLINDER COMPRESSION PRESSURE Check the compression. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 9»(ref-649402-S18955805902014081400000) . HINT: Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> CHECK AND REPAIR ENGINE ASSEMBLY OK --> See step 137
86. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S38259951232014081400000) . HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 132 OK: Go to next step
87. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . Attach a fuel pressure gauge and check the fuel pressure when cranking the engine and after stopping the engine. Standard Vehicle State Specified Condition Cranking engine 304 kPa (3.1 kgf/cm 2 , 44 psi) to 343 kPa (3.5 kgf/cm 2 , 50 psi) 5 minutes after stopping engine 147 kPa (1.5 kgf/cm 2 , 21 psi) or higher NG --> See step 93 OK: Go to next step
88. READ VALUE USING TECHSTREAM (LONG FT #1) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / Long FT #1. RESULT Data List Item Result Suspected Area Proceed to Long FT #1 -15 to +15% Wire harness or connector Fuel A +15% or higher, or less than -15% Fuel injector assembly B HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 123 A: Go to next step
89. PERFORM SIMULATION TEST Check if the idle speed after starting the engine is currently stable and has always been stable in the past. RESULT Problem Symptom Suspected Area Proceed to Current unstable idle speed or history of unstable idle speed Crankshaft position sensor system A All current and past idle speeds are stable Fuel B HINT: Through the customer problem analysis, confirm the fuel being used and the location at which the fuel was added to check if the malfunction is caused by the fuel in the vehicle. B --> REPLACE FUEL A: Go to next step
90. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR OK: Go to next step
91. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Check the harnesses and connectors, referring to DTC P0335 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S35430785422014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
92. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 141 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
93. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When performing the Active Test, if there is no operating noise from the fuel pump, the fuel pump system may be malfunctioning. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. B --> See step 94 A --> REPAIR OR REPLACE FUEL LINE
94. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S19090168192014081400000) . HINT: Make sure there is no foreign matter such as iron particles on the fuel pump and no signs that the fuel pump was stuck. Make sure the internal connector is securely connected. Make sure the fuel pump filter is not clogged. Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 138 OK --> See step 140
95. CHECK FUEL PRESSURE HINT: For the fuel pressure inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . Attach a fuel pressure gauge and check the fuel pressure after stopping the engine. Standard 147 kPa (1.5 kgf/cm 2 , 21 psi) or higher (5 minutes after stopping the engine) HINT: If the engine cannot be started, read the values after cranking the engine. NG --> See step 101 OK: Go to next step
96. READ VALUE USING TECHSTREAM (LONG FT #1) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas AF Control / Long FT #1. RESULT Data List Item Result Suspected Area Proceed to Long FT #1 -15 to +15% Wire harness or connector Fuel A +15% or higher, or less than -15% Fuel injector assembly B HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 123 A: Go to next step
97. PERFORM SIMULATION TEST Check if the idle speed after starting the engine is currently stable and has always been stable in the past. RESULT Problem Symptom Suspected Area Proceed to Current unstable idle speed or history of unstable idle speed Crankshaft position sensor system A All current and past idle speeds are stable Fuel B HINT: Through the customer problem analysis, confirm the fuel being used and the location at which the fuel was added to check if the malfunction is caused by the fuel in the vehicle. B --> REPLACE FUEL A: Go to next step
98. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR OK: Go to next step
99. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Check the harnesses and connectors, referring to DTC P0335 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S35430785422014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
100. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 141 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
101. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP / SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. When performing the Active Test, check for fuel leakage from the fuel pipes. RESULT Result Proceed to Fuel leakage or signs of fuel leakage are present A No fuel leakage or signs of fuel leakage B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When performing the Active Test, if there is no operating noise from the fuel pump, the fuel pump system may be malfunctioning. Check if the vehicle ran out of fuel, as engine starting trouble due to running out of fuel is also detected. B --> See step 102 A --> REPAIR OR REPLACE FUEL LINE
102. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S19090168192014081400000) . HINT: Make sure there is no foreign matter such as iron particles on the fuel pump and no signs that the fuel pump was stuck. Make sure the internal connector is securely connected. Make sure the fuel pump filter is not clogged. Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 138 OK: Go to next step
103. CHECK PURGE VSV Disconnect the fuel vapor feed hose (on the canister side) of the purge VSV. TEXT IN ILLUSTRATION *1 Fuel Vapor Feed Hose (to Canister) *2 Connector *3 Purge VSV Start the engine. Idle the engine. Disconnect the connector of the purge VSV. Check if air flows through the purge VSV. OK Air does not flow HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . NG --> See step 139 OK: Go to next step
104. INSPECT FUEL INJECTOR ASSEMBLY Clean the inside of the surge tank with compressed air. After stopping the engine, measure the HC concentration inside the surge tank for 15 minutes. RESULT Result Proceed to 4000 ppm or higher A Less than 4000 ppm B HINT: If the concentration is 4000 ppm or higher, a fuel injector assembly may have a sealing problem. Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 105 A --> See step 123
105. CHECK INTAKE VALVE Check if carbon is on the intake valves. RESULT Result Proceed to Carbon present A No carbon present B B --> See step 106 A --> CLEAN INTAKE VALVE
106. READ VALUE USING TECHSTREAM (ISC LEARNING VALUE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / ISC Learning Valve. Start the engine and warm it up until the engine coolant temperature stabilizes with the A/C switch and all the accessory switches off. RESULT Data List Item Result Suspected Area Proceed to ISC Learning Value (engine displacement (liters) x 0.9) or more Valve timing Compression A Less than (engine displacement (liters) x 0.9) - B B --> See step 108 A: Go to next step
107. CHECK CYLINDER COMPRESSION PRESSURE Check the compression. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 9»(ref-649402-S18955805902014081400000) . HINT: Perform "Inspection After Repair" after replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> CHECK AND REPAIR ENGINE ASSEMBLY OK --> See step 137
108. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S38259951232014081400000) . HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 132 OK: Go to next step
109. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the tightening and installation condition of the crankshaft position sensor bolt. Check the connection of the crankshaft position sensor connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR OK: Go to next step
110. CHECK SENSOR INSTALLATION (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT)) Check the tightening and installation condition of the camshaft position sensor (for intake camshaft) bolt. Check the connection of the camshaft position sensor (for intake camshaft) connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR (FOR INTAKE CAMSHAFT) OK: Go to next step
111. CHECK SENSOR INSTALLATION (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT)) Check the tightening and installation condition of the camshaft position sensor (for exhaust camshaft) bolt. Check the connection of the camshaft position sensor (for exhaust camshaft) connector. OK Sensor is installed correctly. NG --> SECURELY REINSTALL SENSOR (FOR EXHAUST CAMSHAFT) OK: Go to next step
112. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Check the harnesses and connectors, referring to DTC P0335 inspection procedure. Refer to «PROCEDURE - Step 3»(ref-649418-S35430785422014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
113. CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) - ECM) Check the harnesses and connectors, referring to DTC P0340 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649418-S13005462942014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
114. CHECK HARNESS AND CONNECTOR (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) - ECM) Check the harnesses and connectors, referring to DTC P0365 inspection procedure. Refer to «PROCEDURE - Step 2»(ref-649418-S11186661852014081400000) . HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
115. REPLACE CRANKSHAFT POSITION SENSOR Replace the crankshaft position sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 116 OK --> END (CRANKSHAFT POSITION SENSOR IS DEFECTIVE)
116. REPLACE CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) Replace the camshaft position sensor (for intake camshaft). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 117 OK --> END (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT) IS DEFECTIVE)
117. REPLACE CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) Replace the camshaft position sensor (for exhaust camshaft). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000) . Check the engine start operation. OK Malfunction has been repaired successfully. NG --> See step 141 OK --> END (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT) IS DEFECTIVE)
118. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
119. REPAIR ENGINE IMMOBILISER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649259-S38035525852014081400000)
120. CHECK STARTER SIGNAL CIRCUIT. Refer to «Starter Signal Circuit [08/2013 - ]»(ref-649417-S16105632302014081400000)
121. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S42119309082014081400000)
122. CHECK FUEL PUMP CONTROL CIRCUIT. Refer to «Fuel Pump Control Circuit [08/2013 - ]»(ref-649417-S26173479462014081400000)
123. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S10263243442014081400000)
124. CLEAN OR REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000)
125. INSPECT STARTER ASSEMBLY. Refer to «INSPECTION [08/2013 - ]»(ref-649420-S23551673972014081400000)
126. REPLACE STARTER ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649420-S38038266392014081400000)
127. REPLACE SPARK PLUG. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S38133569742014081400000)
128. CHECK CRANKSHAFT POSITION SENSOR CIRCUIT. Refer to «DTC P0335: Crankshaft Position Sensor "A" Circuit; DTC P0339: Crankshaft Position Sensor "A" Circuit Intermittent [08/2013 - ]»(ref-649418-S23619327272014081400000)
129. CHECK IGNITION COIL POWER SOURCE CIRCUIT. Refer to «PROCEDURE - Step 1»(ref-649418-S10509866402014081400000)
130. REPLACE IGNITION COIL ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S38133569742014081400000)
131. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE OR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S08146821262014081400000)
132. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S38498959152014081400000)
133. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S10089337852014081400000)
134. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11660341322014081400000)
135. REPLACE SPARK PLUG (ABNORMAL CYLINDER). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S38133569742014081400000)
136. REPLACE SPARK PLUG (ALL CYLINDER). Refer to «REMOVAL [08/2013 - ]»(ref-649421-S38133569742014081400000)
137. CHECK VALVE TIMING. Refer to «PROCEDURE - Step 5»(ref-649418-S22558348402014081400000)
138. REPLACE FUEL PUMP. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S42191376872014081400000)
139. INSPECT PURGE VSV. Refer to «INSPECTION [08/2013 - ]»(ref-649412-S09245592702014081400000)
140. REPLACE FUEL PRESSURE REGULATOR. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S23863129222014081400000)
141. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
142. CHECK FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit [08/2013 - ]»(ref-649417-S13501412952014081400000)
143. REPAIR ENGINE IMMOBILISER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-649260-S05394856112014081400000)

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P1607.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (DTC P1607) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P1607 is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

ALL

P2004

P2006

Scheme 107

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on [A].
7. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. HINT: Check DTC P2004 at a coolant temperature of 30°C (86°F) or less. Check DTC P2006 at a coolant temperature of 80°C (176°F) or higher.
8. Turn the ignition switch off and wait for at least 30 seconds.
9. Turn the ignition switch to ON, wait approximately 10 seconds, and then turn the ignition switch off. Repeat this procedure 3 times [B].
10. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
11. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P2004 or P2006.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
15. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 108

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2004 or P2006 is output A P2004 or P2006 and other DTCs are output B HINT: If any DTCs other than P2004 or P2006 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
2. INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Inspect the intake air control valve actuator. Refer to «INSPECTION [08/2013 - ]»(ref-649427-S31936879842014081400000) . NG --> See step 10 OK: Go to next step
3. INSPECT INTAKE MANIFOLD (TUMBLE CONTROL VALVE OPERATION) Inspect the intake manifold. Refer to «INSPECTION [08/2013 - ]»(ref-649427-S21553408782014081400000) . NG --> See step 7 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (ECM - INTAKE AIR CONTROL ACTUATOR) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-3 (IA1-) - U3-4 (M-) Always Below 1 ohms B58-4 (IA1+) - U3-5 (M+) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B58-3 (IA1-) or U3-4 (M-) - Body ground Always 10 kohms or higher B58-4 (IA1+) or U3-5 (M+) - body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK WHETHER DTC OUTPUT RECURS (DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC P2004 or P2006 is output A DTC is not output B B --> See step 8 A --> See step 9
6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
7. REPLACE INTAKE MANIFOLD. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S30796027732014081400000)
8. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)
9. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
10. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL [08/2013 - ]»(ref-649427-S19861733532014081400000)

ALL

P2009

P2010

P2009

P2010

COMPONENT OPERATING RANGE

P2009

P2010

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
8. Check that the coolant temperature is 60°C (140°F) or higher.
9. Wait approximately 10 seconds.
10. Enter the following menus: Powertrain / Engine / Trouble Codes.
11. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P2009 or P2010.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
15. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Inspect the intake air control valve actuator. Refer to «INSPECTION [08/2013 - ]»(ref-649427-S31936879842014081400000) . NG --> See step 8 OK: Go to next step
2. INSPECT INTAKE MANIFOLD (TUMBLE CONTROL VALVE OPERATION) Inspect the intake manifold. Refer to «INSPECTION [08/2013 - ]»(ref-649427-S21553408782014081400000) . NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (ECM - INTAKE AIR CONTROL VALVE ACTUATOR) See step 4 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P2009 OR P2010) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2009 or P2010 is output A DTC is not output B B --> See step 6 A --> See step 7
5. REPLACE INTAKE MANIFOLD. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S30796027732014081400000)
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
8. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL [08/2013 - ]»(ref-649427-S19861733532014081400000)

P2014

P2016

P2017

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Allow 0.5 seconds or more to elapse.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P2014, P2016 or P2017.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE TUMBLE CONTROL VALVE) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the IAC Duty Ratio / All Data / IAC Sensor Voltage. Check the output voltage of IAC Sensor Voltage while changing Control the IAC Duty Ratio from -100 to 100% (or from 100 to -100%) using the Techstream. OK The voltage output of IAC Sensor Voltage remains between 0.2 and 4.8 V while Control the IAC Duty Ratio is changed from -100 to 100% (or from 100 to -100%). HINT: Control the IAC Duty Ratio operation IAC Sensor Voltage (Normal) Suspected Failure Area IAC1 circuit shorted VCIA circuit open VCIA and IAC1 circuit short-circuited IAC1 circuit open EIA1 circuit open Sensor malfunction -100% 0.2 to 1.4 V Remain below 0.2 V Remain higher than 4.8 V Other than the voltage in the 2 columns on the left 100% 3.2 to 4.8 V Remain below 0.2 V Remain higher than 4.8 V NG --> See step 3 OK: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS (DTC P2014, P2016 AND/OR P2017 ARE OUTPUT AGAIN) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to P2014, P2016 and/or P2017 are output again A DTC is not output B B --> See step 8 A --> See step 9
3. CHECK HARNESS AND CONNECTOR (INTAKE AIR CONTROL VALVE ACTUATOR - ECM) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-72 (VCIA) - U3-3 (VDD) Always Below 1 ohms B58-70 (IAC1) - U3-1 (OUT) Always Below 1 ohms B58-71 (EIA1) - U3-2 (GND) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B58-72 (VCIA) or U3-3 (VDD) - Body ground Always 10 kohms or higher B58-70 (IAC1) or U3-1 (OUT) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT ECM (VCIA VOLTAGE) Disconnect the intake air control valve actuator connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition U3-3 (VDD) - Body ground Ignition switch ON 4.5 to 5.5 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Intake Air Control Valve Actuator) NG --> See step 7 OK: Go to next step
5. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Replace the intake air control valve actuator. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S19861733532014081400000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P2014, P2016 AND/OR P2017 ARE OUTPUT AGAIN) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to P2014, P2016 and/or P2017 are output again A DTC is not output B B --> END A --> See step 10
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
8. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)
9. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
10. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

ALL

P2102

P2103

P2102

P2103 (CASE 1)

P2103 (CASE 2)

Scheme 109

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
8. Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
10. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P2102 or P2103.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When either of these DTCs, as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Scheme 110

1. INSPECT THROTTLE BODY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle body. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S34648242772014081400000) . HINT: Perform "Inspection After Repair" after replacing the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 5 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (THROTTLE BODY - ECM) Disconnect the throttle body connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B1-2 (M+) - B58-21 (M+) Always Below 1 ohms B1-1 (M-) - B58-20 (M-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B1-2 (M+) or B58-21 (M+) - Body ground Always 10 kohms or higher B1-1 (M-) or B58-20 (M-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT THROTTLE BODY (VISUALLY CHECK THROTTLE VALVE) Check for foreign objects between the throttle valve and the housing. OK No foreign objects between the throttle valve and housing. HINT: Perform "Inspection After Repair" after cleaning the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REMOVE FOREIGN OBJECT AND CLEAN THROTTLE BODY OK: Go to next step
4. INSPECT THROTTLE BODY (THROTTLE VALVE) Check if the throttle valve opens and closes smoothly. OK Throttle valve opens and closes smoothly. HINT: Perform "Inspection After Repair" after replacing the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 6 OK --> See step 7
5. REPLACE THROTTLE BODY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000)
6. REPLACE THROTTLE BODY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000)
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2109) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2109 is output A DTC P2109 and other DTCs are output B HINT: If any DTCs other than P2109 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
2. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, check "ISC Learning Value" in the freeze frame data. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . HINT: Be sure to confirm "ISC Learning Value" in the freeze frame data as it is used when confirming whether the malfunction has been successfully repaired. NEXT: Go to next step
3. REMOVE FOREIGN OBJECT (CLEAN THROTTLE BODY) Clean off any deposits from the inside of the throttle body. TEXT IN ILLUSTRATION *1 Bore *2 Valve *a Reference *b Throttle Body Cross-section Diagram *c When valve fully opened *d Deposits *e Do not directly apply cleaner Push open the throttle valve and wipe off any carbon from the valve and bore using a cloth soaked in non-residue solvent. NOTE: Make sure that the cloth or your fingers do not get caught in the valve. Make sure that foreign matter does not enter the throttle valve. Do not directly apply non-residue solvent to the throttle body or wash the throttle body. Cleaning solvent may leak into the motor from the shaft and cause problems such as rust or valve movement problems. If there is coating material on the edge of the valve, be careful not to remove it. Push the throttle valve open gently with your finger and check that the throttle valve moves smoothly. HINT: If the throttle valve does not open smoothly, replace the throttle body. NEXT: Go to next step
4. READ VALUE USING TECHSTREAM (ISC LEARNING VALUE) Perform "Inspection After Repair" after cleaning the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . Connect the Techstream to the DLC3. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / ISC Learning Value. Read the value. OK The value is half of "ISC Learning Value" recorded in the freeze frame data or less. HINT: Perform "Inspection After Repair" after replacing the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 6 OK --> END
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
6. REPLACE THROTTLE BODY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000)

ALL

P2111 (THROTTLE ACTUATOR STUCK OPEN)

P2112 (THROTTLE ACTUATOR STUCK CLOSED)

P2111 (THROTTLE ACTUATOR STUCK OPEN)

P2112 (THROTTLE ACTUATOR STUCK CLOSED)

Scheme 111

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
7. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
8. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P2111 or P2112.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When either of these DTCs, as well as other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions, is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P2111 or P2112 is output A DTC P2111 or P2112 and other DTCs are output B HINT: If any DTCs other than P2111 or P2112 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
2. INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. If necessary, clean the throttle body. And check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 5 OK: Go to next step
3. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Check the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 6 A: Go to next step
4. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE BODY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [08/2013 - ]»(ref-649249-S41225597262014081400000) . NEXT --> END
5. REPLACE THROTTLE BODY ASSEMBLY Replace the throttle body assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000) . HINT: Perform "Inspection After Repair" after replacing the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine, and than fully depress and release the accelerator pedal quickly to fully open and close the throttle valve. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P2111 or P2112 is output B B --> See step 8 A --> END
7. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
8. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

Scheme 112

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Slowly depress the accelerator pedal, raise the engine speed to approximately 3000 RPM for approximately 5 seconds, and then idle the engine [B].
8. Check that 16 seconds or more have elapsed since the engine was started.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
10. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P2118.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions, are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Scheme 113

1. READ VALUE USING TECHSTREAM (+BM VOLTAGE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / +BM Voltage. Read the value displayed on the Techstream. Standard voltage 11 to 14 V NG --> See step 2 OK --> See step 4
2. CHECK HARNESS AND CONNECTOR (BATTERY - ECM, ECM - BODY GROUND) Disconnect the ECM connectors. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A49-3 (+BM) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-19 (ME01) - Body ground Always Below 1 ohms B58-104 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
3. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)

Scheme 114

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 20 seconds.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
9. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P2119.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result at step [C].
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC, as well as other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions, is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2119 is output A DTC P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1 and Throttle Position Command. Check the values displayed on the Techstream while fully depressing and releasing the accelerator pedal quickly. RESULT Result Proceed to Throttle Position No. 1 does not change A Throttle Position No. 1 changes even a little B HINT: When a DTC is output, the system changes to fail-safe mode. Therefore, only use the data up until the time the DTC is stored for confirmation. B --> See step 4 A: Go to next step
3. INSPECT THROTTLE BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle body assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S34648242772014081400000) . NG --> See step 7 OK: Go to next step
4. INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 7 OK: Go to next step
5. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Check the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 8 A: Go to next step
6. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE BODY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [08/2013 - ]»(ref-649249-S41225597262014081400000) . NEXT --> END
7. REPLACE THROTTLE BODY ASSEMBLY Replace the throttle body assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000) . HINT: Perform "Inspection After Repair" after replacing the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Allow the engine to idle for 15 seconds or more. Fully depress and release the accelerator pedal several times quickly. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P2119 is output B B --> See step 10 A --> END
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
10. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

P2120

P2122

P2123

P2125

P2127

P2128

P2138

Scheme 115

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Fully depress and release the accelerator pedal [B].
7. Check that 5 seconds or more have elapsed since the DTCs were cleared.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
9. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P2120, P2122, P2123, P2125, P2127, P2128 or P2138.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When any of DTCs P2120, P2121, P2122, P2123, P2125, P2127, P2128 and P2138 is stored, the ECM enters fail-safe mode. If either circuit malfunctions, the ECM limits the engine output. If both of the circuits malfunction, the ECM regards the accelerator pedal as being released. As a result, the throttle valve is closed and the engine idles.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned off.

Scheme 116

1. READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL SENSOR ASSEMBLY) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the value displayed on the Techstream. Standard Voltage Accelerator Pedal Operation Accel Sensor Out No. 1 Accel Sensor Out No. 2 Difference between Accel Sensor Out No. 1 and Accel Sensor Out No. 2 Fully Released 0.5 to 1.1 V 1.2 to 2.0 V More than 0.02 V Fully Depressed 2.6 to 4.5 V 3.4 to 4.75 V TEXT IN ILLUSTRATION *a Fully Depressed *b Fully Released NG --> See step 2 OK --> See step 8
2. CHECK HARNESS AND CONNECTOR (ACCELERATOR PEDAL SENSOR ASSEMBLY - ECM) Disconnect the accelerator pedal sensor assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition A32-6 (VPA) - A49-55 (VPA) Always Below 1 ohms A32-5 (EPA) - A49-59 (EPA) Always Below 1 ohms A32-4 (VCPA) - A49-57 (VCPA) Always Below 1 ohms A32-3 (VPA2) - A49-56 (VPA2) Always Below 1 ohms A32-2 (EPA2) - A49-60 (EPA2) Always Below 1 ohms A32-1 (VCP2) - A49-58 (VCP2) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition A32-6 (VPA) or A49-55 (VPA) - Body ground Always 10 kohms or higher A32-5 (EPA) or A49-59 (EPA) - Body ground Always 10 kohms or higher A32-4 (VCPA) or A49-57 (VCPA) - Body ground Always 10 kohms or higher A32-3 (VPA2) or A49-56 (VPA2) - Body ground Always 10 kohms or higher A32-2 (EPA2) or A49-60 (EPA2) - Body ground Always 10 kohms or higher A32-1 (VCP2) or A49-58 (VCP2) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK ECM (VCPA AND VCP2 VOLTAGE) Disconnect the accelerator pedal sensor assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition A32-4 (VCPA) - A32-5 (EPA) Ignition switch ON 4.5 to 5.5 V A32-1 (VCP2) - A32-2 (EPA2) Ignition switch ON 4.5 to 5.5 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Accelerator Pedal Sensor Assembly) NG --> See step 6 OK: Go to next step
4. REPLACE ACCELERATOR PEDAL ASSEMBLY Replace the accelerator pedal assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11352438972014081400000) . NEXT: Go to next step
5. CHECK WHETHER DTC OUTPUT RECURS (ACCELERATOR PEDAL SENSOR ASSEMBLY DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2120, P2122, P2123, P2125, P2127, P2128, and/or P2138 are output A DTC is not output B B --> END A --> See step 7
6. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
8. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)

ALL

CASE 1

CASE 2

Scheme 117

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Wait for 5 seconds after turning the ignition switch to ON.
7. Operate the accelerator pedal in accordance with the following procedure [B]. Enter the following menus: Powertrain / Engine / Data List / Gas Throttle / Accel Sens. No. 1 Volt %, and Accel Sens. No. 2 Volt %. Slowly depress the accelerator pedal until Accel Sens. No. 1 Volt % is approximately 30% and Accel Sens. No. 2 Volt % is approximately 46%, then slowly release the accelerator pedal.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P2121.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

The accelerator pedal sensor assembly has 2 (main and sub) sensor circuits. If a malfunction occurs in either of the sensor circuits, the ECM limits the engine output. If both circuits malfunction, the ECM regards of the accelerator pedal angle as being fully closed. In this case, the throttle valve remains closed as if the engine is idling.

If a pass condition is detected and then the ignition switch is turned off, the fail-safe operation stops and the system returns to normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2121 is output A DTC P2121 and other DTCs are output B HINT: If any DTCs other than P2121 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
2. READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL SENSOR ASSEMBLY) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the values displayed on the Techstream. Standard Voltage Accelerator Pedal Operation Accel Sensor Out No. 1 Accel Sensor Out No. 2 Fully Released 0.5 to 1.1 V 1.2 to 2.0 V Fully Depressed 2.6 to 4.5 V 3.4 to 4.75 V TEXT IN ILLUSTRATION *a Fully Depressed *b Fully Released NG --> See step 3 OK --> See step 6
3. REPLACE ACCELERATOR PEDAL ASSEMBLY Replace the accelerator pedal assembly. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11352438972014081400000) . NEXT: Go to next step
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2121 is output A DTC is not output B B --> END A --> See step 5
5. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)
7. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)

ALL

SENSOR VOLTAGE DETECTION MONITOR (P2195, P2196)

SENSOR CURRENT DETECTION MONITOR (P2195, P2196)

SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)

SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)

SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION P2195)

SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION P2196)

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.

Scheme 118

Scheme 119

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine, and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
8. On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine / Data List / All Data / Idle Fuel Cut.
9. Drive the vehicle at between 37 and 75 mph (60 and 120 km/h) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
10. Shift the transmission to S position [C].
11. Accelerate the vehicle to 40 mph (64 km/h) or more by depressing the accelerator pedal for at least 10 seconds [D].
12. Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 1400 RPM or more (fuel injection restart engine speed).
13. Allow the vehicle to decelerate until the vehicle speed decreases to less than 6 mph (10 km/h).
14. Repeat steps [C] through [E] above at least 3 times in one driving cycle.
15. Enter the following menus: Powertrain / Engine / Trouble Codes [F].
16. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P2195 or P2196.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [F].
20. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 120

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2195 or P2196 is output A "DTC P2195 or P2196" and "P0136, P0137 or P0138" are output A DTC P2195 or P2196 and other DTCs are output B HINT: If any DTCs relating to the air fuel ratio sensor (DTCs for the air fuel ratio sensor heater or air fuel ratio sensor admittance) are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
2. CONFIRM IF VEHICLE HAS RUN OUT OF FUEL IN PAST Has the vehicle run out of fuel in the past? NO --> See step 4 YES: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 4 A --> DTC CAUSED BY RUNNING OUT OF FUEL
4. READ VALUE USING TECHSTREAM (TEST VALUE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the drive pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / Current. Check that the status of O2 Sensor is Complete. If the status is still Incomplete, drive the vehicle according to the driving pattern again. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / Details / RANGE B1S1. Check the test value of the air fuel ratio sensor output current during fuel cut. Result Result Proceed to Within normal range (0.7 mA or higher, and below 2.2 mA) A Outside normal range (Below 0.7 mA, or 2.2 mA or higher) B B --> See step 14 A: Go to next step
5. READ VALUE USING TECHSTREAM (OUTPUT VOLTAGE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the air fuel ratio sensor at an engine speed of 2500 RPM for 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / All Data / AFS Voltage B1S1 and O2S B1S2. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% to +12%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12% Rich Less than 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12% Lean More than 3.4 V O2S B1S2 (Heated oxygen) +12% Rich More than 0.55 V O2S B1S2 (Heated oxygen) -12% Lean Less than 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Proceed to Lean Lean Actual air fuel ratio lean A Rich Rich Actual air fuel ratio rich A Lean Lean/Rich Air fuel ratio sensor malfunction B Rich Lean/Rich Air fuel ratio sensor malfunction B Lean/Rich Lean/Rich Normal B Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1, O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-649257-S31615066872014081400000) . B --> See step 14 A: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649423-S41759180272014081400000) . OK No leaks in the intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
7. CHECK EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
8. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 2»(ref-649426-S34433188802014081400000) . NG --> See step 16 OK: Go to next step
9. INSPECT FUEL INJECTOR ASSEMBLY Check the fuel injector assembly (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION [08/2013 - ]»(ref-649422-S10292322332014081400000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 18 OK: Go to next step
10. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11660341322014081400000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NEXT: Go to next step
11. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P2195 or P2196 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
12. REPLACE ECM Replace the ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000) . NEXT: Go to next step
13. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
14. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11660341322014081400000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NEXT: Go to next step
15. CHECK WHETHER DTC OUTPUT RECURS (DTC P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 19 A --> END
16. CHECK FUEL LINE Check the fuel lines for leaks or blockage. HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 20
17. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
18. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S10263243442014081400000)
19. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
20. REPLACE FUEL PUMP. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S42191376872014081400000)

AIR FUEL RATIO SENSOR MONITORING METHOD

CRANKSHAFT POSITION SENSOR MONITORING METHOD

AIR FUEL RATIO SENSOR MONITORING METHOD

CRANKSHAFT POSITION SENSOR MONITORING METHOD

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

Scheme 121

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Drive the vehicle at 60 km/h (37 mph) or higher for 2 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: It is acceptable to turn electrical loads on while driving.
7. Idle the engine for 2 minutes or more [C]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Drive the vehicle at less than 30 km/h (19 mph) for 5 seconds or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Accelerate the vehicle from 30 to 60 km/h (19 to 37 mph) over a period of approximately 10 to 20 seconds. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Refer to the values of mass air flow and engine speed in Typical Enabling Conditions before accelerating the vehicle from 30 to 60 km/h (19 to 37 mph).
12. Drive the vehicle at 60 km/h (37 mph) or more for 5 seconds or more [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
13. Drive the vehicle at less than 30 km/h (19 mph) for 5 seconds or more [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Accelerate the vehicle from 30 to 60 km/h (19 to 37 mph) over a period of approximately 10 to 20 seconds. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Refer to the values of mass air flow and engine speed in Typical Enabling Conditions before accelerating the vehicle from 30 to 60 km/h (19 to 37 mph).
15. Drive the vehicle at 60 km/h (37 mph) or more for 5 seconds or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
16. Repeat steps [G] and [H] above at least 2 times [I].
17. Idle the engine for 1 minute or more [J]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
18. Enter the following menus: Powertrain / Engine / Trouble Codes [K].
19. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
20. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
21. Input the DTC: P219A.
22. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
23. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P219A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P219A is output A DTC P219A and other DTCs are output B HINT: If any DTCs other than P219A are output, troubleshoot those DTCs first. B --> See step 14 A: Go to next step
2. READ VALUE USING TECHSTREAM (FREEZE FRAME DATA) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [08/2013 - ]»(ref-649257-S30034271322014081400000) . Freeze Frame Data Items for DTC P219A Vehicle Speed Engine Speed Calculate Load Accelerator Idle Position Short FT #1 Long FT #1 Cylinder #1 Misfire Count to Cylinder #4 Misfire Count A/F Sensor Determination (worst value) #1 Engine Speed Fluctuation Avg (worst value) #1 to #4 HINT: When the sum of Short FT #1 and Long FT #1 is positive, the engine is running lean, and when the sum is negative, the engine is running rich. DTC stored during idling It is possible to conclude that the problem was detected due to a "lean imbalance" (detected using crankshaft speed variation). DTC stored while vehicle being driven It is possible to conclude that the problem was detected due to a "rich imbalance" (detected using the air fuel ratio sensor). NEXT: Go to next step
3. READ VALUE USING TECHSTREAM (MONITOR RESULT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. HINT: If any misfire count ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count) increases while idling or driving the vehicle, proceed to step 6. Perform inspections while focusing on the cylinder whose misfire count has increased. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / Fuel System / Details / A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1. Check the Test Result (A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1). RESULT Result Proceed to A/F SENSOR DETERMINATION is Fail A A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are Fail B ENGINE SPEED FLUCTUATION AVERAGE is Fail B* HINT: When the results of A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are both Pass, drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern again. If both results are still Pass, proceed to step 4. *: Perform inspections while focusing on the cylinder whose engine speed fluctuation value ("Engine Speed Fluctuation Avg (worst value) #1" to "Engine Speed Fluctuation Avg (worst value) #4") was the largest. B --> See step 6 A: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / Gas Misfire / Cylinder #1 to #4 Misfire Count. HINT: When the "Control the Injection Volume" Active Test is selected (injection volume is 0%), if a misfire count increases, proceed to step 6 (Check Intake System). Perform the Control the Injection Volume operation with the engine idling. Check the misfire counts ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count") while decreasing the injection volume in 5% increments. NOTE: Do not decrease the injection volume by higher than 20%. Result The cylinder whose misfire count has not increased can be assumed to be running rich. Therefore, perform inspections while focusing on that cylinder. NEXT: Go to next step
5. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649423-S41759180272014081400000) . OK No leakage in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
7. INSPECT SPARK PLUG Inspect the spark plug of the cylinder causing the imbalance. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 3»(ref-649408-S33370565342014081400000) . HINT: Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 15 OK: Go to next step
8. CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 1»(ref-649408-S33370565342014081400000) . HINT: If the result of the spark test is normal, proceed to the next step. Perform "Inspection After Repair" after repairing or replacing the ignition system. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NEXT: Go to next step
9. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION [08/2013 - ] - Step 9»(ref-649402-S18955805902014081400000) . HINT: Perform "Inspection After Repair" after repairing or replacing the engine assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
10. CHECK TERMINAL VOLTAGE (POWER SOURCE OF FUEL INJECTOR ASSEMBLY) See step 1 NG --> See step 16 OK: Go to next step
11. CHECK FUEL INJECTOR ASSEMBLY OF CYLINDER CAUSING IMBALANCE Check the fuel injector injection [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S10292322332014081400000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 17 OK: Go to next step
12. CHECK FOR CAUSE OF FAILURE If the cause of the problem has not been found even after performing the troubleshooting procedure, perform the inspection below. Check the intake valve for deposits. HINT: As the DTC may have been stored due to deposits on the intake valve, remove the cylinder head and check the intake valve. NEXT: Go to next step
13. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. Result P219A is not output. NEXT --> END
14. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
15. REPLACE SPARK PLUG. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S38133569742014081400000)
16. CHECK FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit [08/2013 - ]»(ref-649417-S13501412952014081400000)
17. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S10263243442014081400000)

P2237 AND P2238

P2238, P2252 AND P2253

P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)

P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)

P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-, GND)

OTHER

P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)

P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)

P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)

P2239 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)

P2252 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)

P2253 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)

P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and wait 5 minutes.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P2237, P2238, P2239, P2252 or P2253.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again.
12. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B7-1 (HA1A) - B58-18 (HA1A) Always Below 1 ohms B7-3 (A1A+) - B58-103 (A1A+) Always Below 1 ohms B7-4 (A1A-) - B58-126 (A1A-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B7-1 (HA1A) or B58-18 (HA1A) - Body ground Always 10 kohms or higher B7-3 (A1A+) or B58-103 (A1A+) - Body ground Always 10 kohms or higher B7-4 (A1A-) or B58-126 (A1A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11660341322014081400000) . HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NEXT: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine. Allow the engine to idle for 5 minutes or more. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P2237, P2238, P2239, P2252 or P2253 is output B B --> See step 4 A --> END
4. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
8. Input the DTC: P2420.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

CASE 1

CASE 2

CASE 3

CASE 1

CASE 2

CASE 3

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine.
7. Idle the engine for 10 minutes or more.
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P2610.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
13. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. REPLACE ECM Replace the ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000) . NEXT: Go to next step
2. CHECK WHETHER DTC OUTPUT RECURS (DTC P2610) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. HINT: If no pending DTCs are output to the Techstream, the repair has been successfully completed. NEXT --> END

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: U0101.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 122

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC U0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: System Select / Health Check. Read the DTCs. Result Result Proceed to DTC U0101 is output A DTC U0101 and other DTCs are output B HINT: If any DTCs other than U0101 are output, troubleshoot those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. INSPECT ECU POWER SOURCE CIRCUIT (TCM POWER SOURCE) Disconnect the TCM connector. Turn the Ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B40-1 (BATT) - B40-8 (E1) Always 11 to 14 V B40-18 (+B) - B40-8 (E1) Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) Result Result Proceed to OK A NG (for U760E) B NG (for U760F) C B --> See step 7 C --> See step 9 A: Go to next step
3. CHECK HARNESS AND CONNECTOR (ECM - TCM) Disconnect the TCM connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B40-6 (CAN+) - B58-24 (CAN+) Always Below 1 ohms B40-7 (CAN-) - B58-1 (CAN-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B40-6 (CAN+) or B58-24 (CAN+) - Body ground Always 10 kohms or higher B40-7 (CAN-) or B58-1 (CAN-) - Body ground Always 10 kohms or higher Result Result Proceed to OK (for U760E) A OK (for U760F) B NG C B --> See step 5 C --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - TCM) A: Go to next step
4. REPLACE TCM Replace the TCM (for U760E). Refer to «REMOVAL [08/2013 - ]»(ref-649430-S10956650162014081400000) . NEXT --> See step 6
5. REPLACE TCM Replace the TCM (for U760F). Refer to «REMOVAL [08/2013 - ]»(ref-649431-S19756798402014081400000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC U0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC U0101 is output B B --> See step 8 A --> END
7. GO TO TCM POWER SOURCE CIRCUIT. Refer to «ECU Power Source Circuit [08/2013 - ]»(ref-649432-S38635475282014081400000)
8. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
9. GO TO TCM POWER SOURCE CIRCUIT. Refer to «ECU Power Source Circuit [08/2013 - ]»(ref-649433-S08461190842014081400000)

RELATED DTCS

If any EVAP system DTCs are stored, the malfunctioning area can be determined using the table below.

Scheme 123

Note. If the reference pressure difference between the first and second checks is more than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) will all be stored.

Scheme 124

TEXT IN ILLUSTRATION

HINT

The canister pressure sensor, the leak detection pump and the vent valve are built into the canister pump module.

Scheme 125

TEXT IN ILLUSTRATION

Note. In the EVAP system of this vehicle, turning ON the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from atmospheric side of the canister.

While the engine is running, if a predetermined condition (closed-loop, etc.) is met, the purge VSV is opened by the ECM and fuel vapors stored in the canister are purged to the intake manifold. The ECM changes the duty cycle ratio of the purge VSV to control purge flow volume.

The purge flow volume is also determined by the intake manifold pressure. Atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.

The following two monitors run to confirm appropriate EVAP system operation.

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. Key-off monitor This monitor checks for EVAP (evaporative emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the ignition switch is turned off. At least 5 hours are required for the fuel to cool down to stabilize the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the ECM monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.
2. Purge flow monitor The purge flow monitor consists of the 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV (Vacuum Switching Valve) is on (open), the ECM monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the ECM begins the 2nd monitor. The 2nd monitor The vent valve is turned ON (closed) and the EVAP pressure is then measured. If the variation in the pressure is less than 0.15 kPa(gauge) [1.125 mmHg(gauge)], the ECM interprets this as the purge VSV being stuck closed, and illuminates the MIL and stores DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressures, before and after of the purge flow monitor, is measured by the ECM. TEXT IN ILLUSTRATION *1 Canister *2 to Intake Manifold *3 ECM *4 Soak Timer *5 Purge VSV (On) *6 Fuel Cap *7 Canister Filter *8 Fuel Tank *9 Leak Detection Pump (Off) *10 Canister Pressure Sensor *11 Reference Orifice (0.02 inches) *12 Vent Valve (Off) *13 Canister Pump Module - - *a EVAP Purge Flow - - Component Operation Canister Contains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank is 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake manifold controlled by purge VSV duty cycle (current-carrying time). (Open: on, Close: off) Roll-over valve Located in fuel tank. Valve closes by its own weight when vehicle overturns to prevent fuel from spilling out. Soak timer Built into ECM. To ensure accurate EVAP monitor, measures 5 hours (+/-15 min) after ignition switch is turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours elapsed, ECM activates see scheme 3 Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When ECM turns valve on, EVAP system is closed. When ECM turns valve off, EVAP system is vented. Negative pressure (vacuum) is created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closing it) and operating leak detection pump see scheme 1 (b) Canister pressure sensor Indicates pressure as voltages. ECM supplies regulated 5 V to pressure sensor, and uses feedback from sensor to monitor EVAP system pressure see scheme 2 (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Has opening with 0.02 inch diameter. Vacuum is produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump, to monitor reference pressure. Reference pressure is used when checking for small EVAP leaks. TEXT IN ILLUSTRATION *1 Vent Valve: off (vent) *2 Canister *3 Reference Orifice (0.02 Inch) *4 Canister Pressure Sensor *5 Leak Detection Pump: off *6 Vent Valve: on (closed) *7 Leak Detection Pump: on - - *a Canister Pump Module see scheme 1 *b Airflow *c Condition: Purge Flow *d Condition: Leak Check *e to Canister Filter (Atmosphere)

Scheme 130

1. CONFIRM DTC Turn the ignition switch off and wait for 10 seconds. Turn the ignition switch to ON. Turn the ignition switch off and wait for 10 seconds. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Confirm DTCs and freeze frame data. If any EVAP system DTCs are stored, the malfunctioning area can be determined using the table below. NOTE: If the reference pressure difference between the first and second checks is greater than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored. NEXT: Go to next step
2. PERFORM EVAP SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. HINT: If no pending DTCs are displayed, perform the Confirmation Driving Pattern. After this confirmation, check for pending DTCs. If no DTCs are displayed, the EVAP system is normal. NEXT: Go to next step
3. PERFORM EVAP SYSTEM CHECK (MANUAL MODE) NOTE: In the Evaporative System Check (Manual Mode), the series of 6 Evaporative System Check steps are performed manually using the Techstream. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Manual Mode. NEXT: Go to next step
4. PERFORM EVAP SYSTEM CHECK (STEP 1/6) Check the EVAP pressure in step 1/6. RESULT DTC *1 Result Suspected Trouble Area Proceed to - Virtually no variation in EVAP pressure Not yet determined A P0451 EVAP pressure fluctuates by +/-0.3 kPa(gauge) [2.25 mmHg(gauge)] or more Canister pressure sensor signal noise B (P0452 or P0453) *2 EVAP pressure is below 42.11009 kPa(abs) [315.86779 mmHg(abs)] or 123.76147 kPa(abs) [928.33479 mmHg(abs)] or more EVAP pressure deviates +/-10 kPa (gauge) [+/-75 mmHg(gauge)] from actual atmosphere pressure*3 Canister pressure sensor or its circuit has malfunction C *1: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. *2: If the canister pressure sensor circuit has an open or short, DTC P0452 or P0453 is stored 0.5 seconds after the ignition switch is turned to ON. HINT: *3: Canister pressure sensor standard output range is 70 to 110 kPa(abs) [525 to 825 mmHg(abs)]. This varies by weather. B --> See step 38 C --> See step 12 A: Go to next step
5. PERFORM EVAP SYSTEM CHECK (STEP 1/6 TO 2/6) Check the EVAP pressure in steps 1/6 and 2/6. RESULT DTC* Result Suspected Trouble Area Proceed to - Virtually no variation in EVAP pressure during step 1/6. Then decreases to reference pressure Not yet determined A P2402 Small difference between EVAP pressures during steps 1/6 and 2/6 Leak detection pump stuck ON B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. HINT: The first reference pressure is the value determined in step 2/6. B --> See step 31 A: Go to next step
6. PERFORM EVAP SYSTEM CHECK (STEP 2/6) HINT: Make a note of the pressures checked in inspection items (A) and (B) below. Check the EVAP pressure 4 seconds after the leak detection pump is activated*1 (A). *1: The leak detection pump begins to operate as step 1/6 finishes and step 2/6 starts. Check the EVAP pressure again when it has stabilized. This pressure is the reference pressure (B). RESULT DTC*2 Result Suspected Trouble Area Proceed to - EVAP pressure in inspection item (B) is between -4.85 kPa(gauge) and -1.057 kPa(gauge) [-36.38 mmHg(gauge) and -7.929 mmHg(gauge)] Not yet determined A P043F and P2401 EVAP pressure in inspection item (B) is -1.057 kPa(gauge) [-7.929 mmHg(gauge)] or more Reference orifice high-flow Leak detection pump stuck OFF B P043E EVAP pressure in inspection item (B) is less than -4.85 kPa(gauge) [-36.38 mmHg(gauge)] Reference orifice clogged C P2419 EVAP pressure in inspection item (A) is more than -0.25 kPa(gauge) [-1.875 mmHg(gauge)] Vent valve stuck closed Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) D *2: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. B --> See step 11 C --> See step 38 D --> See step 13 A: Go to next step
7. PERFORM EVAP SYSTEM CHECK (STEP 2/6 TO 3/6) Check the EVAP pressure in step 3/6. RESULT DTC* Result Suspected Trouble Area Proceed to - EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or more within 10 seconds of proceeding from step 2/6 to step 3/6 Not yet determined A P2420 No variation in EVAP pressure even after proceeding from step 2/6 to step 3/6 Vent valve stuck open (vent) Canister (charcoal filter inside canister) clogged B P0451 No variation in EVAP pressure during steps 1/6 through 3/6 Canister pressure sensor output value stuck Vent valve broken (valve split in two) Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) C *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. B --> See step 27 C --> See step 15 A: Go to next step
8. PERFORM EVAP SYSTEM CHECK (STEP 3/6) Wait until the EVAP pressure change is less than 0.12 kPa(gauge) [0.9 mmHg(gauge)] for 40 seconds. Measure the EVAP pressure and record it. HINT: A few minutes are required for the EVAP pressure to become saturated. When there is little fuel in the fuel tank, it takes up to 15 minutes. NEXT: Go to next step
9. PERFORM EVAP SYSTEM CHECK (STEP 4/6) Check the EVAP pressure in step 4/6. RESULT DTC*1 Result Suspected Trouble Area Proceed to - EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or more within 10 seconds of proceeding from step 3/6 to step 4/6 Not yet determined A P0441 *2 EVAP pressure increases by 0.3 kPa(gauge) [2.25 mmHg(gauge)] or more within 10 seconds of proceeding from step 3/6 to step 4/6 Purge VSV Purge VSV circuit Problems in EVAP hose between purge VSV and intake manifold Problems in EVAP hose between canister and purge VSV ECM B P0441 Variation in EVAP pressure is less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] for 10 seconds, after proceeding from step 3/6 to step 4/6 Purge VSV stuck closed Purge VSV circuit Canister (charcoal filter inside canister) clogged Problems in EVAP hose between purge VSV and intake manifold Problems in EVAP hose between canister and purge VSV ECM C *1: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. *2: This result suggests that due to purge line blockage or purge VSV malfunction, the DTC was stored by the purge flow monitor while the engine was running, or that key-off monitor test result were nearly borderline values. B --> See step 22 C --> See step 17 A: Go to next step
10. PERFORM EVAP SYSTEM CHECK (STEP 5/6) Check the EVAP pressure in step 5/6. Compare the EVAP pressure in step 3/6 and the second reference pressure (step 5/6). RESULT DTC* Result Suspected Trouble Area Proceed to - EVAP pressure from step 3/6 lower than second reference pressure (step 5/6) Not yet determined (no leakage from EVAP system) A P0441 and P0455 EVAP pressure from step 3/6 higher than [second reference pressure (step 5/6) x 0.2] Purge VSV stuck open EVAP gross leak B P0456 EVAP pressure from step 3/6 higher than second reference pressure (step 5/6) EVAP small leak B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. A --> See step 43 B --> See step 17
11. PERFORM EVAP SYSTEM CHECK (STEP 3/6) Check the EVAP pressure in step 3/6. RESULT DTC* Result Suspected Trouble Area Proceed to P043F EVAP pressure less than [reference pressure] measured in step 2/6 Reference orifice high-flow A P2401 EVAP pressure almost same as [reference pressure] measured in step 2/6 Leak detection pump stuck off B *: These DTCs are already present in the ECM when the vehicle arrives and are confirmed in the "Confirm DTC" procedure above. HINT: The first reference pressure is the value determined in step 2/6. A --> See step 38 B --> See step 31
12. INSPECT CANISTER PUMP MODULE (CANISTER PRESSURE SENSOR CIRCUIT) Check the canister pressure sensor circuit, referring to DTC P0451 canister pressure sensor circuit inspection procedure. Refer to «INSPECTION PROCEDURE»(ref-649419-S40751769102014081400000) . NEXT --> See step 49
13. INSPECT CANISTER PUMP MODULE (VENT VALVE OPERATION) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *a Component without harness connected (Canister Pump Module) Apply the battery voltage to terminals VLVB and VGND of the pump module. Touch the canister pump module to confirm the vent valve operation. RESULT Condition Tester Result Suspected Trouble Area Proceed to Apply battery voltage to terminals VLVB and VGND Operating Wire harness or connector between vent valve and ECM Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) ECM A Not operating Vent valve B B --> See step 38 A: Go to next step
14. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Turn the ignition switch off. Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A49-42 (VPMP) - L32-1 (VGND) Always Below 1 ohms A49-42 (VPMP) or L32-1 (VGND) - Body ground Always 10 kohms or higher RESULT Result Suspected Trouble Area Proceed to OK Leak detection pump performance deteriorates Leak detection pump circuit malfunctioning (large resistance exists in the circuit) ECM A NG Wire harness or connector between ECM and canister pump module B B --> See step 40 A: Go to next step
15. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - BODY GROUND) Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to L32-4 (MGND) - Body ground Always Below 1 ohms Canister pump module Wire harness or connector between canister pump module and ECM ECM A 10 kohms or higher Wire harness or connector between canister pump module and body ground B B --> See step 40 A: Go to next step
16. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to A49-34 (MPMP) - L32-3 (MTRB) Always Below 1 ohms Canister pump module ECM A 10 kohms or higher Wire harness or connector between ECM and canister pump module B A --> See step 45 B --> See step 40
17. PERFORM ACTIVE TEST USING TECHSTREAM (PURGE VSV) Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for EVAP Control. Disconnect the hose (connected to the canister) from the purge VSV. TEXT IN ILLUSTRATION *1 Hose (to Canister) *2 Purge VSV Start the engine. Using the Techstream, turn off the purge VSV (Activate the VSV for Evap Control: OFF). Use your finger to confirm that the purge VSV has no suction. Using the Techstream, turn on the purge VSV (Activate the VSV for Evap Control: ON). Use your finger to confirm that the purge VSV has suction. RESULT Test Result Suspected Trouble Area Proceed to No suction when purge VSV turned off, and suction applied when turned on Blockage in the purge line is considered (based on result of step 9): Problems with EVAP hose between canister and purge VSV Canister (charcoal filter inside canister) clogged ECM A Leakage is considered (based on result of step 10): Fuel cap Leakage from EVAP line, fuel tank, or canister assembly B Suction applied when purge VSV turned off Purge VSV stuck open C No suction when purge VSV turned on Purge VSV stuck closed Problems with EVAP hose between purge VSV and intake manifold D B --> See step 20 C --> See step 21 D --> See step 23 A: Go to next step
18. INSPECT EVAP HOSE (PURGE VSV - CANISTER) Check for blockages in the EVAP purge line between the purge VSV and canister. OK No blockages in the EVAP purge line between the purge VSV and canister. NG --> See step 44 OK: Go to next step
19. INSPECT CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the canister. Refer to «INSPECTION [08/2013 - ]»(ref-649412-S14038229942014081400000) . OK No blockages in the canister. OK --> See step 47 NG --> See step 48
20. CHECK FUEL CAP Check that the fuel cap is correctly installed and confirm that the fuel cap meets OEM specifications. Tighten the fuel cap firmly (only one click sound could be heard). HINT: If an EVAP tester is available, check the fuel cap using the tester. Remove the fuel cap and install it onto a fuel cap adapter. Connect an EVAP tester pump hose to the adapter, and pressurize the cap to 3.2 to 3.7 kPa(gauge) [24 to 27.75 mmHg(gauge)] using an EVAP tester pump. Seal the adapter and wait for 2 minutes. Check the pressure. If the pressure is 2 kPa(gauge) [15 mmHg(gauge)] or more, the fuel cap is normal. RESULT Test Result Suspected Trouble Area Proceed to Fuel cap correctly installed - A Fuel cap loose Fuel cap improperly installed Defective fuel cap Fuel cap does not meet OEM specifications B Defective fuel cap - B No fuel cap - C A --> See step 37 B --> See step 35 C --> See step 36
21. INSPECT PURGE VSV Turn the ignition switch off. Disconnect the purge VSV connector. TEXT IN ILLUSTRATION *1 Hose (to Canister) *2 Connector *3 Purge VSV Disconnect the hose (connected to the canister) from the purge VSV. Start the engine. Use your finger to confirm that the purge VSV has no suction. RESULT Test Result Suspected Trouble Area Proceed to No suction Wire harness or connector between purge VSV and ECM (short to ground) ECM A Suction applied Purge VSV B A --> See step 26 B --> See step 39
22. INSPECT EVAP HOSE (PURGE VSV - CANISTER) Check for blockages in the EVAP purge line between the purge VSV and canister. OK No blockages in the EVAP purge line between the purge VSV and canister. NG --> See step 44 OK: Go to next step
23. CHECK EVAP HOSE (PURGE VSV - INTAKE MANIFOLD) Disconnect the hose (connected to the intake manifold) from the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV *2 Hose (to intake manifold) Start the engine. Use your finger to confirm that the hose has suction. RESULT Test Result Suspected Trouble Area Proceed to Suction applied EVAP hose between purge VSV and intake manifold normal Purge VSV Purge VSV power source Wire harness or connector between purge VSV and ECM A No suction Intake manifold port EVAP hose between purge VSV and intake manifold B B --> See step 34 A: Go to next step
24. INSPECT PURGE VSV Remove the purge VSV. Apply battery voltage to the terminals of the purge VSV. TEXT IN ILLUSTRATION *1 Purge VSV Confirm that air flows from port E to port F. RESULT Test Result Condition Suspected Trouble Area Proceed to Air flows Battery voltage is applied to purge VSV terminals Purge VSV normal Purge VSV power source Wire harness or connector between purge VSV and ECM A No air flow Battery voltage is applied to purge VSV terminals Purge VSV B B --> See step 39 A: Go to next step
25. CHECK TERMINAL VOLTAGE (POWER SOURCE OF PURGE VSV) Disconnect the purge VSV connector. Turn the ignition switch to ON. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge VSV) Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Switch Condition Specified Condition Suspected Trouble Area Proceed to B34-1 - Body ground Ignition switch ON 11 to 14 V Purge VSV power source normal Wire harness or connector between purge VSV and ECM A Other than result above Wire harness or connectors between purge VSV and battery B B --> See step 40 A: Go to next step
26. CHECK HARNESS AND CONNECTOR (PURGE VSV - ECM) Disconnect the ECM connector. Disconnect the purge VSV connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B34-2 - B58-28 (PRG) Always Below 1 ohms B34-2 or B58-28 (PRG) - Body ground Always 10 kohms or higher OK --> See step 47 NG --> See step 40
27. INSPECT CANISTER PUMP MODULE (POWER SOURCE FOR VENT VALVE) Turn the ignition switch off. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) - - Disconnect the canister pump module connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Switch Condition Specified Condition Suspected Trouble Area Proceed to L32-5 (VLVB) - Body ground Ignition switch ON 11 to 14 V Wire harness or connector between vent valve and ECM Vent valve Canister (charcoal filter inside canister) clogged ECM A Below 3 V Power source wire harness of vent valve B B --> See step 40 A: Go to next step
28. INSPECT CANISTER PUMP MODULE (VENT VALVE OPERATION) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *a Component without harness connected (Canister Pump Module) Apply the battery voltage to terminals VLVB and VGND of the pump module. Touch the canister pump module to confirm the vent valve operation. RESULT Condition Tester Result Suspected Trouble Area Proceed to Apply battery voltage to terminals VLVB and VGND Operating Wire harness or connector between vent valve and ECM Canister (charcoal filter inside canister) clogged ECM A Not operating Vent valve B B --> See step 38 A: Go to next step
29. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Turn the ignition switch off. Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Test Result Suspected Trouble Area Proceed to A49-42 (VPMP) - L32-1 (VGND) Always Below 1 ohms Canister (charcoal filter inside canister) clogged ECM A 10 kohms or higher Wire harness or connector between ECM and canister pump module B B --> See step 40 A: Go to next step
30. INSPECT CANISTER (CHARCOAL FILTER INSIDE CANISTER) Check for filter blockage in the canister. Refer to «INSPECTION [08/2013 - ]»(ref-649412-S14038229942014081400000) . OK No blockages in the canister. OK --> See step 47 NG --> See step 48
31. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VACUUM PUMP) Turn the ignition switch off. Disconnect the canister pump module connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Canister Pump Module) - - Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. RESULT Tester Connection Switch Condition Test Result Suspected Trouble Area Proceed to L32-3 (MTRB) - Body ground Ignition switch ON 9 to 14 V Wire harness or connector between leak detection pump and body ground Leak detection pump A Below 3 V Wire harness or connector between leak detection pump and ECM ECM B B --> See step 33 A: Go to next step
32. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - BODY GROUND) Turn the ignition switch off. Disconnect the canister pump module connector. Measure the resistance according to the value(s) in the table below. RESULT Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to L32-4 (MGND) - Body ground Always Below 1 ohms Leak detection pump A 10 kohms or higher Wire harness or connector between canister pump module and body ground B A --> See step 38 B --> See step 40
33. CHECK HARNESS AND CONNECTOR (ECM - CANISTER PUMP MODULE) Turn the ignition switch off. Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A49-34 (MPMP) - L32-3 (MTRB) Always Below 1 ohms A49-34 (MPMP) or L32-3 (MTRB) - Body ground Always 10 kohms or higher RESULT Result Suspected Trouble Area Proceed to OK ECM A NG Wire harness or connector between ECM and canister pump module B A --> See step 47 B --> See step 40
34. INSPECT INTAKE MANIFOLD (EVAP PURGE PORT) Stop the engine. Disconnect the EVAP hose from the intake manifold. Start the engine. Use your finger to confirm that the port of the intake manifold has suction. RESULT Tester Connection Suspected Trouble Area Proceed to Suction applied EVAP hose between intake manifold and purge VSV A No suction Intake manifold B A --> See step 41 B --> See step 42
35. CORRECTLY REINSTALL OR REPLACE FUEL CAP HINT: When reinstalling the fuel cap, tighten it firmly (only one click sound could be head). When replacing the fuel cap, use a fuel cap that meets OEM specifications, and install it firmly. NEXT --> See step 49
36. REPLACE FUEL CAP HINT: When installing the fuel cap, tighten it firmly (only one click sound could be head). NEXT --> See step 49
37. LOCATE EVAP LEAK PART Disconnect the vent hose. TEXT IN ILLUSTRATION *1 Fuel Tank *2 Canister *3 Canister Filter *4 Fuel Cap *5 Canister Pump Module - - *a Disconnect the vent hose here - - Connect the EVAP pressure tester tool to the canister pump module with the adapter. TEXT IN ILLUSTRATION *1 Canister Pump Module *2 Adapter *3 EVAP Pressure Tester Tool - - Pressurize the EVAP system to 3.2 to 3.7 kPa(gauge) [24 to 27.75 mmHg(gauge)]. Apply soapy water to the piping and connecting parts of the EVAP system. Look for areas where bubbles appear. This indicates the leak point. Repair or replace the leak point. HINT: Disconnect the hose between the canister and fuel tank from the canister. Block the canister side and conduct an inspection. In this way, the fuel tank can be excluded as an area suspected of causing fuel leaks. NEXT --> See step 49
38. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL [08/2013 - ]»(ref-649412-S32050017252014081400000) . NOTE: When replacing the canister pump module, check the canister pump module interior, canister interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. If liquids are present in the canister interior, replace canister and canister pump module together. Check for filter blockage in the canister. If the charcoal filter inside the canister is clogged, replace the canister and canister pump module together. Check for filter blockage in the canister filter. if the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 Canister Filter - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT --> See step 49
39. REPLACE PURGE VSV Replace the purge VSV. Refer to «REMOVAL [08/2013 - ]»(ref-649412-S33136622432014081400000) . NEXT --> See step 49
40. REPAIR OR REPLACE HARNESS OR CONNECTOR NEXT --> See step 49
41. REPAIR OR REPLACE EVAP PURGE LINE (INTAKE MANIFOLD - PURGE VSV) NEXT --> See step 49
42. INSPECT INTAKE MANIFOLD (EVAP PURGE PORT) Check that the EVAP purge port of the intake manifold is not clogged. If necessary, replace the intake manifold. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S30796027732014081400000) . NEXT --> See step 49
43. REPAIR OR REPLACE PARTS AND COMPONENTS INDICATED BY OUTPUT DTCS Repair the malfunctioning areas indicated by the DTCs that had been confirmed when the vehicle was brought in. NEXT --> See step 49
44. REPAIR OR REPLACE EVAP PURGE LINE (PURGE VSV - CANISTER) NEXT --> See step 49
45. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL [08/2013 - ]»(ref-649412-S32050017252014081400000) . NOTE: When replacing the canister pump module, check the canister pump module interior, canister interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. If liquids are present in the canister interior, replace canister and canister pump module together. Check for filter blockage in the canister. If the charcoal filter inside the canister is clogged, replace the canister and canister pump module together. Check for filter blockage in the canister filter. if the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 Canister Filter - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT: Go to next step
46. PERFORM EVAP SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing an Evaporative System Check, keep the fuel temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. Result Proceed to EVAP system DTCs are output A No DTCs output (No pending DTCs output) B B --> END A: Go to next step
47. REPLACE ECM Replace the ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000) . NEXT --> See step 49
48. REPLACE CANISTER Replace the canister. Refer to «REMOVAL [08/2013 - ]»(ref-649412-S32050017252014081400000) . NOTE: When replacing the canister, check the canister pump module interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. Check for filter blockage in the canister filter. if the canister filter has blockages, replace the canister filter. TEXT IN ILLUSTRATION *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module *6 Canister *7 Canister Filter - - *a Inspection Area (check for disconnection and/or cracks) - - NEXT: Go to next step
49. PERFORM EVAP SYSTEM CHECK (AUTOMATIC MODE) NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing an Evaporative System Check, keep the fuel temperature below 35°C (95°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. HINT: If no pending DTCs are found, the repair has been successfully completed. NEXT --> END

HINT

After a repair, check Monitor Status by performing the Key-Off Monitor Confirmation and Purge Flow Monitor Confirmation described below.

1. KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The fuel tank is less than 90% full. The altitude is less than 7875 ft. (2400 m). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). The vehicle remains stationary (the vehicle speed is 0 km/h [0 mph]). Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch off and wait for 6 hours (8 or 10.5 hours). HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
2. PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-Off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The engine coolant temperature is 4.4°C (40°F) or higher. The intake air temperature is 4.4°C (40°F) or higher. Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the engine coolant temperature reaches more than 75°C (167°F). Increase the engine speed to 3000 RPM once. Allow the engine to idle and turn the A/C switch on for 1 minute. Monitor Status Turn the ignition switch off (if ON or if the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2013 - ] .

1. CHECK HARNESS AND CONNECTOR (ECM - BODY GROUND) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-104 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - BODY GROUND) OK: Go to next step
2. INSPECT ECM (IGSW VOLTAGE) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition A49-28 (IGSW) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 6 OK: Go to next step
3. INSPECT ENGINE ROOM JUNCTION BLOCK ASSEMBLY (EFI MAIN RELAY) Inspect the engine room junction block assembly (EFI MAIN relay). Refer to «INSPECTION [08/2013 - ]»(ref-649425-S19302277682014081400000) . NG --> See step 13 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (ENGINE ROOM JUNCTION BLOCK ASSEMBLY - ECM) Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1E-1 - A49-2 (+B) Always Below 1 ohms 1E-1 - A49-1 (+B2) Always Below 1 ohms 1F-12 - A49-6 (MREL) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1E-1 or A49-2 (+B) - Body ground Always 10 kohms or higher 1E-1 or A49-1 (+B2) - Body ground Always 10 kohms or higher 1F-12 or A49-6 (MREL) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ENGINE ROOM JUNCTION BLOCK ASSEMBLY- ECM) OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (ENGINE ROOM JUNCTION BLOCK ASSEMBLY - BODY GROUND) Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1F-5 - Body ground Always Below 1 ohms 1F-4 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ENGINE ROOM JUNCTION BLOCK ASSEMBLY - BODY GROUND) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ENGINE ROOM JUNCTION BLOCK ASSEMBLY - BATTERY)
6. INSPECT RELAY (IG2 RELAY) Inspect the IG2 relay. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649421-S40284502882014081400000) . NG --> REPLACE RELAY (IG2 RELAY) OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (IG2 RELAY - ECM) Remove the IG2 relay from the engine room relay block. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 5 (IG2 relay terminal) - A49-28 (IGSW) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 5 (IG2 relay terminal) or A49-28 (IGSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - ECM) OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (IG2 RELAY POWER SOURCE) Remove the IG2 relay from the engine room relay block. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 3 (IG2 relay terminal) - Body ground Always 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - BATTERY) OK: Go to next step
9. CHECK HARNESS AND CONNECTOR (IG2 RELAY - BODY GROUND) Remove the IG2 relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (IG2 relay terminal) - Body ground Always Below 1 ohms Result Result Proceed to OK (w/o Smart Key System) A OK (w/ Smart Key System) B NG C B --> See step 12 C --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - BODY GROUND) A: Go to next step
10. CHECK HARNESS AND CONNECTOR (IG2 RELAY - IGNITION SWITCH ASSEMBLY) Remove the IG2 relay from the engine room relay block. Disconnect the ignition switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1 (IG2 relay terminal) - D12-6 (IG2) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1 (IG2 relay terminal) or D12-6 (IG2) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - IGNITION SWITCH ASSEMBLY) OK: Go to next step
11. INSPECT IGNITION SWITCH ASSEMBLY Inspect the ignition switch assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649420-S42270119862014081400000) . NG --> See step 14 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION SWITCH ASSEMBLY - BATTERY)
12. CHECK HARNESS AND CONNECTOR (IG2 RELAY - POWER MANAGEMENT CONTROL ECU) Disconnect the power management control ECU connector. Remove the IG2 relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1 (IG2 relay terminal) - D42-8 (IG2D) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1 (IG2 relay terminal) - D42-8 (IG2D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - POWER MANAGEMENT CONTROL ECU) OK --> See step 15
13. REPLACE ENGINE ROOM JUNCTION BLOCK ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649425-S19069286892014081400000)
14. REPLACE IGNITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649420-S18833162172014081400000)
15. GO TO SMART KEY SYSTEM. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649434-S04636832892014081400000)

1. CHECK MIL Check that the Malfunction Indicator Lamp (MIL) turns on when turning the ignition switch to ON. OK MIL turns on. NG --> See step 2 OK --> See step 10
2. CHECK COMMUNICATION BETWEEN TECHSTREAM AND ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Check the communication between the Techstream and ECM. Result Result Proceed to Communication is not possible A Communication is possible B B --> See step 11 A: Go to next step
3. CHECK MIL (THROTTLE POSITION SENSOR) Disconnect the throttle body connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B HINT: Perform "Inspection After Repair" after replacing the throttle body. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . B --> See step 12 A: Go to next step
4. CHECK MIL (ACCELERATOR PEDAL SENSOR ASSEMBLY) Disconnect the accelerator pedal sensor assembly connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 13 A: Go to next step
5. CHECK MIL (CANISTER PUMP MODULE) Disconnect the canister pump module connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 14 A: Go to next step
6. CHECK MIL (CAMSHAFT POSITION SENSOR (FOR INTAKE CAMSHAFT)) Disconnect the camshaft position sensor (for intake camshaft) connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 16 A: Go to next step
7. CHECK MIL (CAMSHAFT POSITION SENSOR (FOR EXHAUST CAMSHAFT)) Disconnect the camshaft position sensor (for exhaust camshaft) connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 17 A: Go to next step
8. CHECK MIL (INTAKE AIR CONTROL VALVE ACTUATOR) Disconnect the intake air control valve actuator connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B B --> See step 18 A: Go to next step
9. CHECK HARNESS AND CONNECTOR (VC CIRCUIT) Disconnect the throttle body connector. Disconnect the accelerator pedal sensor assembly connector. Disconnect the canister pump module connector. Disconnect the camshaft position sensor (for intake camshaft) connector. Disconnect the camshaft position sensor (for exhaust camshaft) connector. Disconnect the intake air control valve actuator connector. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Short) Tester Connection Condition Specified Condition A49-57 (VCPA) - Body ground Always 10 kohms or higher A49-58 (VCP2) - Body ground Always 10 kohms or higher B58-72 (VCIA) - Body ground Always 10 kohms or higher B58-88 (VCTA) - Body ground Always 10 kohms or higher B58-98 (VCE1) - Body ground Always 10 kohms or higher B58-99 (VCV1) - Body ground Always 10 kohms or higher B58-113 (VCPP) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 15
10. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649257-S23427811172014081400000)
11. GO TO MIL CIRCUIT. Refer to «MIL Circuit [08/2013 - ]»(ref-649417-S32976524802014081400000)
12. REPLACE THROTTLE BODY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S29163396982014081400000)
13. REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11352438972014081400000)
14. REPLACE CHARCOAL CANISTER ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649412-S32050017252014081400000)
15. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
16. REPLACE CAMSHAFT POSITION SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000)
17. REPLACE CAMSHAFT POSITION SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S28646813732014081400000)
18. REPLACE INTAKE AIR CONTROL VALVE ACTUATOR. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S19861733532014081400000)

Scheme 131

Scheme 132

1. w/o Smart Key System When the engine is cranked, the starter relay drive signal output from the ignition switch is input into the STA terminal of the ECM, and the NE signal generated by the crankshaft position sensor is also input into the NE+ terminal. When the ECM interprets that the engine is cranked, it turns transistor Tr1 in the ECM internal circuit on. The current flows to the C/OPN (Circuit Opening) relay when Tr1 is turned on. Then, the fuel pump operates. While the NE signal is input into the ECM when the engine is running, the ECM turns Tr1 on continuously.
2. w/ Smart Key System When the engine is cranked, the starter relay drive signal output from the STAR terminal of the power management control ECU is input into the STA terminal of the ECM, and the NE signal generated by the crankshaft position sensor is also input into the NE+ terminal. When the ECM interprets that the engine is cranked, it turns transistor Tr1 in the ECM internal circuit on. The current flows to the C/OPN (Circuit Opening) relay when Tr1 is turned on. Then, the fuel pump operates. While the NE signal is input into the ECM when the engine is running, the ECM turns Tr1 on continuously.

Scheme 133

Scheme 134

1. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVE THE FUEL PUMP SPEED CONTROL) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operating sound occurs when performing the Active Test on the Techstream. OK Fuel pump operating sound occurs. NG --> See step 2 OK --> See step 8
2. INSPECT ENGINE ROOM JUNCTION BLOCK ASSEMBLY (C/OPN RELAY) Inspect the C/OPN relay. Refer to «INSPECTION [08/2013 - ]»(ref-649425-S19302277682014081400000) . NG --> See step 9 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (C/OPN RELAY - ECM) Disconnect the ECM connector. Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1F-3 - A49-8 (FC) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1F-3 or A49-8 (FC) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (C/OPN RELAY - ECM) OK: Go to next step
4. INSPECT ENGINE ROOM RELAY BLOCK (IG2 RELAY - C/OPN RELAY) Remove the IG2 relay from the engine room relay block. Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1F-2 - 5 (IG2 relay terminal) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1F-2 or 5 (IG2 relay terminal) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - C/OPN RELAY) OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (C/OPN RELAY - FUEL PUMP) Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1F-10 - L12-4 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1F-10 or L12-4 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (C/OPN RELAY - FUEL PUMP) OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (FUEL PUMP - BODY GROUND) Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L12-5 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL PUMP - BODY GROUND) OK: Go to next step
7. INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S19090168192014081400000) . HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 10 OK --> See step 11
8. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649257-S23427811172014081400000)
9. REPLACE ENGINE ROOM JUNCTION BLOCK ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649425-S19069286892014081400000)
10. REPLACE FUEL PUMP. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S42191376872014081400000)
11. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)

1. CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE) Disconnect the fuel injector assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B44-1 - Body ground Ignition switch ON 11 to 14 V B45-1 - Body ground Ignition switch ON 11 to 14 V B46-1 - Body ground Ignition switch ON 11 to 14 V B47-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) NG --> See step 4 OK: Go to next step
2. INSPECT FUEL INJECTOR ASSEMBLY Inspect the fuel injector assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649422-S10292322332014081400000) . HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-649257-S20999044452014081400000) . NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Disconnect the fuel injector assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B44-2 - B58-85 (#10) Always Below 1 ohms B45-2 - B58-84 (#20) Always Below 1 ohms B46-2 - B58-83 (#30) Always Below 1 ohms B47-2 - B58-82 (#40) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B44-2 or B58-85 (#10) - Body ground Always 10 kohms or higher B45-2 or B58-84 (#20) - Body ground Always 10 kohms or higher B46-2 or B58-83 (#30) - Body ground Always 10 kohms or higher B47-2 or B58-82 (#40) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) OK --> See step 7
4. CHECK HARNESS AND CONNECTOR (IG2 RELAY - FUEL INJECTOR ASSEMBLY) Disconnect the fuel injector assembly connector. Remove the IG2 relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B44-1 - 5 (IG2 relay terminal) Always Below 1 ohms B45-1 - 5 (IG2 relay terminal) Always Below 1 ohms B46-1 - 5 (IG2 relay terminal) Always Below 1 ohms B47-1 - 5 (IG2 relay terminal) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B44-1 or 5 (IG2 relay terminal) - Body ground Always 10 kohms or higher B45-1 or 5 (IG2 relay terminal) - Body ground Always 10 kohms or higher B46-1 or 5 (IG2 relay terminal) - Body ground Always 10 kohms or higher B47-1 or 5 (IG2 relay terminal) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - FUEL INJECTOR ASSEMBLY) OK --> See step 6
5. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649422-S10263243442014081400000)
6. CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit [08/2013 - ]»(ref-649417-S02495649362014081400000)
7. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649257-S23427811172014081400000)

1. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Starter Signal. Read the value displayed on the Techstream when the ignition switch is turned to ON and the engine is started. OK Condition Techstream Display Ignition switch ON OFF (starter signal OFF) Engine started ON (starter signal ON) NG --> See step 2 OK --> See step 10
2. CHECK ST RELAY (POWER SOURCE) Inspect the ST relay. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649420-S20189916682014081400000) . Result Result Proceed to OK A NG (w/o Smart Key System) B NG (w/ Smart Key System) C B --> See step 3 C --> See step 7 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - PARK/NEUTRAL POSITION SWITCH ASSEMBLY)
3. CHECK HARNESS AND CONNECTOR (ST RELAY - PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) Remove the ST relay from the engine room relay block. Disconnect the park/neutral position switch assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 2 (ST relay terminal) - B2-9 (L) Always Below 1 ohms 2 (ST relay terminal) - A49-48 (STA) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 2 (ST relay terminal) or B2-9 (L) - Body ground Always 10 kohms or higher 2 (ST relay terminal) or A49-48 (STA) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ST RELAY - PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) OK: Go to next step
4. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649430-S21768177532014081400000) for U760E. Refer to «INSPECTION [08/2013 - ]»(ref-649431-S34978527622014081400000) for U760F). Result Result Proceed to OK A NG (for U760E) B NG (for U760F) C B --> See step 13 C --> See step 14 A: Go to next step
5. CHECK HARNESS AND CONNECTOR (IGNITION SWITCH - ECM - PARK/NEUTRAL POSITION SWITCH) Disconnect the ignition switch assembly connector. Disconnect the park/neutral position switch assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition D12-1 (ST1) - B58-47 (NSW) Always Below 1 ohms D12-1 (ST1) - B2-4 (B) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition D12-1 (ST1) or B58-47 (NSW) - Body ground Always 10 kohms or higher D12-1 (ST1) or B2-4 (B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION SWITCH - ECM - PARK/NEUTRAL POSITION SWITCH) OK: Go to next step
6. INSPECT IGNITION SWITCH ASSEMBLY Inspect the ignition switch assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649420-S42270119862014081400000) . NG --> See step 11 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION SWITCH ASSEMBLY - BATTERY)
7. CHECK HARNESS AND CONNECTOR (ST RELAY - POWER MANAGEMENT CONTROL ECU - PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) Disconnect the ECM connector. Disconnect the park/neutral position switch assembly connector. Disconnect the power management control ECU connector. Remove the ST relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 2 (ST relay terminal) or A49-48 (STA) Always Below 1 ohms 2 (ST relay terminal) - B2-9 (L) Always Below 1 ohms 2 (ST relay terminal) - D42-2 (STA) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 2 (ST relay terminal) or A49-48 (STA) - Body ground Always 10 kohms or higher 2 (ST relay terminal) or B2-9 (L) - Body ground Always 10 kohms or higher 2 (ST relay terminal) or D42-2 (STA) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ST RELAY - POWER MANAGEMENT CONTROL ECU - PARK/NEUTRAL POSITION SWITCH ASSEMBLY - ECM) OK: Go to next step
8. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649430-S21768177532014081400000) for U760E. Refer to «INSPECTION [08/2013 - ]»(ref-649431-S34978527622014081400000) for U760F). Result Result Proceed to OK A NG (for U760E) B NG (for U760F) C B --> See step 13 C --> See step 14 A: Go to next step
9. CHECK HARNESS AND CONNECTOR (POWER MANAGEMENT CONTROL ECU - ECM - PARK/NEUTRAL POSITION SWITCH ASSEMBLY) Disconnect the power management control ECU connector. Disconnect the ECM connector. Disconnect the park/neutral position switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition D42-3 (STAR) - B58-47 (NSW) Always Below 1 ohms D42-3 (STAR) - B2-4 (B) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition D42-3 (STAR) or B58-47 (NSW) - Body ground Always 10 kohms or higher D42-3 (STAR) or B2-4 (B) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER MANAGEMENT CONTROL ECU - ECM - PARK/NEUTRAL POSITION SWITCH ASSEMBLY) OK --> See step 12
10. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649257-S23427811172014081400000)
11. REPLACE IGNITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649420-S18833162172014081400000)
12. GO TO SMART KEY SYSTEM. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649434-S04636832892014081400000)
13. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649430-S40664874602014081400000)
14. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649431-S01077983992014081400000)

1. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE VSV FOR ACIS) Disconnect the vacuum hose from port F on the vacuum switching valve (for ACIS). Connect the Techstream to the DLC3. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Active the VSV for Intake Control. Operate the VSV for ACIS. Check the VSV air flow when switching the VSV on and off. OK Test Condition Specified Condition VSV is ON Air from port E flows out through port F VSV is OFF Air from port E flows out through air filter NG --> See step 4 OK: Go to next step
2. CHECK VACUUM HOSES (VACUUM SWITCHING VALVE - INTAKE AIR CONTROL VALVE, INTAKE MANIFOLD) Check the vacuum hoses. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-649423-S41759180272014081400000) . NG --> REPAIR OR REPLACE VACUUM HOSES OK: Go to next step
3. INSPECT INTAKE MANIFOLD (INTAKE AIR CONTROL VALVE) Inspect the intake air control valve. Refer to «INSPECTION [08/2013 - ]»(ref-649427-S21553408782014081400000) . NG --> See step 10 OK --> See step 8
4. INSPECT VACUUM SWITCHING VALVE (VSV FOR ACIS) Inspect the vacuum switching valve. Refer to «INSPECTION [08/2013 - ]»(ref-649427-S12123358552014081400000) . NG --> See step 9 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (VSV FOR ACIS VOLTAGE) Disconnect the VSV for ACIS connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B52-2 - Body ground Ignition switch ON 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI NO. 3 FUSE - VSV FOR ACIS) OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (VSV FOR ACIS - ECM) Disconnect the VSV for ACIS connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B52-1 - B58-27 (ACIS) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B52-1 or B58-27 (ACIS) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
7. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
8. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-649257-S23427811172014081400000)
9. REPLACE VACUUM SWITCHING VALVE. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S23699138492014081400000)
10. REPLACE INTAKE MANIFOLD. Refer to «REMOVAL [08/2013 - ]»(ref-649427-S30796027732014081400000)

1. CHECK DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: System Select / Health Check. Check DTCs. RESULT Result Proceed to No DTC output A DTC output B B --> GO TO DTC CHART A: Go to next step
2. READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH AND ST1) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Stop Light Switch and ST1. Check the Data List indication when the brake pedal is depressed and released. OK Techstream Display Condition Specified Condition Stop Light Switch Brake pedal released OFF Brake pedal depressed ON ST1 Brake pedal released OFF Brake pedal depressed ON NG --> See step 10 OK: Go to next step
3. INSPECT BRAKE PEDAL Inspect and adjust the brake pedal. Refer to «ADJUSTMENT [08/2013 - ]»(ref-649399-S30197451322014081400000) . HINT: If the stop light switch turns ON too late, the start of brake override system control may be delayed; if it turns ON too soon, brake override system control may begin too early, so conduct inspection of the brake pedal and stop light switch assembly. NG --> See step 9 OK: Go to next step
4. READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %. Read the value displayed on the Techstream. OK Techstream Display Condition Specified Condition Accel Sens. No. 1 Volt % Accelerator Pedal Released --> Depressed --> Released Values smoothly change following accelerator pedal operation Accel Sens. No. 2 Volt % HINT: For numerical values of Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %, refer to the Data List. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-649257-S31615066872014081400000) . NG --> See step 8 OK: Go to next step
5. READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine / Data List / Vehicle Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition Vehicle Speed Vehicle stopped, engine running 0 mph (0 km/h) Vehicle running at constant speed between 10 to 40 mph (16.1 to 64.4 km/h) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the drive test. NG --> See step 7 OK: Go to next step
6. READ VALUE USING TECHSTREAM (FR, FL, RR, RL WHEEL SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Chassis / ABS/VSC/TRAC / Data List / FR Wheel Speed, FL Wheel Speed, RR Wheel Speed and RL Wheel Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition FR Wheel Speed FL Wheel Speed RR Wheel Speed RL Wheel Speed Vehicle stopped, engine running 0 mph (0 km/h) Vehicle running at constant speed between 10 to 40 mph (16.1 to 64.4 km/h) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the drive test. NG --> INSPECT FRONT OR REAR SPEED SENSOR OK --> END
7. GO TO METER / GAUGE SYSTEM (SPEED SIGNAL CIRCUIT). Refer to «Speed Signal Circuit [08/2013 - ]»(ref-649428-S37098547632014081400000)
8. REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S11352438972014081400000)
9. REPAIR OR REPLACE BRAKE PEDAL. Refer to «REMOVAL [08/2013 - ]»(ref-649399-S09584989152014081400000)
10. INSPECT STOP LIGHT SWITCH ASSEMBLY. Refer to «INSPECTION [08/2013 - ]»(ref-649429-S01053010702014081400000)

1. CHECK THAT MIL ILLUMINATES Turn the ignition switch to ON. Check the illumination of the MIL. Result Result Proceed to MIL remains illuminated (Illuminated at all) A MIL remains off (Does not illuminate at all) B MIL illuminates, but turns off after engine is started C B --> See step 5 C --> See step 12 A: Go to next step
2. CHECK WHETHER MIL TURNS OFF Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check if any DTCs have been stored. Note any DTCs. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-649257-S06937007322014081400000) . Check if the MIL goes off. Result Result Proceed to MIL goes off A MIL does not go off B B --> See step 3 A --> See step 8
3. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the ECM connector. Turn the ignition switch to ON. Check if the MIL is illuminated. Result Result Proceed to MIL is not illuminated A MIL is illuminated B TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) B --> See step 4 A --> See step 9
4. CHECK HARNESS AND CONNECTOR (ACCESSORY METER ASSEMBLY - ECM) Disconnect the accessory meter assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Short) Tester Connection Condition Specified Condition F2-10 (CHK) or A49-36 (W) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ACCESSORY METER ASSEMBLY - ECM) OK --> See step 10
5. CHECK IF ENGINE STARTS Start the engine. Result Result Proceed to Engine starts A Engine does not start* B HINT: *: The Techstream cannot communicate with the ECM. B --> See step 11 A: Go to next step
6. CHECK HARNESS AND CONNECTOR (ECM TERMINAL VOLTAGE) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition A49-36 (W) - Body ground Ignition switch ON 11 to 14 V NG --> See step 7 OK --> See step 9
7. CHECK HARNESS AND CONNECTOR (ACCESSORY METER ASSEMBLY - ECM) Disconnect the accessory meter assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition F2-10 (CHK) - A49-36 (W) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ACCESSORY METER ASSEMBLY - ECM) OK --> See step 13
8. REPAIR CIRCUIT INDICATED BY OUTPUT DTC. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-649257-S19875922082014081400000)
9. REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-649421-S05031745702014081400000)
10. REPLACE ACCESSORY METER ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649435-S18324086482014081400000)
11. GO TO VC OUTPUT CIRCUIT. Refer to «VC Output Circuit [08/2013 - ]»(ref-649417-S03489379982014081400000)
12. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-649257-S02996507142014081400000)
13. REPLACE ACCESSORY METER ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-649435-S18324086482014081400000)
