Engine Control System (1AR-FE) (Diagnostic Codes (P1604-U0101) & Circuit Tests): Overview Toyota Venza I facelift

DESCRIPTION

This DTC is stored when the engine does not start even though the STA signal is input or when the engine takes a long time to start, and when the engine speed is low or the engine stalls just after the engine starts.

Using the Techstream, the conditions present when the DTC was stored can be confirmed by referring to the freeze frame data. Freeze frame data records engine conditions when a malfunction occurs. This information can be useful when troubleshooting.

It is necessary to check if the vehicle ran out of fuel before performing troubleshooting, as this DTC is also stored when there is engine starting trouble due to running out of fuel.

Scheme 79

Scheme 80

Scheme 81

1. Reference waveforms showing a normal cold engine start
2. Reference waveforms showing a normal warm engine start
3. Reference values when there is an air leak in the intake system during starting difficulty FREEZE FRAME DATA P1604 STARTABILITY MALFUNCTION Parameter -3 -2 -1 0 1 Unit Engine Speed 398 325 221 159 114 RPM Calculate Load 43.1 42.7 43.1 87.4 87.4 % Vehicle Load 28.2 26.2 26.6 17.2 15.0 % MAF 3.01 2.28 1.59 0.75 0.48 gm/s Atmosphere Pressure 14.5 14.5 14.5 14.5 14.5 psi (gauge) Coolant Temp 85 85 85 85 85 °C Intake Air 46 46 46 46 46 °C Battery Voltage 12.460 12.382 12.324 12.324 12.343 V Throttle Sensor Volt % 16.4 16.0 17.6 16.0 16.0 % Throttl Sensor #2 Volt % 48.6 47.8 49.8 47.8 47.8 % Throttle Sensor Position 0.0 0.0 0.0 0.0 0.0 % Throttle Motor DUTY 17.6 16.0 16.0 16.0 16.0 % Injector (Port) 4240 4302 4612 4612 7776 μs Injection Volum (Cylinder 1) 0.274 0.274 0.187 0.187 0.187 ml Fuel Pump/Speed Status ON ON ON ON ON EVAP (Purge) VSV 0.0 0.0 0.0 0.0 0.0 % Evap Purge Flow 0.0 0.0 0.0 0.0 0.0 % Purge Density Learn Value 0.000 0.000 0.000 0.000 0.000 EVAP Purge VSV OFF OFF OFF OFF OFF Target Air-Fuel Ratio 0.864 0.873 0.882 0.883 0.830 AF Lambda B1S1 0.999 0.999 1.001 1.002 1.005 AFS Voltage B1S1 3.298 3.298 3.307 3.312 3.327 V O2S B1S2 0.015 0.015 0.015 0.015 0.015 V Short FT #1 0.000 0.000 0.000 0.000 0.000 % Long FT #1 3.906 3.906 3.906 3.906 3.906 % Total FT #1 0.000 0.000 0.000 0.000 0.000 Fuel System Status #1 OL OL OL OL OL IGN Advance 8.0 7.0 6.0 0.0 0.0 deg Knock Feedback Value -3.0 -3.0 -3.0 -3.0 -3.0 deg(CA) Knock Correct Learn Value 19.0 19.0 19.0 19.0 19.0 deg(CA) VVT Control Status #1 OFF OFF OFF OFF OFF Starter Signal OFF OFF OFF OFF OFF

MONITOR DESCRIPTION

The ECM continuously monitors its main and sub CPUs while cruise control is operating. This self-check ensures that the ECM is functioning properly. If outputs from the CPUs are different and deviate from the standard, the ECM illuminates the MIL and stores the DTC immediately.

The tumble control valve is built into the intake manifold. The tumble control valve is composed of a position sensor and a DC motor. The DC motor opens and closes the tumble control valve in response to signals from the ECM. The position sensor detects the opening angle of the tumble control valve.

When the tumble control valve is closed, the intake air tumble flow intensifies and negative pressure is generated between the tumble control valve and intake valve which atomizes the fuel. Combustion is enhanced and exhaust gas emissions are reduced at low temperatures.

HINT

After confirming DTCs P2004 and/or P2006, use the Techstream to confirm the Intake Air Control Position while performing Control the IAC Duty Ratio of the Active Test.

REFERENCE (NORMAL CONDITION (ENGINE WARMED UP))

When the ECM has requested a tumble control valve close operation but the actual tumble control valve opening angle is 17 deg. or more for 10 seconds, DTC P2004 is output. When the ECM has requested a tumble control valve open operation but the actual tumble control valve opening angle is less than 35 deg. for 10 seconds, DTC P2006 is output.

The ECM activates the DC motor for the tumble control valve, which opens and closes the tumble control valve. The ECM activates the DC motor based on engine speed, coolant temperature, intake air temperature and other conditions.

When the voltage of the DC motor deviates from the standard range, the ECM determines that a malfunction has occurred and outputs a DTC.

The tumble control valve position sensor is a non-contact type sensor.

The position sensor measures the opening angle of the tumble control valve. The sensor is reliable and accurate, as it is electrically controlled by Hall elements.

Scheme 82

HINT

After confirming DTC P2014, P2016 or P2017, use the Techstream to confirm the IAC Sensor Voltage (tumble control valve position sensor output voltage). Enter the following menus: Powertrain / Engine / Data List / All Data / IAC Sensor Voltage.

The ECM IAC1 terminal voltage increases in correlation with the opening angle of the tumble control valve. When the tumble control valve is fully closed, approximately 0.8 V is applied to the IAC1 terminal. When the tumble control valve is fully open, approximately 3.6 V is applied to the IAC1 terminal.

When the output voltage of the IAC1 terminal deviates from the standard range, the ECM determines that a malfunction has occurred in the position sensor and stores a DTC.

The throttle actuator is operated by the ECM and opens and closes the throttle valve using gears.

The opening angle of the throttle valve is detected by the throttle position sensor, which is mounted on the throttle body. The throttle position sensor provides feedback to the ECM. This feedback allows the ECM to appropriately control the throttle actuator and monitor the throttle opening angle as the ECM responds to driver inputs.

HINT

This Electronic Throttle Control System (ETCS) does not use a throttle cable.

The ECM monitors the electrical current through the electronic actuator, and detects malfunctions and open circuits in the throttle actuator based on this value. If the current is outside the standard range, the ECM determines that there is a malfunction in the throttle actuator. In addition, if the throttle valve does not function properly (for example, stuck on), the ECM determines that there is a malfunction. The ECM then illuminates the MIL and stores a DTC.

1. Example: When the electrical current is below 0.5 A and the throttle actuator duty ratio exceeds 80%, the ECM interprets this as the current being outside the standard range, illuminates the MIL and stores a DTC.

The idle speed is controlled by the Electronic Throttle Control System (ETCS). The ETCS is comprised of a throttle actuator, which operates the throttle valve, and a throttle position sensor, which detects the opening amount of the throttle valve. The ECM controls the throttle actuator to adjust the throttle valve opening amount so that the idle speed is maintained at the target idle speed.

HINT

1. The ISC learned value is the calculated intake air amount corresponding to the throttle opening amount necessary to maintain the idle speed.
2. This malfunction is only detected once per trip. After it has been detected once, the system will not monitor for the malfunction for the rest of the trip.
3. The system uses the throttle body and mass air flow meter sub-assembly to detect this malfunction.

If there are deposits in the throttle valve, a decrease in the ISC flow rate may cause engine stall or unstable idling. Therefore, the necessary ISC flow rate for idling is maintained using the ISC learned value and feedback. The ECM stores this DTC if the ISC learned value approaches its limit. The ECM begins monitoring for the DTC detection conditions when the following preconditions are met

1. 1) The mass air flow meter sub-assembly is normal.
2. 2) Atmospheric pressure is 85 kPa(abs) [638 mmHg(abs)] or higher.
3. 3) The vehicle has been driven at a speed of 30 km/h (18.6 mph) or more at least once.
4. 4) The engine coolant temperature is 45°C (113°F) or less at engine start, the engine is warmed up and conditions for ISC learning are met, or the ignition switch has been turned to ON (include engine running) for 1 hour or more, the engine is warmed up and conditions for ISC learning are met.

The throttle actuator is operated by the ECM, and opens and closes the throttle valve using gears. The opening angle of the throttle valve is detected by the throttle position sensor, which is mounted on the throttle body. The throttle position sensor provides feedback to the ECM. This feedback allows the ECM to appropriately control the throttle actuator and monitor the throttle opening angle as the ECM responds to driver inputs.

HINT

This Electronic Throttle Control System (ETCS) does not use a throttle cable.

The ECM determines that there is a malfunction in the ETCS when the throttle valve remains at a fixed angle despite a high drive current from the ECM. The ECM illuminates the MIL and stores a DTC.

The electronic throttle control system has a dedicated power supply circuit. The voltage (+BM) is monitored and when it is low (below 4 V), the ECM determines that there is a malfunction in the electronic throttle control system and cuts off the current to the throttle actuator.

When the voltage becomes unstable, the electronic throttle control system itself becomes unstable. For this reason, when the voltage is low, the current to the throttle actuator is cut. If repairs are made and the system returns to normal, turn the ignition switch off. The ECM then allows the current to flow to the throttle actuator so that it can be restarted.

HINT

The electronic throttle control system does not use a throttle cable.

Scheme 83

The ECM monitors the battery supply voltage applied to the throttle actuator.

When the power supply voltage (+BM) drops below 4 V for 0.8 seconds or more, the ECM interprets this as an open in the power supply circuit (+BM). The ECM illuminates the MIL and stores the DTC.

If the malfunction is not repaired successfully, the DTC is stored 5 seconds after the engine is next started.

The electronic throttle control system is composed of the throttle actuator, throttle position sensor, accelerator pedal position sensor, and ECM. The ECM operates the throttle actuator to regulate the throttle valve in response to driver inputs. The throttle position sensor detects the opening angle of the throttle valve, and provides the ECM with feedback so that the throttle valve can be appropriately controlled by the ECM.

The ECM determines the actual opening angle of the throttle valve from the throttle position sensor signal. The actual opening angle is compared to the target opening angle commanded by the ECM. If the difference between these two values is outside the standard range, the ECM interprets this as a malfunction in the electronic throttle control system. The ECM then illuminates the MIL and stores the DTC.

HINT

1. This Electronic Throttle Control System (ETCS) does not use a throttle cable.
2. These DTCs relate to the accelerator pedal sensor assembly.

The accelerator pedal sensor assembly is mounted on the accelerator pedal bracket and has 2 sensor circuits: VPA (main) and VPA2 (sub). This sensor is a non-contact type sensor and uses Hall-effect elements in order to yield accurate signals even in extreme driving conditions, such as at high speeds as well as very low speeds. The voltage, which is applied to terminals VPA and VPA2 of the ECM, varies between 0.5 V and 4.75 V in proportion to the operating angle of the accelerator pedal (throttle valve). A signal from VPA indicates the actual accelerator pedal angle (throttle valve opening angle) and is used for engine control. A signal from VPA2 conveys the status of the VPA circuit and is used to check the accelerator pedal sensor assembly itself.

The ECM monitors the actual accelerator pedal angle (throttle valve opening angle) through the signals from VPA and VPA2, and controls the throttle actuator according to these signals.

Scheme 84

HINT

When any of these DTCs are output, check the accelerator pedal sensor assembly voltage using the Techstream. Enter the following menus: Powertrain / Engine / Data List / All Data / Accel Sensor Out No. 1 and Accel Sensor Out No. 2.

HINT

Accelerator pedal positions are expressed as voltages.

When either output voltage of VPA or VPA2 deviates from the standard range, or the difference between the output voltages of the 2 sensor circuits is less than the threshold, the ECM determines that there is a malfunction in the accelerator pedal position sensor. The ECM then illuminates the MIL and stores a DTC.

Example

When the output voltage of VPA drops below 0.4 V for more than 0.5 seconds when the accelerator pedal is fully depressed, DTC P2122 is stored.

HINT

This DTC relates to the accelerator pedal sensor assembly.

Refer to DTC P2120. Refer to DESCRIPTION.

The accelerator pedal position sensor is mounted on the accelerator pedal bracket. The accelerator pedal position sensor has 2 sensor elements and 2 signal outputs: VPA and VPA2. VPA is used to detect the actual accelerator pedal angle (used for engine control) and VPA2 is used to detect malfunctions in VPA. When the difference between the output voltages of VPA and VPA2 deviates from the standard, the ECM determines that the accelerator pedal position sensor is malfunctioning. The ECM turns on the MIL and stores the DTC.

HINT

1. Although the DTC titles say oxygen sensor, these DTCs relate to the air fuel ratio sensor.
2. Sensor 1 refers to the sensor mounted in front of the three-way catalytic converter and located near the engine assembly.

The air fuel ratio sensor generates a voltage* that corresponds to the actual air fuel ratio. This sensor voltage is used to provide the ECM with feedback so that it can control the air fuel ratio. The ECM determines the deviation from the stoichiometric air fuel ratio level, and regulates the fuel injection time. If the air fuel ratio sensor malfunctions, the ECM is unable to control the air fuel ratio accurately.

The air fuel ratio sensor is the planar type and is integrated with the heater, which heats the solid electrolyte (zirconia element). This heater is controlled by the ECM. When the intake air volume is low (the exhaust gas temperature is low), a current flows into the heater to heat the sensor, in order to facilitate accurate oxygen concentration detection. In addition, the sensor and heater portions are the narrow type. The heat generated by the heater is conducted to the solid electrolyte through the alumina, therefore the sensor activation is accelerated.

In order to obtain a high purification rate of the carbon monoxide (CO), hydrocarbon (HC) and nitrogen oxide (NOx) components in the exhaust gas, a three-way catalytic converter is used. For the most efficient use of the three-way catalytic converter, the air fuel ratio must be precisely controlled so that it is always close to the stoichiometric level.

*: Value changes inside the ECM. Since the air fuel ratio sensor is a current output element, the current is converted into a voltage inside the ECM. Any measurements taken at the air fuel ratio sensor or ECM connectors will show a constant voltage.

Scheme 85

HINT

1. When any of these DTCs are set, check the air fuel ratio sensor voltage output by entering the following menus on the Techstream: Powertrain / Engine / Data List / All Data / AFS Voltage B1S1.
2. Short-term fuel trim values can also be read using the Techstream.
3. The ECM regulates the voltages at the A1A+ and A1A- terminals of the ECM to a constant level. Therefore, the air fuel ratio sensor voltage output cannot be confirmed without using the Techstream.
4. If an air fuel ratio sensor malfunction is detected, the ECM sets a DTC.

Sensor Voltage Detection Monitor

Under the air fuel ratio feedback control, if the air fuel ratio sensor voltage output indicates rich or lean for a certain period of time, the ECM determines that there is a malfunction in the air fuel ratio sensor. The ECM illuminates the MIL and stores a DTC.

Example

If the air fuel ratio sensor voltage output is below 2.8 V (very rich condition) and heated oxygen sensor output voltage below 0.69 V for 5 seconds, the ECM stores DTC P2196. Alternatively, if the air fuel ratio sensor voltage output is higher than 3.8 V (very lean condition) and heated oxygen sensor output voltage 0.21 V or more for 5 seconds, DTC P2195 is stored.

Sensor Current Detection Monitor

A rich air fuel mixture causes a low air fuel ratio sensor current, and a lean air fuel mixture causes a high air fuel ratio sensor current. Therefore, the sensor output becomes low during acceleration, and it becomes high during deceleration with the throttle valve fully closed. The ECM monitors the air fuel ratio sensor current during fuel-cut and detects any abnormal current values.

If the air fuel ratio sensor output is 2.2 mA or higher for more than 3 seconds of cumulative time, the ECM interprets this as a malfunction in the air fuel ratio sensor and stores DTC P2195 (stuck on high side). If the air fuel ratio sensor output is below 0.7 mA for more than 3 seconds of cumulative time, the ECM stores DTC P2196 (stuck on low side).

Scheme 86

Refer to DTC P0300. Refer to DESCRIPTION.

Refer to DTC P2195. Refer to DESCRIPTION.

Fuel System Air Fuel Ratio Cylinder Imbalance Monitor

The ECM uses the air fuel ratio sensor and crankshaft position sensor to monitor the difference in air fuel ratios between the cylinders caused by differences in injection volumes between the cylinders, leakage in the intake or exhaust system, etc.

When the air fuel ratios of the cylinders are lean or rich with respect to each other, the ECM determines that a problem is present and stores a DTC.

Air Fuel Ratio Sensor Monitoring Method

When the system detects a difference in air fuel ratios between the cylinders due to fluctuation in the air fuel ratio sensor output over 1 engine cycle (2 crankshaft revolutions), the system determines that there is a problem.

Crankshaft Position Sensor Monitoring Method

The system monitors the engine speed variation and when the variation becomes large, the system determines that there is a difference in air fuel ratios between the cylinders, which it determines to be a problem.

Refer to DTC P2195. Refer to DESCRIPTION.

HINT

Although the DTC titles say oxygen sensor, these DTCs relate to the air fuel ratio sensor.

These DTCs are output when there is an open or short in the air fuel ratio sensor circuit, or if the air fuel ratio sensor output drops. To detect these problems, the voltage of the air fuel ratio sensor is monitored when turning the ignition switch to ON, and the admittance (admittance is an electrical term that indicates the ease of flow of current) is checked while driving. If the voltage of the air fuel ratio sensor is between 0.6 V and 4.5 V, it is considered normal. If the voltage is out of the specified range, or the admittance is less than the standard value, the ECM determines that there is a malfunction in the air fuel ratio sensor. If the same malfunction is detected in next driving cycle, the MIL is illuminated and a DTC is stored.

The description can be found in EVAP (Evaporative Emission) System. Refer to DESCRIPTION.

5 hours* after the ignition switch is turned off, the leak detection pump creates negative pressure (vacuum) in the EVAP (Evaporative Emission) system. The ECM monitors for leaks and actuator malfunctions based on the EVAP pressure.

HINT

*: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.

*: If only a small amount of fuel is in the fuel tank, it takes longer for the EVAP pressure to stabilize.

Scheme 87

TEXT IN ILLUSTRATION

P2420: Vent valve stuck open (vent)

In operation C, the vent valve turns on (closed) and the EVAP system pressure is then measured by the ECM using the canister pressure sensor to conduct an EVAP leak check. If the pressure does not increase when the vent valve is open, the ECM interprets this as the vent valve being stuck open. The ECM illuminates the MIL and stores the DTC.

Scheme 88

The soak timer operates after the ignition switch is turned off. When a certain amount of time has elapsed after turning the ignition switch off, the soak timer activates the ECM to perform malfunction checks which can only be performed after the engine is stopped. The soak timer is built into the ECM.

Scheme 89

1. While the engine is running, the ECM monitors the synchronization of the soak timer and the CPU clock. If these two are not synchronized, the ECM interprets this as a malfunction, illuminates the MIL and stores the DTC.
2. If the soak timer activates the ECM even though only a short amount of time has elapsed since the ignition switch was turned off, or if the soak timer does not activate the ECM even though a considerable amount of time has elapsed since the ignition switch was turned off, the ECM determines that the soak timer is malfunctioning, illuminates the MIL and stores a DTC the next time the ignition switch is turned ON.

The Transmission Control Module (TCM) and ECM perform 2-way communication with each other via the Controller Area Network (CAN). The TCM sends signals to the ECM concerning required engine speed, required engine torque, warning indicators in the combination meter, DTCs and other data. The ECM sends signals to the TCM concerning engine speed, opening angle of the throttle valve, temperature of intake air, temperature of engine coolant, engine torque and other data. If the TCM cannot communicate with the ECM, the TCM will conclude that there is a malfunction in the CAN system, illuminate the MIL and set a DTC.

When the ignition switch is turned to ON, the battery voltage is applied to IGSW of the ECM. The output signal from the MREL terminal of the ECM causes a current to flow to the coil, closing the contact of the engine room junction block assembly (EFI MAIN relay) and supplying power to terminals +B and +B2 of the ECM.

Scheme 90

Scheme 91

The ECM constantly generates 5 V of power from battery voltage supplied to the +B (BATT) terminal to operate the microprocessor. The ECM also provides this power to the sensors through the VC output circuit.

Scheme 92

When the VC circuit is short-circuited, the microprocessor in the ECM and sensors that are supplied with power through the VC circuit are inactivated because the power is not supplied from the VC circuit. Under this condition, the system does not start up and the MIL does not illuminate even if the system malfunctions.

HINT

Under normal conditions, the MIL is illuminated when the ignition switch is turned to ON. The MIL turns off when the engine is started.

Scheme 93

Scheme 94

The fuel injector assemblies are located on the intake manifold. They inject fuel into the cylinders based on signals from the ECM.

Scheme 95

Scheme 96

1. w/o Smart Key System While the engine is being cranked, current flows from terminal ST1 of the ignition switch assembly to the park/neutral position switch assembly and also flows to terminal STA of the ECM (STA Signal).
2. w/ Smart Key System While the engine is being cranked, current flows from terminal STAR of the power management control ECU to the park/neutral position switch assembly and also flows to terminal STA of the ECM (STA signal).

Scheme 97

Scheme 98

This circuit opens and closes the Intake Air Control Valve (IACV) in response to the engine load in order to increase the intake efficiency (ACIS: Acoustic Control Induction System).

Scheme 99

Scheme 100

When the vehicle is being driven with the accelerator pedal depressed, depressing the brake pedal without releasing the accelerator pedal will activate the brake override system to restrict driving torque. The conditions for activating the brake override system as well as the items that are controlled are explained below.

Scheme 101

Activation Conditions

1. Vehicle is running at or above the specified speed.
2. The accelerator pedal is depressed beyond a specified level, and then the brake pedal is depressed.

Note. The vehicle may not enter the brake override system control due to the relation of the accelerator pedal angle and the vehicle's speed.

Items Controlled

1. Driving torque is restricted.

HINT

When this control is activated, the accelerator opening value is forcibly reduced to a fixed value. Therefore, the Accelerator Position value in the Data List is fixed regardless of the actual accelerator opening value (Accel Sens. No. 1 Volt %)

Deactivation Conditions

1. When the Stop Light Switch turns OFF or the actual accelerator pedal angle increases or decreases beyond the specified range.

The MIL (Malfunction Indicator Lamp) is used to indicate vehicle malfunctions detected by the ECM. By turning the ignition switch to ON, power is supplied to the MIL circuit, and the ECM provides the circuit ground which illuminates the MIL.

The MIL operation can be checked visually. When the ignition switch is turned to ON, the MIL should be illuminated and should then turn off. If the MIL remains illuminated or is not illuminated, conduct the following troubleshooting procedure. If the ECM detects any trouble, the MIL illuminates. At this time, the ECM records a DTC in the memory.

Scheme 102

Scheme 103
