Engine Control System (1AR-FE) (Service Information): Diagnosis Toyota Venza I facelift

ON-VEHICLE INSPECTION [08/2013 - ]

1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Inspect the oil control valve (for intake camshaft). Enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank 1). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the Active Test, the air conditioning should be on. Engine coolant temperature when the engine is started should be 30°C (86°F) or less. Standard Condition Tester Operation Specified Condition OCV is OFF Normal engine speed OCV is ON Soon after OCV switched from OFF to ON, engine idles roughly or stalls Inspect the oil control valve (for exhaust camshaft). Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the Active Test, the air conditioning should be on. Engine coolant temperature when engine is started should be 30°C (86°F) or less. Standard Condition Tester Operation Specified Condition 100% Soon after OCV switched from OFF (-100%) to ON (+100%), engine idles roughly or stalls. -100% Normal engine speed

Scheme 218

Scheme 219

Scheme 220

1. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «REMOVAL [08/2013 - ] - Step 26»(ref-649402-S30837215192014081400000)
2. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve. TEXT IN ILLUSTRATION *1 O-ring
3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve. TEXT IN ILLUSTRATION *1 O-ring

INSPECTION [08/2013 - ]

HINT

Use the same procedure for the intake side and exhaust side.

Scheme 221

Scheme 222

1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the oil control valve assembly. TEXT IN ILLUSTRATION *1 Component without harness connected (Camshaft Timing Oil Control Valve) Connect the positive (+) lead from a battery to terminal 1 and the negative (-) lead to terminal 2, and check the movement of the valve. OK Condition Specified Condition Battery positive (+) voltage is applied Valve moves in left arrow direction shown in illustration Battery positive (+) voltage is cut off Valve moves in right arrow direction shown in illustration NOTE: Confirm that the valve moves freely and does not stick in any position. If necessary, replace the camshaft timing oil control valve assembly. HINT: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks will cause the camshaft to advance or retard, and this will cause a DTC to be set. TEXT IN ILLUSTRATION *1 Component without harness connected (Camshaft Timing Oil Control Valve) *2 Battery *3 Valve

1. CHECK THROTTLE BODY ASSEMBLY Check the throttle control motor operating sounds. Turn the ignition switch to ON. When pressing the accelerator pedal, check the operating sound of the running motor. Make sure that no friction noises are emitted from the motor. If friction noise exists, replace the throttle body. Check the throttle position sensor. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Throttle Sensor Position. Depress the accelerator pedal. When the throttle valve is fully opened, check that the value of "Throttle Sensor Position" is within the specification. Standard throttle valve opening percentage 60% or more NOTE: When checking the standard throttle valve opening percentage, make sure the shift lever is in N. If the percentage is less than 60%, replace the throttle body assembly.

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

1. REMOVE WINDSHIELD WIPER MOTOR AND LINK Remove the windshield wiper motor and link. Refer to «REMOVAL [08/2013 - ]»(ref-649436-S28303604982014081400000) .
2. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL [08/2013 - ] - Step 10»(ref-649437-S21602114892014081400000)
3. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «REMOVAL [08/2013 - ] - Step 26»(ref-649402-S30837215192014081400000)
4. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL [08/2013 - ] - Step 6»(ref-649402-S30837215192014081400000)
5. REMOVE NO. 1 ENGINE UNDER COVER
6. REMOVE NO. 2 ENGINE UNDER COVER
7. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT [08/2013 - ] - Step 3»(ref-649406-S06609168452014081400000)
8. REMOVE NO. 1 VACUUM SWITCHING VALVE ASSEMBLY . Refer to «REMOVAL [08/2013 - ] - Step 1»(ref-649412-S37784311342014081400000)
9. REMOVE AIR CLEANER CAP SUB-ASSEMBLY Disconnect the mass air flow meter connector and separate the wire harness clamp from the air cleaner cap. Separate the hose from the hose clamp. Disconnect the ventilation hose from the cylinder head cover. Unlock the hose band and separate the air cleaner cap sub-assembly from the throttle body assembly. Remove the 2 bolts and air cleaner cap sub-assembly.
10. REMOVE THROTTLE BODY ASSEMBLY Disconnect the throttle body assembly connector. Disconnect the fuel tube from the clamp. Disconnect the 2 water by-pass hoses from the throttle body assembly. Remove the 4 bolts and the throttle body assembly with the fuel tube bracket. Remove the bolt and fuel tube bracket. Remove the gasket from the intake manifold.

Scheme 232

1. INSPECT THROTTLE BODY ASSEMBLY TEXT IN ILLUSTRATION *1 Component without harness connected (Throttle Body) Check that the throttle valve opens and closes smoothly. Check that there is no sludge accumulating around the throttle body. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms If the result is not as specified, replace the throttle body assembly.

1. INSPECT ACCELERATOR PEDAL SENSOR ASSEMBLY Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the values displayed on the Techstream. Standard Voltage Tester Display Condition Specified Condition Accel Sensor Out No. 1 Accelerator pedal is released 0.5 to 1.1 V Accelerator pedal is fully depressed 2.6 to 4.5 V Accel Sensor Out No. 2 Accelerator pedal is released 1.2 to 2.0 V Accelerator pedal is fully depressed 3.4 to 4.75 V If the result is not as specified, check the accelerator pedal sensor assembly, wire harness or ECM.

Scheme 233

1. REMOVE ACCELERATOR PEDAL SENSOR ASSEMBLY NOTE: Avoid physical shock to the accelerator pedal sensor assembly. Do not disassemble the accelerator pedal sensor assembly. The accelerator pedal sensor assembly does not require lubrication. Do not apply oil or other lubricants to the accelerator pedal sensor assembly. If applied, the accelerator pedal sensor assembly must be replaced. Disconnect the accelerator pedal sensor assembly connector. Remove the 2 bolts and accelerator pedal sensor assembly.

Note. Perform the mass air flow meter inspection according to the procedure below. Only replace the mass air flow meter when the mass air flow value in the Data List (with the engine stopped) is not within the normal operating range or there is foreign matter on the mass air flow meter platinum hot wire (heater).

HINT

Perform "Inspection After Repairs" after replacing the mass air flow meter. Refer to INITIALIZATION [08/2013 - ] .

1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY NOTE: Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the mass air flow meter while it is installed to the air cleaner case (installed to the vehicle). During the test, do not use the exhaust air duct to perform suction on the exhaust pipe. Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not run the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / MAF. Wait 30 seconds, and read the values on the Techstream. Standard Item Condition Specified Condition MAF Engine not running 30 seconds after turning ignition switch to ON Less than 0.5 g/sec. If the result is not as specified, replace the mass air flow meter sub-assembly. If the result is as specified, inspect the mass air flow meter sub-assembly. Refer to «INSPECTION [08/2013 - ]»(ref-649421-S02331794862014081400000) .

Scheme 234

1. REMOVE MASS AIR FLOW METER SUB-ASSEMBLY Disconnect the mass air flow meter connector. Remove the 2 screws and mass air flow meter.

Scheme 235

Scheme 236

1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Perform a visual check for any foreign matter on the platinum hot wire (heater) of the mass air flow meter shown in the illustration. TEXT IN ILLUSTRATION *1 Platinum Hot Wire (Heater) OK There is no foreign material. Check the intake air temperature sensor (built into the mass air flow meter). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 1 (THA) - 2 (E2) 20°C (68°F) 2.21 to 2.69 kohms 1 (THA) - 2 (E2) 60°C (140°F) 0.49 to 0.67 kohms If the result is not as specified, replace the mass air flow meter sub-assembly. TEXT IN ILLUSTRATION *1 Component without harness connected (Mass Air Flow Meter)
