MONITOR STRATEGY
| Related DTCs | P0327: Knock control sensor range check (low voltage) P0328: Knock control sensor range check (high voltage) |
| Required Sensors/Components (Main) | Knock control sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Time after engine start | 5 seconds or more |
| Auxiliary battery voltage | 10.5 V or higher |
| Power switch | On (IG) |
TYPICAL MALFUNCTION THRESHOLDS
| Knock control sensor voltage | Less than 0.5 V |
| Knock control sensor voltage | Higher than 4.5 V |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and wait 5 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327 or P0328.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 380
Scheme 380: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor range check/rationality P0335: Crankshaft position sensor verify pulse input |
| Required Sensors/Components (Main) | Crankshaft position sensor |
| Required Sensors/Components (Related) | Camshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Verify pulse input (case 1) 1.85 seconds: Verify pulse input (case 2) 0.016 seconds: Range check/rationality |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Lost communication with power management control ECU (U0293) | Not detected |
| Hybrid control module judge | Engine running |
| All of the following conditions are met | |
| Engine speed signal | Signal input |
| Power switch | On (IG) |
| Time after starter off to on | 2.5 seconds or more |
| Number of camshaft position sensor signal pulses | 6 times |
| Auxiliary battery voltage | 7 V or higher |
| Camshaft position sensor circuit fail | Not detected |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| All of the following conditions are met | |
| Starter | Off |
| Engine speed | 600 rpm or higher |
| Time after starter from on to off | 3 seconds or more |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| Both of the following conditions are met | |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | 0.5 seconds or more |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulses | 87 times or less, or 219 times or more |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed signal | No signal |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
COMPONENT OPERATING RANGE
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine.
- Idle the engine for 20 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 381
Scheme 381: WIRING DIAGRAM
| Related DTCs | P0340: Camshaft position sensor verify pulse input P0342: Camshaft position sensor range check (Low voltage) P0343: Camshaft position sensor range check (High voltage) |
| Required Sensors/Components (Main) | Camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds: Camshaft position /sensor verify pulse input 4 seconds: Camshaft position sensor range check (Low voltage, high voltage) |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| All of the following conditions are met | |
| Engine speed | 600 rpm or more |
| Starter | OFF |
| VVT system misalignment | Not detected |
| Camshaft position sensor range check fail (P0342, P0343) | Not detected |
| Camshaft position sensor voltage | 0.3 to 4.7 V |
| Lost communication of power management control ECU (U0293) | Not detected |
P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT
| All of the following conditions are met | |
| Starter | OFF |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | 2 seconds or more |
| Camshaft position sensor verify pulse input fail (P0340) | Not detected |
| Auxiliary battery voltage | 8 V or higher |
P0342 AND P0343: CAMSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)
| Either of the following conditions is met | 1 or 2 |
| 1. Camshaft position and crankshaft position alignment | Misalignment |
| 2. Camshaft position sensor signal | No signal |
P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Camshaft position sensor voltage | Below 0.3 V |
P0342: CAMSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE)
| Camshaft position sensor voltage | Higher than 4.7 V |
P0343: CAMSHAFT POSITION SENSOR RANGE CHECK (HIGH VOLTAGE)
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340, P0342 or P0343.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 382
Scheme 382: WIRING DIAGRAM
| Related DTCs | P0351: Igniter (cylinder 1) circuit/open P0352: Igniter (cylinder 2) circuit/open P0353: Igniter (cylinder 3) circuit/open P0354: Igniter (cylinder 4) circuit/open |
| Required Sensors/Components (Main) | Igniter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Spark cut | Not operating |
| Either of the following conditions is met | A or B |
| A. Engine speed | 1500 rpm or less |
| B. Starter | Off |
| Either of the following conditions is met | C or D |
| C. Both of the following conditions are met | |
| Engine speed | 500 rpm or less |
| Auxiliary battery voltage | 6 V or higher |
| D. All of the following conditions are met | |
| Engine speed | Higher than 500 rpm |
| Auxiliary battery voltage | 10 V or higher |
| Number of sparks after CPU reset | 5 sparks or more |
| Lost communication with power management control ECU (U0293) | Not detected |
| All of the following conditions are met | A, B, C and D |
| A. Ignition signal fail counter | More than 2 times |
| B. Time after condition A is met | 0.256 seconds or more |
| C. Ignition signal fail counter after condition B is met | More than 2 times |
| D. Power switch | On (IG) |
| Confirmed ignition signal input when ignition signal is on to off | 2 times |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353 or P0354.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 383
Scheme 383: WIRING DIAGRAM
Scheme 384
| Related DTC | P0401: EGR valve high flow rate/low flow rate |
| Required sensors/Components (Main) | EGR valve assembly Manifold absolute pressure sensor |
| Required sensors/Components (Related) | Engine coolant temperature sensor Vehicle speed sensor |
| Frequency of operation | Once per driving cycle |
| Duration | Within 3 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Time after engine started | 3 seconds or more |
| Time after engine fuel cut | 2000 msec or more |
| Engine speed | 950 to 1600 rpm |
| Vehicle speed | 20 km/h (12.4 mph) or more |
| Engine coolant temperature | 70°C (158°F) or higher |
| Auxiliary battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Atmospheric pressure | 76 kPa(abs) [750 mmHg(abs)] or higher |
| Manifold pressure change | Less than 1 kPa(gauge) [7.5 mmHg(gauge)] |
| At engine speed | 1050 rpm |
MONITOR RESULT
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $31 | $BD | Multiply by 0.01 | KPa | Delta Manifold Absolute Pressure |
P0401: EXHAUST GAS RECIRCULATION / VVT / EGR FLOW INSUFFICIENCY
Scheme 385
Scheme 385: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
- Accelerate the vehicle to 60 km/h (37 mph) or more by depressing the accelerator pedal for at least 10 seconds [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: When accelerating the vehicle, depress the accelerator pedal more than normal to start the engine.
- Idle the engine for 30 seconds or more [C].
- Accelerate the vehicle to 60 km/h (37 mph) with the shift lever in B [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Perform fuel cut operation for 5 seconds or more, with the accelerator pedal fully released [E]. HINT: When fuel cut is operating "Idle Fuel Cut" in Data List is ON.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor [F].
- Check that Exhaust Gas Recirculation/VVT / Current is Complete. HINT: If the monitor item Exhaust Gas Recirculation/VVT / Current is Incomplete, perform the driving pattern again.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Exhaust Gas Recirculation / VVT / Details.
- Check the Details (EGR FLOW INSUFFICIENCY). HINT: Make sure that the value is between MIN and MAX.
- If the monitor item Exhaust Gas Recirculation/VVT / Current is still Incomplete, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Power train / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0401.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the DTC judgment result is INCOMPLETE or N/A, perform steps [D] and [E] again.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0403: EGR valve circuit range check |
| Required Sensors/Components (Main) | EGR valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Engine | Running |
| Auxiliary battery voltage | 10.5 V or higher |
| Time after power switch off to on (IG) | 0.5 seconds or more |
| One of the following conditions is met | Conditions A, B, C or D |
| A. All of the following conditions are met | |
| EGR1 output terminal voltage | Low |
| Either of the following conditions is met | 1 or 2 |
| 1. Step motor | Driving |
| 2. EGR1 | Not operating |
| B. All of the following conditions are met | |
| EGR2 output terminal voltage | Low |
| Either of the following conditions is met | 3 or 4 |
| 3. Step motor | Driving |
| 4. EGR2 | Not operating |
| C. All of the following conditions are met | |
| EGR3 output terminal voltage | Low |
| Either of the following conditions is met | 5 or 6 |
| 5. Step motor | Driving |
| 6. EGR3 | Not operating |
| D. All of the following conditions are met | |
| EGR4 output terminal voltage | Low |
| Either of the following conditions is met | 7 or 8 |
| 7. Step motor | Driving |
| 8. EGR4 | Not operating |
Scheme 386
Scheme 386: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode).Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up [B].
- Drive the vehicle at 20 km/h (12 mph) or more for 10 minutes [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0403.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system has a normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 387
Scheme 387: WIRING DIAGRAM
| Related DTCs | P0420: Catalyst deterioration |
| Required Sensors/Components (Main) | Air fuel ratio sensor Heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Mass air flow meter sub-assembly Crankshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Approximately 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0037, P0038, P102D (Heated oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0136, P0137, P0138, P0139, P0607 (Heated oxygen sensor) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR system (closed)) P219A (Air fuel ratio imbalance) |
| Auxiliary battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or higher |
| Idling | Off |
| Engine speed | Less than 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10% or higher, and less than 70% |
| All of the following conditions (a), (b) and (c) are met | |
| (a) Mass air flow rate | 2.5 gm/sec or more, and less than 50 gm/sec |
| (b) Front catalyst temperature (estimated) | 530°C (986°F) or higher, and less than 770°C (1418°F) |
| (c) Rear catalyst temperature (estimated) | 480°C (896°F) or higher, and less than 700°C (1292°F) |
| Oxygen Storage Capacity (OSC) of Three-way Catalytic Converter (TWC) | Less than 0.173 g |
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $21 | $A9 | Multiply by 0.0003 | No dimension | Oxygen storage capacity of catalyst bank 1 |
| $21 | $AF | Multiply by 0.001 | No dimension | Oxygen storage capacity of catalyst bank 1 (Normalization) |
P0420: CATALYST EFFICIENCY / O2 STORAGE B1
Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.
Scheme 388
Scheme 388: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that Catalyst Efficiency / Current is Incomplete.
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the park (P) selected [A].
- Drive the vehicle at approximately 75 km/h (47 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
- Turn the power switch off and wait for at least 30 seconds [C].
- Turn the power switch on (IG) and turn the Techstream on.
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [D].
- Drive the vehicle at approximately 75 km/h (42 mph) for 10 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item change to Complete as the Catalyst Efficiency monitor operates.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor item does not change to Complete, and no pending DTCs are stored, perform the following procedure.
- Drive the vehicle at a speed 100 km/h (62 mph) for 10 minutes or more [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor item does not change to Complete, and no pending DTCs are stored, extend the driving time.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 is output A DTC P0420 and other DTCs are output B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine warm it up. Run the engine at an engine speed of 2500 rpm for approximately 90 seconds. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, warm up the engine after charging control has completed. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Data List / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the output voltages of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by -12.5% or increases the injection volume by 12.5%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) 12.5% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) 12.5% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen) -12.5% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Tree-way catalytic converter Gas leaks from exhaust system EGR valve assembly A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean Lean Actual air fuel ratio lean May occur Extremely lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Rich Rich Actual air fuel ratio rich - Extremely rich actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Lean: During the Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume for A/F Sensor Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume for A/F Sensor Active Test, the output voltage of the air fuel ratio sensor and the heated oxygen sensor alternates correctly. B --> See step 7 C --> See step 8 D --> See step 10 A: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> See step 14 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 6 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 18 OK: Go to next step
- REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: FRONT AND REAR CATALYST) NOTE: When replacing the front exhaust pipe assembly in order to replace the three-way catalytic converter, it is not necessary to replace the heated oxygen sensor. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Replace the front exhaust pipe assembly (TWC: Front and rear catalyst). Refer to «COMPONENTS»(ref-553443-S17462321522013051700000) . NEXT --> END
- REPLACE AIR FUEL RATIO SENSOR (SENSOR 1) Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-553431-S07823217142013051700000) . NEXT --> See step 15
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> See step 14 OK: Go to next step
- REPLACE HEATED OXYGEN SENSOR (SENSOR 2) Replace the heated oxygen sensor. Refer to «REMOVAL»(ref-553431-S31300248292013051700000) . NEXT --> See step 15
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> See step 14 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 13 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 18 OK: Go to next step
- CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO Check the case of extremely rich or lean actual air fuel ratio, referring to the DTC P0171 Inspection Procedure. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1)»(ref-553435-S26925324782013051700000) . NEXT --> See step 15
- REPAIR OR REPLACE EXHAUST GAS LEAK POINT Repair or replace exhaust gas leak point. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (P0420) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 is output A DTC is not output (No pending DTCs output) B B --> END A: Go to next step
- REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: FRONT AND REAR CATALYST) NOTE: When replacing the front exhaust pipe assembly in order to replace the three-way catalytic converter, it is not necessary to replace the heated oxygen sensor. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Replace the front exhaust pipe assembly (TWC: Front and rear catalyst). Refer to «COMPONENTS»(ref-553443-S17462321522013051700000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553426-S07103638412013051700000)
| Required Sensors/Components (Main) | Canister pump module |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 2 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 kPa(abs) [525 mmHg(abs)] or higher, and less than 111 kPa(abs) [832 mmHg(abs)] |
| Auxiliary battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Power switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Fuel vapor-containment valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions (a) and (b) are met before Key-OFF | |
| (a). Duration that vehicle is being driven | 5 minutes or more |
| (b). Purge flow | Performed |
| Engine coolant temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
| Intake air temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
Key-off Monitor Sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (closed) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
3. VENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the both of the following condition is met | |
| Vacuum introduction time | 15 minutes or less |
| Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (open) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa(gauge) [-15 mmHg(gauge)] or less, or 3 kPa(gauge) [22.5 mmHg(gauge)] or higher |
| 2. Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa(gauge) [-15 to 22.5 mmHg(gauge)] |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when fuel vapor-containment valve closed | 0.35 kPa(gauge) [2.62 mmHg(gauge)] or higher |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | Less than 0.35 kPa(gauge) [2.62 mmHg(gauge)] |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| One of the following conditions is met | |
| Canister pressure when 1.9 seconds after reference pressure measurement began | Higher than -0.25 kPa(gauge) [-1.87 mmHg(gauge)] |
| Reference pressure (vary with atmospheric pressure) | Less than -4.75 kPa(gauge) [-35.63 mmHg(gauge)] |
| Reference pressure (vary with atmospheric pressure) | 0.957 kPa(gauge) [-7.178 mmHg(gauge)] or higher |
| Reference pressure | Not saturated |
| Reference pressure difference between the first and second | 0.9 kPa(gauge) [6.75 mmHg(gauge)] or higher |
Refer to EVAP system. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P043E, P043F, P2401, P2402 or P2419.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components (Main) | Purge VSV and canister pump module |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes: Purge VSV stuck open/closed Within 30 seconds: Purge flow |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Engine | Running |
| Engine coolant temperature | 4.4°C (40°F) or higher |
| Intake air temperature | 4.4°C (40°F) or higher |
| Pressure sensor of canister pump module malfunction (P0451, P0452, P0453) | Not detected |
| Purge VSV | Not operated by scan tool |
| EVAP system check | Not operated by scan tool |
| Auxiliary battery voltage | 10 V or higher |
| Purge duty cycle | 8% or higher |
| Monitor runs whenever following DTCs are not stored | None |
| Key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 kPa(abs) [525 mmHg(abs)] or higher, and less than 111 kPa(abs) [832 mmHg(abs)] |
| Auxiliary battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Power switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Fuel vapor-containment valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions (a) and (b) are met before Key-OFF | |
| (a). Duration that vehicle is being driven | 5 minutes or more |
| (b). Purge flow | Performed |
| Engine coolant temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
| Intake air temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
Key-off Monitor Sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (closed) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
3. VENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the both of the following condition is met | |
| Vacuum introduction time | 15 minutes or less |
| Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (open) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa(gauge) [-15 mmHg(gauge)] or less, or 3 kPa(gauge) [22.5 mmHg(gauge)] or higher |
| 2. Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa(gauge) [-15 to 22.5 mmHg(gauge)] |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when fuel vapor-containment valve closed | 0.35 kPa(gauge) [2.62 mmHg(gauge)] or higher |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | Less than 0.35 kPa(gauge) [2.62 mmHg(gauge)] |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| EVAP pressure when vacuum introduction for canister was complete | Higher than [reference pressure x 0.2] |
| EVAP pressure change for 10 seconds after purge VSV ON (open) | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
| Both of the following conditions are met | Conditions 1 and 2 |
| 1. EVAP pressure change when purge operation is started | Less than 0.1 kPa(gauge) [0.75 mmHg(gauge)] |
| 2. EVAP pressure change during purge operation when vent valve is closed | Less than 0.5 kPa(gauge) [3.75 mmHg(gauge)] |
Refer to EVAP system. Refer to MONITOR RESULT .
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and wait 15 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P0441) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. RESULT Result Proceed to DTC P0441 is output A DTC P0441 and other DTCs are output B HINT: If any DTCs other than DTC P0441 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 6 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553426-S07103638412013051700000)
- GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-553432-S09962455652013051700000)
| Required Sensors/Components (Main) | Canister pump module |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Less than 15 seconds: P0451 0.5 seconds: P0452, P0453 |
| MIL Operation | Immediately: P0452, P0453 2 driving cycles: P0451 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Atmospheric pressure | 70 kPa(abs) [525 mmHg(abs)] or higher, and less than 111 kPa(abs) [832 mmHg(abs)] |
| Auxiliary battery voltage | 10.5 V or higher |
| Intake air temperature | 4.4°C (40°F) or higher, and less than 50°C (122°F) |
| Pressure sensor of canister pump module malfunction (P0452, P0453) | Not detected |
| Either of the following conditions 1 or 2 is met | |
| 1. Engine | Running |
| 2. Key-off duration | 5, 7 or 9.5 hours |
| All of the following conditions are met | |
| Power switch | On (IG) |
| Auxiliary battery voltage | 8 V or higher |
| Frequency that EVAP pressure change 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher | 10 times or more in 10 seconds |
| EVAP system pressure sensor | Less than 42.11009 kPa(abs) [315.86779 mmHg(abs)] |
P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE
| EVAP system pressure sensor | Higher than 123.76147 kPa(abs) [928.33479 mmHg(abs)] |
P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air.
- Check that the intake air temperature is between 4.4 and 50°C (40 and 122°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0451, P0452 or P0453.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 389
Scheme 389: WIRING DIAGRAM
Scheme 390
| Related DTCs | P0505: Idle air control system functional check |
| Required Sensors/Components (Main) | Electronic throttle control system |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes (idling after warm up) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR system (closed)) P0451, P0452, P0453, P1451, P1452, P1453 (EVAP system) P219A (Air fuel ratio imbalance) |
| Engine | Running |
| Either of the following conditions is met | 1 or 2 |
| 1. Both of the following conditions A and B met | |
| A. Engine speed - Target engine speed | Less than -100 rpm, or higher than 150 rpm |
| B. IAC flow rate learned value | 0.5 L/sec. or less, or 6.1 L/sec. or more for 5 seconds or more |
| 2. Both of the following conditions C and D met | |
| C. Frequency that both of following conditions (a) and (b) met | 5 times or more |
| (a) Engine speed - Target engine speed | Less than -100 rpm, or higher than 150 rpm |
| (b) Vehicle condition | Stopped after being driven at 10 km/h (6.25 mph) or more |
| D. Either of the following conditions is met | (c) or (d) |
| (c) Amount of change of IAC flow rate learned value | +1.837 L/sec. or more, or -3.08 L/sec. or less |
| (d) IAC flow rate learned value | 0.5 L/sec. or less, or 6.1 L/sec. or more |
Scheme 391
Scheme 391: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and drive the vehicle until the coolant temperature reaches 70°C (158°F) or higher with all the accessories switch off [B].
- Turn the power switch off and wait for at least 30 seconds.
- Disconnect the cable from the negative (-) auxiliary battery terminal.
- Reconnect the cable to the negative (-) auxiliary battery terminal.
- Turn the power switch on (IG) and turn the Techstream on.
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and rev the engine for 5 seconds with the park (P) selected [C].
- Idle the engine for 5 minutes or more [D]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [I].
- Accelerate the vehicle to 10 km/h (6.25 mph) or more [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Stop the vehicle and rev the engine for 5 seconds with the park (P) selected [G].
- Idle the engine for 20 seconds or more [H].
- Repeat the steps [F] through [H] 10 times.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [I].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If a permanent DTC is not output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS»(ref-553426-S12385392922013051700000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-553439-S25933161592013051700000) . OK No leaks from the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 6 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 11 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY (THROTTLE VALVE) Check the throttle body assembly condition. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 9 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0505) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0505 is output A DTC is not output B B --> END A --> See step 10
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-553431-S15528202342013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553426-S07103638412013051700000)
| Related DTCs | P050A: Cold start idle air speed control system |
| Required Sensors/Components (Main) | Throttle body assembly |
| Required Sensors/Components (Related) | Mass air flow meter sub-assembly Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR system (closed)) P219A (Air fuel ratio imbalance) |
| Auxiliary battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | Off |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10°C (14°F) or higher, and less than 65°C (149°F) |
| Engine idling time | 0 seconds or more |
| Fuel-cut | Off |
| Vehicle speed | Less than 60 km/h (37.5 mph) |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or higher |
| Accumulated mass air flow | Less than 57.5 g (varies with engine coolant temperature) |
- Start the engine and warm it up for 5 minutes or more.
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 65°C (14 to 149°F).
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 27 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas AF Control / Short FT #1 and Long FT #1. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. Standard Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY (THROTTLE VALVE) Check that there are no deposits around the throttle valve and throttle valve condition. OK No deposits around the throttle valve and throttle valve moves smoothly. NG --> See step 6 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 20 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. OK --> See step 20 NG --> See step 17
- REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-553431-S15528202342013051700000) . NEXT --> See step 19
- CHECK PCV SYSTEM Check the PCV hose connections. Refer to «COMPONENTS»(ref-553426-S12385392922013051700000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> See step 14 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-553439-S25933161592013051700000) . OK No leaks from the intake system. NG --> See step 15 OK: Go to next step
- CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 16 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 12 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 17 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Operate the VVT system through the Active test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 Inspection Procedure. Refer to «PROCEDURE - Step 2»(ref-553435-S38772913542013051700000) . NG --> See step 18 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF). Refer to «PROCEDURE - Step 6»(ref-553435-S36252050592013051700000) OK --> See step 20 NG --> See step 21
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV valve or hose. NEXT --> See step 19
- REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 19
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 19
- REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . NEXT --> See step 19
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. HINT: Refer to DTC P0011 Inspection Procedure. Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1)»(ref-553435-S15127919302013051700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 65°C (14 and 149°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 21 A --> END
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 65°C (14 and 149°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 21 A --> See step 28
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-553290-S25504548052013051700000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 65°C (14 and 149°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM). Refer to «PROCEDURE - Step 3»(ref-553435-S19650573052013051700000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-553431-S27742479932013051700000) . HINT: If the results of the inspections performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 65°C (14 and 149°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 26 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
| Related DTCs | P050B: Cold start ignition timing performance |
| Required Sensors/Components (Main) | Throttle body assembly |
| Required Sensors/Components (Related) | Mass air flow meter sub-assembly Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR system (closed)) P219A (Air fuel ratio imbalance) |
| Auxiliary battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | Off |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10°C (14°F) or higher, and less than 50°C (122°F) |
| Engine idling time | 0 seconds or more |
| Fuel-cut | Off |
| Vehicle speed | Less than 60 km/h (37.2 mph) |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or higher |
| Accumulated time when ignition timing retard is cut off | 8 seconds or more |
- Start the engine and warm it up for 5 minutes or more.
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 26 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas AF Control / Short FT #1 and Long FT #1. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. Standard Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY (THROTTLE VALVE) Check that there are no deposits around the throttle valve and throttle valve condition. OK No deposits around the throttle valve and throttle valve moves smoothly. NG --> See step 6 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 20 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. OK --> See step 20 NG --> See step 17
- REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-553431-S15528202342013051700000) . NEXT --> See step 19
- CHECK PCV SYSTEM Check the PCV hose connections. Refer to «COMPONENTS»(ref-553426-S12385392922013051700000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> See step 14 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-553439-S25933161592013051700000) . OK No leaks from the intake system. NG --> See step 15 OK: Go to next step
- CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 16 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 12 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 17 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Operate the VVT system through the Active test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 Inspection Procedure. Refer to «PROCEDURE - Step 2»(ref-553435-S38772913542013051700000) . NG --> See step 18 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF). Refer to «PROCEDURE - Step 6»(ref-553435-S36252050592013051700000) OK --> See step 20 NG --> See step 21
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV valve or hose. NEXT --> See step 19
- REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 19
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 19
- REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . NEXT --> See step 19
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. HINT: Refer to DTC P0011 Inspection Procedure. Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1)»(ref-553435-S15127919302013051700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 21 A --> END
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 21 A --> See step 27
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-553290-S25504548052013051700000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM). Refer to «PROCEDURE - Step 3»(ref-553435-S19650573052013051700000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-553431-S27742479932013051700000) . HINT: If the results of the inspections performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 28 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTCs | P0560: ECM system voltage range check |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Both of the following conditions are met | |
| Auxiliary battery voltage | Less than 3.5 V |
| Stand-by RAM | Initialized |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 392
Scheme 392: WIRING DIAGRAM
| Related DTCs | P0604: ECM RAM error |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 6 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTC | P0606: ECM/PCM processor performance |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Auxiliary battery voltage | 8 V or higher |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | 0.5 seconds or more |
| Either of the following conditions is met | A or B |
| A. DMA communication | No response |
| B. Watchdog from monitoring processor | Not toggle |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 1 second or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTCs | P0607: Control module performance |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | Heated oxygen sensor |
| Frequency of Operation | Continuous |
| Duration | 60 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Engine | Running |
| Estimated heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) |
| Heated oxygen sensor transistors | Fail |
Scheme 393
Scheme 393: CONFIRMATION DRIVING PATTERN
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on [B].
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [C].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and wait 2 minutes [D].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
- Idle the engine for 1 minute [F].
- Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [I].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [I] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P060A: Internal control module monitoring processor performance |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Either of the following conditions is met | 1 or 2 |
| 1. All of the following conditions are met | |
| CPU reset | 1 time or more |
| Throttle position sensor voltage - Learned throttle position sensor closed position voltage | 2.6 V or higher |
| Electronic throttle actuator | Off |
| 2. CPU reset | 2 times or more |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTCs | P060B: Internal control module A/D processing performance |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 times: Case 1 30 times: Case 2 and 3 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Auxiliary battery voltage | 8 V or higher |
| Knock control sensor circuit | Fail |
| Knock control sensor serial communication | Fail |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328 are output C B --> See step 3 C --> See step 4 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- GO TO DTC P0327, P0328. Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-553436-S36900986262013051700000)
| Related DTCs | P060E: Internal control module and throttle position performance |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second: Case 1 13 times: Case 2 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Monitor runs whenever the following DTCs are not stored | None |
| DMA communication error | Not detected |
| Difference of main throttle position and sub throttle position | 0.3 V or higher |
| Stop light switch signal (CPU) and stop light switch signal (Monitor IC) | Different |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTCs | P062F: Internal control module EEPROM functional |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 3 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Time after power switch on (READY) | 10 seconds or more |
| Auxiliary battery voltage | 8 V or higher |
| Power switch | On (IG) |
| Permanent fault code data | Mismatch (3 times or more) |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and wait 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P062F is output B B --> See step 2 A --> See step 3
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
| Related DTCs | P0630: VIN not programmed |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Both of the following conditions are met | |
| Auxiliary battery voltage | 8 V or higher |
| Power switch | On (IG) |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0630) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0630 is output A DTC P0630 and other DTCs are output B NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. HINT: If any DTCs other than P0630 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INPUT VIN Input the VIN. Refer to «REGISTRATION»(ref-553305-S18447824122013051700000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
| Related DTCs | P0657: Electronic throttle actuator supply voltage circuit range check |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | Throttle actuator |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Both of the following conditions are met | |
| Power switch | On (IG) to off |
| Electronic throttle actuator power supply voltage | 7 V or higher |
| Both of the following conditions are met | |
| Last trip condition | Met |
| Electronic throttle actuator power supply | On |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the Techstream off.
- Turn the power switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) auxiliary battery terminal.
- Turn the power switch on (IG).
- Wait 10 seconds or more.
- Turn the power switch off.
- Wait 15 seconds or more.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0657) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Turn the power switch on (IG). Wait 10 seconds or more. Turn the power switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTCs | P106A: Absolute pressure sensor rationality |
| Required Sensors/Components (Main) | Canister pressure sensor Manifold absolute pressure sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 65 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0106, P0107, P0108 (Manifold absolute pressure) P0401 (EGR system (closed)) P0452, P0453 (Evaporative emission system pressure sensor) |
| Time elapsed after engine stop | 50 minutes |
| Time after ECM started by soak-timer | 60 seconds or more |
| Auxiliary battery voltage | 10.5 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature sensor | 10°C (14°F) or higher |
| Difference between EVAP pressure and manifold absolute pressure | Higher than 7.442 kPa(gauge) [55.672 mmHg(gauge)] |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) [A].
- Start the engine and Idle for 10 seconds.
- Turn the power switch off.
- Leave the power switch off for 55 minutes [B].
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P106A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P106A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P106A is output A DTC P106A and other DTCs are output B HINT: If any DTCs other than P106A are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- READ VALUE USING TECHSTREAM (VAPOR PRESSURE PUMP AND MAP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Vapor Pressure Pump and MAP. Compare the Vapor Pressure Pump and MAP data from the Data List with day's atmospheric pressure*. HINT: *: Standard atmospheric pressure is 101 kPa(abs) [760 mmHg(abs)]. For every 100 m (328 ft) increase in altitude, pressure drops by 1 kPa (7.5 mmHg). The pressure also varies due to the weather (high atmospheric pressure, low atmospheric pressure). Also, check "Atmosphere Pressure" in the Data List. If you do not know the atmospheric pressure refer to the Vapor Pressure Pump value of other vehicles in the workshop and check the difference in pressure. RESULT Result Proceed to If the Vapor Pressure Pump value differs from the atmospheric pressure by 3.5 kPa(gauge) [26.254 mmHg(gauge)] or higher A If the MAP value differs from the atmospheric pressure by 3.5 kPa(gauge) [26.254 mmHg(gauge)] or higher B B --> See step 4 A: Go to next step
- REPLACE CANISTER Replace the canister. Refer to «REMOVAL»(ref-553426-S04178548692013051700000) . NEXT --> See step 5
- REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL»(ref-553426-S14243589372013051700000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG) and the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Vapor Pressure Pump and MAP. Confirm that the difference between Vapor Pressure Pump and MAP are 3.5 kPa(gauge) [26.25 mmHg(gauge)] or less. NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
| Required Sensors/Components (Main) | Purge VSV and canister pump module |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 kPa(abs) [525 mmHg(abs)] or higher, and less than 111 kPa(abs) [832 mmHg(abs)] |
| Auxiliary battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Power switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Fuel vapor-containment valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions (a) and (b) are met before Key-OFF | |
| (a). Duration that vehicle is being driven | 5 minutes or more |
| (b). Purge flow | Executed |
| Engine coolant temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
| Intake air temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
Key-off Monitor Sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (closed) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
3. VENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the both of the following condition is met | |
| Vacuum introduction time | 15 minutes or less |
| Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (open) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa(gauge) [-15 mmHg(gauge)] or less, or 3 kPa(gauge) [22.5 mmHg(gauge)] or higher |
| 2. Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa(gauge) [-15 to 22.5 mmHg(gauge)] |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when fuel vapor-containment valve closed | 0.35 kPa(gauge) [2.62 mmHg(gauge)] or higher |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | Less than 0.35 kPa(gauge) [2.62 mmHg(gauge)] |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| EVAP pressure when vacuum introductions for canister complete | Between conditions 1 and 2 |
| Condition 1 | Higher than second reference pressure |
| Condition 2 | Lower than [second reference pressure x 0.2] |
| EVAP pressure when vacuum introduction for canister was complete | Higher than [second reference pressure x 0.2] |
Refer to EVAP system. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P1420 or P1421.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components (Main) | Fuel tank and canister pump module |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 20 minutes (varies with the amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 kPa(abs) [525 mmHg(abs)] or higher, and less than 111 kPa(abs) [832 mmHg(abs)] |
| Auxiliary battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Power switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Fuel vapor-containment valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions (a) and (b) are met before Key-OFF | |
| (a). Duration that vehicle is being driven | 5 minutes or more |
| (b). Purge flow | Performed |
| Engine coolant temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
| Intake air temperature | 4.4°C (40°F) or higher, and less than 35°C (95°F) |
Key-off Monitor Sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (closed) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
3. VENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the both of the following condition is met | |
| Vacuum introduction time | 15 minutes or less |
| Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (open) | 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa(gauge) [-15 mmHg(gauge)] or less, or 3 kPa(gauge) [22.5 mmHg(gauge)] or higher |
| 2. Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa(gauge) [-15 to 22.5 mmHg(gauge)] |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa(gauge) [3.75 mmHg(gauge)] or higher |
10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when fuel vapor-containment valve closed | 0.35 kPa(gauge) [2.62 mmHg(gauge)] or higher |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement | 0.25 kPa(gauge) [-1.87 mmHg(gauge)] or less |
| 2. Reference pressure (vary with atmospheric pressure) | 4.75 kPa(gauge) [-35.63 mmHg(gauge)] or higher, and less than -0.957 kPa(gauge) [-7.178 mmHg(gauge)] |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa(gauge) [6.75 mmHg(gauge)] |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while fuel vapor-containment valve and vent valve are open | Less than 0.35 kPa(gauge) [2.62 mmHg(gauge)] |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa(gauge) [2.25 mmHg(gauge)] |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Between conditions 1 and 2 |
| Condition 1 | Higher than third reference pressure |
| Condition 2 | Lower than [third reference pressure x 0.2] |
P1422: FUEL TANK SMALL LEAK
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Higher than [third reference pressure x 0.2] |
P1423: FUEL TANK GROSS LEAK
Refer to EVAP system. Refer to MONITOR RESULT .
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P1422 or P1423.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
