MONITOR STRATEGY
| Related DTCs | P0010: Camshaft timing oil control valve assembly range check |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Starter | Off |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | 0.5 seconds or more |
| Either of the following conditions is met | A or B |
| A. All of the following conditions are met | |
| Auxiliary battery voltage | 11 V or higher, and less than 13 V |
| Target duty cycle | Less than 70% |
| Current cut status | Not cut |
| B. All of the following conditions are met | |
| Auxiliary battery voltage | 13 V or higher |
| Target duty cycle | Less than 80% |
| Current cut status | Not cut |
TYPICAL MALFUNCTION THRESHOLDS
| Camshaft position actuator oil control valve status from MIC | Fail |
COMPONENT OPERATING RANGE
| Camshaft position actuator oil control valve status from MIC | Pass |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 324
Scheme 324: WIRING DIAGRAM
PROCEDURE
- READ OUTPUT DTC (DTC P0010) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTC after recording the freeze frame data and DTC. Turn the power switch off and wait for at least 30 seconds. Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and allow the engine to idle. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0010 is output A DTC is not output B B --> See step 4 A: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION»(ref-553431-S15435274722013051700000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Disconnect the camshaft timing oil control valve assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D25-1 (+) - D28-36 (OC1+) Always Below 1 ohms D25-2 (-) - D28-59 (OC1-) Always Below 1 ohms D25-1 (+) or D28-36 (OC1+) - Body ground Always 10 kohms or higher D25-2 (-) or D28-59 (OC1-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553431-S03614773002013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
| Related DTCs | P0011: Advanced camshaft timing P0012: Retarded camshaft timing |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly Camshaft timing gear assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediately Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010 (Camshaft timing oil control valve assembly) P0016 (VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) |
| Auxiliary battery voltage | 11 V or higher |
| Engine speed | 500 to 4000 rpm |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| All of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
P0011: ADVANCED CAMSHAFT TIMING
| All of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
P0012: RETARDED CAMSHAFT TIMING
- If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the camshaft timing oil control valve assembly for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.
MONITOR RESULT
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $35 | $81 | Multiply by 0.01 | Second | Forced movement of oil control valve time |
P0011, P0012: EXHAUST GAS RECIRCULATION/VVT / IN VVT STUCK B1
Scheme 325
Scheme 325: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). HINT: P0011 is output: Clear the DTC without using the Techstream. P0012 is output: Clear the DTC with using the Techstream.
- Turn the power switch off and wait for 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Accelerate the vehicle to 60 km/h (37 mph) or more by depressing the accelerator pedal for at least 10 seconds [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the engine stops, further depress the accelerator pedal to restart the engine.
- Idle the engine for 30 seconds or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011 or P0012.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
- Accelerate the vehicle to 60 km/h (37 mph) or more by depressing the accelerator pedal for at least 10 seconds [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 30 seconds or more [G].
- Check the DTC judgment result again [H]. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0016: Camshaft timing misalignment at idling |
| Required Sensors/Components (Main) | Camshaft timing gear assembly |
| Required Sensors/Components (Related) | Camshaft position sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 1 minute |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) |
| Engine speed | 900 to 1100 rpm |
| Either of the of following conditions is met | |
| VVT learned value at maximum retarded valve timing | Less than 22°CA (Crankshaft Angle) |
| VVT learned value at maximum retarded valve timing | More than 47°CA (Crankshaft Angle) |
Scheme 326
Scheme 326: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
- Drive the vehicle at 60 km/h (37 mph) for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result again [G]. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0016 is output A DTC P0016 and other DTCs are output B HINT: If any DTCs other than P0016 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up the engine coolant temperature reaches 75°C (167°F) or higher. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) / Gas Valve Control / VVT Change Angle #1. Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. HINT: Test not possible with park (P) selected during charge control. Move the shift lever to N to perform test. If the DTCs are stored after the Active Test, clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . NG --> See step 4 OK: Go to next step
- ADJUST VALVE TIMING Adjust the valve timing. Refer to «DISASSEMBLY»(ref-553433-S01924237192013051700000) . NEXT --> See step 7
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY See step 2 NG --> See step 9 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER See step 6 NG --> See step 11 OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly. Refer to «REMOVAL»(ref-553433-S39395898102013051700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P0016 is output B B --> See step 8 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553431-S03614773002013051700000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY - Step 41»(ref-553433-S31804077582013051700000)
| Related DTCs | P0031: Air fuel ratio sensor heater range check (low current) P0032: Air fuel ratio sensor heater range check (high current) P101D: Air fuel ratio sensor heater performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second: P101D 10 seconds: P0031 10.24 seconds: P0032 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Air fuel ratio sensor heater performance fail (P101D) | Not detected |
| Output duty cycle | 30% or higher |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Output duty cycle | Higher than 0% |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Air fuel ratio sensor heater high current counter | 1.024 seconds or more |
| Active heater off control counter for high current | 0.512 seconds or more |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Air fuel ratio sensor heater low current fail (P0031) | Not detected |
| Active heater off control for on stuck | Operating |
| Output duty cycle | 10% or higher, and less than 60% |
| Heater on current | 0.8 A or higher |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Heater on current | Less than 0.8 A |
| Both of the following conditions are met | |
| Heater output | On |
| Hybrid IC high current limiter monitor input | Fail |
| All of the following conditions are met | |
| Hybrid IC high current limiter monitor input | Fail |
| Heater off current | Higher than 11 A |
| Heater on current | 0.8 A or higher |
| Both of the following conditions are met | |
| Heater output | On |
| Hybrid IC high current limiter monitor input | Pass |
| Heater off current | 11 A or less |
Scheme 327
Scheme 327: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 2500 rpm for 1 minute [C]. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, perform steps [C] and [D] after charging control has completed.
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031, P0032 or P101D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 328
Scheme 328: WIRING DIAGRAM
| Related DTCs | P0037: Heated oxygen sensor (sensor 2) heater range check (low current) P0038: Heated oxygen sensor (sensor 2) heater range check (high current) P0141: Heated oxygen sensor (sensor 2) heater performance P102D: Heated oxygen sensor (sensor 2) heater performance |
| Required Sensors/Components (Main) | Heated oxygen sensor (sensor 2) heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous: P0037, P0038, P102D Once per driving cycle: P0141 |
| Duration | 0.5 seconds: P0037, P102D 2.064 seconds: P0038 10 seconds: P0141 |
| MIL Operation | Immediate: P0037, P0038, P102D 2 driving cycles: P0141 |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Learned heater off current operation | Succeeded |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Heater on current - Learned heater off current | 0.3 A or less |
| Heater output | On |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Heater off current | Higher than 3.5 A |
| Hybrid IC high current limiter monitor input | Fail |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Hybrid IC high current limiter monitor input | Fail |
| Heater output | On |
| All of the following conditions are met | |
| Heated oxygen sensor heater circuit fail (P0037, P0038, P102D) | Not detected |
| Auxiliary battery voltage | 10.5 V or higher |
| Fuel cut | Off |
| Time after fuel cut on to off | 30 seconds or more |
| Accumulated heater on time | 100 seconds or more |
| Learned heater off current operation | Completed |
| Duration that heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Heated oxygen sensor heater low current fail (P0037) | Not detected |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Heater output | Off |
| Heater off current | Higher than 3.5 A |
| Hybrid IC high current limiter monitor input | Fail |
| Heater on current - Learned heater off current | 0.3 A or less |
| Heater on current | 1 A or less |
| Both of the following conditions are met | |
| Hybrid IC high current limiter monitor input | Fail |
| Heater output | On |
| Heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heater on current | Higher than 1 A |
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $42 | $91 | Multiply by 0.001 | Ohm | Oxygen sensor heater resistance bank 1 sensor 2 |
P0141: O2 SENSOR HEATER / O2 HEATER B1S2
Scheme 329
Scheme 329: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 2500 rpm for 1 minute [C]. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, perform steps [C] and [D] after charging control has completed.
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0141 or P102D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 330
Scheme 330: WIRING DIAGRAM
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Throttle position voltage | 0.2 V or higher, and less than 2 V |
| Time after engine start | 5 seconds or more |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine coolant temperature | 70°C (158°F) or higher |
| Estimated load | 30% or higher, and less than 70% |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Crankshaft position sensor circuit fail (P0335) | Not detected |
| Throttle position sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| EVAP system pressure sensor circuit fail (P0452, P0453) | Not detected |
| Leak detection pump fail (P2401, P2402) | Not detected |
| EVAP vent valve fail (P2419, P2420) | Not detected |
| Both of the following conditions are met | |
| Average engine load value ratio | Less than 0.83, or higher than 1.15 (varies with estimated engine load) |
| Average air fuel ratio | Less than -20%, or higher than 20% |
Scheme 331
Scheme 331: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-553439-S25933161592013051700000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS»(ref-553426-S12385392922013051700000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 6 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 9 OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-553431-S27742479932013051700000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0101. Check the DTC judgment. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553426-S07103638412013051700000)
| Related DTCs | P0102: Mass air flow meter range check (low voltage) P0103: Mass air flow meter range check (high voltage) |
| Required Sensors/Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 rpm 2 driving cycles: Engine speed 4000 rpm or higher |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Command to stop mass air flow meter power supply voltage | Off |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | Higher than 4.9 V |
| Mass air flow meter voltage | 0.2 to 4.9 V |
Scheme 332
Scheme 332: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- During normal driving, increase the vehicle speed to 80 km/h (50 mph) [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Depress the accelerator pedal fully to increase the vehicle speed to between 100 and 120 km/h (62 and 75 mph) (engine speed of 4000 rpm or more) and then maintain the speed for at least 5 seconds [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 333
Scheme 333: WIRING DIAGRAM
| Related DTCs | P0106: Manifold absolute pressure sensor stuck |
| Required Sensors/Components (Main) | Manifold absolute pressure sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 6 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0107, P0108 (Manifold absolute pressure) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0401 (EGR system (closed)) P106A (Evaporative emission control system pressure sensor - Manifold pressure sensor correlation) |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine coolant temperature | 30°C (86°F) or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine speed | 1000 rpm or more |
| Throttle valve | Close |
| EGR valve | Close |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or higher |
| Difference between manifold absolute pressure and atmospheric pressure | Higher than -3 kPa(gauge) [-22.5 mmHg(gauge)] |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher).
- Move the shift lever to N.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0106.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTC OUTPUT (IN ADDITION TO DTC P0106) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0106 is output A DTC P0106 and other DTCs are output B HINT: If any DTCs other than P0106 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- READ VALUE USING TECHSTREAM (MAP) Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAP. Read the MAP value at power switch on (IG). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up. Read the MAP value at idling. Standard Engine condition Techstream Display Power switch on (IG) 80 to 110 kPa(abs) [600 or 825 mmHg(abs)] Idling 28 to 48 kPa(abs) [210 to 360 mmHg(abs)] NG --> See step 3 OK --> See step 4
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-553439-S25933161592013051700000) . OK No leaks in the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK --> See step 5
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR. Refer to «REMOVAL»(ref-553426-S14243589372013051700000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
| Related DTCs | P0107: Manifold absolute pressure sensor range check (low voltage) P0108: Manifold absolute pressure sensor range check (high voltage) |
| Required Sensors/Components (Main) | Manifold absolute pressure sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Auxiliary battery voltage | 8 V or higher |
| Power switch | On (IG) |
| Time after power switch off to on (IG) | More than 0.5 seconds |
| Manifold absolute pressure sensor voltage | Less than 0.5 V |
| Manifold absolute pressure sensor voltage | Higher than 4.5 V |
| Manifold absolute pressure sensor voltage | 0.5 to 4.5 V |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0107 or P0108.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 334
Scheme 334: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (after engine stop) P0111: Intake air temperature sensor rationality (after cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Time after hybrid system READY-on | 10 seconds or more |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine coolant temperature at ECM started by internal engine off timer | 40°C (-40°F) or higher |
| Engine coolant temperature before hybrid system stop | 70°C (158°F) or higher |
| Time that mass air flow is low before engine stop | 90 seconds or more |
| Accumulated mass air flow amount before engine stop | 2578 g or more |
| Key-off duration | 30 minutes |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine water pump circuit fail (P261B, P261C, P261D) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| All of the following conditions are met | |
| Key-off duration | 5 hours or more |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature | 70°C (158°F) or higher |
| Accumulated mass air flow amount | 2578 g or more |
| Either of the following conditions is met | 1 or 2 |
| 1. Duration while engine load is low | 90 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine water pump circuit fail (P261B, P261C, P261D) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Intake air temperature change | Less than 1°C (1.8°F) |
| Intake air temperature change | Less than 1°C (1.8°F) |
Scheme 335
Scheme 335: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-553431-S27742479932013051700000)
| Related DTCs | P0112: Intake air temperature sensor range check (low voltage) P0113: Intake air temperature sensor range check (high voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Both of the following conditions are met | |
| Auxiliary battery voltage | 8 V or higher |
| Power switch | On (IG) |
| Intake air temperature sensor voltage [Intake air temperature] | Less than 0.18 V [Higher than 128°C (262°F)] |
| Intake air temperature sensor voltage [Intake air temperature] | Higher than 4.91 V [Less than -55°C (-67°F)] |
| Intake air temperature sensor voltage [Intake air temperature] | 0.18 to 4.91 V [-55 to 128°C (-67 to 262°F)] |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 336
Scheme 336: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (chattering) P0117: Engine coolant temperature sensor range check (low voltage) P0118: Engine coolant temperature sensor range check (high voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | Less than 0.14 V, or higher than 4.91 V [Higher than 135°C (275°F), or less than -60°C (-76°F)] |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | Less than 0.14 V [Higher than 135°C (275°F)] |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | Higher than 4.91 V [Less than -60°C (-76°F)] |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | 0.14 to 4.91 V [-60 to 135°C (-76 to 275°F)] |
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 337
Scheme 337: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor rationality (cold start monitor) P0116: Engine coolant temperature sensor rationality (soak monitor) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Less than 60°C (140°F) |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 2219 g or more |
| Fuel cut | Off |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Engine water pump circuit fail (P261B, P261C, P261D) | Not detected |
| Thermostat fail (P0128) | Not detected |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
| All of the following conditions are met | |
| Auxiliary battery voltage | 10.5 V or higher |
| Engine | Running |
| Soak time | 5 hours or more |
| Either of the following condition is met | 1 or 2 |
| 1. Engine coolant temperature | 60°C (140°F) or higher |
| 2. Accumulated mass air flow | 3438 g or more |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Engine water pump circuit fail (P261B, P261C, P261D) | Not detected |
| Thermostat fail (P0128) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) (varies with engine coolant temperature of last trip engine stop) |
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 338
Scheme 338: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
- Check that the engine coolant temperature is 60°C (140°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT WATER INLET WITH THERMOSTAT SUB-ASSEMBLY Inspect the water inlet with thermostat sub-assembly (thermostat operating temperature). Refer to «INSPECTION»(ref-553423-S26445290502013051700000) . NG --> See step 5 OK --> See step 3
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-553431-S10081364622013051700000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE WATER INLET WITH THERMOSTAT SUB-ASSEMBLY. Refer to «REMOVAL»(ref-553423-S24613733272013051700000)
| Related DTCs | P011B: Engine coolant temperature/intake air temperature sensor correlation |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Soak Time | 7 hours or more |
| Auxiliary battery voltage | 10.5 V or higher |
| Time after engine start | 15 seconds or more |
| Either of the following conditions is met | (a) or (b) |
| (a) Intake air temperature after engine start | 10°C (14°F) or higher |
| (b) Engine coolant temperature before engine start | 10°C (14°F) or higher |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Engine water pump circuit fail (P261B, P261C, P261D) | Not detected |
| Engine water pump operation counter | 15 seconds or more |
| Deviated engine coolant temperature and intake air temperature | Less than -25°C (-45°F), or higher than 25°C (45°F) |
Scheme 339
Scheme 339: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure) [A].
- Turn the power switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P011B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to create conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air. Read the value displayed on the Techstream. Standard Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the outside temperature gauge of the vehicle (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent swings in the temperature display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Read the value displayed on the Techstream. Standard The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are no heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-553431-S27742479932013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-553431-S10081364622013051700000)
| Related DTCs | P0120: Throttle position sensor 1 range check (chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (low voltage) P0123: Throttle position sensor 1 range check (high voltage) P0220: Throttle position sensor 2 range check (chattering) P0222: Throttle position sensor 2 range check (low voltage) P0223: Throttle position sensor 2 range check (high voltage) P2135: Throttle position sensor range check (correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 (Case 1) 0.4 seconds: P2135 (Case 2) |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Either of the following conditions is met | A or B |
| A. Power switch on (IG) | 0.012 seconds or more |
| B. Electronic throttle actuator power | On |
P0120, P0122, P0123, P0220, P0222, P0223 AND P2135
| Both of the following conditions are met | |
| Either of the following conditions is met | A or B |
| A. Power switch | On (IG) |
| B. Electric throttle actuator power | On |
| Throttle position sensor circuit fail (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.54 V or higher |
| Either of the following conditions is met | A or B |
| A. Difference of learned throttle position sensor opener position voltage between VTA2 and VTA1 | Higher than 1.6 V |
| B. Difference of learned throttle position sensor opener position voltage between VTA2 and VTA1 | Less than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or higher |
| Either of following conditions met | A or B |
| A. VTA2 voltage | 1.75 V or less |
| B. VTA2 voltage when VTA1 0.2 to 2.02 V | 4.8 V or higher |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 to 2.02 V | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| Both of the following conditions are met | |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | Higher than 0.2 V, and less than 4.54 V |
| VTA2 voltage | Higher than 1.75 V, and less than 4.8 V |
Scheme 340
Scheme 340: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM stops the engine and the vehicle can be driver using solely the hybrid system. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the power switch is then turned off.
Scheme 341
Scheme 341: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed loop fuel control |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Thermostat Cooling system |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 87 seconds: Engine coolant temperature at engine start -3.33°C (26°F) or higher 186 seconds: Engine coolant temperature at engine start -14.44°C (6°F) or higher, and less than -3.33°C (26°F) 1200 seconds: Engine coolant temperature at engine start less than -14.44°C (6°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Thermostat fail (P0128) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0101, P0102, P0103) | Not detected |
| Time until actual engine coolant temperature reaches closed loop fuel control enabling temperature | 87 seconds: Engine coolant temperature at engine start -3.33°C (26°F) or higher 186 seconds: Engine coolant temperature at engine start -14.44°C (6°F) or higher, and less than -3.33°C (26°F) 1200 seconds: Engine coolant temperature at engine start less than -14.44°C (6°F) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
- Check that the engine coolant temperature is 10°C (50°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine.
- Wait 21 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT WATER INLET WITH THERMOSTAT SUB-ASSEMBLY Inspect the thermostat opening temperature. Refer to «INSPECTION»(ref-553423-S26445290502013051700000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE WATER INLET WITH THERMOSTAT SUB-ASSEMBLY. Refer to «REMOVAL»(ref-553423-S24613733272013051700000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-553431-S10081364622013051700000)
| Related DTCs | P0128: Coolant thermostat |
| Required Sensors/Components (Main) | Thermostat Engine coolant temperature sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 600 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0031, P0032, P0101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR system (closed)) P219A (Air fuel ratio imbalance) |
| Auxiliary battery voltage | 11 V or higher |
| Either of the following conditions is met | 1 or 2 |
| 1. All of the following conditions are met | |
| Engine coolant temperature at engine start - Intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of the following conditions are met | |
| Engine coolant temperature at engine start - Intake air temperature at engine start | Higher than 7°C (12.6°F) |
| Engine coolant temperature at engine start | 56°C (133°F) or less |
| Intake air temperature at engine start | 10°C (14°F) or higher |
| Accumulated time at vehicle speed of 128 km/h (80 mph) or more | Less than 20 seconds |
| Duration that both of following conditions met | 5 seconds or more |
| (a) Estimated engine coolant temperature | 75°C (167°F) or higher |
| (b) Engine coolant temperature sensor output | Less than 75°C (167°F) |
Scheme 342
Scheme 342: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is less than 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT FRONT EXHAUST PIPE ASSEMBLY Inspect the front exhaust pipe assembly (exhaust flow control valve operation. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-553442-S14678320192013051700000) . NG --> See step 8 OK: Go to next step
- INSPECT WATER INLET WITH THERMOSTAT SUB-ASSEMBLY Inspect the thermostat opening temperature. Refer to «INSPECTION»(ref-553423-S26445290502013051700000) . NG --> See step 6 OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE WATER INLET WITH THERMOSTAT SUB-ASSEMBLY. Refer to «REMOVAL»(ref-553423-S24613733272013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- REPLACE FRONT EXHAUST PIPE ASSEMBLY. Refer to «REMOVAL»(ref-553443-S31781427932013051700000)
| Related DTCs | P0136: Heated oxygen sensor voltage check (voltage malfunction) P0136: Heated oxygen sensor circuit continuity check (circuit short) P0137: Heated oxygen sensor voltage check (low voltage) P0137: Heated oxygen sensor circuit continuity check (circuit open) P0138: Heated oxygen sensor circuit continuity check (out of range) P0139: Heated oxygen sensor response rate during fuel cut |
| Required Sensors/Components (Main) | Heated oxygen sensor (sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter sub-assembly Throttle position sensor Air fuel ratio sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection, heated oxygen sensor abnormal voltage during fuel cut. Continuous: Other |
| Duration | 20 seconds: Heated oxygen sensor voltage check (voltage malfunction, low voltage) 30 seconds: Heated oxygen sensor circuit continuity check (circuit short) 90 seconds: Heated oxygen sensor circuit continuity check (circuit open) 10 seconds: Heated oxygen sensor circuit continuity check (out of range) 6 seconds: Heated oxygen sensor response rate during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0016 (VVT system - misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0037, P0038, P102D (Heated oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0128 (Thermostat) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0401 (EGR system (closed)) P0451, P0452, P0453, P1451, P1452, P1453 (EVAP system) P219A (Air fuel ratio imbalance) |
| Auxiliary battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or higher |
| Idling | Off |
| Engine speed | Less than 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10% or higher, and less than 70% |
P0136 AND P0137: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION AND LOW VOLTAGE)
| Auxiliary battery voltage | 11 V or higher |
| Estimated heated oxygen sensor temperature | Less than 700°C (1292°F) |
| ECM monitor | Completed |
| DTC P0607 | Not set |
P0136: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)
| Auxiliary battery voltage | 11 V or higher |
| Estimated heated oxygen sensor temperature | 450°C (842°F) or higher, and less than 750°C (1382°F) |
| DTC P0607 | Not set |
P0137: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)
| Auxiliary battery voltage | 11 V or higher |
| Time after engine start | 2 seconds or more |
P0138: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)
| Engine coolant temperature | 75°C (167°F) or higher |
| Catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | On |
P0139: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT
| All of the following conditions (a), (b) and (c) met | |
| (a) OSC (Oxygen Storage Capacity) of Catalyst | 2.1 g or more |
| (b) Commanded air fuel ratio | 14.3 or less |
| (c) Heated oxygen sensor voltage | 0.21 V or higher, and less than 0.59 V |
P0136: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION)
| All of the following conditions (a), (b) and (c) met | |
| (a) OSC (Oxygen Storage Capacity) of Catalyst | 2.1 g or more |
| (b) Commanded air fuel ratio | 14.3 or less |
| (c) Heated oxygen sensor voltage | Less than 0.21 V |
P0137: HEATED OXYGEN SENSOR VOLTAGE CHECK (LOW VOLTAGE)
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor impedance | Less than 5 ohms |
P0136: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)
| Duration of following condition | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or higher |
P0137: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)
| Duration of following condition | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
P0138: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)
| Either of the following conditions is met | |
| Duration until heated oxygen sensor voltage drops to 0.2 V after fuel cut | 6 seconds or more |
| Duration until heated oxygen sensor voltage drops from 0.35 to 0.2 V during fuel cut | 1 second or more |
P0139: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $02 | $08 | Multiply by 0.001 | V | Maximum sensor voltage |
P0137: O2 SENSOR / MAX VOL B1S2
| Monitor ID | Test ID | Scaling | Unit | Description |
| $02 | $8B | Multiply by 0.001 | Seconds | 0.35 - 0.2 V sensor switch time |
P0139: O2 SENSOR / RL F/C B1S2
| Monitor ID | Test ID | Scaling | Unit | Description |
| $02 | $8D | Multiply by 0.001 | Seconds | Duration that sensor voltage drops to 0.2 V during fuel-cut |
P0139: O2 SENSOR / F/C TIME B1S2
| Monitor ID | Test ID | Scaling | Unit | Description |
| $02 | $8F | Multiply by 0.0003 | G | Maximum oxygen storage capacity |
P0136: O2 SENSOR / MAX OSC B1S2
- This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
- Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (The catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.
Scheme 343
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the shift lever in D, drive the vehicle at 75 to 120 km/h (47 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 344
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 75 km/h (47 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, drive the vehicle with the shift lever in B position, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P014C: Air fuel ratio sensor (sensor 1) response rate (rich to lean response rate) P014D: Air fuel ratio sensor (sensor 1) response rate (lean to rich response rate) P015A: Air fuel ratio sensor (sensor 1) response rate (rich to lean delay) P015B: Air fuel ratio sensor (sensor 1) response rate (lean to rich delay) |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when the following conditions are met | |
| Auxiliary battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idle | Off |
| Engine speed | 1000 rpm or higher, and less than 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | Off |
| Engine load | 10% or higher, and less than 70% |
| Catalyst monitor | Not yet |
| Mass air flow | 6 g/sec or more, and less than 15 g/sec |
| Rich to Lean Response rate deterioration level | 0.037 V or less |
P014C: AIR FUEL RATIO SENSOR RESPONSE RATE (RICH TO LEAN RESPONSE RATE)
| Lean to Rich Response rate deterioration level | 0.04 V or higher |
P014D: AIR FUEL RATIO SENSOR RESPONSE RATE (LEAN TO RICH RESPONSE RATE)
| Rich to Lean delay level | 345 msec or more |
P015A: AIR FUEL RATIO SENSOR RESPONSE RATE (RICH TO LEAN DELAY)
| Lean to Rich delay level | 345 msec or more |
P015B: AIR FUEL RATIO SENSOR RESPONSE RATE (LEAN TO RICH DELAY)
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $01 | $93 | Multiply by 0.00012 | V | Rich to Lean response rate deterioration level |
P014C: O2 SENSOR / RL RES RATE B1S1
| Monitor ID | Test ID | Scaling | Unit | Description |
| $01 | $94 | Multiply by 0.00012 | V | Lean to Rich response rate deterioration level |
P014D: O2 SENSOR / LR RES RATE B1S1
| Monitor ID | Test ID | Scaling | Unit | Description |
| $01 | $95 | Multiply by 0.001 | Second | Rich to Lean delay level |
P015A: O2 SENSOR / RL DELAY B1S1
| Monitor ID | Test ID | Scaling | Unit | Description |
| $01 | $96 | Multiply by 0.001 | Second | Lean to Rich delay level |
P015B: O2 SENSOR / LR DELAY B1S1
Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.
Scheme 345
Scheme 345: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on.
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that O2 Sensor / Current is Incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1 and LR DELAY B1S1 do not exist in the Detail of O2 Sensor monitor at this time (the initial value of "0.000" is indicated in each test item).
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check that O2 Sensor / Current becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1 and LR DELAY B1S1.
- If the monitor item O2 Sensor / Current does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-553305-S41780263202013051700000) .
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P014C, P014D, P015A or P015B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result is INCOMPLETE or N/A, drive the vehicle again under an increased load and then recheck the judgment result.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P015A OR P015B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P015A or P015B is output A DTC P014C, P014D, P015A or P015B and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P015A or P015B are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 11 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 1»(ref-553432-S11904137722013051700000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 14 OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P015A OR P015B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC P014C, P014D, P015A or P015B are output A DTC is not output B B --> See step 12 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-553431-S07823217142013051700000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P015A OR P015B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P015A or P015B are output B B --> See step 13 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-553431-S07823217142013051700000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-553305-S14896367972013051700000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1)»(ref-553435-S26925324782013051700000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-553431-S07823217142013051700000)
| Related DTCs | P0171: Fuel trim lean P0172: Fuel trim rich |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter sub-assembly Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0010 (VVT oil control valve) P0011 (VVT system - advance) P0012 (VVT system - retard) P0016 (VVT system - misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) P0401 (EGR system (Closed)) P219A (Air fuel ratio imbalance) |
| Fuel system status | Closed loop |
| Auxiliary battery voltage | 11 V or higher |
| Either of the following conditions is met | 1 or 2 |
| 1. Engine speed | Less than 1100 rpm |
| 2. Intake air amount per revolution | 0.12 g/rev or more |
| Catalyst monitor | Not executed |
| Purge-cut | Executing |
| Either of the following conditions is met | 1 or 2 |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or higher (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 346
Scheme 346: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the power switch off and wait for at least 30 seconds.
- Turn the power switch on (IG) and turn the Techstream on [A].
- Press the EV/HV mode selection switch to select HV mode.
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 5 minutes or more [C].
- Drive the vehicle at a speed between 75 and 120 km/h (47 and 75 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0171 or P0172 is output A DTC P0171 or P0172 and other DTCs are output B HINT: If any DTCs other than P0171 or P0172 are output, troubleshoot those DTCs first. B --> See step 23 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS»(ref-553426-S12385392922013051700000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-553439-S25933161592013051700000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine. Warm up the engine and run the engine at an engine speed of 2500 rpm for approximately 90 seconds. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, warm up the engine after charging control has completed. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Perform the Control the Injection Volume for A/F Sensor operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and the heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by -12.5% or increases the injection volume by 12.5%. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) 12.5% Rich Below 3.1 V -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) 12.5% Rich Higher than 0.55 V -12.5% Lean Below 0.4 V RESULT Status AFS Voltage B1S1 Status O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - A Lean Lean Actual air fuel ratio lean PCV valve and hose PCV hose connections Fuel injector assembly blockage Gas leak from exhaust system Intake system Fuel pressure Mass air flow meter sub-assembly Engine coolant temperature sensor EGR valve assembly A Rich Rich Actual air fuel ratio rich Fuel injector assembly leak or blockage Gas leak from exhaust system Ignition system Fuel pressure Mass air flow meter sub-assembly Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor EGR valve assembly B Rich Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor B Lean: During Control the Injection Volume for A/F Sensor, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS Voltage B1S1 is consistently below 3.1 V, and the O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the air fuel ratio sensor and the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-553305-S02986196612013051700000) . B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Read the Data List twice, when the engine is both cold and warmed up. Standard Techstream Display Condition Specified Condition Coolant Temp Cold engine Same as ambient air temperature Warm engine Between 80 and 100°C (176 and 212°F) NG --> See step 24 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAF, Coolant Temp and Engine Speed. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 2500 rpm. HINT: During charging control, the engine speed is set at idle. Therefore, the engine speed does not increase when depressing the accelerator pedal. In this case, read the Data List after charging control has completed. Standard Techstream Display Condition Specified Condition MAF Shift lever position: P A/C: Off Engine Speed: 2500 rpm Between 4.5 gm/sec and 8.5 gm/sec NG --> See step 18 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-553434-S00186218912013051700000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-553424-S41937506812013051700000) . HINT: If the result of the spark test is normal, proceed to the next step. If the spark plugs or ignition system malfunctions, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Misfire / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). NEXT: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Check the injection and volume. HINT: Refer to the fuel injector assembly inspection procedure. Refer to «INSPECTION»(ref-553438-S09714085492013051700000) . If the fuel injector assembly malfunction, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Misfire / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). OK --> See step 15 NG --> See step 25
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 26 OK: Go to next step
- CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) See step 2 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 1»(ref-553432-S11904137722013051700000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-553431-S07823217142013051700000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Data List / Primary / Throttle Idle Position and MAP. Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in the EGR valve. RESULT Result Proceed to Outside of standard range A Within standard range B B --> See step 18 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-553426-S07103638412013051700000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 28 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-553290-S25504548052013051700000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-553431-S27742479932013051700000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553305-S22976237422013051700000) . Turn the power off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0171 or P0172 is output B B --> See step 27 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-553305-S14271064972013051700000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-553431-S10081364622013051700000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-553438-S38272280762013051700000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-553431-S07823217142013051700000)
- REPLACE ECM. Refer to «REMOVAL»(ref-553431-S24148051042013051700000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-553426-S07103638412013051700000)
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor Camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature sensor Intake air temperature sensor Mass air flow meter sub-assembly |
| Frequency of Operation | Continuous |
| Duration | 1000 crankshaft revolutions (soon after engine is started: 1 time, other 4 times) (Emissions related misfire) 200 crankshaft revolutions (1 or 3 times) (Catalyst damaging misfire) |
| MIL Operation | 2 driving cycles: Emission related misfire MIL flashes immediately: Catalyst damaging misfire |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0016 (VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0327, P0328 (Knock control sensor) P0335 (Crankshaft position sensor) P0340, P0342, P0343 (Camshaft position sensor) P0351, P0352, P0353, P0354 (Igniter) |
| Auxiliary Battery voltage | 8 V or higher |
| VVT system | Not operated by scan tool |
| Engine speed | 850 to 5500 rpm |
| Either of the following conditions (a) or (b) is met | |
| (a) Engine coolant temperature at engine start | Higher than -7°C (19°F) |
| (b) Engine coolant temperature | Higher than 20°C (68°F) |
| Fuel cut | Off |
| First 1000 revolutions after engine start, or check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| All of the following conditions 1, 2, 3 and 4 are met | Crankshaft 200 revolutions x 3 |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 3000 rpm |
| 4. Intake air amount per revolution | Less than 0.65 g/rev |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| Number of misfire per 200 revolutions | 130 or more (varies with intake air amount per rpm) |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A1 | $0B | Multiply by 1 | Time | Total EWMA* misfire count of all cylinders in last ten driving cycles |
P0300: MISFIRE / EWMA MISFIRE
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A1 | $0C | Multiply by 1 | Time | When power switch on (IG), total misfire count of all cylinders in last driving cycle is displayed. While engine is running, total misfire count of all cylinders in current driving cycle is displayed. |
P0300: MISFIRE / MISFIRE RATE
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A2 | $0B | Multiply by 1 | Time | Total EWMA* misfire count of cylinder 1 in last ten driving cycles |
P0301: MISFIRE / EWMA MISFIRE1
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A2 | $0C | Multiply by 1 | Time | When power switch on (IG), total misfire count of cylinder 1 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 1 in current driving cycle is displayed. |
P0301: MISFIRE / MISFIRE RATE1
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A3 | $0B | Multiply by 1 | Time | Total EWMA* misfire count of cylinder 2 in last ten driving cycles |
P0302: MISFIRE / EWMA MISFIRE2
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A3 | $0C | Multiply by 1 | Time | When power switch on (IG), total misfire count of cylinder 2 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 2 in current driving cycle is displayed. |
P0302: MISFIRE / MISFIRE RATE2
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A4 | $0B | Multiply by 1 | Time | Total EWMA* misfire count of cylinder 3 in last ten driving cycles |
P0303: MISFIRE / EWMA MISFIRE3
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A4 | $0C | Multiply by 1 | Time | When power switch on (IG), total misfire count of cylinder 3 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 3 in current driving cycle is displayed. |
P0303: MISFIRE / MISFIRE RATE3
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A5 | $0B | Multiply by 1 | Time | Total EWMA* misfire count of cylinder 4 in last ten driving cycles |
P0304: MISFIRE / EWMA MISFIRE4
| Monitor ID | Test ID | Scaling | Unit | Description |
| $A5 | $0C | Multiply by 1 | Time | When power switch on (IG), total misfire count of cylinder 4 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 4 in current driving cycle is displayed. |
P0304: MISFIRE / MISFIRE RATE4
*: EWMA (Exponential Weighted Moving Average) misfire counts for last 10 driving cycles (calculated) Calculation: 0.1 x (current counts) + 0.9 x (previous average). Initial value for (previous average) = 0
- Connect the Techstream to the DLC3.
- Turn the power switch on (IG).
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE»(ref-553290-S22500871302013051700000) .
- Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-553305-S15065568862013051700000) .
- Read the misfire counts of each cylinder, Cylinder #1 Misfire Count to Cylinder #4 Misfire Count, with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle so that the vehicle conditions displayed in Misfire RPM and Misfire Load of the Data List are the same as the freeze frame data. Perform this step several times. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, confirm the Misfire RPM and Misfire Load in the Data List. Engine speed Duration Idling 4.5 minutes or more 1000 4.5 minutes or more 2000 2.5 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the power switch off until the output DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data are cleared.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the power switch off and wait for at least 30 seconds.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
