Diagnostics: Other Subaru Outback BH

Automatic Trans 12 illustrations ~983 words

CHECK

Check the following items when problem has occurred.

Note. Use copies of this page for interviewing customers.

Customer Check List For Interview Chart. Scheme 841

Scheme 841: Customer Check List For Interview Chart
Scheme 841: Customer Check List For Interview Chart

CAUTION

  1. Supplemental Restraint Systems "Airbag"

Airbag system wiring harness is routed near the transmission control module (TCM).

CAUTIONAll airbag system wiring harness and connectors are colored yellow. Do not use electrical test equipment on these circuit. Be careful not to damage airbag system wiring harness when performing diagnostics and servicing the TCM.
  1. Measurement

When measuring voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert the pin more than 5 mm (0.20 in).

BATTERY

Measure battery voltage and specific gravity of electrolyte.

  1. Standard voltage: 12V or more
  2. Specific gravity: Above 1.260

TRANSMISSION GROUND

Make sure that the ground terminal bolt is tightened securely.

Scheme 842

Scheme 842: TRANSMISSION GROUND
Scheme 842: TRANSMISSION GROUND
  1. Chassis side Tightening torque: 13+/-3 N.m (1.3+/-0.3 kgf-m, 9.4+/-2.2 ft-lb) (Scheme 842): Tightening Ground Terminal Bolt

ATF LEVEL

Make sure that ATF level is in the specification.

Checking ATF Level. Scheme 843

Scheme 843: Checking ATF Level
Scheme 843: Checking ATF Level

FRONT DIFFERENTIAL OIL LEVEL

Make sure that front differential oil level is in the specification.

Checking Differential Oil Level. Scheme 844

Scheme 844: Checking Differential Oil Level
Scheme 844: Checking Differential Oil Level

MEASUREMENT

Only for models with VDC system, measure input/output signal voltage.

TCM I/O Signal Waveform Chart. Scheme 845

Scheme 845: TCM I/O Signal Waveform Chart
Scheme 845: TCM I/O Signal Waveform Chart

Data Link Connector

Note. With 2.5 L engine, see SELF-DIAGNOSTIC SYSTEM . With 3.0L engine, SELF-DIAGNOSTIC SYSTEM .

Scheme 846

Scheme 846: READING DIAGNOSTIC TROUBLE CODE
Scheme 846: READING DIAGNOSTIC TROUBLE CODE

Scheme 847

Scheme 847
Scheme 847

Scheme 848

Scheme 848
Scheme 848

Scheme 849

Scheme 849
Scheme 849
  1. Prepare Subaru Select Monitor kit. (Scheme 846): Preparing Subaru Select Monitor Kit
  2. Connect diagnosis cable to Subaru Select Monitor.
  3. Insert cartridge into Subaru Select Monitor. (Scheme 847): Inserting Cartridge Into Subaru Select Monitor
  4. Connect Subaru Select Monitor to data link connector. Data link connector located in the lower portion of the instrument panel (on the driver's side). (Scheme 848): Locating Data Link Connector Connect diagnosis cable to data link connector. CAUTION: Do not connect scan tools except for Subaru Select Monitor and OBD-II general scan tool.
  5. Turn ignition switch to ON (engine OFF) and Subaru Select Monitor switch to ON. (Scheme 849): Subaru Select Monitor On/Off Switch
  6. On the << Main Menu >> display screen, select the {Each System Check} and press the [YES] key.
  7. On the << System Selection Menu >> display screen, select the {Engine Control System} and press the [YES] key.
  8. Press the [YES] key after displayed the information of engine type.
  9. On the << Transmission Diagnosis >> display screen, select the {Diagnostic Code(s) Display} and press the [YES] key.
  10. On the << Diagnostic Code(s) Display >> display screen, select the {Current Diagnostic Code(s)} or {History Diagnostic Code(s)} and press the [YES] key.

Note. For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL. With 2.5 L engine, see SUBARU SELECT MONITOR (SSM) PROCEDURE . With 3.0 L engine, see SUBARU SELECT MONITOR (SSM) PROCEDURE . For detailed concerning diagnostic trouble codes, refer to the DIAGNOSTIC TROUBLE CODE LIST. See List of Diagnostic Trouble Codes .

Scheme 850

Scheme 850: READ CURRENT DATA
Scheme 850: READ CURRENT DATA
  1. On the << Main Menu >> display screen, select the {Each System Check} and press the [YES] key.
  2. On the << System Selection Menu >> display screen, select the {Transmission Control System} and press the [YES] key.
  3. Press the [YES] key after displayed the information of transmission type.
  4. On the << Transmission Diagnosis >> display screen, select the {Current Data Display & Save} and press the [YES] key.
  5. On the << Data Display Menu >> display screen, select the {Data Display} and press the [YES] key.
  6. Using the scroll key, move the display screen up or down until the desired data is shown. A list of the support data is shown in the following chart. (Scheme 850): Subaru Select Monitor Chart NOTE: For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL. With 2.5 L engine, see «SUBARU SELECT MONITOR (SSM) PROCEDURE»(ref-11745-S36014840652001010900000). With 3.0 L engine, see «SUBARU SELECT MONITOR (SSM) PROCEDURE»(ref-63535-S24135659122001020900000).

CLEAR MEMORY MODE

  1. On the << Main Menu >> display screen, select the {2. Each System Check} and press the [YES] key.
  2. On the << System Selection Menu >> display screen, select the {Transmission Control System} and press the [YES] key.
  3. Press the [YES] key after displayed the information of engine type.
  4. On the << Transmission Diagnosis >> display screen, select the {Clear Memory} and press the [YES] key.
  5. When the `Done' and `Turn Ignition Switch OFF' are shown on the display screen, turn the Subaru Select Monitor and ignition switch to OFF. NOTE: For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL. With 2.5 L engine, see «SUBARU SELECT MONITOR (SSM) PROCEDURE»(ref-11745-S36014840652001010900000) . With 3.0 L engine, see «SUBARU SELECT MONITOR (SSM) PROCEDURE»(ref-63535-S24135659122001020900000) .

Reading Diagnostic Trouble Codes (Without Subaru Select Monitor). Scheme 851

Scheme 851: Reading Diagnostic Trouble Codes (Without Subaru Select Monitor)
Scheme 851: Reading Diagnostic Trouble Codes (Without Subaru Select Monitor)

The AT OIL TEMP warning light flashes the code corresponding to the faulty part.

The long segment (1.2 sec on) indicates a "ten", and the short segment (0.2 sec on) signifies a "one".

Identifying Long & Short Segments (Without Subaru Select Monitor). Scheme 852

Scheme 852: Identifying Long & Short Segments (Without Subaru Select Monitor)
Scheme 852: Identifying Long & Short Segments (Without Subaru Select Monitor)

WITH SUBARU SELECT MONITOR

Refer to SUBARU SELECT MONITOR for information about how to obtain and understand trouble codes. See Subaru Select Monitor .

WITHOUT SUBARU SELECT MONITOR

Current trouble codes shown on the display are cleared by turning the ignition switch OFF after conducting on-board diagnostics operation. Previous trouble codes, however, cannot be cleared since they are stored in the TCM memory which is operating on the back-up power supply. These trouble codes can be cleared by removing the specified fuse (located under the light or left lower position of the instrument panel).

CLEAR MEMORY

  1. Removal of No. 4 fuse (for at least one minute)
  1. The No. 4 fuse is located in the line to the memory back-up power supply of the TCM. Removal of this fuse clears the previous trouble codes stored in the TCM memory.
  2. Be sure to remove the No. 4 fuse for at least the specified length of time. Otherwise, trouble codes may not be cleared.

Refer to SUBARU SELECT MONITOR for information about how to clear trouble codes. (Scheme 850)
