ADJUSTMENT
Move select lever from "P" position to "1" position. You should be able to feel the detentes in each position. If the detentes cannot be felt or the position pointer is improperly aligned, adjust the cable.
Scheme 28
Scheme 29
Scheme 30
Scheme 31
- Prior to removal, set lever to "N" position.
- Remove rear exhaust pipe and muffler.
- Remove heat shield cover. (Scheme 28): Removing Heat Shield Cover
- Loosen the adjusting nut on each side. (Scheme 29): Locating Adjustment Nuts
- Turn adjusting nut B until it lightly touches the connector. (Scheme 30): Adjusting Select Cable
- While preventing adjusting nut B from moving with a wrench, tighten adjusting nut A. Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb) (Scheme 31): Tightening Adjustment Nuts
- After completion of fitting, make sure that the select lever operates smoothly all across the operating range.
