Removal
Disconnect the ground cable from battery.
Scheme 89
Disconnect the connector from manifold absolute pressure sensor.
Scheme 90
Remove the manifold absolute pressure sensor from throttle body.
Installation
Install in the reverse order of removal.
Note. Use new O-rings.
Tightening torque
2.0 Nm (0.2 kgf-m, 1.5 ft-lb)
Disconnect the ground cable from battery.
Scheme 91
Disconnect the connector from mass air flow and intake air temperature sensor.
Remove the mass air flow and intake air temperature sensor.
Scheme 92
Install in the reverse order of removal.
Tightening torque
1.0 Nm (0.10 kgf-m, 0.74 ft-lb)
Disconnect the ground cable from battery.
Scheme 93
Disconnect the connector from EGR valve.
Scheme 94
Remove the EGR valve from intake manifold.
Scheme 95
Install in the reverse order of removal.
Note. Use a new gasket.
Tightening torque
19 Nm (1.9 kgf-m, 13.7 ft-lb)
