Disassembly
Move the clamp, and disconnect the evaporation hose from the joint pipe.
Scheme 206
Remove the bolt which installs the joint pipe on the fuel filler pipe.
Scheme 207
Disconnect the evaporation hose from the fuel filler pipe.
Scheme 208
Remove the shut valve from the fuel filler pipe.
Assembly
Install the shut valve on the fuel filler pipe.
Connect the evaporation hose to the fuel filler pipe.
Scheme 209
Connect the evaporation hose to the evaporation pipe.
Scheme 210
Install the evaporation pipe to the fuel filler pipe.
