Disassembly
Disconnect the engine ground terminal from intake manifold.
Scheme 61
Remove the ignition coil & ignitor ASSY.
Remove the throttle body.
Remove the EGR valve.
Remove the PCV pipe.
Scheme 62
Remove the fuel pipe protector LH.
Scheme 63
Remove the fuel pipe protector RH.
Scheme 64
Disconnect the pressure regulator vacuum hose (A) from intake manifold.
Scheme 65
Disconnect the connectors (A) from fuel injector.
Remove the harness band (B) which holds engine harness to injector pipe.
Scheme 66
Remove the purge control solenoid valve.
Remove the harness band clips which install the engine harness.
Scheme 67
Remove the bolts which hold the engine harness to intake manifold.
Scheme 68
Remove the engine harness from intake manifold.
Remove the bolts which install injector pipe on the intake manifold as shown in the figure.
Scheme 69
Scheme 70
Scheme 71
- RH side
- LH side
Remove the fuel injectors from injector pipe.
Loosen the clamp which holds fuel injector pipe RH to fuel hose, and then disconnect the pipe from fuel hose.
Scheme 72
Loosen the clamp which holds fuel injector pipe LH to fuel hose, and then disconnect the pipe from fuel hose.
Scheme 73
Remove the fuel injector pipe.
Remove the bolt which installs pressure regulator on intake manifold.
Remove the bolt which installs the fuel pipes on intake manifold.
Scheme 74
Remove the fuel pipe assembly and pressure regulator, from intake manifold.
Assembly
Note. When assembling the nipple, apply liquid gasket.
Liquid gasket
THREE BOND 1105 (Part No. 32005014)
Tighten the bolt which installs the fuel pipes on intake manifold.
Tightening torque
6.4 Nm (0.65 kgf-m, 4.7 ft-lb)
Scheme 75
Tighten the bolt which installs pressure regulator on intake manifold.
Tightening torque
19 Nm (1.9 kgf-m, 13.7 ft-lb)
Connect the fuel injector pipe.
Connect the fuel injector pipe LH to fuel hose, and tighten the clamp screw.
Scheme 76
Connect the fuel injector pipe RH to fuel hose, and tighten the clamp screw.
Scheme 77
Install the fuel injectors.
Tighten the bolts which install injector pipe on intake manifold.
Scheme 78
Scheme 79
Scheme 80
- RH side Tightening torque: 19 Nm (1.9 kgf-m, 13.7 ft-lb)
- LH side Tightening torque: 19 Nm (1.9 kgf-m, 13.7 ft-lb) Tightening torque: 5 Nm (0.5 kgf-m, 4.25 ft-lb)
Install the engine harness onto intake manifold.
Tighten the bolts which install engine harness on intake manifold.
Tightening torque
19 Nm (1.9 kgf-m, 13.7 ft-lb)
Scheme 81
Hold the engine harness by harness band clips.
Scheme 82
Install the purge control solenoid valve.
Connect the connectors (A) to fuel injector.
Hold the engine harness to injector pipe by harness band (B).
Scheme 83
Connect the pressure regulator vacuum hose (A) to intake manifold.
Scheme 84
Install the fuel pipe protector RH.
Tightening torque
19 Nm (1.9 kgf-m, 13.7 ft-lb)
Scheme 85
Install the fuel pipe protector LH.
Tightening torque
19 Nm (1.9 kgf-m, 13.7 ft-lb)
Scheme 86
Install the PCV pipe.
Scheme 87
Install the EGR valve.
Install the throttle body to intake manifold.
Install the ignition coil & ignitor ASSY.
Install the engine ground terminal to intake manifold.
Tightening torque
19 Nm (1.9 kgf-m, 13.7 ft-lb)
