Preparation Tool Saab 9-2X I

Fuel System 7 illustrations ~415 words

Scheme 1

Scheme 1: Intake Manifold
Scheme 1: Intake Manifold
  1. Intake manifold
  2. Gasket
  3. Guide pin
  4. PCV pipe
  5. EGR valve
  6. Fuel pipe protector RH
  7. Fuel pipe protector LH
  8. Fuel injector pipe
  9. Fuel injector
  10. O-ring
  11. O-ring
  12. O-ring
  13. Purge control solenoid valve
  14. Plug cord holder
  15. Nipple
  16. Fuel pipe ASSY
  17. Fuel hose
  18. Clip
  19. Pressure regulator
  20. Gasket
  21. Nipple Tightening torque: Nm (kgf-m, ft-lb) T1: 1.5 (0.15, 1.1) T2: 5.0 (0.5, 4.25) T3: 17 (1.7, 12.5) T4: 19 (1.9, 13.7) T5: 25 (2.5, 18.1)

Scheme 2

Scheme 2: Air Intake System
Scheme 2: Air Intake System
  1. Gasket
  2. Throttle body
  3. Manifold absolute pressure sensor
  4. O-ring Tightening torque: Nm (kgf-m, ft-lb) T1: 2.0 (0.2, 1.5) T2: 8 (0.8, 5.8)

Scheme 3

Scheme 3: Crankshaft Position, Camshaft Position And Knock Sensors
Scheme 3: Crankshaft Position, Camshaft Position And Knock Sensors
  1. Crankshaft position sensor
  2. Knock sensor
  3. Camshaft position sensor
  4. Camshaft position sensor support Tightening torque: Nm (kgf-m, ft-lb) T1: 6.4 (0.65, 4.7) T2: 24 (2.4, 17.4)

Scheme 4

Scheme 4: Fuel Tank
Scheme 4: Fuel Tank
  1. Heat shield cover
  2. Fuel tank band
  3. Protector LH
  4. Protector RH
  5. Fuel tank
  6. Canister hose A
  7. Clamp
  8. Fuel pump gasket
  9. Fuel pump assembly
  10. Fuel cut valve gasket
  11. Fuel cut valve
  12. Evaporation hose A
  13. Clip
  14. Joint pipe
  15. Evaporation hose C
  16. Evaporation hose B
  17. Evaporation hose D
  18. Evaporation hose E
  19. Evaporation pipe assembly
  20. Retainer
  21. Quick connector
  22. Jet pump hose A
  23. Fuel level sensor
  24. Fuel pipe assembly
  25. Jet pump hose B
  26. Evaporation hose F
  27. Fuel sub level sensor gasket
  28. Jet pump filter
  29. Fuel sub level sensor
  30. Protector cover
  31. Vent valve hose
  32. Vent valve
  33. Fuel tank pressure sensor
  34. Fuel tank pressure sensor hose
  35. Vent valve gasket
  36. Fuel tank sensor control valve
  37. Purge hose
  38. Clip
  39. Cover bracket
  40. Filler hose Tightening torque: Nm (kgf-m, ft-lb) T1: 4.4 (0.45, 3.3) T2: 7.4 (0.75, 5.4) T3: 33 (3.4, 25)

Scheme 5

Scheme 5: Fuel Line
Scheme 5: Fuel Line
  1. Clamp
  2. Fuel return hose A
  3. Fuel damper valve (return)
  4. Fuel return hose B
  5. Evaporation hose A
  6. Clip
  7. Fuel delivery hose A
  8. Fuel delivery hose B
  9. Fuel damper valve bracket
  10. Fuel damper valve (delivery)
  11. Fuel pipe ASSY
  12. Evaporation hose B
  13. Joint pipe
  14. Canister hose A
  15. Pressure control solenoid valve
  16. Pressure control solenoid valve bracket
  17. Drain hose C
  18. Canister upper bracket
  19. Cushion rubber
  20. Canister lower bracket
  21. Canister
  22. Drain valve
  23. Drain filter
  24. Pressure control solenoid valve tube
  25. Drain hose A
  26. Connector drain
  27. Drain hose B
  28. Clamp Tightening torque: Nm (kgf-m, ft-lb) T1: 25 (2.5, 18.1) T2: 23 (2.3, 16.6) T3: 33 (3.4, 25)

Scheme 6

Scheme 6: Fuel Filler Pipe
Scheme 6: Fuel Filler Pipe
  1. Fuel filler pipe ASSY
  2. Evaporation hose holder
  3. Clamp
  4. Clamp
  5. Evaporation hose A
  6. Evaporation pipe
  7. Evaporation pipe holder
  8. Filler pipe packing
  9. Filler ring
  10. Filler cap
  11. Shut valve
  12. Evaporation hose B
  13. Evaporation hose C
  14. Joint pipe
  15. Fuel filler pipe protector
  16. Clamp Tightening torque: Nm (kgf-m, ft-lb) T1: 4.4 (0.45, 3.3) T2: 7.5 (0.76, 5.53)
ILLUSTRATIONTOOL NUMBERDESCRIPTIONREMARKS
32005086CONNECTOR REMOVERUsed for removing quick connector.

PREPARATION TOOL COMPATIBILITY

Scheme 7

Scheme 7
Scheme 7
