Terminal Assignment of Engine Control Units

Terminal Assignment of Motronic Control Unit M 2.8.3 (X 25 Xe in Vectra-B), Excerpt

1. Ground (terminal 31)
2. Terminal SM1, ground, engine telltale H30
3. Battery voltage (terminal 30)
4. Terminal SM2, odometer signal
5. Diagnostic excitation lead to diagnostic plug X13 terminal 6
6. Data lead to diagnostic plug X13 terminal 7

Terminal Assignment of Motronic Control Unit (20 Se, 20 Nej, C 20 Ne, C 20 Let, C 20 Xe, X 20 Se, C 25 Xe, X 25 Xe in Omega-B, X 30 Xe), Excerpt

1. Terminal SM2, odometer signal
2. Diagnostic excitation lead to diagnostic plug X13/XD terminal 6
3. Battery voltage (terminal 30)
4. Ground
5. Terminal SM1, ground, engine telltale H30
6. Data lead to diagnostic plug X 13/XD terminal 7

Terminal Assignment of Simtec Control Unit 56.1 (C 18 Xel, X 20 Xev), Excerpt

1. Diagnostic excitation lead to diagnostic plug X13 terminal 6 (C 18 XEL in Astra-F) or X13 terminal B (X 20 XEV in Calibra)
2. Battery voltage (terminal 30)
3. Ground (terminal 31)
4. Terminal SM2, odometer signal
5. Terminal SM1, ground, engine telltale H30
6. Data lead to diagnostic plug X13 terminal 7 (C 18 XEL in Astra-F) or X13 terminal G (X 20 XEV in Calibra)

Terminal Assignment of Simtec Control Unit 56.5 (X 18 Xe, X 20 Xev), Excerpt

1. Data lead to diagnostic plug XD/X13 terminal 7
2. Terminal SM2, odometer signal
3. Ground
4. Diagnostic excitation lead to diagnostic plug XD/X13 terminal 6
5. Terminal SM1, ground, engine telltale H30
6. Battery voltage (terminal 30)

Terminal Assignment of Multec Control unit(12 Nz, C 12 Nz, C 14 Nz), Excerpt

Terminal Assignment of Multec-S Control Unit (X16 Xel in Vectra-B) and Multec-M Control Unit (X 16 Szr in Astra F, Vectra-B; X 16 Xel in Astra-F), Excerpt

Terminal Assignment of Multec Control Unit (X 14 Xe and X 16 Xe in Corsa-B, Combo, Tigra), Multec-M ITMS-6R Control Unit (X 16 Xel in Astra-F Up to MY '96.5), Excerpt

Terminal Assignment of Multec-M Control Unit (14 Se, C 14 Se, C 16 Se), Multec Control Unit (X 12 Sz, X 16 Sz), Multec IEFI-6 Control Unit (16 LZ2 in Vectra B) and Multec Control Unit (16 LZ2 in Astra-F), Excerpt

Terminal Assignment of Wiring Harness Plug for Diesel Control Unit (25 Dt, X 25 Dt), Excerpt

1. Terminal SM1, ground, engine telltale H 30
2. Battery voltage (terminal 30)
3. Battery voltage (terminal 30)
4. Ground (terminal 31)
5. Ground (terminal 31)
6. Terminal SM2, odometer signal
7. Data lead to diagnostic plug XD terminal 7
