Tail Lamp Replacement
| Callout | Component Name |
|---|---|
| Preliminary Procedure Open the rear compartment lid in order to access the tail lamp screws. | |
| 1 | Tail Lamp Assembly Screws (Qty: 2) Tighten 2.5 N·m (22 lb in) |
| 2 | Chassis Electrical Connector Procedure Lift the tail lamp in order to disengage the retainer clips then disconnect the electrical connector. |
| 3 | Tail Lamp Assembly Tip Transfer the bulb into the new tail lamp. |
| 4 | Quarter Filler Panel Nuts (Qty: 2) Tip Ensure the quarter filler panel nuts are not damaged. Replace if damaged. |
