PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

AV COMMUNICATION SYSTEM

1. Do not apply voltage of 7.0 V or higher to the measurement terminals.
2. Use the tester with its open terminal voltage being 7.0 V or less.
3. Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before checking the circuit.

Scheme 50

Scheme 51

1. Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).]
2. Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of twisted line will be lost.)

Commercial Service Tools

Tool name Description Power tool Loosening screws

Scheme 52

Scheme 53

POSITION DETECTION PRINCIPLE

The navigation system periodically calculates the vehicle's current position according to the following three signals

1. Travel distance of the vehicle as determined by the vehicle speed sensor
2. Turning angle of the vehicle as determined by the gyroscope (angular velocity sensor)
3. Direction of vehicle travel as determined by the GPS antenna (GPS information)

The current position of the vehicle is then identified by comparing the calculated vehicle position with map data read from the map SD-card (map-matching), and indicated on the screen as a vehicle mark. More accurate data is judged and used by comparing vehicle position detection results found by the GPS with the result by map-matching.

The current vehicle position will be calculated by detecting the distance the vehicle moved from the previous calculation point and its direction.

1. Travel distance Travel distance calculations are based on the vehicle speed sensor input signal. Therefore, the calculation may become incorrect as the tires wear down. To prevent this, an automatic distance correction function has been adopted.
2. Travel direction

Change in the travel direction of the vehicle is calculated by a gyroscope (angular velocity sensor) and a GPS antenna (GPS information). They have both advantages and disadvantages.

Scheme 54

More accurate traveling direction is detected because priorities are set for the signals from these two devices according to the situation.

MAP-MATCHING

Map-matching compares a current location detected by the method in the "Location Detection Principle" with a road map data from map SD-card.

Note. The road map data is based on data stored in the map SD-card.

Scheme 55

The vehicle position may not be corrected under the following circumstances and after driving for a certain time when GPS information is difficult to receive. In this case, the vehicle mark on the display must be corrected manually.

Scheme 56

Scheme 57

1. In map-matching, alternative routes to reach the destination will be shown and prioritized, after the road on which the vehicle is currently driven has been judged and the vehicle mark has been repositioned. Alternative routes will be shown in different order of priority, and the incorrect road can be avoided if there is an error in distance and/or direction. They are of the same priority if two roads are running in parallel. Therefore, the vehicle mark may appear on either of them alternately, depending on maneuvering of the steering wheel and configuration of the road.
2. Map-matching does not function correctly when a road on which the vehicle is driving is new and not recorded in the map SD-card, or when road pattern stored in the map data and the actual road pattern are different due to repair. The map-matching function may find another road and position the vehicle mark on it when driving on a road not present in the map. Then, the vehicle mark may change to it when the correct road is detected.
3. Effective range for comparing the vehicle position and travel direction calculated by the distance and direction with the road data read from the map SD-card is limited. Therefore, correction by map-matching is not possible when there is an excessive gap between current vehicle position and the position on the map.

GPS (Global Positioning System)

GPS (Global Positioning System) is developed for and is controlled by the US Department of Defense. The system utilizes GPS satellites (NAVSTAR), transmitting out radio waves while flying on an orbit around the earth at an altitude of approximately 21, 000 km (13, 049 mile).

The receiver calculates the travel position in three dimensions (latitude/longitude/altitude) according to the time lag of the radio waves that four or more GPS satellites transmit (three-dimensional positioning). The GPS receiver calculates the travel position in two dimensions (latitude/longitude) with the previous altitude data if the GPS receiver receives only three radio waves (two-dimensional positioning). GPS position correction is not performed while stopping the vehicle.

Scheme 58

Accuracy of the GPS will deteriorate under the following conditions

1. In two-dimensional positioning, GPS accuracy will deteriorate when altitude of the vehicle position changes.
2. The position of GPS satellite affects GPS detection precision. The position detection may not be precisely performed.
3. The position detection is not performed if GPS receiver does not receive radio waves from GPS satellites. (Inside a tunnel, parking in a building, under an elevated highway etc.) GPS receiver may not receive radio waves from GPS satellites if any object is placed on the GPS antenna.

Note. The detection result has an error of approximately 10 m (32.81 ft) even with a high-precision three dimensional positioning. There may be cases when the accuracy is lowered and radio waves are stopped intentionally because the GPS satellite signal is controlled by the US trace control center.

SATELLITE RADIO FUNCTION

1. Satellite radio function is built into NAVI control unit.
2. Sound signal (satellite radio) is received by satellite radio antenna and transmitted to NAVI control unit. NAVI control unit outputs sound signal to each speaker and woofer.

AUXILIARY INPUT FUNCTION

1. Sound can be output from an external device by connecting a device with USB connector and AUX jack.
2. AUX sound signals are transmitted to each speaker and woofer via NAVI control unit.

USB CONNECTION FUNCTION

1. iPod® or music files in USB memory can be played.
2. Sound signals are transmitted from USB connector and AUX jack to the NAVI control unit and output to each speaker and woofer.
3. iPod® is recharged when connected to USB connector and AUX jack.

iPod® is a trademark of Apple inc., registered in the U.S. and other countries.

Note. Use the enclosed USB harness when connecting iPod® to USB connector and AUX jack.

SPEED SENSITIVE VOLUME SYSTEM

1. Volume level of this system gone up and down automatically in proportion to the vehicle speed.
2. The control level can be selected by the customer.

HANDS-FREE PHONE SYSTEM

1. TEL adapter unit is controlled with AV communication from NAVI control unit.
2. The connection between cellular phone and TEL adapter unit is performed with Bluetooth™ communication.
3. The voice guidance signal is input from the TEL adapter unit to the NAVI control unit and output to the front speaker when operating the cellular phone.
4. TEL adapter unit has the on board self-diagnosis function. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-516456-S07824139952012120600000) ".

When A Call Is Originated

1. Spoken voice sound output from the microphone (microphone signal) is input to TEL adapter unit.
2. TEL adapter unit outputs to cellular phone with Bluetooth™ communication as a TEL voice signal.
3. Voice sound is then heard at the other party.

When Receiving A Call

1. Voice sound is input to own cellular phone from the other party.
2. TEL voice signal is input to TEL adapter unit by establishing Bluetooth™ communication from cellular phone, and the signal is output to front speaker.

On-Board Diagnosis Item

1. On-board diagnosis is performed in service test mode.
2. On-board diagnosis checks if the system operates normally.

SERVICE TEST MODE

Scheme 59

1. Start the engine.
2. Turn OFF audio.
3. While pressing the "SET UP" switch, turn the MENU dial counterclockwise 3 clicks or more first, then clockwise and counterclockwise 3 clicks or more, respectively. (After the diagnosis mode starts, the initial screen of the diagnosis mode appears.)

The Details of Error Count

The error count guides "0" when the error occurs. The next time it counts up "1" if it is normal with the ignition switch ON. It continues the count up unless the initialization of hands free phone system is performed.

Scheme 60

Scheme 61

PHYSICAL VALUES

Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (R) Ground Woofer amp. ON signal Output Ignition switch ON - 12.0 V 2 (W) 3 (GR) Sound signal front speaker LH Output Ignition switch ON Sound output. 4 (LG) 5 (W) Sound signal rear speaker LH Output Ignition switch ON Sound output. 6 (G) 15 (V) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch. 0 V Keep pressing SEEK UP switch. 1.4 V Keep pressing SEEK DOWN switch. 2.5 V Keep pressing switch. 3.5 V Except for above. 5.0 V 7 (L) Ground ACC power supply Input Ignition switch ACC - Battery voltage 9 (V) 8 (GR) Illumination control signal Input Ignition switch ON Lighting switch 1ST When meter illumination is maximum Lighting switch 1ST When meter illumination is step 11 Lighting switch 1ST When meter illumination is minimum 0 V 11 (G) 12 (R) Sound signal front speaker RH Output Ignition switch ON Sound output. 13 (BR) 14 (Y) Sound signal rear speaker RH Output Ignition switch ON Sound output. 16 (R) 15 (V) Steering switch signal B Input Ignition switch ON Keep pressing VOL DOWN switch. 0 V Keep pressing VOL UP switch. 1.4 V Keep pressing switch. 2.5 V Except for above. 5.0 V 18 (Y) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 19 (BR) Ground Battery power supply Input Ignition switch OFF - Battery voltage 21 (B) Ground EQ1 - Ignition switch ON - 0 V 23 (B) Ground EQ3 (1) - Ignition switch ON - 0 V 25 (G) Ground Reverse signal Input Ignition switch ON Shift position is in R. 12.0 V Shift position is in other than R. 0 V 30 (W) 31 (B) Sound signal woofer Output Ignition switch ON Sound output. 32 - Shield - - - - 34 (BR) 35 (Y) Sound signal (TEL voice, voice guidance) Input Ignition switch ON During voice guide output with the switch pressed. 36 (B) Ground TEL ground - Ignition switch ON - 0 V 37 - Shield - - - - 38 (SB) (1) (G) (2) - AV communication signal (H) Input/Output - - - 39 (LG) (1) (R) (2) - AV communication signal (L) Input/Output - - - 41 (V) Ground Camera image signal Input Ignition switch ON At rear camera image is displayed. 42 - Shield - - - - 43 (LG) Ground Camera power supply Output Ignition switch ON Shift position is in "R". 6.0 V 44 (L) - Camera ground - Ignition switch ON - 0 V 45 (B) - USB ground - - - - 46 (W) - USB D- signal Input/Output - - - 47 (G) - USB D+ signal Input/Output - - - 48 (R) - V BUS signal Output - - - 49 (Y) 51 (L) AUX sound signal LH Input - - - 50 (BR) 51 (L) AUX sound signal RH Input - - - 52 - Shield - - - - 53 - Shield - - - - 54 Ground GPS antenna signal Input Ignition switch ON Not connected to GPS antenna connector. 5.0 V 55 - Shield - - - - 70 Ground Antenna amp. ON signal Output Ignition switch ACC - 12.0 V 71 - Antenna signal Input - - - 73 - Satellite radio antenna signal Input - - - (1) Models without rear camera. (2) Models with rear camera

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 1 (BR) 4 (B) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery voltage 2 (L) 4 (B) ACC power supply Input Ignition switch ACC - 7.0 - 16.0 V Battery voltage 3 (SB) 4 (B) Ignition signal Input Ignition switch ON - 7.0 - 16.0 V Battery voltage 7 (G) 8 Microphone signal Input Ignition switch ON Give a voice. Outputs waveform synchronized with voice is input. 9 (BR) 10 (GR) Sound signal (TEL voice, voice guidance) Output Ignition switch ON During voice guide output with the switch pressed. Outputs waveform synchronized with sound. 23 (B) 4 (B) Control signal - Ignition switch ON - 3.1 V or less 0 V 24 (B) 4 (B) Control signal - Ignition switch ON - 3.1 V or less 0 V 27 (B) 4 (B) Control signal - Ignition switch ON - 3.1 V or less 0 V 28 (Y) 4 (B) Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) Waveform according to vehicle speed is input. NOTE: The maximum voltage varies depending on the specification (destination unit). 29 (R) 8 Microphone VCC Output Ignition switch ON - 4.7 - 5.3 V 5.0 V 33 4 (B) TEL antenna signal Input/Output Ignition switch ON Not connected to TEL antenna connector. - 5.0 V 34 - Shield - - - - - 35 (SB) - AV communication signal (H) Input/Output - - - - 36 (LG) - AV communication signal (L) Input/Output - - - - 39 (SB) - AV communication signal (H) Input/Output - - - - 40 (SB) - AV communication signal (H) Input/Output - - - - 41 (LG) - AV communication signal (L) Input/Output - - - - 42 (LG) - AV communication signal (L) Input/Output

DETAILED FLOW

1. CHECK SYMPTOM Check the malfunction symptoms by performing the following items. Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred). Check the symptom. GO TO 2.
2. PERFORM DIAGNOSIS BY SYMPTOM Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-516456-S07870560722012120600000) " (navigation system) or " «SYMPTOM TABLE»(ref-516456-S21246934352012120600000) " (hands-free phone system). GO TO 3.
3. REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace the malfunctioning parts. GO TO 4.
4. FINAL CHECK Perform the operation to check that the malfunction symptom is solved or any other symptoms are present. Is there any symptom? YES: GO TO 2 . NO: INSPECTION END

RELATED TO NAVIGATION

Note. Combined part of AV switch and NAVI control unit.

RELATED TO AUDIO

RELATED TO USB

Note. Check that there is no malfunction of USB equipment main body before performing a diagnosis.

iPod® is a trademark of Apple inc., registered in the U.S. and other countries.

RELATED TO AUXILIARY INPUT

Note. Check that there is no malfunction of AUX equipment main body before performing a diagnosis.

RELATED TO STEERING SWITCH

RELATED TO CAMERA

RELATED TO HANDS-FREE PHONE

1. Check that the cellular phone is corresponding type (Bluetooth™ enabled) when the hands-free related malfunction vehicle is in service before performing a diagnosis.
2. There is a case that malfunction occurs due to the version change of the phone type, etc. even though it is a corresponding type. Therefore, confirm it by changing the cellular phone to another corresponding type phone, and check that it operates normally. It is necessary to distinguish whether the cause is the vehicle or cellular phone. Check to ensure the customer's phone is supported by checking the phone compatibility for the hands-free system.

Simple Check for Bluetooth™ Communication

If cellular phone and TEL adapter unit cannot be connected with Bluetooth™ communication, following procedure allows the technician to judge which device has malfunction.

Scheme 69

1. Turn on a cellular phone, not connecting Bluetooth™ communication.
2. Start CONSULT, then start Windows®.
3. Set CONSULT near a cellular phone.
4. When operated Bluetooth™ registration by cellular phone, check if CONSULT* would be displayed on the device name. (If other Bluetooth™ device is located near cellular phone, a name of the device would be displayed also.) NOTE: *:Displayed device name is "NISSAN-********". If no device name is displayed, cellular phone is malfunction. Repair the cellular phone first, then perform diagnosis. If CONSULT is displayed on device name, cellular phone is normal. Perform diagnosis as per the following table.

1. The majority of the audio malfunctions are the result of outside causes (bad CD/cassette, electromagnetic interference, etc.). Check the symptoms below to diagnose the malfunction.
2. The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning. Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and operation of each piece of electrical equipment, and then determine the cause.

Note. CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incorrectly mastered by the customer on a computer. Check if the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the "red book" Compact Disc Standard and may not play.

Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other sources, is not a malfunction.

Note. Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking the signal. Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the antenna and the waves reflected by mountains or buildings.

MAP SD-CARD

RELATED TO ROUTE CALCULATION AND VISUAL GUIDANCE

RELATED TO VEHICLE ICON

RELATED TO VOICE GUIDANCE

RELATED TO TRAFFIC INFORMATION

RELATED TO TELEPHONE

Exploded View

Refer to " EXPLODED VIEW ".
