Audio, Visual, Navigation System (Audio with Navigation): Removal & Installation Nissan Juke I

Entertainment Systems 2 illustrations ~406 words

REMOVAL

  1. Remove cluster lid C. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Remove NAVI control unit screws.
  3. Disconnect NAVI control unit connectors to remove NAVI control unit and brackets as a single unit.
  4. Remove brackets screws to remove NAVI control unit.

INSTALLATION

Install in the reverse order of removal.

  1. Remove front door finisher. Refer to " «EXPLODED VIEW»(ref-516440-S12210806372012120600000) ".
  2. Remove front door speaker screws, then disconnect front door speaker connector and remove front door speaker.

Install in the reverse order of removal.

  1. Remove front pillar garnish. Refer to " «EXPLODED VIEW»(ref-516440-S27595990792012120600000) ".
  2. Remove tweeter clip, then disconnect tweeter connector and remove tweeter.

Install in the reverse order of removal.

  1. Remove rear door finisher. Refer to " «EXPLODED VIEW»(ref-516440-S36610909242012120600000) ".
  2. Remove rear door speaker screws, then disconnect rear door speaker connector and remove rear door speaker.

Install in the reverse order of removal.

  1. Remove luggage side lower finisher LH. Refer to " «EXPLODED VIEW»(ref-516440-S34798080822012120600000) ".
  2. Disconnect woofer connector.
  3. Remove woofer screws to remove woofer.

Install in the reverse order of removal.

Scheme 43

Scheme 43: Exploded View
Scheme 43: Exploded View
  1. Remove headlining. Refer to " «NORMAL ROOF: EXPLODED VIEW»(ref-516440-S26015776292012120600000) " (normal roof) or " «SUNROOF: EXPLODED VIEW»(ref-516440-S30023703952012120600000) " (sunroof).
  2. Disconnect antenna feeder connector.
  3. Remove nut to remove antenna base.

Install in the reverse order of removal.

CAUTIONIf the antenna base mounting nut is tightened looser than the specified torque, then this will lower the sensitivity of the antenna. On the other hand, if the nut is tightened tighter than the specified torque, then this will deform the roof panel.
  1. Remove instrument panel. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Remove antenna feeder clip, then remove GPS antenna screw and remove GPS antenna.

Install in the reverse order of removal.

  1. Remove glove box assembly. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Remove TEL adapter unit screws.
  3. Disconnect TEL adapter unit connectors to remove TEL adapter unit and bracket as a single unit.
  4. Remove bracket screws to remove TEL adapter unit.

Install in the reverse order of removal.

  1. Remove headlining. Refer to " «NORMAL ROOF: EXPLODED VIEW»(ref-516440-S26015776292012120600000) " (normal roof) or " «SUNROOF: EXPLODED VIEW»(ref-516440-S30023703952012120600000) " (sunroof).
  2. Remove microphone connector and pawl to remove microphone.

Install in the reverse order of removal.

Removal and Installation

REMOVAL

Refer to " REMOVAL AND INSTALLATION ".

Install in the reverse order of removal.

  1. Remove back door lower finisher. Refer to " «EXPLODED VIEW»(ref-516440-S21219103762012120600000) ".
  2. Remove rear view camera screws to remove rear view camera.

Install in the reverse order of removal.

  1. Remove cluster tray. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Push the pawl from the back of cluster tray to remove USB connector and AUX jack.

Install in the reverse order of removal.

Scheme 44

Scheme 44: Feeder Layout
Scheme 44: Feeder Layout
