Component Description
| Part name | Description |
|---|---|
| NAVI control unit | Operational switch of navigation system and audio system are integrated. Includes the audio, hands-free phone, navigation, satellite radio, rear view monitor, USB connection and AUX connection functions. Map data can be loaded from the SD-card inserted in the built-in SD-card slot. Sound signals are output to each speaker and woofer. It inputs the illumination signals that are required for the display dimming control. It inputs the signals for driving status recognition (vehicle speed, reverse and parking brake). Touch panel function can be operated for each system by touching a display directly. It supplies power to rear view camera. Camera image signal is input from rear view camera. |
| Map SD-card | A collection of Map data. |
| Front door speaker | Outputs sound signal from NAVI control unit. Outputs mid and low range sounds. |
| Tweeter | Outputs sound signal from NAVI control unit. Outputs high range sounds. |
| Rear door speaker | Outputs sound signal from NAVI control unit. Outputs high, mid and low range sounds. |
| Woofer | Woofer amp. ON signal is input from NAVI control unit. Outputs sound signal from NAVI control unit. Outputs low range sounds. |
| Steering switch | Operations for audio and hands-free phone are possible. Steering switch signal (operation signal) is output to NAVI control unit. |
| TEL adapter unit | Inputs the TEL voice signal from TEL antenna and outputs it to the NAVI control unit. It is connected with the NAVI control unit via AV communication and controlled with the NAVI control unit. |
| TEL antenna | Receives the TEL voice signal and outputs it to the TEL adapter unit. TEL antenna is unified with a TEL adapter unit. |
| Microphone | Used for hands-free phone operation. Microphone signal is transmitted to TEL adapter unit. Power (microphone VCC) is supplied from TEL adapter unit. |
| GPS antenna | GPS signal is received and transmitted to NAVI control unit. |
| Antenna base | A radio antenna base integrated with radio antenna amp. and satellite radio antenna is adopted. ANTENNA AMP. Radio signal received by rod antenna is amplified and transmitted to NAVI control unit. Power (antenna amp. ON signal) is supplied from NAVI control unit. SATELLITE RADIO ANTENNA Receives satellite radio waves and outputs it to NAVI control unit. |
| Rear view camera | Camera power supply is input from NAVI control unit. The image of vehicle rear view is transmitted to NAVI control unit. |
| USB connector and AUX jack | Sound signal of auxiliary input is transmitted to NAVI control unit. Sound signal of USB input is transmitted to NAVI control unit. |
Scheme 39
Note. An antenna base integrated with radio antenna amp. and satellite radio antenna is adopted.
Scheme 40
System Description
Refer to Owner's Manual for navigation and audio system operating instructions.
Audio function and display are built into NAVI control unit.
This navigation has the following functions.
- Map data on SD-card.
- Full support for playback of music from iPod® and USB device.
- High resolution color 5 inch display with touch panel function.
- FM/AM twin digital tuner.
- USB mass storage connection.
- Satellite radio.
- Hands-free phone system.
iPod® is a trademark of Apple inc., registered in the U.S. and other countries.
Description
- The navigation system can be operated by control panel of the NAVI control unit and display (touch panel) of the NAVI control unit.
- Guide sound during the operation of the navigation system is output from NAVI control unit to front speaker.
- NAVI control unit calculates the vehicle location based on the signals from GYRO (angle speed sensor), vehicle sensor, and GPS satellite, as well as the map data from map SD-card. It is displayed on display of the NAVI control unit.
Camera Image Operation Principle
- The NAVI control unit supplies power to the rear view camera when receiving a reverse signal.
- The rear view camera transmits camera images to the NAVI control unit when power is supplied from the NAVI control unit.
- The NAVI control unit combines a warning message and fixed guide lines with an image received from the rear view camera to display a rear view camera image on the screen.
During on board diagnosis the diagnosis function of TEL adapter unit starts with the operation of the steering switch and performs the diagnosis when ignition switch ACC.
TEL adapter unit supplies power to microphone. The microphone transmits the sound voice to the TEL adapter unit.
TEL adapter unit identifies the vehicle model according to the control signal and performs the control.
- The NAVI control unit supplies power to the rear view camera when receiving a reverse signal.
- The rear view camera transmits camera images to the NAVI control unit when power is supplied from the NAVI control unit.
Scheme 41
- CHECK CONTINUITY CAMERA POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect NAVI control unit connector and rear view camera connector. Check continuity between NAVI control unit harness connector and rear view camera harness connector. NAVI control unit Rear view camera Continuity Connector Terminal Connector Terminal M118 43 D111 1 Existed Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M118 43 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE CAMERA POWER SUPPLY Connect NAVI control unit connector and rear view camera connector. Turn ignition switch ON. Shift the selector lever to "R" position. Check voltage between NAVI control unit harness connector and ground. Probe Condition Reference value (Approx.) (+) (-) NAVI control unit Connector Terminal Connector Terminal M118 43 M107 20 Shift position is in "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-516456-S36975327102012120600000) ".
- CHECK CONTINUITY CAMERA IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect NAVI control unit connector and rear view camera connector. Check continuity between NAVI control unit harness connector and rear view camera harness connector. NAVI control unit Rear view camera Continuity Connector Terminal Connector Terminal M118 41 D111 3 Existed Check continuity between NAVI control unit harness connector and ground. NAVI control unit Ground Continuity Connector Terminal M118 41 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
- CHECK CAMERA IMAGE SIGNAL Connect NAVI control unit connector and rear view camera connector. Turn ignition switch ON. Shift the selector lever to "R" position. Check signal between NAVI control unit harness connector and ground. Probe Condition Reference value (+) (+) NAVI control unit Connector Terminal Connector Terminal M118 41 M107 20 At rear view camera image is displayed. Is inspection result normal? YES: Replace NAVI control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-516456-S36975327102012120600000) ". NO: Replace rear view camera. Refer to " «REMOVAL AND INSTALLATION»(ref-516456-S27077351292012120600000) ".
When the navigation system is turned on, a voltage signal is supplied from the NAVI control unit to the woofer. When this signal is received, the woofer will turn on.
Transmits the steering switch signal to NAVI control unit.
Transmits the steering switch signal to NAVI control unit.
Transmits the steering switch signal to NAVI control unit.
Note. For Navigation system operation information, refer to Navigation system Owner's Manual.
BASIC OPERATIONS
| Symptom | Possible cause | Possible solution |
|---|---|---|
| No image is displayed. | The brightness is at the lowest setting. | Adjust the brightness of the display. |
| The display is turned off. | Press " / " to turn on the display. | |
| No voice guidance is available or the volume is too high or too low. | The volume is not set correctly, or it is turned off. | Adjust the voice guidance volume level. |
| No map is displayed on the screen. | The map SD-card is not inserted. | Insert the map SD-card correctly. |
| A screen other than map screen is displayed. | Press "MAP". | |
| The screen is too dim. The movement is slow. | The temperature in the interior of the vehicle is low. | Wait until the interior of the vehicle has warmed up. |
| Some pixels in the display are darker or brighter than others. | This condition is an inherent characteristic of liquid crystal displays. | This is not a malfunction. |
| Some menu items cannot be selected. | Some menu items become unavailable while the vehicle is driven. | Park the vehicle in a safe location, and then operate the navigation system. |
Note. Locations stored in the Address Book and other memory functions may be lost if the vehicle's battery is disconnected or becomes discharged. If this occurs, service the vehicle's battery as necessary and re-enter the information in the Address Book.
