Audio, Visual, Navigation System (Audio Without Navigation): Removal & Installation Nissan Juke I

Entertainment Systems 2 illustrations ~399 words

REMOVAL

  1. Remove cluster lid C. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Remove audio unit screws.
  3. Disconnect audio unit connectors to remove audio unit and brackets as a single unit.
  4. Remove brackets screws to remove audio unit.

INSTALLATION

Install in the reverse order of removal.

  1. Remove front door finisher. Refer to " «EXPLODED VIEW»(ref-516440-S12210806372012120600000) ".
  2. Remove front door speaker screws, then disconnect front door speaker connector and remove front door speaker.

Install in the reverse order of removal.

  1. Remove front pillar garnish. Refer to " «EXPLODED VIEW»(ref-516440-S27595990792012120600000) ".
  2. Remove tweeter clip, then disconnect tweeter connector and remove tweeter.

Install in the reverse order of removal.

  1. Remove rear door finisher. Refer to " «EXPLODED VIEW»(ref-516440-S36610909242012120600000) ".
  2. Remove rear door speaker screws, then disconnect rear door speaker connector and remove rear door speaker.

Install in the reverse order of removal.

  1. Remove luggage side lower finisher LH. Refer to " «EXPLODED VIEW»(ref-516440-S34798080822012120600000) ".
  2. Disconnect satellite radio tuner connectors.
  3. Remove screws to remove satellite radio tuner and brackets as a single unit.
  4. Remove brackets screws to remove satellite radio tuner.

Install in the reverse order of removal.

Scheme 15

Scheme 15: Exploded View
Scheme 15: Exploded View
  1. Remove headlining. Refer to " «NORMAL ROOF: EXPLODED VIEW»(ref-516440-S26015776292012120600000) " (normal roof) or " «SUNROOF: EXPLODED VIEW»(ref-516440-S30023703952012120600000) " (sunroof).
  2. Disconnect antenna feeder connector.
  3. Remove nut to remove antenna base.

Install in the reverse order of removal.

CAUTIONIf the antenna base mounting nut is tightened looser than the specified torque, then this will lower the sensitivity of the antenna. On the other hand, if the nut is tightened tighter than the specified torque, then this will deform the roof panel.
  1. Remove glove box assembly. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Remove TEL adapter unit screws.
  3. Disconnect TEL adapter unit connectors to remove TEL adapter unit and bracket as a single unit.
  4. Remove bracket screws to remove TEL adapter unit.

Install in the reverse order of removal.

  1. Remove headlining. Refer to " «NORMAL ROOF: EXPLODED VIEW»(ref-516440-S26015776292012120600000) " (normal roof) or " «SUNROOF: EXPLODED VIEW»(ref-516440-S30023703952012120600000) " (sunroof).
  2. Remove microphone connector and pawl to remove microphone.

Install in the reverse order of removal.

  1. Remove glove box assembly. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Remove iPod adapter connector and screws.
  3. Remove iPod adapter and brackets from the vehicle as a single unit.
  4. Remove brackets screws to remove iPod adapter.

Install in the reverse order of removal.

  1. Remove glove box assembly. Refer to " «EXPLODED VIEW»(ref-516429-S42949579312012120600000) ".
  2. Push the pawl from the back of glove box assembly to remove iPod connector.

Install in the reverse order of removal.

Refer to " REMOVAL AND INSTALLATION ".

Install in the reverse order of removal.

Scheme 16

Scheme 16: Feeder Layout
Scheme 16: Feeder Layout
