Scheme 87
UNIQUE SWITCH
The switch integrates 2 types of LEDs*, filters that pass or absorb specified wavelengths (filter 1, filter 2), and filters adapted to both display colors (filter 3), enabling 2 different symbols to be displayed at a same position by LED changeover.
*: Abbreviation of light emitting diode. It is a semiconductor device that lights up when electric current is applied.
Operation description of unique switch
In drive mode
- LED1 lights up, the light from LED1 passes filter 1 and filter 3, and "ECO INFO" is displayed.
In air conditioner mode
Scheme 88
- LED2 lights up, the light from LED2 passes filter 2 and filter 3, and " " is displayed.
Scheme 89
MULTI DISPLAY UNIT INPUT/OUTPUT SINGNAL
| Reception unit | Signal name | Description |
|---|---|---|
| A/C auto amp. | A/C operation signal | Transmits the air conditioner operation status to the A/C auto amp. |
| ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. | |
| A/C ECO setting signal | Transmits the "CLIMATE ECO" ON/OFF status on the SET UP screen of the multi display unit. | |
| ECM (M/T models) | ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. |
| NORMAL mode signal | Transmits the "D-MODE" NORMAL switch status of the multi display unit. | |
| SPORT mode signal | Transmits the "D-MODE" SPORT switch status of the multi display unit. | |
| TCM (CVT models) | ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. |
| NORMAL mode signal | Transmits the "D-MODE" NORMAL switch status of the multi display unit. | |
| SPORT mode signal | Transmits the "D-MODE" SPORT switch status of the multi display unit. | |
| EPS control unit | ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. |
| NORMAL mode signal | Transmits the "D-MODE" NORMAL switch status of the multi display unit. | |
| SPORT mode signal | Transmits the "D-MODE" SPORT switch status of the multi display unit. |
OUTPUT SIGNAL
| Transmit unit | Signal name | Description |
|---|---|---|
| A/C auto amp. | A/C display signal | Receives a display signal according to the air conditioner status from the A/C auto amp. |
| ECM | Engine speed signal | Receives the engine speed signal. |
| Engine torque signal | Receives the engine torque signal calculated by ECM. | |
| Fuel consumption monitor signal | Receives the consumption monitor signal calculated by ECM. | |
| Boost pressure signal | Receives the boost pressure signal calculated by ECM. | |
| Engine status signal | Receives the engine status signal. | |
| BCM | Position light request signal | Receives a position light request signal according to the light switch status. |
| ABS actuator and electric unit (control unit) | Decel G sensor signal | Receives the decel. G sensor signal calculated by the ABS actuator and electric unit (control unit). |
| Side G sensor signal | Receives the side G sensor signal calculated by the ABS actuator and electric unit (control unit). | |
| Combination meter | Vehicle speed signal | Receives the vehicle speed signal. |
| Odometer signal | Receives the odometer signal. |
INPUT SIGNAL
DATA MONITOR
| Monitor item | Unit | Description |
|---|---|---|
| ECO SW | On / Off | Displays the ECO switch signal status sent via CAN communication. |
| NORMAL SW | On / Off | Displays the NORMAL switch signal status sent via CAN communication. |
| SPORTS SW | On / Off | Displays the SPORTS switch signal status sent via CAN communication. |
| BOOST PRESSURE | KPa | Displays the boost pressure signal value received from ECM via CAN communication. |
| ENGINE SPEED | Tr/min | Displays the engine speed signal value received from ECM via CAN communication. |
| ENGINE TORQUE | Nm | Displays the engine torque signal value received from ECM via CAN communication. |
| BATTERY VOLTAGE | V | Displays the input voltage value. |
| FUEL CONSUMPTION | Mm 3 | Displays the fuel consumption signal value received from ECM via CAN communication. |
| VEHICLE SPEED | Km/h | Displays the vehicle speed signal value received from the combination meter via CAN communication. |
| LONG ACC | G | Displays the decel G signal received from ABS actuator and electric unit (control unit) via CAN communication. |
| TRANCE ACC | G | Displays the side G signal received from ABS actuator and electric unit (control unit) via CAN communication. |
| DIST TOTAL | Km | Displays the mileage signal value received from the combination meter via CAN communication. |
| POSI LIGHT REQ | On / Off | Displays the parking lamp signal value received from BCM via CAN communication. |
| CLUSTER ILL REQ | On / Off | Displays the dimming signal value received from BCM via CAN communication. |
| ENGINE STATUS | STOP / STALL / RUN / CRA | Displays the engine status signal value received from ECM via CAN communication. |
| A/C SW (1) | On / Off | Displays the A/C switch signal status sent via CAN communication. |
| AUTO SW (1) | On / Off | Displays the AUTO switch signal status sent via CAN communication. |
| RR DEF SW (1) | On / Off | Displays the RR DEF switch signal status sent via CAN communication. |
| FR DEF SW (1) | On / Off | Displays the FR DEF switch signal status sent via CAN communication. |
| VENT SW1 (1) | On / Off | Displays the air outlet switch signal status sent via CAN communication. |
| VENT SW2 (1) | VENT / B/L / FOOT / D/F | Displays the air outlet switch signal status sent via CAN communication. |
| INTAKE SW (1) | On / Off | Displays the air intake switch signal status sent via CAN communication. |
| INTAKE SW LONG PUSH (1) | On / Off | Displays the air intake switch hold signal status sent via CAN communication. |
| OFF SW (1) | On / Off | Displays the OFF switch signal status sent via CAN communication. |
| TEMP SW1 (1) | On / Off | Displays the temperature control dial signal status sent via CAN communication. |
| FAN SW1 (1) | On / Off | Displays the fan control dial signal status sent via CAN communication. |
| A/C SW IND | On / Off | Displays the A/C switch indicator signal value received from the A/C auto amp. via CAN communication. |
| A/C INDICATOR | On / Off | Displays the A/C display signal value received from the A/C auto amp. via CAN communication. |
| OFF INDICATOR | On / Off | Displays the OFF display signal value received from the A/C auto amp. via CAN communication. |
| AIR VENT IND | Non-display / VENT / B/L / FOOT / D/F / DEF | Displays the air outlet indicator signal value received from the A/C auto amp. via CAN communication. |
| FR DEF SW IND | On / Off | Displays the RF DEF indicator signal value received from the A/C auto amp. via CAN communication. |
| FRE SW IND | On / Off | Displays the FRE indicator signal value received from the A/C auto amp. via CAN communication. |
| REC SW IND | On / Off | Displays the REC indicator signal value received from the A/C auto amp. via CAN communication. |
| RR DEF SW IND | On / Off | Displays the RR DEF indicator signal value received from the IPDM E/R via CAN communication. |
| AUTO IND | Off / Auto | Displays the AUTO indicator signal value received from the A/C auto amp. via CAN communication. |
| TEMP IND | °C | Displays the temperature setting unit signal value received from the A/C auto amp. via CAN communication. |
| FAN IND | Off / speed | Displays the fan setting signal value received from the A/C auto amp. via CAN communication. |
| (1) This is not used to determine ON/OFF of the indicator lamp. | ||
| (1) | This is not used to determine ON/OFF of the indicator lamp. |
PHYSICAL VALUES
Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 1 (Y) 10 (B) 11 (B) Battery power supply Input Ignition switch OFF 9 V - 16 V Battery power supply 2 (V) 10 (B) 11 (B) Illumination signal Input Ignition switch OFF Lighting switch 1ST position. 9 V - 16 V 12 V Lighting switch OFF position. 0 V 0 V 5 (GR) 10 (B) 11 (B) Illumination control signal Input Ignition switch ON Lighting switch 1ST position. When illumination control level is maximum. 0 V - 16 V Lighting switch 0 V - 16 V 1ST position. When illumination control level is midway. Lighting switch 1ST position. When meter illumination is minimum. 12 V 6 (L) - CAN-H - - - - 7 (SB) 10 (B) 11 (B) Ignition power supply Input Ignition switch ON 9 V - 16 V Battery power supply 12 (P) - CAN-L
