USB Box - Lancer: Other Mitsubishi Lancer X рестайлинг

Entertainment Systems 5 illustrations ~173 words

HOW TO INITIATE THE SERVICE MODE

Refer to MMCS - SERVICE MODE .

HOW TO TERMINATE THE SERVICE MODE

Refer to MMCS - SERVICE MODE .

Scheme 223

Scheme 223: HOW TO TERMINATE THE SERVICE MODE
Scheme 223: HOW TO TERMINATE THE SERVICE MODE

Scheme 224

Scheme 224
Scheme 224
  1. Select "USB BOX" on "Service" screen.
  2. Displays the version information of the USB box. NOTE: H/W version: The hardware version information of the USB box is displayed in 2 digits. S/W version: The software version information of the USB box is displayed in 7 digits.

The USB Adapter Data Cannot Be Replayed - Vehicles With Radio And CD Player

CAUTIONBefore replacing the USB box, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226

PROBABLE CAUSES

  1. The radio and CD player may be defective.
  2. The USB box may be defective.
  3. The USB adapter may be defective.
  4. The USB cable may be defective.
  5. Damaged harness wires and connectors

The USB Adapter Data Cannot Be Replayed - Vehicles With MMCS

CAUTIONBefore replacing the USB box, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 227

Scheme 227
Scheme 227
  1. The multivision display may be defective.
  2. The USB box may be defective.
  3. The USB adapter may be defective.
  4. The USB cable may be defective.
  5. Damaged harness wires and connectors
