GENERAL INFORMATION
To the Mitsubishi multi-communication system (MMCS), the multivision display (7-inch liquid crystal display of wide 2 DIN size) with built-in hard disk drive (40 GB) and CD/DVD drive has been installed. (The map data includes Hawaii, Alaska, Puerto Rico, and the Virgin Islands.)
Scheme 100
Scheme 101
Scheme 102
- The NAVTEQ map data has been stored. (Map data stored in hard disk drive)
- The 7-inch wide liquid crystal monitor has been adopted. The operation switch for operability has been equipped.
- Most sophisticated LSI* has been used as one for car navigation system. NOTE: *: LSI stands for Large Scale Integration, and is a large-scale integrated circuit (IC) containing between 1, 000 and 100, 000 circuit elements.
- U.S. English, French, and Spanish are available to select.
- Adopting the Rockford Fosgate® premium sound system enables a great variety of sound and field settings through communication with the audio amplifier.
- The hands free interface system can be used by connecting the hands free module.
- By attaching the satellite radio tuner, the SIRIUS™ satellite radio broadcasting becomes available.
- The language collaboration control between meter and hands free module is supported.
- The multivision display can be operated by the steering wheel audio remote control switch.
The audio and video adapter has been established to the center tray in order to connect visual equipment such as game machine and video player.
| Function | Content |
|---|---|
| Navigation | Displays the navigation functions including the map display, search, guidance, information search. Also, calculates Carpool/HOV lane. The sound volume of the navigation guidance varies according to the vehicle speed by the vehicle speed-linked function. |
| Current vehicle location | Displays the position information of current location. (Longitude and latitude, altitude, GPS reception status) |
| CD/DVD | Plays the CD or DVD inserted to the drive (Designed for MP3/WMA file) |
| Music server | Plays music recorded in the hard disk drive and records a music CD. |
| Radio | Displays the receiving station information. Also, the operation of receiving channel can be performed. |
| Sound control | Adjusts the high/middle/low tone and balance. Function to set music type, sound field, and others when adopting the Rockford Fosgate® premium sound system |
| AUX | Plays the image and sound input through the audio and video adapter. (Image cannot be seen during driving because of the driving restriction.) |
| USB/iPod | Plays the sound input through the USB adapter. |
| Drive information | Displays the average fuel consumption, instantaneous fuel consumption, possible cruising distance, driving time, and lap time. |
| Environmental data | Displays the atmospheric pressure, altitude and ambient temperature. |
| A/C information | Displays the A/C information. |
| ETACS function customization | ETACS-ECU customization function |
| Mobile Phone/Bluetooth Audio | Function to operate the hands free interface system using the multivision display < Vehicles with hands free module > |
| SIRIUS | Displays the receiving channel and receiving channel name, and changes the band ranges and channels. < Vehicles with satellite radio tuner > |
| Calendar | Displays the calendar. |
FUNCTION CHART
CIRCUIT OPERATION
CAN box unit receives the vehicle information stored in the ETACS-ECU via CAN bus lines.
TECHNICAL DESCRIPTION (COMMENT)
CAN box unit communicates with ETACS-ECU via CAN bus lines. This diagnostic trouble code is set when the vehicle information received from the ETACS-ECU is invalid.
In case of AM/FM radio broadcasting cannot be received, the roof antenna (antenna rod, antenna base), antenna fender or multivision display may have a problem.
Note. The radio wave may not be received if the vehicle is placed in the area which is exposed to a special electric field. Thus, check that the radio broadcasting can be received using the radio of another vehicle before carrying out diagnosis.
If the CAN box unit functions do not work at all, the CAN box unit power supply system, ground system, or CAN box unit may have a problem.
