Scheme 52
Scheme 53
- Two types of radio and CD player, radio and CD player or CD changer built-in type radio and CD player, have been established. The radio and CD player was designed to create a uniformity impression with the instrument panel. Also, a new function automatically corrects the sound quality and volume during driving.
The audio adapter has been established onto the center tray. With this modification, portable music player can be connected.
| Item | Radio and CD player | CD changer built-in type radio and CD player |
|---|---|---|
| Electronic tuning radio | Equipped | Equipped |
| SIRIUS satellite radio | Equipped (Only the vehicles with the satellite radio tuner) | |
| USB | Equipped (Only the vehicles with the USB box or hands free module) | Equipped (Only the vehicles with the USB box or hands free module) |
| Hands free interface system | Equipped (Only the vehicles with the hands free module) | Equipped (Only the vehicles with the hands free module) |
| CD player*1 (compatible with MP3*2) | Equipped | Equipped |
| 6-disk CD autochanger*1 (compatible with MP3*2) | Equipped | |
| Audio integrated 4-ch power amplifier and digital signal processor (DSP) | General 140 W | General 140 W |
| Audio amplifier-integrated 8-ch power amplifier and digital signal processor (DSP) | General 710 W (maximum) |
RADIO AND CD PLAYER REFERENCE CHART
Note. *1: CD-R/CD-RW may not be played. *2: Some may not be played.
TECHNICAL DESCRIPTION (COMMENT)
The audio unit, ETACS-ECU, or CAN bus line may have a problem.
The center panel assembly or CAN bus line may have a problem.
OPERATION
When the ignition switch is in the ON or ACC position, the radio and CD player power can be turned ON. With the radio and CD player power ON, when the ignition switch is turned to the OFF position, the power for radio and CD player is also turned OFF.
- When the position light is illuminated, the audio illumination is switched to the nighttime illumination.
- When the brightness is adjusted using the combination meter rheostat switch, the audio illumination brightness is also adjusted.
CIRCUIT OPERATION
Power is continuously supplied to the radio and CD player.
