Scheme 2
- Two types of radio and CD player, or CD changer built-in type radio and CD player have been established. The radio and CD player was designed to create a uniformity impression with the instrument panel.
The audio adapter has been established onto the center tray. With this modification, portable music player can be connected.
| Item | Radio and CD player | CD changer built-in type radio and CD player |
|---|---|---|
| Electronic tuning radio | Equipped | Equipped |
| SIRIUS™ satellite radio | Equipped (Only the vehicles with the satellite radio tuner) | Equipped (Only the vehicles with the satellite radio tuner) |
| Hands free interface system | Equipped (Only the vehicles with the hands free module) | Equipped (Only the vehicles with the hands free module) |
| CD player (1) (compatible with MP3 (2) ) | Equipped | Equipped |
| 6-disk CD autochanger (1) (compatible with MP3 (2) ) | Equipped | |
| Audio integrated 4-ch power amplifier and digital signal processor (DSP) | General 140 W | General 140 W |
| Audio amplifier-integrated 8-ch power amplifier and digital signal processor (DSP) < Rockford Fosgate® premium sound system > | General 710 W (maximum) | |
| (1) CD-R/CD-RW may not be played. (2) Some may not be played. | ||
| (1) | CD-R/CD-RW may not be played. |
| (2) | Some may not be played. |
GENERAL INFORMATION
TECHNICAL DESCRIPTION (COMMENT)
The audio unit, ETACS-ECU, or CAN bus line may have a problem.
The radio and CD player or CAN bus line may have a problem.
The radio and CD player or CAN bus line may have a problem.
The radio and CD player or CAN bus line may have a problem.
The radio and CD player or CAN bus line may have a problem.
The radio and CD player, center panel assembly, or CAN bus line may have a problem.
The center panel assembly or CAN bus line may have a problem.
OPERATION
When the ignition switch is in the ON or ACC position, the radio and CD player power can be turned ON. With the radio and CD player power ON, when the ignition switch is turned to the OFF position, the power for radio and CD player is also turned OFF.
Provided that the audio diagnostic trouble code is not set, if the power for radio and CD player cannot be turned ON, the radio and CD player, or power supply circuit for radio and CD player may have a problem, or the option coding information may be inconsistent.
If the audio sound is not output, the radio and CD player, audio amplifier, or power supply circuit of audio amplifier may have a problem, or the option coding information may be inconsistent.
If the sound is not output from one of the speakers, the speaker, radio and CD player, communication line from the radio and CD player to the speakers may have a problem.
If the sound is not heard from one of the speakers, the speaker, radio and CD player, audio amplifier, communication line from the radio and CD player to the audio amplifier, or communication line from the audio amplifier to the speaker may have a problem. Also, the option coding information may be inconsistent.
When the audio does not operate normally by operating the audio control unit of the center panel unit, the radio and CD player, center panel unit, or the power supply circuit system of center panel unit may be faulty.
- When the position light is illuminated, the audio illumination is switched to the nighttime illumination.
- When the brightness is adjusted using the combination meter rheostat switch, the audio illumination brightness is also adjusted.
The center panel unit, radio and CD player, combination meter, or communication line from the radio and CD player to the combination meter may have a problem.
If the external input sound is not output, the radio and CD player, audio communication line of radio and CD player, or audio adapter may have a problem.
See also:
• SYSTEM CHECK
