CENTRAL DOOR LOCKING SYSTEM DIAGNOSIS

The central door locking system is controlled by the simplified wiring system (SWS). For troubleshooting, refer to SIMPLIFIED WIRING SYSTEM (SWS) - LANCER - EVOLUTION .

POWER WINDOW DIAGNOSIS

The power window is controlled by the simplified wiring system (SWS). For troubleshooting, refer to SIMPLIFIED WIRING SYSTEM (SWS) - LANCER - EVOLUTION .

Glass & Door Diagnostic Troubleshooting Strategy

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a glass and door fault.

1. Gather information from the customer.
2. Verify that the condition described by the customer exists.
3. Find the malfunction by following the Symptom Chart.
4. Verify malfunction is eliminated.

Symptom Chart

SYMPTOM CHART

Diagnosis

1. STEP 1. Check the door window glass installation. Q: Is the door window glass installed correctly? YES: Go to Step 2. NO: Assemble the door window glass again (Refer to «DOOR ASSEMBLY»(ref-183226-S24050307232005081200000) ). Then go to Step 3 .
2. STEP 2. Check the clearance at the top of the door window glass. Q: Is the clearance at the top of the door window glass correct? YES: Go to Step 3. NO: Adjust the door window glass (Refer to «DOOR WINDOW GLASS ADJUSTMENT»(ref-183226-S38447558342005081200000) ). Then go to Step 3.
3. STEP 3. Retest the system. Q: Is any water leaking? YES: Return to Step 1. NO: The procedure is complete.

1. STEP 1. Check the door window glass installation condition. Q: Is the door window glass installed correctly? YES: Go to Step 2. NO: Assemble the door window glass again (Refer to «DOOR GLASS & REGULATOR»(ref-183226-S07213110912005081200000) ). Then go to Step 4 .
2. STEP 2. Check the door sash. Q: Is the door sash in good condition? YES: Go to Step 3. NO: Repair or replace the door sash, then go to Step 4 .
3. STEP 3. Inspect the window regulator assembly. Q: Is the window regulator assembly in good condition? YES: Go to Step 4. NO: Repair or replace the window regulator assembly, then go to Step 4.
4. STEP 4. Retest the system. Q: Does the door window glass operate correctly? YES: The procedure is complete. NO: Return to Step 1.

1. STEP 1. Check the weatherstrip. Q: Is the weatherstrip in good condition? YES: Go to Step 2. NO: Replace the weatherstrip, then go to Step 3 .
2. STEP 2. Check the door fit (alignment). Q: Is the door fit (alignment) correct? YES: Go to Step 3. NO: Adjust the door fit (Refer to «DOOR FIT ADJUSTMENT»(ref-183226-S09841358042005081200000) ). Then go to Step 3.
3. STEP 3. Retest the system. Q: Is any water leaking? YES: Return to Step 1. NO: The procedure is complete.

1. STEP 1. Check the drain hole. Q: Is the drain hole clogged? YES: Clean the drain hole, then go to Step 3 . NO: Go to Step 2.
2. STEP 2. Check the weatherstrip. Q: Is the weatherstrip in good condition? YES: Go to Step 3. NO: Repair or replace the weatherstrip, then go to Step 3.
3. STEP 3. Retest the system. Q: Is any water leaking? YES: Return to Step 1. NO: The procedure is complete.

1. STEP 1. Adjust the latch and striker engagement. Refer to «DOOR FIT ADJUSTMENT»(ref-183226-S09841358042005081200000) . Q: Is the latch and striker engagement adjusted? YES: Go to Step 2. NO: Adjust the latch and striker (Refer to «DOOR FIT ADJUSTMENT»(ref-183226-S09841358042005081200000) ). Then go to Step 4 .
2. STEP 2. Check for lock rod damage. Q: Is the lock rod damaged? YES: Repair or replace the lock rod, then go to Step 4 . NO: Go to Step 3.
3. STEP 3. Check the door handle flexibility (amount of movement of handle required to open door). Q: Is the door handle flexibility good? YES: Go to Step 4. NO: Adjust the door handle (Refer to «DOOR OUTSIDE HANDLE PLAY CHECK»(ref-183226-S00592613122005081200000) and «DOOR INSIDE HANDLE PLAY ADJUSTMENT»(ref-183226-S17058169552005081200000) ). Then go to Step 4.
4. STEP 4. Retest the system. Q: Does the door open easily? YES: The procedure is complete. NO: Return to Step 1.

1. STEP 1. Check the door hinge position. Q: Is the door hinge correct? YES: Go to Step 2. NO: Adjust the door hinge (Refer to «DOOR FIT ADJUSTMENT»(ref-183226-S09841358042005081200000) ). Then go to Step 4 .
2. STEP 2. Check the door. Q: Is the door in good condition? YES: Go to Step 3. NO: Repair or replace door, then go to Step 4 .
3. STEP 3. Check the grease. Q: Is the door check or door hinge grease sufficient? YES: Go to Step 4. NO: Apply the grease, then go to Step 4.
4. STEP 4. Retest the system. Q: Does the door open and close correctly? YES: The procedure is complete. NO: Return to Step 1.

Adjust the door fit (Refer to DOOR FIT ADJUSTMENT ). Then check that the gap has been improved.

1. STEP 1. Check the weatherstrip for holding condition. Q: Is the weatherstrip holding firmly? YES: Go to Step 2. NO: Adjust fit of door (Refer to «GLASS SLIDING MECHANISM CHECK & ADJUSTMENT»(ref-183226-S34630896552005081200000) ). Then go to Step 5 .
2. STEP 2. Check the weatherstrip for installation condition. Q: Is the weatherstrip for installed properly? YES: Go to Step 3. NO: Repair or replace the weatherstrip. Then go to Step 5 .
3. STEP 3. Check the clearance. Q: Are the door glass and the door weatherstrip holder assembled correctly? YES: Go to Step 4. NO: Adjust the door glass and the door weatherstrip (Refer to «GLASS SLIDING MECHANISM CHECK & ADJUSTMENT»(ref-183226-S34630896552005081200000) ). Then go to Step 5 .
4. STEP 4. Check the door. Q: Is the door deformed? YES: Repair or replace the door. Then go to Step 5. NO: Go to Step 5.
5. STEP 5. Retest the system. Q: Has the wind noise been improved? YES: Return to Step 1. NO: This diagnosis complete.

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Attach cloth tape to every place, such as panel seams, projections, molding seams, glass and body seams, etc. which might conceivably be the source of wind noise.
2. Then make a road test to check that the places not covered by tape are not sources of wind noise.
3. Remove the strips of tape one by one, making a road test after each is removed, until a wind noise source is discovered.
4. When such a place is found, cover it again and repeat the procedure to check if there are any other noise source.
5. If no others are found, the last remaining tape is the only source.
6. Cut the remaining piece of tape into smaller pieces, attach it again as it was before, and then remove the pieces one by one to narrow down the source.
7. Check that wind noise occurs when the last remaining tape is removed, and that noise does not occur when it is reattached.
8. When the source(s) of the wind noise is finally located, attach butyl tape, body sealer or similar material to obstruct this source as much as possible.

Scheme 28

Scheme 29

Scheme 30

CIRCUIT BREAKER (INCORPORATED IN THE POWER WINDOW MOTOR) INSPECTION

1. Pull the power window switch to the UP position to fully close the door window glass, and keep pulling the switch for 10 additional seconds.
2. Release the power window switch from the UP position and immediately press it to the DOWN position. The condition of the circuit breaker is good if the door window glass starts to move downwards within 60 seconds.

CENTRAL DOOR LOCKING SYSTEM INSPECTION

Check the following. Execute troubleshooting procedures if operations malfunction. (Refer to DIAGNOSIS in SWS DIAGNOSTIC TROUBLESHOOTING STRATEGY ). ).

1. Insert the key into the driver's key cylinder and turn once to the unlock side to unlock the driver's door. Turn the key once again to the unlock side to unlock all doors.
2. All doors can be locked or unlocked using the front door < RH > key cylinder key operation.
3. All door can be locked using the driver's inside door lock knob.
4. All doors can be locked using the door lock switch built into the front power window (main or sub < RH >) switch.
