DOOR OUTER OPENING WEATHERSTRIP
The left doors uses Natural (White) colored weather-stripping. The right doors use Pink weather-stripping.
WATERPROOF FILM
Use 3M(tm) AAD Part No. 8633 (ribbon seal) or equivalent.
POWER WINDOW TIMER FUNCTION CHECK
After the doors are closed and the ignition switch is turned to the LOCK (OFF) position, the power windows should work within 30 seconds. If not, carry out the troubleshooting. See MULTIPLEX CONTROL SYSTEMS article.
POWER WINDOW OPERATING CURRENT CHECK
- Remove the power window fuse and connect an ammeter as shown (Scheme 14)
- When the power window switch is pressed to the UP position, a large amount of current flows at the time the window starts to close and when it is fully closed, so measure the operation current in the interval between these 2 points. Standard value A) 4-6 Amps, [power supply voltage 14-15 volts at 25°C (77°F)].
- If the operation current is outside the standard value, see «MULTIPLEX CONTROL SYSTEMS»(ref-169966) article.
Scheme 14
POWER WINDOW MOTOR CHECK
- Connect a battery directly to the motor terminals and check that the motor runs smoothly.
- Check that the motor runs in the opposite direction when the battery is connected with the polarity reversed.
- If defect is found, replace the window regulator as an assembly.
Scheme 15
Scheme 16
Power Window Main Switch's Front (LH) Switch Check
Connect the terminal No. 13 to the battery positive post, and the terminal No. 12 to the battery negative post.
