Doors & Side Windows - Evolution: Removal & Installation Mitsubishi Lancer IX

Windows 19 illustrations ~314 words

>>A<< Striker Installation

Align the center of the striker and latch within 1.5 mm (0.06 inch), and install.

Scheme 31

Scheme 31: >>A<< Striker Installation

Scheme 32

Scheme 32: Door Switch Check

Scheme 33

Scheme 33

Scheme 34

Scheme 34: Removal & Installation

Scheme 35

Scheme 35

<< A >> Window Regulator Assembly/Power Window Regulator Motor Assembly Removal

  1. Remove the door window glass installation bolts. CAUTION: If film or others are adhered to the door window glass, attach special tool MB990480 to the outside of the glass to prevent the film from peeling off.
  2. Lift the door window glass, and attach special tool MB990480 to the glass as shown to prevent the glass from falling.
  3. Remove the window regulator assembly and power window motor assembly.

Scheme 36

Scheme 36

Scheme 37

Scheme 37: << B >> Center Sash Upper Removal
  1. Remove the door outer opening weatherstrip from the center sash upper only.
  2. Remove the center sash upper mounting screws, and then remove the center sash upper from the door panel.

>>A<< Center Sash Upper Installation

Securely insert the center sash upper into the window rear sash (door).

Installation

When installing the window regulator assembly, tighten the bolts to the specified torque in the order shown.

Scheme 38

Scheme 38: Installation

>>A<< Door Check Installation

Install the door check so that the identification mark faces upwards.

Scheme 39

Scheme 39: >>A<< Door Check Installation

Scheme 40

Scheme 40

>>B<< Lower Sash Installation

Securely insert the rear lower sash into the window rear sash.

Scheme 41

Scheme 41: >>C<< Door Inside Handle Installation
  1. Install the inside lock cable to the door inside handle as follows: Install the inner cable end in the inside lock cable to the clip in the door inside handle. Turn the inside lock knob to the door lock position. Install the outer cable end to the door inside handle securely. Install the clip to the inner cable.
  2. Install the inside handle rod to the door inside handle.
  3. Install the door inside handle to the door.

Scheme 42

Scheme 42: Front Door Lock Actuator Check

Scheme 43

Scheme 43: Actuator Operation Check

Scheme 44

Scheme 44: Actuator Switch Check < Left Side >

Scheme 45

Scheme 45: Actuator Operation Check

Scheme 46

Scheme 46

Scheme 47

Scheme 47: < Driver's Side>

Scheme 48

Scheme 48: < Passenger's Side >

Scheme 49

Scheme 49
