Power Windows - Except Evolution: Removal & Installation Mitsubishi Lancer IX

A) Door Inside Handle Cover Removal

1. Insert a flat-tipped screwdriver into the rear end of the tapping screw cap on the door inside handle cover, and pry out the cap to the direction shown. (Scheme 6) Then remove the tapping screw.
2. Insert special tool MB990784 into the clearance between the door inside handle cover and the door inside handle, and disengage the claws of the door inside handle. (Scheme 7)
3. Insert special tool MB990784 into the rear end of the inside handle cover, and pry out the cover to the direction shown (Scheme 7)

Scheme 6

Scheme 7

A) Waterproof Film Installation

Apply the specified adhesive on the waterproof film, then glue it on the door window glass. see scheme 4

Scheme 8

A) Window Regulator Assembly/Power Window Motor Assembly Removal

1. Remove the door window glass installation bolts.
2. Lift the door window glass, and attach special tool MB990480 to the glass as shown (Scheme 9)
3. Remove the window regulator assembly and power window motor assembly.

Scheme 9

B) Center Sash Upper Removal

1. Remove the door outer opening weatherstrip from the center sash upper only. (Scheme 10)
2. Remove the center sash upper mounting screws, and then remove the center sash upper from the door panel.

Scheme 10

A) Center Sash Upper Installation

Securely insert the center sash upper into the window rear sash (door).

B) Window Regulator Assembly/Power Window Motor Assembly Installation

When installing the window regulator assembly, tighten the bolts to the specified torque in the order shown. (Scheme 11)

Scheme 11

Scheme 12

Scheme 13
