Doors & Side Windows - Evolution: Other Mitsubishi Lancer IX

Windows 19 illustrations ~797 words

Central Door Locking System

The central door locking system operates the door lock actuator to lock or unlock the doors and liftgate using the operation of the door lock switch or key built into the driver's side inside door lock knob and front power window (main or sub) switch. The system has the following operations and features.

  1. Insert the key into the driver's key cylinder and turn once to the unlock side to unlock the driver's door. Turn the key once again to the unlock side to unlock all doors.
  2. All doors can be locked or unlocked using the front door < RH > key cylinder key operation.
  3. All doors and liftgate can be locked using the driver's inside door lock knob.
  4. All doors can be locked using the door lock switch built into the front power window (main or sub < RH >) switch.
  5. A key reminder function that automatically unlocks all doors when door lock operation is performed and the front doors are opened while the key is inserted into the ignition switch is provided.

Power Windows

When the power window (main or sub) switch is operated, the door windows will open or close. This system has the following operations and features

  1. There is a power window lock switch featured on the power window main switch to prevent the door window glass from opening/closing with the front passenger's and rear power window sub-switch.
  2. The power window of the door window glass can be opened/closed for 30 seconds with the timer function after the ignition switch is turned OFF. (The timer expires if the front door < LH or RH > is opened when the timer is in operation.)
  3. The power window main switch contains a one-touch down switch that will automatically open driver's side door window only.

POWER WINDOW TIMER FUNCTION CHECK

After the doors are closed and the ignition switch is turned to the "LOCK" (OFF) position, the power windows should work within 30 seconds. The timer expires at the point the front door is opened during that 30 second time. If not, carry out the troubleshooting. (Refer to DIAGNOSIS in SWS DIAGNOSTIC TROUBLESHOOTING STRATEGY ).

POWER WINDOW OPERATING CURRENT CHECK

  1. Remove the power window fuse and connect an ammeter as shown in the illustration.
  2. When the power window switch is pressed to the "UP" position, a large amount of current flows at the time the window starts to close and when it is fully closed, so measure the operation current in the interval between these two points. Standard value (A): 5 +/- 1A [Power supply voltage 14.5 +/- 0.5V,25°C (77°F)]
  3. If the operation current is outside the standard value, refer to POWER WINDOW in SYMPTOM CHART in SIMPLIFIED WIRING SYSTEM (SWS) - LANCER - EVOLUTION article.

Scheme 50

Scheme 50

Scheme 51

Scheme 51: POWER WINDOW RELAY CHECK

Scheme 52

Scheme 52

POWER WINDOW CHECK

  1. Operate the power window switch of each seat to check and see that the power windows operate properly. If they don't then execute troubleshooting remedies. (Refer to DIAGNOSIS in SWS DIAGNOSTIC TROUBLESHOOTING STRATEGY ). ).
  2. Turn ON the power window lock switch of the power window main switch. Then operate the passenger's seat and back seat's power window sub switch to ensure that they do not operate. If they do, replace the power window main switch. (Refer to «DOOR ASSEMBLY»(ref-183226-S24050307232005081200000) ).

DOOR OUTSIDE HANDLE PLAY CHECK

  1. Check that the door outside handle play is within the standard value range. Standard value (A): Front door: 2.3 +/- 2.1 mm (0.09 +/- 0.08 inch) Rear door: 1.3 +/- 1.7 mm (0.05 +/- 0.07 inch)
  2. If the door outside handle play is not within the standard value range, check the door outside handle or the door latch assembly. Replace, if necessary.

Scheme 53

Scheme 53

Scheme 54

Scheme 54: DOOR INSIDE HANDLE PLAY ADJUSTMENT
  1. Check that the door inside handle play is within the standard value range. Standard value (B): Front door: 10.4 +/- 9.6 mm (0.41 +/- 0.38 inch) Rear door: 10 +/- 9.6 mm (0.39 +/- 0.38 inch)
  2. If the door inside handle play is outside the standard value range.
  3. Remove the door trim assembly. (Refer to «DOOR TRIM»(ref-183233-S07753827192005081200000) ). ).
  4. Remove the waterproof film (Refer to «WINDOW GLASS RUNCHANNEL & DOOR OPENING WEATHERSTRIP REMOVAL & INSTALLATION»(ref-183226-S11247686002005081200000) .)
  5. Adjust the door inside handle play with the outer cable end connecting the door inside handle and inside lock cable.

Scheme 55

Scheme 55: REMOVAL & INSTALLATION

Power Window Main Switch's Front < LH > Switch Check

Connect the terminal number 13 to the battery (+) post, and the terminal number 12 to the battery (-) post.

Scheme 56

Scheme 56: Main Switch

Scheme 57

Scheme 57

Scheme 58

Scheme 58: Sub Switch

Scheme 59

Scheme 59

Scheme 60

Scheme 60: POWER WINDOW REGULATOR MOTOR CONTINUITY CHECK

Scheme 61

Scheme 61

Scheme 62

Scheme 62: REMOVAL & INSTALLATION

Central Door Lock Switch Continuity Check

Remove the power window switch. ( see scheme 21)

Scheme 63

Scheme 63: < Driver's Side >

Scheme 64

Scheme 64

Scheme 65

Scheme 65: < Passenger's Side >

Scheme 66

Scheme 66

Scheme 67

Scheme 67: < Front Door >

Scheme 68

Scheme 68: < Rear Door >
