Manual HVAC - Except Evolution: Adjustments Mitsubishi Lancer IX

Manual HVAC System 11 illustrations ~288 words

COMPRESSOR DRIVE BELT ADJUSTMENT

Refer to SPECIFICATIONS & DRIVE BELT ROUTING - EXCEPT EVOLUTION

ADJUSTMENT

  1. Select a quiet area for testing. Duplicate conditions as much as possible. Switch compressor on and off several times to clearly identify compressor noise. To duplicate high ambient conditions (high head pressure), restrict air flow through condenser. Install manifold gauge set to make sure discharge pressure doesn't exceed 2,070 kPa (300.2 psi).
  2. Tighten all compressor mounting bolts, clutch mounting bolt, and compressor drive belt. Check to assure clutch coil is tight (no rotation or wobble).
  3. Check refrigerant hoses for rubbing or interference that can cause unusual noises.
  4. Check refrigerant charge. (Refer to «PRESSURE SWITCH CHECK»(ref-183658-S06177086362005081800000) .)
  5. Recheck compressor noise as in Step 1 .
  6. If noise still exists, loosen compressor mounting bolts and retighten. Repeat Step 1 .
  7. If noise continues, replace compressor and repeat Step 1 .

Scheme 231

Scheme 231: BLOWER RELAY CONTINUITY CHECK

Scheme 232

Scheme 232

Scheme 233

Scheme 233: A/C COMPRESSOR RELAY CONTINUITY CHECK

Scheme 234

Scheme 234

Scheme 235

Scheme 235: FAN CONTROL RELAY CONTINUITY CHECK

Scheme 236

Scheme 236

>> D << AIR GAP ADJUSTMENT

Apply voltage from the battery to the magnetic clutch and check that the clutch air gap is inside the standard value. If outside the standard value, use a shim to adjust the gap.

  1. Standard value: 0.3 - 0.5 mm (0.012 - 0.020 inch)

Note. The shims are available in 0.05 mm steps across the thickness range 0.35 - 0.70 mm, and in 0.1 mm steps of thickness.

Scheme 237

Scheme 237

Scheme 238

Scheme 238: REFRIGERANT TEMPERATURE SWITCH
  1. Dip the metal part of the refrigerant temperature switch into engine oil and increase the oil temperature using a gas burner or similar. CAUTION: Do not heat more than necessary.
  2. When the oil temperature reaches the standard value, check the continuity between the terminals.

Scheme 239

Scheme 239

Scheme 240

Scheme 240

Scheme 241

Scheme 241: REMOVAL AND INSTALLATION
