FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Center member to frame bolt | 69 ± 10 N.m (51 ± 7 ft-lb) |
| Center member to crossmember bolt | 69 ± 10 N.m (51 ± 7 ft-lb) |
| Crossmember mounting bolt | 49 ± 10 N.m (36 ± 7 ft-lb) |
| Crossmember mounting nut | 167 ± 9 N.m (123 ± 7 ft-lb) |
| Cylinder clamp assembly bolt, gear box connecting bolt | 70 ± 10 N.m (52 ± 7 ft-lb) |
| Engine mount insulator to bracket bolt | 84 ± 17 N.m (62 ± 13 ft-lb) |
| Engine mount bracket to engine nut | 67 ± 7 N.m (50 ± 5 ft-lb) |
| Engine mount insulator to frame bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Front roll stopper to center member bolt | 35 ± 5 N.m (26 ± 4 ft-lb) |
| Front roll stopper to transaxle nut | 52 ± 7 N.m (39 ± 5 ft-lb) |
| Lower arm and crossmember connecting bolt front | 186 ± 10 N.m (137 ± 7 ft-lb) |
| Lower arm and crossmember connecting bolt rear | 167 ± 9 N.m (123 ± 7 ft-lb) |
| Lower arm to knuckle connecting nut | 108 ± 10 N.m (80 ± 7 ft-lb) |
| Oil pump eye bolt | 57 ± 7 N.m (42 ± 5 ft-lb) |
| Pressure tube flare nut | 15 ± 3 N.m (11 ± 2 ft-lb) |
| Rear roll bracket to harness clamp bolt | 11 ± 1 N.m (93 ± 13 in-lb) |
| Rear roll stopper to crossmember bolt | 35 ± 5 N.m (26 ± 4 ft-lb) |
| Rear roll stopper to rear roll mount bracket nut | 52 ± 7 N.m (39 ± 5 ft-lb) |
| Rear roll mount bracket to transaxle bolt | 69 ± 10 N.m (51 ± 7 ft-lb) |
| Stabilizer bracket bolt | 21 ± 4 N.m (16 ± 2 ft-lb) |
| Steering shaft and gear box connecting bolt | 18 ± 2 N.m (13 ± 2 ft-lb) |
| Transaxle mount to frame bolt | 82 ± 7 N.m (61 ± 5 ft-lb) |
| Transaxle mount to transaxle nut | 47 ± 7 N.m (35 ± 5 ft-lb) |
| Tie rod end to knuckle fixing nut | 25 ± 4 N.m (18 ± 3 ft-lb) |
