>> A << CAMSHAFT SPROCKET BOLT TIGHTENING
Use special tools MB990767 and MD998719 to prevent the camshaft sprocket from turning, and then tighten the camshaft sprocket bolt.
Scheme 396
- Tightening torque: 88 +/- 10 N.m (65 +/- 7 ft-lb)
Scheme 397
- Clean the hole in the crankshaft sprocket.
- Clean and degrease the mating surfaces of the crankshaft sprocket; sensing blade; and spacer NOTE: Degreasing is necessary to prevent decrease in friction between the mating surface due to presence of oil.
FASTENER TIGHTENING SPECIFICATIONS
| Items | Specifications |
|---|---|
| Generator and ignition system | |
| Ignition coil | 10 ± 2 N.m (89 ± 17 in-lb) |
| Spark plug | 25 ± 2 N.m (19 ± 3 ft-lb) |
| Crankshaft bolt | 182 ± 4 N.m (134 ± 3 ft-lb) |
| Generator brace (M10) | 49 ± 5 N.m (36 ± 3 ft-lb) |
| Generator brace (MB) | 23 ± 2 N.m (17 ± 1 ft-lb) |
| Lock bolt | 23 ± 2 N.m (17 ± 1 ft-lb) |
| Adjusting bolt | 5 ± 1 N.m (45 ± 8 in-lb) |
| Generator pivot nut | 44 ± 10 N.m (33 ± 6 ft-lb) |
| Cam position sensor | 8.8 ± 10 N.m (79 ± 9 in-lb) |
| Cam position sensor support | 14 ± 1 N.m (124 ± 9 in-lb) |
| Cam position sensing cylinder | 22 ± 4 N.m (16 ± 3 ft-lb) |
| Timing belt | |
| Camshaft sprocket bolt | 88 ± 10 N.m (65 ± 7 ft-lb) |
| Crank angle sensor | 9.8 ± 2.0 N.m (87 ± 17 in-lb) |
| Timing belt rear cover | 10 ± 2 N.m (89 ± 17 in-lb) |
| Timing belt tensioner | 23 ± 3 N.m (17 ± 2 ft-lb) |
| Engine support bracket, right | 49 ± 5 N.m (36 ± 3 ft-lb) |
| Timing belt cover | 10 ± 2 N.m (89 ± 17 in-lb) |
| Fuel system and emission system | |
| Fuel return pipe | 9 ± 2 N.m (88 ± 17 in-lb) |
| Fuel rail | 12 ± 1 N.m (102 ± 13 in-lb) |
| Fuel pressure regulator | 9 ± 2 N.m (88 ± 17 in-lb) |
| EGR Valve | 22 ± 4 N.m (16 ± 3 ft-lb) |
| Throttle body | 19 ± 3 N.m (14 ± 2 ft-lb) |
| Vacuum hose and pipe assembly | 11 ± 1 N.m (98 ± 8 in-lb) |
| Solenoid valve assembly | 9 ± 2 N.m (88 ± 17 in-lb) |
| Throttle body stay | 24 ± 3 N.m (17 ± 2 ft-lb) |
| Intake and exhaust manifold | |
| Manifold differential pressure sensor | 5 ± 1 N.m (45 ± 8 in-lb) |
| Exhaust manifold (M10) | 30 ± 2 N.m (21 ± 2 ft-lb) |
| Exhaust manifold (M8) | 17 ± 2 N.m (13 ± 1 ft-lb) |
| Oxygen sensor | 44 ± 5 N.m (33 ± 3 ft-lb) |
| Exhaust manifold bracket (M10) | 35 ± 6 N.m (26 ± 4 ft-lb) |
| Exhaust manifold bracket (M8) | 19 ± 3 N.m (14 ± 2 ft-lb) |
| Engine hanger | 19 ± 3 N.m (14 ± 2 ft-lb) |
| Oil dipstick guide | 14 ± 1 N.m (124 ± 9 in-lb) |
| Exhaust manifold cover | 13 ± 1 N.m (115 ± 8 in-lb) |
| Intake manifold | 19 ± 3 N.m (14 ± 2 ft-lb) |
| Intake manifold stay | 31 ± 3 N.m (23 ± 2 ft-lb) |
| Water pump and water hose | |
| Water pump | 23 ± 3 N.m (17 ± 2 ft-lb) |
| Water inlet pipe | 14 ± 1 N.m (124 ± 9 in-lb) |
| Thermostat case | 24 ± 1 N.m (17 ± 1 ft-lb) |
| Water inlet fitting | 19 ± 1 N.m (14 ± 1 ft-lb) |
| Water outlet fitting | 14 ± 1 N.m (124 ± 9 in-lb) |
| Engine coolant temperature gauge unit | 10.8 ± 1.0 N.m (96 ± 9 in-lb) |
| Engine coolant temperature sensor | 29 ± 9 N.m (22 ± 6 ft-lb) |
| Connector bracket | 14 ± 1 N.m (124 ± 9 in-lb) |
| Rocker arms and camshaft | |
| Rocker arm shaft | 31 ± 3 N.m (23 ± 2 ft-lb) |
| Rocker cover | 3.4 ± 0.5 N.m (30 ± 4 in-lb) |
| Cylinder head and valves | |
| Cylinder head bolt [74 N.m (54 ft-lb) and then completely loosen finally tighten] | 20 N.m + 90° + 90° (15 ft-lb + 90° + 90°) |
| Oil pump and oil pan | |
| Oil pump cover | 10 ± 2 N.m (89 ± 17 in-lb) |
| Front case | 14 ± 1 N.m (124 ± 9 in-lb) |
| Relief plug | 44 ± 5 N.m (33 ± 3 ft-lb) |
| Oil screen | 19 ± 3 N.m (14 ± 2 ft-lb) |
| Upper oil pan (M8) | 24 ± 3 N.m (17 ± 2 ft-lb) |
| Upper oil pan (M6) | 9 ± 3 N.m (80 ± 26 in-lb) |
| Lower oil pan | 11 ± 1 N.m (98 ± 8 in-lb) |
| Baffle plate | 11 ± 1 N.m (98 ± 8 in-lb) |
| Cover | 7 ± 1 N.m (62 ± 8 in-lb) |
| Drain plug | 39 ± 5 N.m (29 ± 3 ft-lb) |
| Oil pressure switch | 10 ± 2 N.m (89 ± 17 in-lb) |
| Piston and connecting rod | |
| Connecting rod cap nut | 20 ± 2 N.m + 90° to 100° (15 ± 1 ft-lb + 90° to 100°) |
| Crankshaft and cylinder block | |
| Bearing cap bolt | 25 ± 2 N.m + 90° to 100° (18 ± 1 ft-lb + 90° to 100°) |
| Oil seal case | 11 ± 1 N.m (98 ± 8 in-lb) |
| Rear plate | 11 ± 1 N.m (98 ± 8 in-lb) |
| Drive plate bolt | 98 ± 5 N.m (72 ± 3 ft-lb) |
| Flywheel bolt | 98 ± 5 N.m (72 ± 3 ft-lb) |
| Knock sensor | 23 ± 2 N.m (17 ± 1 ft-lb) |
FASTENER TIGHTENING SPECIFICATIONS
GENERAL SPECIFICATIONS
| Descriptions | Specifications | ||
|---|---|---|---|
| Type | In-line OHV, SOHC | ||
| Number of cylinders | 4 | ||
| Combustion chamber | Pentroof type | ||
| Total displacement dm 3 (cubic inches) | 1,999 (122) | ||
| Cylinder bore mm (in) | 81.5 (3.21) | ||
| Piston stroke mm (in) | 95.8 (3.77) | ||
| Compression ratio | 9.5 | ||
| Number of valve | Intake | 8 | |
| Exhaust | 8 | ||
| Valve timing | Intake valve | Opens (BTDC) | 2° |
| Closes (ABDC) | 58° | ||
| Exhaust valve | Opens (BBDC) | 58° | |
| Closes (ATDC) | 10° | ||
| Lubrication system | Pressure feed, full-flow filtration | ||
| Oil pump type | Trochoid type | ||
| Cooling system | Water-cooled forced circulation | ||
| Water pump type | Centrifugal impeller type | ||
