REMOVAL AND INSTALLATION
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 322
>> A << ENGINE FRONT MOUNTING CUSHION STOPPER INSTALLATION
Arrow marks on the engine front mounting cushion stopper should face the shown direction.
Note. Disregard F and R stamped as a shared part.
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 323
>> A << TRANSAXLE MOUNTING STOPPER INSTALLATION
Install the transaxle mounting stopper so that its arrow points upward.
Scheme 324
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 325
Scheme 326
>> A << ENGINE FRONT ROLL STOPPER BRACKET INSTALLATION
Install the front roll stopper so that its hole points towards the front side of the vehicle.
| CAUTION | Before removing the steering wheel and air bag module assembly, always refer to AIR BAG RESTRAINT SYSTEMS article. Also, set the front wheels so that they are facing straight forward, and remove the ignition key. If you fail to do this, the SRS clock spring will be damaged, causing the SRS air bag to be inoperative and serious injury. *1: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. *2: Indicates parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in the unladen condition. If the vehicle is equipped with the Brembo™ disc brake, during maintenance, take care not to contact the parts or tools to the caliper because the paint of caliper will be scratched. |
Scheme 327
Required Special Tool
- MB991897: Ball Joint Remover
<< A >> LOWER ARM ASSEMBLY REMOVAL
Lift the transaxle with a transmission jack, and then withdraw the front mounting bolt on the left lower arm assembly.
Scheme 328
<< C >>FRONT AXLE NO.1 CROSSMEMBER ASSEMBLY REMOVAL
Retain the crossmember with a transmission jack, and then remove the crossmember mounting bolt.
Scheme 329
>> A << STABILIZER BAR INSTALLATION
Align the identification color on the left side of the stabilizer bar with the right end of the bushing.
