Engine - Intake-Air System - Hybrid: Other Mazda Tribute II

Mechanical 8 illustrations ~405 words

INTAKE AIR DISTRIBUTION AND FILTERING - HYBRID

The air intake system consists of the

  1. Air cleaner (ACL) pipe
  2. Engine ACL
  3. ACL element
  4. Intake air resonator assembly
  5. Mass air flow (MAF) sensor
  6. ACL outlet pipe

The intake air system

  1. cleans intake air with a replaceable, ACL element
  2. measures airflow and air temperature with the MAF sensor.

The engine ACL element is made of treated, pleated paper. A new ACL element must be installed periodically as scheduled. Engine performance and fuel economy are adversely affected when maximum restriction of the ACL element is reached.

Scheme 1000

Scheme 1000: INTAKE AIR SYSTEM EXPLODED VIEW - HYBRID
Scheme 1000: INTAKE AIR SYSTEM EXPLODED VIEW - HYBRID

Scheme 1001

Scheme 1001
Scheme 1001

Scheme 1002

Scheme 1002
Scheme 1002
  1. For additional information, see the appropriate procedure(s).

Scheme 1003

Scheme 1003: INTAKE MANIFOLD REMOVAL/INSTALLATION - HYBRID
Scheme 1003: INTAKE MANIFOLD REMOVAL/INSTALLATION - HYBRID

Scheme 1004

Scheme 1004
Scheme 1004

Scheme 1005

Scheme 1005
Scheme 1005

Scheme 1006

Scheme 1006
Scheme 1006

Scheme 1007

Scheme 1007
Scheme 1007
  1. With the vehicle in NEUTRAL, position it on a hoist. See «LIFTING»(ref-373073-S06960946762010100600000) .
  2. Release the fuel pressure. See «FUEL SYSTEM PRESSURE RELEASE»(ref-348657-S11437714852009112700000) .
  3. Disable the vehicle high-voltage electrical system. CAUTION: Before removing the high-voltage cables, the vehicle electrical system must be completely shut down for at least 5 minutes to allow for the high-voltage capacitors to discharge.
  4. Remove the fuel rail. See «FUEL RAIL AND FUEL INJECTOR EXPLODED VIEW -- 2.5L»(ref-348657-S12020442732009112700000) .
  5. Remove the Throttle Body (TB). See «THROTTLE BODY REMOVAL/INSTALLATION - HYBRID»(ref-373096-S18823737122010100600000) .
  6. Remove the accessory drive belt tensioner. See «ACCESSORY DRIVE BELT TENSIONER - HYBRID REMOVAL/INSTALLATION»(ref-373078-S24857711742010100600000) .
  7. Disconnect the Engine Oil Pressure (EOP) switch electrical connector.
  8. Disconnect the Manifold Absolute Pressure (MAP) sensor electrical connector.
  9. Disconnect the Evaporative Emission (EVAP) canister purge valve electrical connector.
  10. Disconnect the EVAP tube-to-EVAP canister purge valve quick connect coupling and the brake booster vacuum tube from the intake manifold.
  11. Disconnect the Knock Sensor (KS) electrical connector and detach the 2 pin-type retainers.
  12. Detach the 2 wiring retainers from the intake manifold near the throttle body mounting area.
  13. Detach the transaxle shift cable routing retainer from the intake manifold.
  14. Remove the cooling fan motor and shroud. See «COOLING FAN MOTOR AND SHROUD REMOVAL/INSTALLATION - HYBRID»(ref-373089-S41567519492010100600000) .
  15. Remove the 7 bolts and position the intake manifold aside to access the PCV hose connector. To install, tighten to 18 N.m {1.8 kgf.m, 159 in.lbf}. NOTE: The cylinder head side of the intake manifold is showing the location of the 7 bolts.
  16. Squeeze the 2 PCV hose connector tabs and disconnect the PCV hose from the intake manifold.
  17. Remove the intake manifold and gaskets.
  18. To install, reverse the removal procedure. Inspect and install new intake manifold gaskets if necessary.
