Park Position Clutch Application Chart
| Gear/Manual Lever Position | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| PARK | X |
PARK POSITION CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 463
Reverse Position Clutch Application Chart
| Gear/Manual Lever Position | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| REVERSE | X | X |
REVERSE POSITION CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 464
Neutral Position Clutch Application Chart
| Gear/Manual Lever Position | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| NEUTRAL | X | X |
NEUTRAL POSITION CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 465
1st Gear Above 6 km/h (4 mph) Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 1st gear | X | X |
1ST GEAR ABOVE 6 KM/H (4 MPH) CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 466
2nd Gear Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 2nd gear | X | X |
2ND GEAR CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 467
3rd Gear Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 3rd gear | X | X |
3RD GEAR CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 468
4th Gear Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 4th gear | X | X |
4TH GEAR CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
5th Gear Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 5th gear | X |
5TH GEAR CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
6th Gear Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 6th gear | X | X | X |
6TH GEAR CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Manual LOW Position and 1st Gear Below 6 km/h (4 mph) Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 1st gear | X | X | X |
MANUAL LOW POSITION AND 1ST GEAR BELOW 6 KM/H (4 MPH) CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
Scheme 469
5th Gear Failsafe Clutch Application Chart
| Gear | Direct (3, 5, R) | Overdrive (4, 5, 6) | Forward (1, 2, 3, 4) | Low/Reverse (L, R) | Intermediate (2, 6) | One-Way |
|---|---|---|---|---|---|---|
| 5th gear | X | X |
5TH GEAR FAILSAFE CLUTCH APPLICATION CHART
For component information, see MECHANICAL COMPONENTS AND FUNCTIONS .
