Power Retractable Hardtop

CAUTIONWhen removing/installing or transporting the audio amplifier, hold it by its front waterproof cover. Otherwise the waterproof cover could deform and water penetration could cause the audio amplifier to malfunction. Always keep the front waterproof cover for the audio amplifier as the bottom surface when storing the audio amplifier. Otherwise the waterproof cover could deform and water penetration could cause the audio amplifier to malfunction.

Scheme 58

Scheme 58
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) )
  4. Remove in the order indicated in the illustration.
  5. Install in the reverse order of removal.

Scheme 59

Scheme 59

Antenna Amplifier

  1. Turn on the audio unit and radio, and measure the voltage at manual antenna connector terminal C. If the voltage is B+, inspect the manual antenna. If the voltage is not B+, inspect the audio unit or the antenna feeder.

Scheme 60

Scheme 60

Feeder

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Disconnect the manual antenna connector.
  4. Inspect for continuity between the manual antenna terminals using an ohmmeter. If not as specified, replace the manual antenna.

Scheme 61

Scheme 61

Scheme 62

Scheme 62
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Seat (RH) (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) ) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) ) Side shelf (RH) (See «SIDE SHELF REMOVAL/INSTALLATION»(ref-430296-S33668404262011101700000) ) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) ) Partition board (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) ) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S12262640872011101700000) )
  4. Disconnect the antenna feeder No. 1.
  5. Remove the clip A.
  6. Partially peel back the floor covering.
  7. Detach clips B.
  8. Detach clips C.
  9. Disconnect the wiring harness from the clip D.
  10. Disconnect the connector.
  11. Detach clips D and E.
  12. Remove the antenna feeder No. 2.
  13. Install in the reverse order of removal.
