Entertainment System: Overview Mazda MX-5 NC рестайлинг

Scheme 1

Scheme 2

Scheme 3

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-430296-S25778296992011101700000) )
4. Remove the knee bolster. (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-430296-S09121117682011101700000) )
5. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) )
6. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) )
7. Remove the installation bolt. CAUTION: The center panel unit may be damaged if it is pulled out with the installation bolt installed. Verify that the installation bolt is removed before pulling out the center panel unit.
8. Remove in the order indicated in the illustration.
9. Install in the reverse order of removal. CAUTION: When installing the center panel unit, make sure that the wiring harness and antenna feeder are not caught between the unit and dashboard. If the wiring harness or the antenna feeder is caught between the unit and dashboard, it may cause malfunctions.

Scheme 4
