CENTER PANEL UNIT DISASSEMBLY/ASSEMBLY
| CAUTION | Before disassembling the center panel unit, spread a cloth on the floor to put the disassembled parts on. This protects the surface of the panel from scratches or dirt. |
- Disassemble in the order indicated in the illustration.
- Assemble in the reverse order of disassembly.
Scheme 55
Screw A Assemble Note
- Tighten screws A at the position shown in the illustration.
Scheme 56
Scheme 57
Scheme 57: Except Power Retractable Hardtop
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
- Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat belt set plate (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) ) Seat back crossmember assembly (See «SEAT BACK CROSSMEMBER ASSEMBLY REMOVAL/INSTALLATION»(ref-430315-S38025087972011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) ) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-430296-S26289501072011101700000) )
- Remove in the order indicated in the illustration.
- Install in the reverse order of removal.
