Entertainment System: Diagnosis Mazda MX-5 NC рестайлинг

Entertainment Systems 22 illustrations ~808 words

DOOR SPEAKER INSPECTION

  1. Verify the resistance between door speaker terminals. If the resistance is not within the specification, replace the door speaker. Resistance Without Bose®: 4 ohms With Bose®: 1 ohm
  2. Connect a 1.5 V battery to the door speaker and verify that noise is heard from the door speaker. If no noise is heard, replace the door speaker.

Scheme 5

Scheme 5
Scheme 5

CENTER SPEAKER INSPECTION

  1. Verify the resistance between center speaker terminals. If the resistance is not within the specification, replace the center speaker. Resistance 3.6 ohms
  2. Connect a 1.5 V battery to the center speaker and verify that noise is heard from the center speaker. If no noise is heard, replace the center speaker.

Scheme 6

Scheme 6
Scheme 6

MANUAL ANTENNA INSPECTION

Note. A amplifier is built into the manual antenna.

SIRIUS SATELLITE RADIO ANTENNA INSPECTION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Disconnect the SIRIUS satellite radio antenna connector. (See «SIRIUS SATELLITE RADIO ANTENNA REMOVAL/INSTALLATION»(ref-430309-S33302479452011101700000) )
  4. Verify that the continuity between SIRIUS satellite radio antenna terminals is as indicated in illustration. If not as indicated in the chart, replace the SIRIUS satellite radio antenna.

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION
Scheme 9: SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) ) Partition board (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) ) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S12262640872011101700000) )
  4. Remove in the order indicated in the illustration.
  5. Install in the reverse order of removal.

Scheme 10

Scheme 10: ANTENNA FEEDER LOCATION
Scheme 10: ANTENNA FEEDER LOCATION

ANTENNA FEEDER NO. 1 INSPECTION

  1. Verify that the continuity is as indicated in the chart. If not as indicated in the chart, replace the antenna feeder No. 1.

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: Except Power Retractable Hardtop
Scheme 13: Except Power Retractable Hardtop

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Seat (RH) (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) ) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat belt set plate (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) ) Seat back crossmember assembly (See «SEAT BACK CROSSMEMBER ASSEMBLY REMOVAL/INSTALLATION»(ref-430315-S38025087972011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) ) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-430296-S26289501072011101700000) ) Side shelf (RH) (See «SIDE SHELF REMOVAL/INSTALLATION»(ref-430296-S33668404262011101700000) ) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) ) Partition board (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) ) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S12262640872011101700000) )
  4. Disconnect the antenna feeder No. 1.
  5. Remove the clip A.
  6. Partially peel back the floor covering.
  7. Detach clips B.
  8. Detach clips C.
  9. Disconnect the wiring harness from the clip D.
  10. Disconnect the connector.
  11. Detach clips D and E.
  12. Remove the antenna feeder No. 2.
  13. Install in the reverse order of removal.

ANTENNA FEEDER NO. 2 INSPECTION

  1. Verify that the continuity is as indicated in the chart. If not as indicated in the chart, replace the antenna feeder No. 2.

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19: SIRIUS SATELLITE RADIO ANTENNA FEEDER REMOVAL/INSTALLATION
Scheme 19: SIRIUS SATELLITE RADIO ANTENNA FEEDER REMOVAL/INSTALLATION

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) ) Partition board (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) ) Trunk side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) )
  4. Disconnect the SIRIUS satellite radio antenna connector. (See «SIRIUS SATELLITE RADIO ANTENNA REMOVAL/INSTALLATION»(ref-430309-S33302479452011101700000) )
  5. Pull the SIRIUS satellite radio antenna feeder cover No. 1 outward and detach clips A.
  6. Detach clip B.
  7. Cut the band.
  8. Pull the SIRIUS satellite radio antenna feeder cover No. 2 outward and detach pin C, clip D and E.
  9. Detach clip F.
  10. Detach clip G and H.
  11. Disconnect the connector.
  12. Remove the SIRIUS satellite radio antenna feeder.
  13. Install in the reverse order of removal.

Scheme 23

Scheme 23
Scheme 23

SIRIUS SATELLITE RADIO ANTENNA FEEDER INSPECTION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) ) Partition board (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) ) Trunk side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) )
  4. Disconnect the SIRIUS satellite radio antenna connector. (See «SIRIUS SATELLITE RADIO ANTENNA REMOVAL/INSTALLATION»(ref-430309-S33302479452011101700000) )
  5. Disconnect the SIRIUS satellite radio antenna feeder connector. (See «SIRIUS SATELLITE RADIO ANTENNA FEEDER REMOVAL/INSTALLATION»(ref-430309-S09552443452011101700000) )
  6. Verify that the continuity is as indicated in illustration. If not as indicated in the chart, replace the SIRIUS satellite radio antenna feeder.

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

ACCESSORY SOCKET INSPECTION

  1. Connect a tester as shown in the illustration and verify that there is continuity. If the continuity cannot be verified, replace the accessory socket.

Scheme 26

Scheme 26
Scheme 26
