Entertainment System: Removal & Installation Mazda MX-5 NC рестайлинг

Center Panel Unit Removal Note

1. Pull the center panel unit outward, detach clip A from the dashboard, and then remove the center panel unit.
2. When removing the center panel unit, disconnect the audio unit connector (24-pin) first to aid in disconnecting other connectors and the antenna plug.

DOOR SPEAKER REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-430296-S08313422672011101700000) )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 27

Door Speaker Installation Note

1. Remove the door speaker with the wiring harness passing through the groove of the door module.

Scheme 28

CENTER SPEAKER REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 29

Center Speaker Cover Removal Note

1. Insert a tape-wrapped fastener remover into the service hole.
2. Pry with the tape-wrapped fastener remover in the direction shown in illustration by the arrow to remove the center speaker cover.

Scheme 30

REAR SPEAKER REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Hands-free telephone (HF/TEL) unit (with HF/TEL system) (See «HANDS-FREE TELEPHONE (HF/TEL) UNIT REMOVAL/INSTALLATION»(ref-430309-S33780907172011101700000) )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 31

Scheme 32

1. Inspect for resistance between the rear speaker terminals using an ohmmeter. If the resistance is not within the specification, replace the rear speaker. Resistance Without Bose®: 8 ohms With Bose®: 3.6 ohms

TWEETER/DOOR UPPER SPEAKER REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-430296-S08313422672011101700000) )
4. Disconnect the connector.
5. Remove the screws.
6. Remove the tweeter/door upper speaker (with Bose®).
7. Install in the reverse order of removal.

Scheme 33

Scheme 34

1. Inspect for resistance between the tweeter terminals using an ohmmeter. If the resistance is not within the specification, replace the tweeter. Resistance 4 ohms

Scheme 35

1. Inspect for resistance between the door upper speaker terminals using an ohmmeter. If the resistance is not within the specification, replace the door upper speaker. Resistance 3.6 ohms

AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION

Note. AudioPilot®2 is a registered trademark of Bose® Corporation.

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 36

CONDENSER REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat belt set plate (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) ) Seat back crossmember assembly (See «SEAT BACK CROSSMEMBER ASSEMBLY REMOVAL/INSTALLATION»(ref-430315-S38025087972011101700000) ) Rear side trim (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S18640304332011101700000) ) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-430296-S26289501072011101700000) )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 37

MANUAL ANTENNA REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 38

Mounting Nut Removal Note

1. Use snap-ring pliers to remove the mounting nut.

Scheme 39

SIRIUS SATELLITE RADIO ANTENNA REMOVAL/INSTALLATION

Scheme 40

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Open the SIRIUS satellite radio antenna feeder cover No. 1 in the direction of arrow (1).
4. Disconnect the connector.
5. Remove in the order indicated in the illustration.
6. Install in the reverse order of removal.

SIRIUS Satellite Radio Antenna Removal Note

1. While pressing the tabs, pull the SIRIUS satellite radio antenna outwards.

Scheme 41

SIRIUS Satellite Radio Antenna Installation Note

1. When installing the ground plate, align the SIRIUS satellite radio antenna notch with the ground plate projection, and then install it.

Scheme 42

ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-430296-S12626857422011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) ) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-430309-S35925058662011101700000) ) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-430296-S25778296992011101700000) ) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-430296-S09121117682011101700000) ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) ) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-430310-S13032094912011101700000) ) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) ) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-430298-S03665070312011101700000) ) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) ) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-430296-S15633193382011101700000) ) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-430312-S33964143232011101700000) ) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-430296-S24557577942011101700000) ) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-430313-S32529974172011101700000) ) Female wedge (See «CONVERTIBLE TOP DISASSEMBLY/ASSEMBLY»(ref-430307-S36837664932011101700000) ) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-430296-S17095533582011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S34429732322011101700000) ) Fuse box No. 1 Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-430296-S01303206792011101700000) )
4. Remove clips A and B.
5. Disconnect the connector.
6. Remove the antenna feeder No. 1.
7. Install in the reverse order of removal.

Scheme 43

AUDIO CONTROL SWITCH REMOVAL/INSTALLATION

Note. For vehicles with the cruise control system, the audio control switch harness and the cruise control switch harness are united, therefore they cannot be separated.

Scheme 44

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-430310-S13032094912011101700000) )
4. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) )
5. Remove in the order indicated in the illustration.
6. Install in the reverse order of removal.

Scheme 45

Scheme 46

1. Verify the resistance and continuity between the audio control switch terminals. If the resistance and continuity are not as indicated in illustration, replace the audio control switch.
2. Verify that the LED illuminates. If the LED does not illuminate, replace the audio control switch.

MICROPHONE REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .
3. Remove the meter hood. (See «METER HOOD REMOVAL/INSTALLATION»(ref-430296-S15633193382011101700000) )
4. Remove the microphone in the direction of the arrow (2) shown in the illustration while pressing the microphone tabs in the direction of the arrow (1).
5. Install in the reverse order of removal.

Scheme 47

Scheme 48

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Front seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) )
4. Remove in the order indicated in the illustration.
5. Install in the reverse order of removal.

Scheme 49

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) )
4. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) )
5. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) )
6. Remove in the order indicated in the illustration.
7. Install in the reverse order of removal.

Accessory Socket Removal Note

1. While pressing a tape-wrapped fastener remover against the cap projection, pull the accessory socket outward.

Scheme 50

Cap Removal Note

1. While pressing the tabs, pull the cap outwards.

Scheme 51

AUXILIARY JACK REMOVAL/INSTALLATION

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) )
4. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) )
5. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) )
6. While pressing the tabs, pull the auxiliary jack.
7. Install in the reverse order of removal.

Scheme 52

Scheme 53

Scheme 54

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) ) Auxiliary jack (See «AUXILIARY JACK REMOVAL/INSTALLATION»(ref-430309-S21433703522011101700000) )
4. Connect a commercially-available nonresistant plug to the auxiliary jack.
5. Verify that the continuity between the auxiliary jack terminals is as indicated in illustration. If not as indicated in the chart, replace the auxiliary jack.
