Wiring color codes
- Two-color wires are indicated by a two-color code symbol.
- The first letter indicates the base color of the wire and the second the color of the stripe.
| CODE | COLOR | CODE | COLOR |
|---|---|---|---|
| B | Black | O | Orange |
| BR | Brown | P | Pink |
| G | Green | R | Red |
| GY | Gray | V | Violet |
| L | Blue | W | White |
| LB | Light Blue | Y | Yellow |
| LG | Light Green |
WIRING COLOR CODES CHART
Scheme 21
Scheme 22
Scheme 23
- When replacing a fuse, be sure to replace it with one of the same capacity. If a fuse fails again, the circuit probably has a short and the wiring should be inspected.
- Be sure the negative battery terminal is disconnected before replacing a main fuse.
- When replacing a pullout fuse, use the fuse puller.
Vehicle harness-side connector
The viewing direction of vehicle harness-side connectors is from the harness side.
* : Part names are shown in illustration only when there are multiple connector drawings.
