SELECTOR LEVER REMOVAL/INSTALLATION
| WARNING | Handling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read AIR BAG SAFETY PRECAUTIONS before handling the air bag module. See AIR BAG SAFETY PRECAUTIONS . |
Scheme 272
- Disconnect the negative battery cable.
- Remove in the order indicated in the figure.
- Install in the reverse order of removal.
- Inspect the shift-lock. (See «SHIFT-LOCK INSPECTION»(ref-178053-S33674445982005061000000) .)
- Inspect the shift-lock release lever. (See «SHIFT-LOCK RELEASE LEVER INSPECTION»(ref-178053-S21861779992005061000000) .)
- Inspect the key interlock system. (See «KEY INTERLOCK INSPECTION»(ref-178053-S35013998342005061000000) .)
Scheme 273
Scheme 273: SELECTOR CABLE INSTALLATION NOTE
Scheme 274
Scheme 275
Scheme 276
- Shift the selector lever and manual shaft to P position. CAUTION: Bending the selector cable as shown in the figure will damaged the cable and cause it to become loose during shifting. When handling and installing the selector cable, hold it straight.
- Install the selector cable to the manual shaft lever so that the spring side of the selector cable end faces upward.
- Install the selector cable to the steering shaft bracket securely.
- Install the selector cable to the selector lever bolt.
- Install nut A onto the selector lever bolt temporarily.
- Pull the selector lever to the R position side gate of P position, and tighten nut A. Tightening Torque 16-22 N.m {1.6-2.3 kgf.m, 12-16 ft.lbf}
- Verify that the selector lever bolt end is exposed from the nut.
