Automatic Transaxle - Service, Removal & Installation [JA5AEL]: Maintenance Mazda MPV II рестайлинг

Automatic Trans 3 illustrations ~280 words

OIL COOLER FLUSHING

CAUTIONPower flushing should be performed very carefully when removing the accumulated debris from the fluid baffle, otherwise the debris cannot be removed or the problem becomes even worse.

Note. The contaminated cooler line (oil pipes and hoses) and auxiliary cooler (if equipped) must be flushed completely when ATX is overhauled or replaced. Performing back and reverse power flushing two times each does not work because debris or particles flow out from the feed pipe side of ATX.

Scheme 247

Scheme 247: RECOMMENDED POWER-FLUSHING MANUFACTURER
Scheme 247: RECOMMENDED POWER-FLUSHING MANUFACTURER

Back Flushing

  1. Using the power flushing equipment manufacturer's instructions, connect equipment so the flushing fluid flows in the opposite direction of normal fluid flow.
  2. Flush oil cooler/lines until discharge fluid is clean.

Scheme 248

Scheme 248: Forward Flushing
Scheme 248: Forward Flushing
  1. Connect power flushing equipment so the flushing fluid flows in the direction of normal fluid flow.
  2. Flush oil cooler/lines until discharge fluid is clean.

Scheme 249

Scheme 249: OIL COOLER REMOVAL/INSTALLATION
Scheme 249: OIL COOLER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Drain the coolant into a container. (See ENGINE COOLANT REPLACEMENT .)
  3. Drain the ATF into a container. (See «AUTOMATIC TRANSAXLE FLUID (ATF) REPLACEMENT»(ref-178052-S24716482602005061000000) .)
  4. Remove the battery, battery tray, and battery tray bracket.
  5. Remove the air cleaner component. (See INTAKE-AIR SYSTEM REMOVAL/INSTALLATION .)
  6. Remove the radiator grille.
  7. Remove the front bumper.
  8. Remove the splash shield.
  9. Remove the mudguard.
  10. Remove in the order indicated in the figure.
  11. Install in the reverse order of removal.
  12. Add ATF to the specified level. (See «AUTOMATIC TRANSAXLE FLUID (ATF) REPLACEMENT»(ref-178052-S24716482602005061000000) .)
  13. Add coolant to the specified level. (See ENGINE COOLANT REPLACEMENT .)
  14. Connect the negative batter cable.
  15. Inspect for oil leakage from the oil pipes and oil hoses.
  16. Inspect for coolant from the hoses.
  17. Inspect the ATF level and condition. (See «AUTOMATIC TRANSAXLE FLUID (ATF) INSPECTION»(ref-178052-S08601116972005061000000) .)
  18. Carry out the line pressure test. (See «LINE PRESSURE TEST»(ref-178052-S18792528502005061000000) .)
  19. Carry out the road test. (See «ROAD TEST»(ref-178052-S24978590142005061000000) .)
