Basic HVAC System: Diagnosis Mazda CX-5 I

AIR FILTER INSPECTION

1. Verify that there is no damage, excessive dirt, or abnormal odor on the air filter. If there is any malfunction, replace the air filter. NOTE: The air filter cannot be reused by cleaning it with water or compressed air.

Scheme 68

Scheme 69

Scheme 70

Scheme 71

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Discharge the refrigerant. (See «REFRIGERANT CHARGING»(ref-615479-S35473472702014051000000) ).
3. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [SKYACTIV-G 2.0]»(ref-615406-S03293741932014051000000) ).
4. Remove the following parts: Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-615468-S12815760182014051000000) ). Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-615433-S35529177272014051000000) ). Windshield wiper motor (See «WINDSHIELD WIPER MOTOR AND LINK REMOVAL/INSTALLATION»(ref-615468-S30088470602014051000000) ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) ). Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-615455-S39827127492014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-615455-S05478494922014051000000) ). Audio unit (with audio unit) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-615447-S03341336152014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ). Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-615439-S02571559392014051000000) ). Hood release lever from the lower panel (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-615426-S03763202762014051000000) ). Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-615455-S27517637452014051000000) ). Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-615455-S22693767982014051000000) ). Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-615402-S33501432122014051000000) ). (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-615401-S27884901952014051000000) ). Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-615455-S35240345352014051000000) ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-615424-S35878193132014051000000) ). (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-615423-S04013315272014051000000) ). Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-615435-S37273804732014051000000) ). Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-615435-S37273804732014051000000) ). Switch panel (See «SWITCH PANEL REMOVAL/INSTALLATION»(ref-615455-S35661694702014051000000) ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-615455-S01676134032014051000000) ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-615411-S04733672172014051000000) ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S18284409542014051000000) ).
5. Remove the dashboard. (See «DASHBOARD REMOVAL/INSTALLATION»(ref-615455-S31406314522014051000000) ). CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
6. Remove the bolt, then disconnect the cooler hose (LO) and cooler pipe. (Scheme 68): Identifying Cooler Hose (LO) And Cooler Pipe Mounting Bolt With Torque Specifications
7. Disconnect the heater hose.
8. Remove the blower unit. (See «BLOWER UNIT REMOVAL/INSTALLATION»(ref-615407-S07180625702014051000000) ). (Scheme 69): Identifying Heater Hose And Clip
9. Disconnect the drain hose. (Scheme 70): Disconnecting Drain Hose
10. Remove the nut, then remove the A/C unit. Do not allow compressor oil to spill.
11. Install in the reverse order of removal. (See «A/C UNIT INSTALLATION NOTE»(ref-615407-S14776915732014051000000) ).
12. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [SKYACTIV-G 2.0]»(ref-615406-S41034731322014051000000) ).
13. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(ref-615479-S38875091672014051000000) ). (Scheme 71): Identifying A/C Unit With Mounting Nuts And Torque Specifications

EVAPORATOR INSPECTION

1. Inspect the evaporator for damage, cracks, and oil leakage. If there is any malfunction, replace the evaporator.
2. Visually inspect the fins for bending. If there is any bending, use the end of a flathead screwdriver to straighten the fins.

HEATER CORE INSPECTION

1. Inspect the heater core for damage, cracks, and water leakage. If there is any malfunction, replace the heater core.
2. Visually inspect the fins for bending. If there is any bending, use the end of a flathead screwdriver to straighten the fins.
3. Visually inspect the heater hose for deformation. Repair with pliers if there is deformation. If there is any malfunction, replace the heater core.

CONDENSER INSPECTION

1. Inspect the condenser for cracks, damage, and oil leakage. If there is any malfunction, replace the condenser.
2. Visually inspect for bent fins for clogging of foreign material. If any fins are clogged, remove the foreign material.
3. Visually inspect for bent fins. If any fins are bent, use the end of a flathead screwdriver to straighten fins.

Scheme 72

Scheme 73

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Discharge the refrigerant. (See «REFRIGERANT CHARGING»(ref-615479-S35473472702014051000000) ).
3. Remove the front under cover No.1. (See «FRONT UNDER COVER NO.1 REMOVAL/INSTALLATION»(ref-615433-S34343193522014051000000) ).
4. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [SKYACTIV-G 2.0]»(ref-615406-S03293741932014051000000) ).
5. Remove the following parts: Plug hole plate (See «PLUG HOLE PLATE REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615399-S02010689542014051000000) ). Air cleaner, air hose and fresh air duct component (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615404-S24638618012014051000000) ). Coolant reserve tank (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615406-S37590576392014051000000) ). Cooling fan component (See «COOLING FAN MOTOR REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615406-S32490169072014051000000) ). Radiator (See «RADIATOR REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615406-S23709300162014051000000) ).
6. Remove the condenser. (See «CONDENSER REMOVAL/INSTALLATION»(ref-615407-S20726918412014051000000) ).
7. Disconnect the block joint type pipes by grasping female side of the block with hand holding firmly then loosen the connection bolt A. (Scheme 72): Removing Condenser With Mounting Bolts And Torque Specifications
8. Remove bolt B.
9. Remove the bracket.
10. Remove the receiver/drier. Do not allow compressor oil to spill. (Scheme 73): Identifying Receiver/Drier, Bracket And Bolt CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise will occur. Always immediately plug all open fittings after removing any refrigeration cycle parts to keep moisture or foreign material out of the cycle.
11. Install in the reverse order of removal.
12. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [SKYACTIV-G 2.0]»(ref-615406-S41034731322014051000000) ).
13. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(ref-615479-S38875091672014051000000) ).
