Full-auto Air Conditioner

The airflow mode main link is installed to the airflow mode actuator. When removing the airflow mode main link, refer to the airflow mode actuator removal/installation. (See «AIRFLOW MODE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-615402-S03223421972014051000000) ).

Scheme 103: Manual Air Conditioner

Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) ).
Detach the hook (1), then remove the airflow mode rod (2). (Scheme 103): Removing Airflow Mode Rod
Remove the screw, then airflow mode main link.
Install in the reverse order of removal. (See «AIRFLOW MODE MAIN LINK INSTALLATION NOTE»(ref-615407-S30041984652014051000000) ). (Scheme 104): Identifying Airflow Mode Main Link With Screws
