MAGNETIC CLUTCH ADJUSTMENT [FULL-AUTO AIR CONDITIONER]

Scheme 6

Scheme 7

1. Remove the front under cover No.2. (See «FRONT UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-615433-S21444705852014051000000) ).
2. Measure the clearance around the entire circumference between the pressure plate and A/C compressor pulley using a thickness gauge.
3. Verify the clearance. If not within the specification, remove the pressure plate and adjust the clearance by changing the shim (0.2 mm {0.008 in}, 0.5 mm {0.02 in} ) or the number of shims. (See «MAGNETIC CLUTCH DISASSEMBLY/ASSEMBLY [FULL-AUTO AIR CONDITIONER]»(ref-615402-S08216177242014051000000) ). Magnetic clutch clearance 0.35-0.65 mm {0.014-0.025 in} (Scheme 6): Measuring Clearance Circumference Between Pressure Plate And A/C Compressor Pulley Using Thickness Gauge (Scheme 7): Identifying Shim

Scheme 8

1. Connect battery to terminal A of magnetic clutch and ground to A/C compressor body. (Scheme 8): Identifying Shim And Shaft
2. Verify that the magnetic clutch operates. If there is any malfunction, replace the magnetic clutch.
