On-Board Diagnostic - Automatic Transaxle [FS5A-EL]: Overview Mazda 6 GH рестайлинг

Scheme 629

Scheme 630

1. Connect the M-MDS (IDS) to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. Select "Self Test". Select "Modules". Select "TCM". NOTE: Snapshot data appears at the top of the help screen when the displayed DTC is selected. Snapshot data The snap shot data stores the currently detected DTC data. The recording timing for the freeze frame data/snap shot data differs depending on the number of DTC drive cycles. For a DTC with a drive cycle number 1, only the malfunction determination data is recorded. For a DTC with a drive cycle number 2, both the malfunction determination and undetermined data is recorded.
3. Verify the DTC according to the directions on the M-MDS screen.

See also:
• DTC P2504:00 [MZR 2.5]
