Scheme 875
![Scheme 875: AUTOMATIC TRANSAXLE LOCATION INDEX [AY6A-EL]](https://i.diagnostdata.com/repair/d0/d0fa1ace00b0481a7b7492886ec6bc063a883007613b9c54175708679bf9c508.webp)
| 1 | Drive plate (See DRIVE PLATE REMOVAL/INSTALLATION [AY6A-EL] .) |
|---|---|
| 2 | Torque converter (See TORQUE CONVERTER REMOVAL/INSTALLATION [AY6A-EL] .) |
| 3 | Oil seal (oil pump) (See OIL SEAL (OIL PUMP) REPLACEMENT [AY6A-EL] .) |
| 4 | Oil seal (differential) (See OIL SEAL (DIFFERENTIAL) REPLACEMENT [AY6A-EL] .) |
| 5 | Differential gear O-ring (See DIFFERENTIAL GEAR O-RING REPLACEMENT [AY6A-EL] .) |
| 6 | TCM (See TRANSAXLE RANGE (TR) SWITCH INSPECTION [AY6A-EL] .) (See TRANSAXLE RANGE (TR) SWITCH REMOVAL/INSTALLATION [AY6A-EL] .) (See TCM INSPECTION [AY6A-EL] .) (See TCM REMOVAL/INSTALLATION [AY6A-EL] .) (See TCM NEUTRAL POSITION LEARNING [AY6A-EL] .) |
| 7 | Oil seal (manual shaft) (See OIL SEAL (MANUAL SHAFT) REPLACEMENT [AY6A-EL] .) |
| 8 | Coupler component (See COUPLER COMPONENT INSPECTION [AY6A-EL] .) (See COUPLER COMPONENT REMOVAL/INSTALLATION [AY6A-EL] .) |
| 9 | Control waive body (See CONTROL VALVE BODY REMOVAL/INSTALLATION [AY6A-EL] .) |
| 10 | Control valve body cover (See CONTROL VALVE BODY COVER REPLACEMENT [AY6A-EL] .) |
| 11 | Input/turbine speed sensor (See INPUT/TURBINE SPEED SENSOR INSPECTION [AY6A-EL] .) (See INPUT/TURBINE SPEED SENSOR REMOVAL/INSTALLATION [AY6A-EL] .) |
| 12 | Automatic transaxle (See MECHANICAL SYSTEM TEST [AY6A-EL] .) (See ROAD TEST [AY6A-EL] .) (See AUTOMATIC TRANSAXLE FLUID (ATF) INSPECTION [AY6A-EL] .) (See AUTOMATIC TRANSAXLE FLUID (ATF) REPLACEMENT [AY6A-EL] .) (See AUTOMATIC TRANSAXLE FLUID (ATF) LEVEL ADJUSTMENT [AY6A-EL] .) (See AUTOMATIC TRANSAXLE REMOVAL/INSTALLATION [AY6A-EL] .) (See AUTOMATIC TRANSAXLE CLEANING [AY6A-EL] .) (See AUTOMATIC TRANSAXLE DISASSEMBLY/ASSEMBLY PRECAUTION [AY6A-EL] .) |
| 13 | TCC control solenoid (See TORQUE CONVERTER CLUTCH (TCC) CONTROL SOLENOID INSPECTION [AY6A-EL] .) (See TORQUE CONVERTER CLUTCH (TCC) CONTROL SOLENOID REMOVAL/INSTALLATION [AY6A-EL] .) |
| 14 | Shift solenoid B (See SHIFT SOLENOID B INSPECTION [AY6A-EL] .) (See SHIFT SOLENOID B REMOVAL/INSTALLATION [AY6A-EL] .) |
| 15 | Line pressure control solenoid (See LINE PRESSURE CONTROL SOLENOID INSPECTION [AY6A-EL] .) (See LINE PRESSURE CONTROL SOLENOID REMOVAL/INSTALLATION [AY6A-EL] .) |
| 16 | Shift solenoid A (See SHIFT SOLENOID A INSPECTION [AY6A-EL] .) (See SHIFT SOLENOID A REMOVAL/INSTALLATION [AY6A-EL] .) |
| 17 | Shift solenoid F (See SHIFT SOLENOID F INSPECTION [AY6A-EL] .) (See SHIFT SOLENOID F REMOVAL/INSTALLATION [AY6A-EL] .) |
| 18 | Shift solenoid E (See SHIFT SOLENOID E INSPECTION [AY6A-EL] .) (See SHIFT SOLENOID E REMOVAL/INSTALLATION [AY6A-EL] .) |
| 19 | Shift solenoid D (See SHIFT SOLENOID D INSPECTION [AY6A-EL] .) (See SHIFT SOLENOID D REMOVAL/INSTALLATION [AY6A-EL] .) |
| 20 | Shift solenoid C (See SHIFT SOLENOID C INSPECTION [AY6A-EL] .) (See SHIFT SOLENOID C REMOVAL/INSTALLATION [AY6A-EL] .) |
| 21 | TFT sensor (See TRANSAXLE FLUID TEMPERATURE (TFT) SENSOR INSPECTION [AY6A-EL] .) (See TRANSAXLE FLUID TEMPERATURE (TFT) SENSOR REMOVAL/INSTALLATION [AY6A-EL] .) |
| 22 | M position switch Up switch Down switch (See M POSITION SWITCH INSPECTION [AY6A-EL] .) (See M POSITION SWITCH REMOVAL/INSTALLATION [AY6A-EL] .) (See UP SWITCH INSPECTION [AY6A-EL] .) (See UP SWITCH REMOVAL/INSTALLATION [AY6A-EL] .) (See DOWN SWITCH INSPECTION [AY6A-EL] .) (See DOWN SWITCH REMOVAL/INSTALLATION [AY6A-EL] .) |
| 23 | Oil cooler (See OIL COOLER FLUSHING [AY6A-EL] .) (See OIL COOLER REMOVAL/INSTALLATION [AY6A-EL] .) |
AUTOMATIC TRANSAXLE LOCATION INDEX
Scheme 876
| 1 | Converter housing (See CONVERTER HOUSING REMOVAL/INSTALLATION [AY6A-EL] .) |
|---|---|
| 2 | Breather hose (See BREATHER COMPONENT REMOVAL/INSTALLATION [AY6A-EL] .) |
| 3 | B1 break piston cover (See B1 BRAKE PISTON COVER REMOVAL/INSTALLATION [AY6A-EL] .) |
| 4 | Oil strainer (See OIL STRAINER REMOVAL/INSTALLATION [AY6A-EL] .) |
| 5 | VSS (See VEHICLE SPEED SENSOR (VSS) INSPECTION [AY6A-EL] .) (See VEHICLE SPEED SENSOR (VSS) REMOVAL/INSTALLATION [AY6A-EL] .) |
| 6 | Front planetary gear component and input shaft (See FRONT PLANETARY GEAR COMPONENT AND INPUT SHAFT REMOVAL/INSTALLATION [AY6A-EL] .) (See FRONT PLANETARY GEAR COMPONENT AND INPUT SHAFT DISASSEMBLY/ASSEMBLY [AY6A-EL] .) |
| 7 | Oil pump (See OIL PUMP REMOVAL/INSTALLATION [AY6A-EL] .) (See OIL PUMP DISASSEMBLY/ASSEMBLY [AY6A-EL] .) |
AUTOMATIC TRANSAXLE LOCATION INDEX
Operation inspection
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the line pressure control solenoid is small, perform inspection in a quiet place.
Scheme 877
- Connect the positive battery terminal to terminal B of line pressure control solenoid via the 12-21 W bulb and connect the negative battery terminal to terminal A of line pressure control solenoid. CAUTION: Do not apply impact to line pressure control solenoid. Do not damage the terminals.
- Verify that operating sound is heard from the line pressure control solenoid. If there is any malfunction, replace the control valve body.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the shift solenoid A is small, perform inspection in a quiet place.
Scheme 878
- Connect the shift solenoid A terminal B to the battery positive terminal, connect the battery negative terminal to solenoid body. CAUTION: Do not apply impact to shift solenoid A. Do not damage the terminals.
- Verify that operating sound is heard from the shift solenoid A. If there is any malfunction, replace the shift solenoid A.
Scheme 879
Scheme 880
- Connect the shift solenoid A terminal B to the battery positive terminal, connect the battery negative terminal to solenoid body. CAUTION: Do not apply impact to shift solenoid A. Do not damage the terminals.
- Blow compressed air to inspect the condition of the airflow shown in the illustration. If there is any malfunction, replace the shift solenoid A.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the shift solenoid B is small, perform inspection in a quiet place.
- Connect the shift solenoid B terminal B to the battery positive terminal, connect the battery negative terminal to solenoid body. CAUTION: Do not apply impact to shift solenoid B. Do not damage the terminals.
- Verify that operating sound is heard from the shift solenoid B.
- If there is any malfunction, replace the shift solenoid B.
Scheme 881
Scheme 882
Scheme 883
- Connect the shift solenoid B terminal B to the battery positive terminal, connect the battery negative terminal to solenoid body. CAUTION: Do not apply impact to shift solenoid B. Do not damage the terminals.
- Blow compressed air to inspect the condition of the airflow shown in the illustration. If there is any malfunction, replace the shift solenoid B.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the shift solenoid C is small, perform inspection in a quiet place.
Scheme 884
- Connect the positive battery terminal to terminal B of shift solenoid C via the 12-21 W bulb and connect the negative battery terminal to terminal A of shift solenoid C. CAUTION: Do not apply impact to shift solenoid C. Do not damage the terminals.
- Verify that operating sound is heard from the shift solenoid C. If there is any malfunction, replace the control valve body.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the shift solenoid D is small, perform inspection in a quiet place.
Scheme 885
- Connect the positive battery terminal to terminal B of shift solenoid D via the 12-21 W bulb and connect the negative battery terminal to terminal A of shift solenoid D. CAUTION: Do not apply impact to shift solenoid D. Do not damage the terminals.
- Verify that operating sound is heard from the shift solenoid D. If there is any malfunction, replace the control valve body.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the shift solenoid E is small, perform inspection in a quiet place.
Scheme 886
- Connect the positive battery terminal to terminal B of shift solenoid E via the 12-21 W bulb and connect the negative battery terminal to terminal A of shift solenoid E. CAUTION: Do not apply impact to shift solenoid E. Do not damage the terminals.
- Verify that operating sound is heard from the shift solenoid E. If there is any malfunction, replace the control valve body.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the shift solenoid F is small, perform inspection in a quiet place.
Scheme 887
- Connect the positive battery terminal to terminal B of shift solenoid F via the 12-21 W bulb and connect the negative battery terminal to terminal A of shift solenoid F. CAUTION: Do not apply impact to shift solenoid F. Do not damage the terminals.
- Verify that operating sound is heard from the shift solenoid F. If there is any malfunction, replace the control valve body.
| CAUTION | Do not apply battery positive voltage to terminals for more than 3 s. |
Note. Because the operation sound of the TCC control solenoid is small, perform inspection in a quiet place.
Scheme 888
- Connect the positive battery terminal to terminal B of TCC control solenoid via the 12-21 W bulb and connect the negative battery terminal to terminal A of TCC control solenoid. CAUTION: Do not apply impact to TCC control solenoid. Do not damage the terminals.
- Verify that operating sound is heard from the TCC control solenoid. If there is any malfunction, replace the control valve body.
