Automatic Transmission - Automatic Transaxle Shift Mechanism: Removal & Installation Mazda 6 GH рестайлинг

AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION

Scheme 1304

Scheme 1305

1. Disconnect the selector lever component connector. Disconnect the negative battery cable. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .) Disconnect the selector lever component connector.
2. Remove the selector lever component. Disconnect the selector cable from the selector lever component. Remove the selector lever component.
3. Install in the reverse order of removal.

Scheme 1306

Scheme 1307

1. Disconnect the negative battery cable.
2. Remove the aerodynamic under cover NO. 2. (FS5A-EL) (See «AERODYNAMIC UNDER COVER NO. 2 REMOVAL/INSTALLATION»(ref-448621-S11343791992012012000000) .)
3. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .)
4. Remove the dashboard. (See «DASHBOARD REMOVAL/INSTALLATION»(ref-448656-S12911950632012012000000) .)
5. Remove the A/C unit. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-448620-S04194369372012012000000) .)
6. Remove the SAS control module. (See «SAS CONTROL MODULE REMOVAL/INSTALLATION»(ref-448570-S09331687822012012000000) .)
7. Remove in the order Indicated in the table.
8. Install in the reverse order of removal.
9. Adjust the selector cable after having installed. (See «SELECTOR CABLE ADJUSTMENT»(ref-448660-S21438127662012012000000) .) SELECTOR CABLE AND CLIP REFERENCE CHART 1 Clip 2 Selector cable (transaxle side) 3 Nut 4 Selector cable (selector lever side)

Scheme 1308

Scheme 1309

1. Remove the negative battery cable.
2. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .)
3. Shift the selector lever to the P position.
4. Unlock the lock piece of the selector cable (selector lever side) in the order as shown in the illustration.
5. Verify that the manual shaft is in the P position.
6. Lock the lock piece and safety lock of the selector cable (selector lever side) in the order as shown in the illustration.

Scheme 1310

1. Switch the ignition to ON.
2. Perform the following procedures to inspect the selector lever. If there is any malfunction, adjust the selector cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448660-S23046278992012012000000) .) Verify that the selector lever can be operated as shown in the illustration. Verify that the selector lever can be operated smoothly and moderately.

Shift-Lock System Inspection

1. Switch the ignition to ON.
2. Shift the selector lever to the P position.
3. Perform the following procedures to inspect the shift-lock system.

1. If there is any malfunction, inspect the shift-lock solenoid. (See «SHIFT-LOCK SOLENOID INSPECTION»(ref-448660-S04009904892012012000000) .)

1. Verify that the selector lever cannot be selected from P to R position when the brake pedal is released.
2. Verify that the selector lever can be selected from P to R position when the brake pedal is depressed.

Shift-Lock Solenoid Inspection

Scheme 1311

1. Disconnect the selector lever component connector. Disconnect the negative battery cable. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .) Disconnect the selector lever component connector.
2. According to the table, measure the voltage between selector lever component terminals and body GND. If there is any malfunction, repair or replace the related wiring harness. If there is no malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448660-S23046278992012012000000) .)
