Shift-lock solenoid specification
| Terminal | Connected to | Test condition | Voltage (V) |
|---|---|---|---|
| E-GND | Brake switch | Brake pedal depressed | B+ |
| Brake pedal released | Below 1.0 | ||
| I-GND | Ignition switch | Switch the ignition to ACC or ON | B+ |
| Switch the ignition to off | Below 1.0 | ||
| K-GND | Body GND | Under any conditions | Below 1.0 |
SHIFT-LOCK SOLENOID SPECIFICATIONS CHART
